VBOX VBOX2-86B2 User manual

User Manual
VBOX HD Network DVD
(VBOX2-86B2)
Ver：
：：
：2.200
OftenFull.COM

Inde
1．
．．
．Product and Accessories ................................................................4
2．
．．
．Appearance & Remote Controller .................................................4
3．
．．
．Connecting the cables..................................................................11
4．
．．
．Initialize Settings..........................................................................13
4.1 Best video output effect .................................................................13
4.2 Configure network..........................................................................13
5．
．．
．Common Operation .....................................................................13
5.1 Main Menu .....................................................................................14
5.2 Media Pla er...................................................................................14
5.3Network Access ...............................................................................16
5.4 Content Downloading.....................................................................17
5.5 Progress Management....................................................................18
5.6 S stem Settings...............................................................................19
6．
．．
．VBOX Services ..............................................................................21
7．
．．
．Q&A ..............................................................................................22
8．
．．
．Specifications ...............................................................................24
9．
．．
．About this manual .......................................................................25
10．
．．
．Contacts........................................................................................25

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
1
Statement
The user manual is nol provided for learning how to operate the VBOX
pla er. The content in this manual has been checked carefull to insure ever
detail is correct. And our compan won’t inform the changes for the
information in this manual if there are in the future.
The content in this manual is protected b the law of cop right. Nobod is
allowed to cop , send, store or translate it for business usage before getting the
permission of the cop right owner.
The warrant for this product is one ear since the date of bu ing. Please
keep the invoice or receipt as the bu ing certificate. during the warrant period,
consumers are allowed to change or repair the pla er because of the defects of
the product material or processing. Our compan will repair or chane the
defected pla er according to the factual condition. However, the warrant
service does not include the damage caused b improper operation and the
damage caused b the repairing of the unauthorized third part . What’s more, it
also does not include the damage caused b improper disassembling and the
damage caused b the consuming material such as earphone and carr ing strap.
An losses or file losing caused b using this product, the manufacturer
won’t take an direct or indirect responsibilit .
Because the network conditions ma varies in different areas, we cannot
promise the VBOX pla er can download contents from the internet fast and eas
ever where.

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
2
Attention
Improper placement or operation would damage the pla er. During
operating and transporting process, please take care so as to avoid
dropping the pla er onto the ground.
Before operating, please make sure our power suppl status good.
Please take out batter from the remote controller if ou would not
use the pla er for a long time so as to avoid the damages caused b
the erosion of the batter .
Please adjust volume to safe level because too high volume ma cause
damage to our audition. Please decrease the volume or stop using
the pla er if ou feel tinnitus.
Within 15 da s after ou bu the pla er, please fill in “Return Receipt
of Warrant Card” carefull and mail or bring it to us for registration,
so as to provide ou much better service.
2 1.5V AAA batter can run the remote controller as long as 6 months.
The lifespan of batter ma var because of the different using
conditions, manufacturing companies or producing dates.

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
3
About Using and Deposit Environment
Please operate the pla er in the place where termperature is from 0℃
to 50℃.
Please deposit and transport the pla er in the place where
termperature is from -30℃ to 80℃.
Please operate the pla er in the place where humidit is from 10%RH
to 85%RH.
Please deposit the pla er in the place where humidit is from
5%RH-95%RH.
Please do not drop the pla er when using it, otherwise the dropping
ma scratch the covers or do harm to the harddisk.
In order to prevent static, please avoid operating the pla er in
especiall dr environment.
In order to lower the possibilit of getting an electric shock or hurt,
please do not operating the pla er in moist place or in the water.
In order the avoid the disturbance of bio-iatrical remote devices,
please do not use WIFI in hospital, airport, gas station, etc.

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
4
Welcome to use VBOX HD Network DVD (AG: VBOX)! VBOX will bring ou
the new entertainment experience.
VBOX is the media center of our home. VBOX can pla video, photo, music
media files. You can download and pla all these kinds of medies from Internet
directl .
1．
．．
．Product and Accessories
Here comes all basic equipments of an VBOX product:
1 VBOX machine
1 VBOX remote controller(with a pair of AAA batteries)
User manual, User Registion Card
12V AC adapter with power suppl cable.
1 mposite AV cable
1 RJ45 network cable
For different sales market, there ma be following option accessories:
USB WIFI Net Card
Composite Video Cable
HDMI 1.3 AV Cable
SPDIF Fiber Audio Cable
SPDIF Coaxial Audio Cable
Please consult our VBOX seller or Login http://vbox.21cn.com for more detail
information of above accessories.
2．
．．
．Appearance & Remote Controller
This chapter introduce the VBOX Appearance & Remote Controller.
See Illustration 1-1 for VBOX front panel

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
5
123456
Illustration 1-1: VBOX front panel
No. Name Description
1 Harddisk Indicator Red light indicates reading/writing
harddisk
2 Remote Sensor Receive signals from the remote
controller
3 Network Indicator Green light indicates network data
transfering
4 Power switch Press to On/Off VBOX
Press and Hold to force shutdown
5 USB Jack 1 For USB WIFI NetCard or external
storage device plugin
6 USB Jack 2 For USB WIFI NetCard or external
storage device plugin
See Illustration 1-2 for VBOX back panel
Illustration 1-2: VBOX back panel

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
6
No. Name Description
1 SPDIF Fiber Output Connect to amplifier via Fiber Audio
cable to output DTS/AC3 surround audio
effect.
2 SPDIF Coaxial
Output
Connect to amplifier via Coaxial Audio
cable to output DTS/AC3 surround audio
effect.
3 HDMI 1.3 Output Connect to TV/Projector/amplifier via
HDMI 1.3 Cable
4 VGA Output Connect to PC monitor via VGA cable
5 Component Video
Output
Connect to TV/Projector via Component
Video Cable (YPbPr)
6 Composite Video
Output
Connect to TV/Projector via
CompositeVideo Cable
7 Stereo Audio Output
Output Stereo Audio signals
8 RJ45 Network
Interface
10/100Base-T，Connect to ADSL Modem
or Router
9 DC 12V Input 220V AC to 12V DC 2A adapter
See Illustration 1-3 for VBOX remote controller

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
7
Illustration 1-3: VBOX remote controller

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
8
No.
Name Description
1 Power Shutdown. We strongl suggest use this ke to
shutdown VBOX to protect the data in harddisk.
2 0～9 Input the numbers or the corresponding characters
b repeat the same ke within one second.
Ke ①-⑥ also the shortcuts to select the items in
the main menu.
3 Loop/Random When pla ing video, set/unset loop pla ing
When pla ing music, set pla ing in sequence or
random
4 Up/Down/
Left/Right
Move around the highlight cursor
5 OK Confirm the selection
6 PageUp/PageDown
PageUp or PageDown to scroll the information
7 Menu Go into the main menu when not pla ing an thing.
When pla ing video, call out the pla back menu.
8 Screen Switch 4:3/16:9 output or zoom the output
9 Function Cooperate with other ke s to be the short cuts for
functions
10 Batter Cabin Press and push open the batter cabin.
11 Pla /Pause When browsing video files, pla from last break
point.
When browsing other files, pla the music pla list
12 Forward/Backard When pla ing Video files, provide 2-64 mutiple
speed forward or backward1 abilit
13 Setting Go into s stem settings
14 Mute Shut up or resume audio output
1
It nees support from the video file format.

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
9
15 HDMI/YPbPr/
VGA/AV
Switch using different video ouput
16 Help Displa the available ke s and their functions an
time
17 Volumn+/- Increase/Decrease the audio ouput volumn
18 Search When browsing internet contents, open the search
box
19 Delete Delete the selected files or director when
browsing local storage
Delete the selected task when browsing download
progress
Delete the character upon the cursor when inputing
Remove a VBOX from the favorite list when
browsing VBOXes
20 Return Return to last step.
21 SubTitle Open/Close the subtitle when pla ing video files, or
switch to pla next subtitile if there is more than
one.
22 Audio Track Switch to next audio track when pla ing video files.
23 Stop Stop and markup the break point when pla ing
video files.
Stop pla ing music at other time.
24 Video/Music/
Photo/Download
Short cut to browse video files, music files, photo
files or internet contents.
Harddisk Installation Guide
VBOX supports 2.5 inch SATA harddisk. Illustration 1-4 is showing how to
install the harddisk drive.

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
10
Step 1 Loose the screws(①②) on the harddisk carbin, open the cover
Step 2 Lean the harddisk and then plug in the slots slowl .
Step 3 Recover the cabin then tigh the screws.
[Notice]
If ou prepare the master storage b ourself, we suggest ou using internel
harddisks over 80G. For new harddisks, ou need to initialize it with the
partition & format function of VBOX, so that to get the best download and
pla back effect.

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
11
3．
．．
． Connecting the cables
This chapter telling the operations of first time using VBOX.
Use the VBOX cables as Illustration 2-1
[Connections]
1) Connect VBOX and TV with the composite AV cable, use the same color to
match the pins and the jacks.
2) Connect VBOX with ADSL modem or router with the network cable.
3) Connect VBOX with AC power with the power adapter, notice that VBOX
use 220V AC power source.
4) Press the power button in the front of VBOX, blue ra s shining through the
button means VBOX is working.
5) Turn on the TV, switch the TV signal source to the set of input jacks which
ou used in step 1. VBOX startup screen will appears on our TV if the
upper operations all right.
6) Install the AAA batteries in the remote controller, start to use VBOX.

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
12
[Notice]
1) You can use Component Video cable or HDMI AV cable instead of
composite for best pla back effect. Component Videl Cable or HDMI AV
Cable are not basic accessories of VBOX, ou need to bu them in addition.
2) You can use HDMI cable or SPDIF fiber/coaxial audio cable connect VBOX
with the amplifier to output the DTS/AC3 surronding audio signals.
HDMI/Firber/coaxial cables are not basic accessories of VBOX, ou need to
bu them in addition.
3) If ou brought the VBOX without an storage device (Harddisk or SD cards),
ou need to install our storage device first of all the above steps. For best
pla back effect, we suggest using internal harddisk as the master storage.
a) Refer to last chapter if ou use internal harddisk.
b) If ou use external USB master storage device, please do not
plug/unplug it when VBOX is running.
c) If ou use SD card as the master storage, plug the SD card (ma with
the card reader) into the SD slot in front of VBOX. Notice to make
sure the write-protect switch on the SD card is on the un-protect
status. Please use high-speed (50X above) and large capabilit (2G
above) SD as the master storage of VBOX.
d) If ou use external harddisk as master storage, please use the build-in
partition & format function to initialize our harddisk. VBOX can onl
read NTFS partitions and not able to download an thing into NTFS
partitions.
4) First time to use VBOX, ou need to setup network connection method in
the setting dialog until "connected" sign appears on the right-top conner
of the main menu.

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
13
4．
．．
． Initialize Settings
4.1 Best video output effect
Since VBOX-86B2 supports composite video output, VGA output,
component video output and HDMI video output, ou need to select suitable
cable and setup our TV/Projector to use corresponding input signal source to
get the best pla ing effect.
We suggest to use HDMI or Component video interface to connect VBOX
and TV/Projector.
Please check out the manual of our TV/Projector, make sure the video
signal process abilit of our TV/Projector. Then setup VBOX to use the highest
standard of our TV/Projector to output video signals.
To adjust the video signal output settings, press “settings” then select
“Video output”, setup “Video cable”, “screen size” and “scan lines”.
Warning: If your TV do not support HD but you set VBOX output HD
signals by force, you may see nothing on your screen after trying to play a
video. Although this will not do harm to your TV/Projector in general case,
however, you are not able to do anything since you see nothing. The way to
save yourself from that situation is to find a thin pin insert into the small reset
role at the bottom of VBOX, press it to reset VBOX to the factory settings.
4.2 Configure network
VBOX support internel fixed netcard or wifi wireless netcard. VBOX
supports up to 128 bits WEP share-ke encr ption method.
If ou have computers need to share the internet access with VBOX, we
suggest ou bu and use network routers. We suggest ou use fixed network
connections for best transfer effect. If ou use WIFI network, please make sure
the space is clean between the WIFI net card and the WIFI AP. Also make sure
the WIFI signal stronger than level 5.
5．
．．
．Common Operation

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
14
5.1 Main Menu
You can use LEFT/RIGHT arrow ke and OK ke to select the main menu
items. ①-⑥ is the short cut for main menu items when ou are sta ing in
main menu. The color ke s at the bottom of the remote controller are short
cuts for main menu item 1-4 an time when ou using VBOX.
The network connection status is at the right top conner of main menu.
“Offline” means network un-available; “Disabled” means network connected
but service not available; “Connected” means network is ok and service is
available.
VBOX embed software versions and master storage format are listed at the
bottom of main menu. EXT2 files s stem format is recommended for hish speed
read/write HD video files which is large than 4G. Before asking help for VBOX
service, please provide us with the VBOX embed software version & master
storage file s stem format.
5.2 Media Player
[Description]
There are video pla er, music pla er and photo pla er.
There are operation tips on the top of the media pla er.
Storage information is at the bottom of the screen, or the pla ing media
file name.
File of the current director are listed in the screen center, file size on our
right hand.
[Navigation]
UP/DOWN: Select a file or director
LEFT: Entr parent director
RIGHT: View detail of the file or director
PageUp/PageDown: Page up/down the list
VOLUMN & MUTE: Adjust the audio volumn.

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
15
OK: Pla the selected file, or enter the selected director
MENU: Back to main menu
RETURN: Back to parent director or main menu
[Modification]
①: Cop the selected file or director into the clipboard.
②: Cut the selected file or director into the clipboard.
③: Paste the file or director in the clipboard into current director
④: Delete the selected file or director
⑤: Create new director
⑥: Rename the selected file or director
⑨: Proect or Un-protect the selected file or director to be cleaned
automaticall .
[Pla back]
PLAY: Pla the selected file and start from the position last time stop
pla ing.
Use the following ke s when pla ing video:
PLAY: Pause or resume pla back
BACKWARD: 2X - 64X speed pla ing backward
PageUp: Pla the previous file in the pla list.
PageDown: Pla the next file in the pla list.
STOP & RETURN: Stop pla ing and back to the file list. If stop pla ing
be ond 60 seconds, VBOX will show ou the stopped position and next time ou
can use PLAY ke to resume from the same position.
Audio: Switch ot next sound track if the pla ing file has more than one
sound track. Notice: ou will hear nothing if ou are using Stereo output
while switch to an DTS sound track. DTS sound track can onl be output to
HDMI/SPDIF jacks for amplifiers.
SUBTITLE: Switch to next sub-title, or close sub-title.
Time Scale Seeking: Press LEFT/RIGHT when pla ing video to call out the

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
16
Time Scaler. Then press LEFT/RIGHT for 1 minutes seeking, UP/DOWN for
10 seconds seeking and PageUp/PageDown for 10 minutes seeking.
ZOOM: Switch 4:3 or 16:9 screen size.
[Music]
Use the following ke s when pla ing music:
PageDown: Pla next music in the list.
PageUp: Pla previous music in the list.
STOP: Stop pla ing music
Random: Select pla ing in order or random
VOLUMN & MUTE: Adjust the audio volumn.
[Photo]
Use the following ke s when pla ing photo:
RIGHT: Pla next photo in the list.
LEFT: Pla last photo in the list.
OK: Pause the slide show on the current photo, or resume slide pla ing
⑤-⑨: Set slide interval to 5-9 seconds.
5.3Network Access
[samba]
VBOX can share director from LAN computers. To do so, ou need to
share a director on our computer named ‘vbox’ first. Then repeat
pressing LEFT on our remote controller to navigate to root dir and select
‘network’. Input the IP address of our computer. VBOX will list files and
directories from our PC if the above steps all right.
[FTP]
FTP function can help ou access the files in VBOX from the PC. You
can cop files between PC & VBOX b using FTP.
To enable FTP function, open “settings”->”Network”->”FTP”, then set
up the FTP password. After doing so, ou can input ftp://<vbox IP> in our

www.oftenfull.com Enjo HD Life VBOX HD Network DVD User Manual
17
explorer address bar and then ke -in the ftp password in the pop-up
window. The data inside VBOX master storage will be listed if the above
steps all right.
5.4 Content Downloading
[Description]
There are “Graphics” & “Simple” modes for “Content Downloading”
module. In Graphics mode, poster pictures are tiled as well as the digest
words. In Simple mode, onl text words are listed for faster operation. You
can switch these two displa ing st le in “Settings”.
[Simple St le]
There is operation tips on the top of the screen.
Storage information at the bottom of the screen, or the pla ing
music.
Video t pes are listed on our left hand. Use UP/DOWN arrow ke to
select video t pes. Sub-t pes will appears automaticall if there is an .
Videos are listed on our right hand. Use RIGHT arrow ke to enter
the list and then use UP/DOWN arrow ke to select. LEFT arrow ke lead
ou back to the video t pe list.
Use DELETE ke in the content list to switch the sorting order: no
sort/accending/decending.
Press OK on a video content will bring ou the detail information of
that video, includes name, brief introduction, poster, lenght in minutes,
language and area. Use UP/DOWN to view last/next video information.
RETURN to back to the content list. OK again to download the current
VIDEO.
If there onl one file for the selected video, download task will be
created directl . Otherwise, a file list appears for selection. Use RIGHT ke
