Vax WASH Vax V-020 Series User manual

vax.co.uk Please read carefully before using this cleaner.
Always fully extend the mains cable before use.
Retain for future reference.
instruction manual
Carpet Washer
Vax model number:
V-020 Series
Vax Careline: (UK) 0844 412 8455
(R I) 1-800 928 308

1. Diagram
vax.co.uk
2 parts overview
9
515
13
13
12
10
11
14
1
2
3
4
8
7
6
16
1 Power Button (Red)
2 Water Pump Button (Green)
3 Carry Handle
4 Power Cord
5 Container Release Clips
6 Casters
7 Hose Connection Port
8 Solution Tube Port
9 Exhaust Filter
10 Hose
11 Hose Cylinder Connector
12 Solution Tube
13 Solution Tube Connector
14 Fibreflow Wash Head
15 Wash Tool
16 Vax Cleaning Solution
17 2 Piece Extension Tube
17

3
Vax Careline: (UK) 0844 412 8455
(R I) 1-800 928 308
safety information
2. Safety Information
For Household Use Only
When using the carpet washer, basic safety precautions
should always be observed, including the following:
1. Do not leave the carpet washer unattended when
plugged in. Unplug it from socket when not in use.
2. To prevent electric shock do not use outdoors.
3. Not to be used as a toy. Close supervision is
necessary when used by or near children or the
infirm.
4. Use only as described in this manual.
5. The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
6. Do not use the carpet washer if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord is damaged,
it must be replaced by the manufacturer or a
recommended Service Agent to avoid hazard and
invalidating the guarantee.
7. Do not pull or carry by the cord, use the cord as a
handle, allow the cord to come into contact with
hot or sharp surfaces or close a door on the cord.
8. Do not unplug by pulling on the cord.
9. Do not handle the plug or carpet washer with wet
hands.
10. Do not put any objects into openings or operate
with openings blocked, keep them free of anything
that may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of
the body away from openings and moving parts.
12. Do not use the carpet washer on any glowing,
burning or smoking particles.
13. Do not use without the clean water tank and dirty
water tank in place.
14. Turn off all controls before unplugging.
15. Do not use to pick up flammable or combustible
liquids such as petrol, or use in areas where they
may be present.
16. Keep the carpet washer on the floor.
17. Do not use an extension cord.
18. Do not attempt to remove blockages with sharp
objects as they may cause damage.
19. Store indoors put away after use to prevent tripping
accidents.
20. Using improper voltage may result in damage to the
motor and possible injury to the user. The correct
voltage is listed on the rating label.
21. A hazard may occur if the carpet washer runs over
the power supply cord.
NOTE: Carpets should be dry va uumed
thoroughly before washing.
NOTE: If the supply ord is damaged, it must
be repla ed by the manufa turer, a Vax
servi e agent or similarly qualified persons in order
to avoid hazard.
NOTE: The arpet washer must be unplugged
from the mains so ket outlet after use, and
before leaning or maintaining the arpet washer.
IMPORTANT: This arpet washer is not
intended for ommer ial use.
!
!
!
!

vax.co.uk
4 preparing the carpet / assembly
3. Preparing the Carpet
IMPORTANT: Do not use the Carpet Washer as a
dry va uum.
1. Dry vacuum carpet thoroughly.
2. Remove as much furniture from the room as
possible. If you are unable to remove the furniture,
place plastic or foil under and around the legs until
the carpet has dried completely.
Helpful Hints for Carpet Cleaning:
1. nly use Vax carpet cleaning solution with this
carpet washer.
2. Do not oversaturate carpet with cleaning solution
while using the carpet washer.
3. For heavily soiled areas, additional applications may
be necessary.
4. Allow plenty of time to dry carpet thoroughly.
5. Wipe cleaning solution from woodwork and wood
to prevent any damage.
6. Try not to w alk on carpet until it is completely dry.
7. After carpet is thoroughly dry, vacuum the carpet
using a vacuum cleaner with a revolving brushbar.
8. Before cleaning, determine where to start and end,
making sure not to walk over previously cleaned
areas.
Che k for Colour Fastness:
Before cleaning carpet, test for colour fastness. Dampen a
white cloth with solution. Test a small area in a closet.
Gently rub the cloth over the area. Check each colour for
colour bleeding. If the cloth remains clean, it should be
safe to clean the carpet.
4. Assembly
Push solution tube cylinder connector (A) firmly into
solution port (A1).
Twist solution tube cylinder connector (A1) a quarter turn
to the right to lock into place (Fig.4/1).
Push hose cylinder connector (B) firmly into hose
connection port (B1).
Twist to the right until hose cylinder connector locks into
place (Fig.4/2).
Wrap solution tube (A) around hose (B). Ensure that
the solution tube is wrapped loosely enough to allow
the solution to flow freely through the tube (Fig.4/3).
!
Fig.4/3
A
B
Fig.4/1
A
A1
Fig.4/2
B1
B

After wrapping the tube around the hose, affix solution
tube (A) to hose (B) using clips provided (C) to hold it in
place (Fig.4/4).
Push end of solution tube onto connective valve
on the wash tool (Fig.4/5).
5. Usage
Plug in machine to power supply.
Press the red button to turn on the power.
Press the green button to activate the pump.
n the Fibreflow wash head ensure that the rocker switch
(A) is towards the back of the head to allow water to flow
through the head (Fig.5/1).
In order to help suck up excess water, the rocker switch
(A) can be pushed to the front position on the Fibreflow
wash head. This will prevent water flow, allowing excess
water to be removed (Fig.5/2).
In order to wash upholstery, including stairs and soft
furnishings simply detach Fibreflow wash head from
wand and solution tube and replace with wash tool as
shown (Fig.5/3).
NOTE: Do not store leaner with solution in
lean water tank or dirty water in dirty water
tank. Mineral deposits and mildew an form whi h will
affe t the performan e of the arpet washer.
5
assembly / usage
Fig.4/4
A
B
C
Fig.4/5
!
Fig.5/1
A
A
Fig.5/2
Fig.5/3
Vax Careline: (UK) 0844 412 8455
(R I) 1-800 928 308

vax.co.uk
6 troubleshooting / uk service & help
6. Troubleshooting
WARNING: To redu e risk of personal injury,
unplug arpet washer before servi ing.
PROBLEM: The leaner won't run
Cause: Not properly plugged into electrical outlet.
Solution: Plug in firmly.
Cause: No electricity in electrical outlet.
Solution: Check fuse or breaker.
Cause: n/off switch not turned on.
Solution: Push on/off switch to ‘on’.
Cause: Blown fuse/tripped breaker.
Solution: Reset circuit breaker or replace fuse.
PROBLEM: Cleaner/a essories won’t pi k up
Cause: Accessories not attached correctly.
Solution: Refer to page 6 for fitting information.
Cause: The hose is clogged.
Solution: Remove the hose and tools. Remove the
obstruction.
7. UK Service & Help
Vax Careline (UK) 0844 412 8455
(R I) 1-800 928 308
Monday-Friday 8.30am to 6.30pm
Saturday-Sunday 9.00am to 5.00pm
If you have any queries or concerns about using your
carpet washer, call the Vax Careline. Calls are charged at
the UK national rate.
Please make a note of the serial number and model
number of the carpet cleaner before calling. For the
nearest Service Agent, please call the Vax Careline.
vax. o.uk
!

7
technical specification
8. Technical Specification
Voltage: 220 ~ 240V 50Hz
Wattage: 1300W
Clean water tank volume: 4 litres
Dirty water tank volume: 4 litres
Cord length: 10m
Weight: 7.7Kg
Subject to change without notice.
Vax Careline: (UK) 0844 412 8455
(R I) 1-800 928 308

EEC STATEMENT OF COMPLIANCE
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
V-020 Series Carpet Washer is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice.
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwi h, Wor estershire, WR9 OQH, UK
email: info@vax. o.uk - website: vax. o.uk
