0 - 1VAUXHALL Astra GTC
VAUXHALL Astra GTC
Infotainment Manual
Model Year 2012
Edition: October 2011
TS 1709-B-12

Introduction .................................... 2
Radio ........................................... 24
CD Player .................................... 40
AUX input ..................................... 46
USB port ...................................... 48
Digital picture frame ..................... 52
Navigation .................................... 55
Speech recognition .................... 100
Phone ........................................ 115
Index .......................................... 136
Contents

2Introduction
Introduction
General information ....................... 2
Theft-deterrent feature ................... 3
Control elements overview ............ 4
Usage .......................................... 11
Basic operation ............................ 13
Tone settings ............................... 18
Volume settings ........................... 21
Personalisation ............................ 23
General information
The Infotainment system provides
you with state-of-the-art in-car
infotainment.
For the AM, FM and DAB (not
CD 300) wavebands the radio is
equipped with twelve automatically
assignable channel presets.
Furthermore, 36 channels can be
allocated manually (waveband-
independent).
The integrated audio player will
entertain you with audio CDs and
MP3/WMA CDs.
Furthermore, you can connect
external data storage devices, e.g.
iPod, MP3 player or USB stick (not
CD 300), or a portable CD player to
the Infotainment system as further
audio sources.
The digital sound processor provides
you with several preset equalizer
modes for sound optimisation.
The navigation system (only
Navi 600 / Navi 900) with dynamic
route planning will reliably guide you
to your destination, and, if desired,
will automatically avoid traffic jams or
other traffic problems.
Optionally, the Infotainment system
can be operated using controls on the
steering wheel or via the speech
recognition system (if available).
In addition the Infotainment system
can be equipped with a mobile phone
portal.
The well-thought-out design of the
control elements, the clear displays
and a large multifunction knob enable
you to control the system easily and
intuitively.
Important information on
operation and traffic safety
9Warning
The Infotainment system has to be
used so that the vehicle can be
driven safely at all times. If in doubt
stop your vehicle and operate the
Infotainment system while the
vehicle is stationary.

Introduction 3
9Warning
The usage of the navigation
system (only Navi 600 / Navi 900)
does not release the driver from
the responsibility for a correct,
vigilant attitude in road traffic. The
related traffic regulations must
always be followed.
Only make entries (e.g.
addresses) with the vehicle
stationary.
If a navigation instruction
contradicts traffic regulations, the
traffic regulations always apply.
9Warning
In some areas one-way streets
and other roads and entrances
(e.g. pedestrian zones) that you
are not allowed to turn into are not
marked on the map. In such areas
the Infotainment system may
issue a warning that must be
accepted. Here you must pay
particular attention to one-way
streets, roads and entrances that
you are not allowed to drive into.
Radio reception
Radio reception may be disrupted by
static, noise, distortion or loss of
reception due to
■ changes in distance from the
transmitter,
■ multi-path reception due to
reflection,
■ shadowing.
Theft-deterrent feature
The Infotainment system is equipped
with an electronic security system for
the purpose of theft deterrent.
The Infotainment system therefore
functions only in your vehicle and is
worthless to a thief.

4Introduction
Control elements overview
Instrument panel Navi 600 / Navi 900

Introduction 5
1RADIO (BAND) ..................... 24
Activate radio or change
waveband .............................. 24
2CD/AUX ................................ 46
Start CD/MP3/WMA
replay or change audio
source ................................... 46
3Search backwards ................ 24
Radio: search backwards ..... 24
CD/MP3/WMA: skip track
backwards ............................. 42
4Radio station buttons 1...6 .... 25
Long press: save station ....... 25
Short press: select station ....25
5m knob .................................. 11
Press: switch on/off
Infotainment system .............. 11
Turn: adjust volume .............. 11
6Search forwards .................... 24
Radio: search forwards ......... 24
CD/MP3/WMA: skip track
forwards ................................ 42
7AS (1/2) ................................. 25
Automatic memory levels
(preset radio stations) ........... 25
Short press: select
autostore list .......................... 25
Long press: save stations
automatically ......................... 25
8FAV (1/2/3) ............................ 26
Lists of favourites (preset
radio stations) ....................... 26
9TP ......................................... 33
Activate or deactivate
radio traffic service ................ 33
10 CD ejection ........................... 42
11 CONFIG ................................ 21
System settings ..................... 21
12 TONE .................................... 18
Tone settings ........................ 18
13 INFO ....................................... 4
Radio: information on the
currently played station ......... 24
CD/MP3/WMA:
information on the
currently inserted CD ............ 42
Digital picture frame:
shows currently selected
picture/photo ......................... 52
Navigation: information,
e.g., on the current location ..55
14 Multifunction knob ................. 13
Turn: mark menu options
or set numeric values ........... 13
Press (the outer ring):
select/activate the marked
option; confirm set value;
switch function on/off ............ 13
15 Eight-way switch ................... 56
Navigation: move display
window in map view .............. 56
16 CD slot .................................. 42
17 BACK .................................... 13
Menu: one level back ............ 13
Input: delete last character
or entire entry ........................ 13

6Introduction
18 RPT ....................................... 93
Repeat last navigation
message ............................... 93
19 DEST .................................... 56
Navigation destination
entry ...................................... 56
20 PHONE ............................... 115
Open telephone menu ........ 128
Activate/deactivate mute ....... 11
21 NAVI ...................................... 56
Display map ......................... 56

Introduction 7
Instrument panel CD 400

8Introduction
1RADIO (BAND) ..................... 24
Activate radio or change
waveband .............................. 24
2CD ......................................... 46
Start CD/MP3/WMA replay ... 46
3Search backwards ................ 24
Radio: search backwards ..... 24
CD/MP3/WMA: skip track
backwards ............................. 42
4Radio station buttons 1...6 .... 25
Long press: save station ....... 25
Short press: select station ....25
5m knob .................................. 11
Press: switch on/off .............. 11
Infotainment system ............. 11
Turn: adjust volume .............. 11
6Search forwards .................... 24
Radio: search forwards ......... 24
CD/MP3/WMA: skip track
forwards ................................ 42
7AS (1/2) ................................. 25
Automatic memory levels
(preset radio stations) ........... 25
Short press: select
autostore list .......................... 25
Long press: save stations
automatically ......................... 25
8FAV (1/2/3) ............................ 26
Lists of favourites (preset
radio stations) ....................... 26
9TP ......................................... 33
Activate or deactivate
radio traffic service ................ 33
If Infotainment system
switched off: display time
and date ................................ 33
10 CD ejection ........................... 42
11 CONFIG ................................ 21
Open settings menu .............. 21
12 INFO ....................................... 4
Radio: information on the
currently played station ......... 24
CD/MP3/WMA:
information on the
currently inserted CD ............ 42
13 Multifunction knob ................. 13
Turn: mark menu options
or set numeric values ........... 13
Press: select/activate the
marked option; confirm set
value; switch function on/off .. 13
14 CD slot .................................. 42
15 BACK .................................... 13
Menu: one level back ............ 13
Input: delete last character
or entire entry ........................ 13
16 TONE .................................... 18
Tone settings ........................ 18
17 PHONE ............................... 115
Open telephone main menu 128
Activate mute ........................ 11
18 AUX ....................................... 46
Change audio source ............ 46

Introduction 9
Instrument panel CD 300
