Vava VA-AH015 User manual

VAVA ULTRASONIC HUMIDIFIER
User Guide
MIST
HUMIDITY
TIMER
SLEEP
ON/ OFF
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
11
12
13
Product Diagram
1. Rotatable Nozzles
2. Water Tank
3. Power Cord
4. Humidity Sensor
5. Base
6. LED Display
7. Power Button
8. Sleep Button
9. Mist Button
10. Humidity Button
11. Timer Button
12. Air Inlet
13. Drain Side
Specifications
Model
Operating Voltage
Power
Water Tank Capacity
Mist Output
VA-AH015
US / CA: AC 120V 60Hz
UK: AC 230V 50Hz
26W (High Mist)
21W (Medium Mist)
17W (Low Mist)
5 L / 172.4 oz
350mL / hour (High Mist)
250mL / hour (Medium Mist)
150mL / hour (Low Mist)
How to Use
WATER
①②
Adding Water
①Tank Cap
②Tank Inlet
Rotate the tank cap counterclockwise to loosen it, add an appropriate amount of water
into the tank, and screw the cap clockwise to fasten it until no water leaks. Do not rotate
with excessive force.

VAVA ULTRASONIC HUMIDIFIER
User Guide
MIST
HUMIDITY
TIMER
SLEEP
ON/ OFF
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
11
12
13
Product Diagram
1. Rotatable Nozzles
2. Water Tank
3. Power Cord
4. Humidity Sensor
5. Base
6. LED Display
7. Power Button
8. Sleep Button
9. Mist Button
10. Humidity Button
11. Timer Button
12. Air Inlet
13. Drain Side
Specifications
Model
Operating Voltage
Power
Water Tank Capacity
Mist Output
VA-AH015
US / CA: AC 120V 60Hz
UK: AC 230V 50Hz
26W (High Mist)
21W (Medium Mist)
17W (Low Mist)
5 L / 172.4 oz
350mL / hour (High Mist)
250mL / hour (Medium Mist)
150mL / hour (Low Mist)
How to Use
WATER
①②
Adding Water
①Tank Cap
②Tank Inlet
Rotate the tank cap counterclockwise to loosen it, add an appropriate amount of water
into the tank, and screw the cap clockwise to fasten it until no water leaks. Do not rotate
with excessive force.

VAVA ULTRASONIC HUMIDIFIER
User Guide
MIST
HUMIDITY
TIMER
SLEEP
ON/ OFF
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
11
12
13
Product Diagram
1. Rotatable Nozzles
2. Water Tank
3. Power Cord
4. Humidity Sensor
5. Base
6. LED Display
7. Power Button
8. Sleep Button
9. Mist Button
10. Humidity Button
11. Timer Button
12. Air Inlet
13. Drain Side
Specifications
Model
Operating Voltage
Power
Water Tank Capacity
Mist Output
VA-AH015
US / CA: AC 120V 60Hz
UK: AC 230V 50Hz
26W (High Mist)
21W (Medium Mist)
17W (Low Mist)
5 L / 172.4 oz
350mL / hour (High Mist)
250mL / hour (Medium Mist)
150mL / hour (Low Mist)
How to Use
WATER
①②
Adding Water
①Tank Cap
②Tank Inlet
Rotate the tank cap counterclockwise to loosen it, add an appropriate amount of water
into the tank, and screw the cap clockwise to fasten it until no water leaks. Do not rotate
with excessive force.

VA-AH015
www.vava.com
Learn more about the EU Declaration of Conformity:
https://www.vava.com/downloads-VA-AH015-CE-Cert.html
E-mail: [e-mail]
Tel: [phone] (Monday-Friday: 9:00 – 17:00 PST)
Address: 46724 Lakeview Blvd, Fremont, CA 94538
NORTH AMERICA
EUROPE
E-mail:
[e-mail](UK)
[e-mail](DE)
[e-mail](FR)
[e-mail](ES)
[e-mail](IT)
EU Importer: ZBT International Trading GmbH, Halstenbeker Weg 98C,
25462 Rellingen, Deutschland
MANUFACTURER
Shenzhen NearbyExpress Technology Development Company Limited
Address: 333 Bulong Road, Jialianda Industrial Park, Building 1,
Bantian, Longgang District, Shenzhen, China, 518129
Note:
1. Remove the nozzle before you uplift the water tank, and put it back on when the water
tank is placed onto the base after the water has been added.
2. When you fail to open the tank cap, wipe the cap dry and rotate it with proper force.
Operation and Functions
Add water into the tank, connect to a power source, the unit is now in standby mode.
Note: The buttons on the control panel are the same as those on the remote control.
（1）Power On / Off
①In standby mode, tap the Power Button once to enter Level 2 Misting by default and a
beep sound will be heard. The LED display will show the mist level, environmental RH, and
temperature.
②Tap it again to power off the misting, and a beep sound will be heard. The LED display
shows the RH and temperature only.
（2）Mist Adjustment
The mist level can be adjusted from 1 ~ 3 levels with a tap of the Mist Button. A beep sound
will be heard with each tap and the LED display will show the corresponding mist level.
（3）Humidity Setting
①Tap the Humidity Button once to activate continuous misting and the “CO” icon on the
Display flashes 3 times. Before the flashing ends, you can set the humidity level from 30%
to 95% through the Humidity Button by 5 with each tap. When set, the corresponding
humidity value will flash 3 times to confirm the setting and the humidity icon will keep
flashing.
Note: The misting works normally if the set humidity on the unit is higher than the RH and
stops if the set humidity is lower than the RH.
②After the humidity is set, tap and hold the Humidity Button for 1.5 seconds to exit the
setting, the LED display will flash “CO” 3 times. The humidity icon will disappear.
③When the humidity is set, the Mist Button remains responsive.
（4）Timer Setting
①Tap the Timer Button once, the LED display will show “--H” and flash 3 times. Before the
flashing ends, set the timer from 1 to 12 hours by tapping the Timer Button. The
corresponding timer will show on the LED Display and flash 3 times to confirm the setting.
②When the timer is set, tap and hold the Timer Button for 1.5 seconds to exit the setting.
The LED display will show “—H”which will disappear after flashing 3 times.
③A beep sound will be heard each time you tap the Timer Button.
（5）Sleep Mode
①Tap the Sleep Button once to enter sleep mode. All icons on the LED display (except the
sleep icon) will turn off. In sleep mode, the Mist Button, Humidity Button, and Timer Button
remain functional, but the beep sound is disabled.
②In sleep mode, tap the Power Button to turn off the unit. Tap the Sleep Button to exit
sleep mode, the sleep mode icon will disappear.
（6）Memory Function
With power connected, the unit will resume the humidity setting selected the last time it
has been turned off (the humidity setting icon will not be shown on the LED display). The
timer and sleep mode settings will be cleared.
（7）Water Tank Light
The water tank light will turn on / off with the power.
（8）Low Water or Water Tank Removal Protection
①When water in the tank is depleted or the water tank is removed, the unit will stop
working and the water shortage icon will appear on the LED display.
②The unit will resume working once water is added or the tank is placed back on the base.

VA-AH015
www.vava.com
Learn more about the EU Declaration of Conformity:
https://www.vava.com/downloads-VA-AH015-CE-Cert.html
E-mail: [e-mail]
Tel: [phone] (Monday-Friday: 9:00 – 17:00 PST)
Address: 46724 Lakeview Blvd, Fremont, CA 94538
NORTH AMERICA
EUROPE
E-mail:
[e-mail](UK)
[e-mail](DE)
[e-mail](FR)
[e-mail](ES)
[e-mail](IT)
EU Importer: ZBT International Trading GmbH, Halstenbeker Weg 98C,
25462 Rellingen, Deutschland
MANUFACTURER
Shenzhen NearbyExpress Technology Development Company Limited
Address: 333 Bulong Road, Jialianda Industrial Park, Building 1,
Bantian, Longgang District, Shenzhen, China, 518129
Note:
1. Remove the nozzle before you uplift the water tank, and put it back on when the water
tank is placed onto the base after the water has been added.
2. When you fail to open the tank cap, wipe the cap dry and rotate it with proper force.
Operation and Functions
Add water into the tank, connect to a power source, the unit is now in standby mode.
Note: The buttons on the control panel are the same as those on the remote control.
（1）Power On / Off
①In standby mode, tap the Power Button once to enter Level 2 Misting by default and a
beep sound will be heard. The LED display will show the mist level, environmental RH, and
temperature.
②Tap it again to power off the misting, and a beep sound will be heard. The LED display
shows the RH and temperature only.
（2）Mist Adjustment
The mist level can be adjusted from 1 ~ 3 levels with a tap of the Mist Button. A beep sound
will be heard with each tap and the LED display will show the corresponding mist level.
（3）Humidity Setting
①Tap the Humidity Button once to activate continuous misting and the “CO” icon on the
Display flashes 3 times. Before the flashing ends, you can set the humidity level from 30%
to 95% through the Humidity Button by 5 with each tap. When set, the corresponding
humidity value will flash 3 times to confirm the setting and the humidity icon will keep
flashing.
Note: The misting works normally if the set humidity on the unit is higher than the RH and
stops if the set humidity is lower than the RH.
②After the humidity is set, tap and hold the Humidity Button for 1.5 seconds to exit the
setting, the LED display will flash “CO” 3 times. The humidity icon will disappear.
③When the humidity is set, the Mist Button remains responsive.
（4）Timer Setting
①Tap the Timer Button once, the LED display will show “--H” and flash 3 times. Before the
flashing ends, set the timer from 1 to 12 hours by tapping the Timer Button. The
corresponding timer will show on the LED Display and flash 3 times to confirm the setting.
②When the timer is set, tap and hold the Timer Button for 1.5 seconds to exit the setting.
The LED display will show “—H”which will disappear after flashing 3 times.
③A beep sound will be heard each time you tap the Timer Button.
（5）Sleep Mode
①Tap the Sleep Button once to enter sleep mode. All icons on the LED display (except the
sleep icon) will turn off. In sleep mode, the Mist Button, Humidity Button, and Timer Button
remain functional, but the beep sound is disabled.
②In sleep mode, tap the Power Button to turn off the unit. Tap the Sleep Button to exit
sleep mode, the sleep mode icon will disappear.
（6）Memory Function
With power connected, the unit will resume the humidity setting selected the last time it
has been turned off (the humidity setting icon will not be shown on the LED display). The
timer and sleep mode settings will be cleared.
（7）Water Tank Light
The water tank light will turn on / off with the power.
（8）Low Water or Water Tank Removal Protection
①When water in the tank is depleted or the water tank is removed, the unit will stop
working and the water shortage icon will appear on the LED display.
②The unit will resume working once water is added or the tank is placed back on the base.

VA-AH015
www.vava.com
Learn more about the EU Declaration of Conformity:
https://www.vava.com/downloads-VA-AH015-CE-Cert.html
E-mail: [e-mail]
Tel: [phone] (Monday-Friday: 9:00 – 17:00 PST)
Address: 46724 Lakeview Blvd, Fremont, CA 94538
NORTH AMERICA
EUROPE
E-mail:
[e-mail](UK)
[e-mail](DE)
[e-mail](FR)
[e-mail](ES)
[e-mail](IT)
EU Importer: ZBT International Trading GmbH, Halstenbeker Weg 98C,
25462 Rellingen, Deutschland
MANUFACTURER
Shenzhen NearbyExpress Technology Development Company Limited
Address: 333 Bulong Road, Jialianda Industrial Park, Building 1,
Bantian, Longgang District, Shenzhen, China, 518129
Note:
1. Remove the nozzle before you uplift the water tank, and put it back on when the water
tank is placed onto the base after the water has been added.
2. When you fail to open the tank cap, wipe the cap dry and rotate it with proper force.
Operation and Functions
Add water into the tank, connect to a power source, the unit is now in standby mode.
Note: The buttons on the control panel are the same as those on the remote control.
（1）Power On / Off
①In standby mode, tap the Power Button once to enter Level 2 Misting by default and a
beep sound will be heard. The LED display will show the mist level, environmental RH, and
temperature.
②Tap it again to power off the misting, and a beep sound will be heard. The LED display
shows the RH and temperature only.
（2）Mist Adjustment
The mist level can be adjusted from 1 ~ 3 levels with a tap of the Mist Button. A beep sound
will be heard with each tap and the LED display will show the corresponding mist level.
（3）Humidity Setting
①Tap the Humidity Button once to activate continuous misting and the “CO” icon on the
Display flashes 3 times. Before the flashing ends, you can set the humidity level from 30%
to 95% through the Humidity Button by 5 with each tap. When set, the corresponding
humidity value will flash 3 times to confirm the setting and the humidity icon will keep
flashing.
Note: The misting works normally if the set humidity on the unit is higher than the RH and
stops if the set humidity is lower than the RH.
②After the humidity is set, tap and hold the Humidity Button for 1.5 seconds to exit the
setting, the LED display will flash “CO” 3 times. The humidity icon will disappear.
③When the humidity is set, the Mist Button remains responsive.
（4）Timer Setting
①Tap the Timer Button once, the LED display will show “--H” and flash 3 times. Before the
flashing ends, set the timer from 1 to 12 hours by tapping the Timer Button. The
corresponding timer will show on the LED Display and flash 3 times to confirm the setting.
②When the timer is set, tap and hold the Timer Button for 1.5 seconds to exit the setting.
The LED display will show “—H”which will disappear after flashing 3 times.
③A beep sound will be heard each time you tap the Timer Button.
（5）Sleep Mode
①Tap the Sleep Button once to enter sleep mode. All icons on the LED display (except the
sleep icon) will turn off. In sleep mode, the Mist Button, Humidity Button, and Timer Button
remain functional, but the beep sound is disabled.
②In sleep mode, tap the Power Button to turn off the unit. Tap the Sleep Button to exit
sleep mode, the sleep mode icon will disappear.
（6）Memory Function
With power connected, the unit will resume the humidity setting selected the last time it
has been turned off (the humidity setting icon will not be shown on the LED display). The
timer and sleep mode settings will be cleared.
（7）Water Tank Light
The water tank light will turn on / off with the power.
（8）Low Water or Water Tank Removal Protection
①When water in the tank is depleted or the water tank is removed, the unit will stop
working and the water shortage icon will appear on the LED display.
②The unit will resume working once water is added or the tank is placed back on the base.
