VDarts H2 User manual

VDarts H2. H2L. H3L
安裝使用說明書
Installation and User Manual
www.vdarts.net
OK
Vdarts H3L
H2 H2L H3L. .

English 02-14
................
繁 體 15-27
................
1

Package Contents
目錄
02
03
FAQ
Package Contents
Product Specifications
04-05
Precautions
06
Dartboard
Installation
07-09
User Guide
10
General Rules
of Darts
11
Member Card Instructions
and FAQ
12-14
-Dart Board
-Soft Tip Darts
-Soft Dart Tips
-Installation And User manual
-Member Card
-Tape Measure
-Throw Line Marker
-H2: USB
-H2L & H3L: Power Cord 2

Main material:ABS plastic
H2L Size:54×57×7cm
Target surface:15.5 inches
H2L Weight:5.5kg
H3L Weight:5.5kg
H3L Weight:5.5kg
H2 Size:54×57×5cm
H2 Weight:3.3kg
Power supply:100-240V
Noise reduction: Yes
Confirm Button
Bluetooth Indicator
Product Specifications
VDarts H2&H2L Global Online Dartboard
Signal Output Port
AC connector jack
Power button
VDarts H2&H2L Global Online Dartboard:15.5 inches target area 1 to 4 players
AC connector Bluetooth (The bluetooth indicator light will keep flashing when
device is not connected.)
3
Dart Board
Dartboard Switch
Signal Output Port
AC connector jack
Dry Battery
Power button
H2
H2L
H3L
(for confirming your selection)
OK
Vdarts H3L

Precautions
VDarts H2&H2L Global Online Dartboard
4
Warning
■Safety Precautions
-Dropping the product or allowing it to get wet can cause damages. Electric
shock may occur when in contact with liquids.
■Power Cord & Plug Precautions
-Make sure the plug is completely inserted into the outlet to prevent electric
shock.
-Precautions to avoid electric shock or short circuit:
-Do not bend, stretch, damage, or hang heavy objects on the power cord.
-Do not use AC connecter if broken. Replace immediately to prevent electric shock
or short circuit.
-Make sure your hands are dry before handling the AC connector to prevent
electric shock or short circuit.
-Do not use other power supply except for current (100-240V).
-Switch off power and disconnect power supply when product is not in use.
■Dart Throwing Precautions
-Using too much strength in throwing darts may lead to hand, wrist, and
shoulder injury or damaged product.
-Do not throw darts toward any person, animal, or object to prevent
injuries and property damages.
-Only throw darts toward the dartboard.
-Do not walk in between the dartboard and the player when a game is
ongoing.
■Choking Hazard
-Product contains small parts. Please keep product away from children
under 3 years of age. Use with adult supervision only.
Please follow all instructions carefully. If any unusual activity is observed
with the product, please turn off power immediately, unplug power
cord, and contact us or your distributor.

Precautions
VDarts H2&H2L Global Online Dartboard
■Prohibit Dismantling
-Do not attempt to open, modify, or repair the product by yourself.
Doing so may cause malfunction, deformation, or other damages.
-Contact manufacturer or distributor immediately if unusual activity is
observed. Incorrect use of product may result in injuries or property
damages.
■Hanging the Dartboard
-Make sure the wall is strong enough to hang the dartboard and
prevent falling or dropping of the product.
-Make sure the metal parts are fastened correctly when installing
the board. This should also be checked regularly.
-Use screws for hanging the board on wooden surfaces; and use
bolts when hanging on concrete walls.
■Darts
-Only use soft-tip darts not weighing over 20g. Do not use hard-tip or
steel-tip darts to avoid damages to the board.
-Maximum suggested weight of soft-tip darts is 20g.
■Hitting the Board
-Do not hit or press the dartboard heavily. Doing so can cause the board to
fall, which in turn can cause serious damages.
■Health Caution
-Prolonged use of the product may lead to hand or wrist fatigue. Avoid
excessive use and throwing.
-Consult the doctor before using the product if you have any existing hand
or wrist injury.
-Rest in between plays when playing long-term to avoid fatigue.
■Playing Age
-This product is suitable for ages 16 and up. Adult supervision is required for
ages below 16.
■Where to Install
-This product is made for indoor use only.
5

Installation for dart board
VDarts H2&H2L Global Online Dartboard
Installation Place Of Dartboard
Dartboard Installation
244cm
Throw Line
Dartboard
keep the center of the dartboard (bull)173cm away from floor
Height
Set the throw line (point where darts are thrown) 244cm from
the surface of the dartboard.
Distance
1. Only use screws for installation on wood surfaces.
2. Use bolts or studs if dartboard is to be installed on a concrete wall.
！
1.prepare four screws
2.Fasten the screw by putting their parts into the holes
3.Make sure the distance is 173cm between the dartboard
centre and the floor.
4.keep screw head 5mm out of the wall.
5.make sure the wooden screws are fastened properly by
shaking them lightly.
Nail Holes
Wall
Dartboard
OK
Vdarts H3L
20 118
4
13
6
10
15
2
17
3
19
7
16
8
11
14
9
12
5
VDarts H2L
173cm
6

User Guide
VDarts H2&H2L Global Online Dartboard
Required Devices
Electronic devices such as smart phones or
tablets with bluetooth connection and are
connected to the internet.
Connection method
The bluetooth indicator light will flash after
the dartboard ispowered on. Turn on your
device’s bluetooth and search for
“VDarts (Product Model)” (iOS devices).
Bluetooth PIN code: 1608
You can start playing after successfully
connecting via bluetooth.
Download & Installation
[Android Devices]
Processor: Quad-Core 1.2GHz Memory: 2GB
Operating System: Android 4.4.2 Bluetooth: 4.0
Support OpenGL 2.0
[Apple Devices]
iPhone 5 or iPad 3 & newer devices iOS 8
& new system version
4.0
7
Please use the QR code scanning software on
your phone to scan the QR code,or search
“VDartsGame”on Google play or App store
to download the APP.
OK
Vdarts H3L
iOS Android
For Intel
CPU APP

8
Bluetooth pairing and connection
User Manual
VDarts H2&H2L Global Online Dartboard
Turn on the dartboard. The Bluetooth
indicator light will flash which means
the dartboard is in search mode.
Turn on Bluetooth on your phone/tablet
(Settings – Bluetooth)
VDartsGame
VDartsGame
01
02
Open APP,wait 5-10 seconds,
APP will automatically link with
dartboard.
03
After that you can login,
choose and start the game.
05
When connected successfully, the Bluetooth indicator light will stop blinking
and remain solid blue.
04
Notice: You do not need to link the device manually. Wait for the device to connect automatically.
If asked for the PIN code, enter 1608.
If connection fails, reboot your dartboard or device, and try again.
For more information, visit http://help.vdarts.net/en/
OK
Vdarts H3L
20 118
4
13
6
10
15
2
17
3
19
7
16
8
11
14
9
12
5
VDarts H2L
20 118
4
13
6
10
15
2
17
3
19
7
16
8
11
14
9
12
5
VDarts H2

9
Game Interface
User Guide
VDarts H2&H2L Global Online Dartboard
If you need any adjustments, click these
buttons:
Back
Next Turn/Switch Player
Exit
EXIT
Log In
Online PK Game Setting

10
Basic rules for dart
Basic rules for throwing dart
General Rules of Darts
VDarts H2&H2L Global Online Dartboard
■When it is your turn, throw the darts one by one. After throwing
three darts, you have completed your turn. This is called “one throw”.
■After a player finishes his “one throw”, the turn is given to the next
player. When all players finish their “one throw”, the round will end
and the next round will start...
■When all rounds are finished, the game will end.The number of rounds
is dependent on the type of game being played.
12
3
Aiming
Grip the barrel
and stand stably.
1
Take back
Decide the target and
draw back your forearm
as much as possible.
2
Throw
Lock your elbow and throw
the dart to target area by
swinging forearm to dart board
straightly.
3

11
Q: My dartboard won’t start.
A: Please check and make sure that the AC connector is properly
connected and that the board is plugged in.
Q: The dartboard is not responding.
A: Try hitting the same area with the dart.
Q: The tips of my darts are broken or damaged.
A: Unscrew the tip from the barrel and replace it with a new tip.
Q: I cannot connect via bluetooth.
A: Exit the game app, reboot your device, and try connecting again.
If problem persists, switch off the dartboard and switch it back on again.
Q: My device keeps displaying “Searching VDarts H2…”
A: If your board doesn’t connect to your device’s bluetooth automatically,
you will have to connect it manually. Go to
your device’s settings – Bluetooth – Search device – input
connection “VDarts Home Dartboard”– Enter PIN code: 1608.
Frequently Asked Questions
VDarts H2&H2L Global Online Dartboard
If you have any other questions, please visit our Help Center:
http://help.vdarts.net/en/
help.vdarts.net

Member Card Instructions and FAQ
Differences in Membership Cards:
VDarts H2&H2L Global Online Dartboard
Items
Logging
in
Pairing
Advantage
Disadvantage
System Activated
Member Card
Player uses the ID number found
at the back of the card to login.
Input card number as the
account, and last 6 digits as the
password. Log in and activate
your e-mail to modify
information or check scores.
You need to create a
new account if you lose the
card or forget the ID number.
You need to register a new
account before you can use
your member card.
Your account is already
paired with the
member card.
Card is system activated so you
will be able to use it as soon as
you get it.
You can set your own ID
and Password which will be
easier to remember.
Player cannot use the ID number to
directly login.
You need to create a VDarts account
(must be 5 ~ 16 letters and numbers)
on the VDarts member platform.
Add a member card in “Member
card management”after logging in.
Enter the ID card number to pair
your member card to your account.
Ordinary Member Card
12

VDarts H2&H2L Global Online Dartboard
13
Member Card Instructions and FAQ
(Picture 1)
System Activated
Member Card
(Picture 2)
Ordinary
Member Card
Try logging in using your
card’s ID number.
If you have the System
Activated Card, you will be able
to log in successfully.
Information such as points,
ranking,and location will be
shown. (Picture1)
Q: How do I register/login to become a VDarts member?
A: Please go to our web site http://logiin.vdarts.net/singUp.html, or download the
APP on Google play or APPLE store on your mobile device and register. If you
have a VDATRS member card, you can pair it to your account. Your account can
be paired to multiple member cards and can be used to add money and
recharge. The balance of your account can be shared by multiple member
cards.
Try logging in using your
card’s ID number.
If you have the ordinary
member card, you will be
asked to register an account.
How to know which card you have:
Member Card Q & A:

VDarts H2&H2L Global Online Dartboard
14
Member Card Instructions and FAQ
Q: What should I do if I forget my member card password?
A: Please go to http://login.vdarts.net/forgetPassword.html and follow the
instructions. If you still have a problem logging in, please contact our customer
support at [email protected].
Q: My member card cannot be paired to my account. It says that my card is already
in use.
A: Please follow the instructions below:
1. Use your member card ID number as your account and take the last 6 digits of
the ID number as your password to log into VDarts member platform.
2. Delete your original account and then log out.
3. Log into your account again and pair the card in the member card
management. If not successful, please send an email to [email protected]
(There are two kinds of member cards: the “System Activated Member Card”
(Use ID number as your login details) and the“Ordinary Member Card”
(register an account first to login)).
Q: Will my scores and competition record be gone if my member card is damaged?
A: All your data is saved to your account. You only need to pair a new member
card to your account and it will save your data history automatically.
Q: How do I get a ranking/rating (Initial: N1)?
A: VDarts will give you a ranking/rating after competing with other players online
for over 10 times.
Q: Why doesn’t my rating change? I have improved a lot recently.
A: Remember that you need to login to your member account before entering the
game for VDarts to record your data. Since the system averages the last
30 games you played, you might have to play more to see a change in your
rating/ranking.

產品內容
目錄
15
16
常見問題的
處理方法
產品內容
產品規格
17-18
使用注意事項
19
飛鏢靶的安裝
20-22
使用方法
23
飛鏢的基本規則
&基本投擲方法
24
會員卡說明與Q&A
25-27
15
-飛鏢靶
-軟式飛鏢
-替換用鏢頭
-使用說明書（本書）
-會員卡
-量尺
-VDarts投擲線地貼
-H2：USB線
-H2L & H3L: 電源線

產品規格
VDarts H2. H2L. H3L 全球聯網飛鏢靶
信號輸出接口
AC連接器連接插孔
電源按鈕
VDarts H2. H2L.H3L 電子聯網飛鏢靶的靶面尺寸15.5英寸；可供4人同時使用；AC連接器；
藍牙(通電後,當藍牙未連接設備時，藍牙指示燈在閃爍狀態。當連接成功後,藍牙指示燈常亮）
16
飛鏢靶
飛鏢靶的底面
信號輸出接口
AC連接器連接插孔
乾電池
電源按鈕
H2
主要材質:ABS plastic
H2L 尺寸:54×57×7cm
靶面尺寸:15.5 inches
H2L 重量:5.5kg
H3L 尺寸:54×57×7cm
H3L 重量:5.5kg
H2 尺寸:54×57×5cm
H2 重量:3.3kg
電源:100-240V
靜音裝置:有
確定鍵
藍牙指示燈
H2L
H3L
(遊戲選擇確定)
OK
Vdarts H3L

使用注意事項
17
警告
因錯誤使用本產品可能會導致使用者死亡、嚴重受傷、或者輕微受傷及損壞財物。
■關於異常、故障
-請不要超出說明書規定的操作範圍去進行操作，如果產品出現什麼異常情況，
請馬上切斷電源，拔下電源頭，然後聯繫本產品的店家或經銷商。
■關於受潮
-請不要讓本產品受潮，否者可能會引起觸電等事故。
■關於電源線和電源插頭
-電源插頭必須完全插入插座，如果不完全插入，可能會造成觸電事故。
-電源線請注意以下幾個事項，避免引起觸電或短路事故。
不能損壞、不要對他加熱、不要延伸、不要對其加工、不要切斷、不要彎曲、
不要在電源線上懸掛重物。
-AC連接器如果出現損壞，要立即停止使用，予以更換。如不馬上更換而繼續使用的話，
可能會引起觸電或短路事故。
-請不要用濕手去插拔AC連接器，那樣可能會引起觸電事故。
-請勿使用指定電源（100～240V)以外的電源。
-不使用本產品時請切斷電源，拔掉AC連接器，不然有可能因絕緣部位老化導致觸電、
故障事故。
■關於投擲方法
-請不要將飛鏢投向人或者動物，那樣會造成傷害事故。
-請擲飛鏢時，請確認飛鏢靶周圍沒有人、動物、或者容易受到撞擊而損壞的物體。
飛鏢脫靶或者從飛鏢靶彈回可能會導致附近的物體受損或者受傷。
-請不要從正在投鏢的人和飛鏢盤之間穿過，那樣可能會導致傷害。
-請不要過分用力，以免弄傷手、腕和肩膀。同時過分用力也可能會損壞產品，
造成故障或變形。
■關於防止誤食
-小零件不能放在小孩能夠接觸到的地方，另外一定要確認折斷的箭頭或者飛鏢是否有遺失，
防止被嬰幼兒誤食。
VDarts H2. H2L. H3L 全球聯網飛鏢靶

使用注意事項
■關於禁止拆解
-請不要自行把本產品及其配件進行拆解、改造、或者維修。因為那樣可能會導致引發
故障以及變形等事故、出現故障請聯絡店家或者經銷商處理,錯誤使用本產品有可能受傷
以及損壞財物的危險。
■懸掛注意事項
-飛鏢靶懸掛的位置要選擇有足夠強度能夠支撐飛鏢盤在牆上，確保掛上以後不會掉下來。
如果牆壁強度不夠，可能會導致飛鏢盤掉下，造成受傷或出現故障。
-安裝飛鏢靶時要確認金屬小零件是否鬆弛或歪斜，裝好以後要定期檢查。
防止掉下傷人或出現故障。
-請使用木鏍絲釘安裝飛鏢靶。如安裝在混凝土牆上，請配合使用螺栓。
■關於飛鏢
-本產品為軟式飛鏢專用，絕對不得使用硬式飛鏢。另外請不要使用超過20克重的飛鏢，
否則可能會導致損壞或故障的發生。
■關於撞擊
-請不要用力撞擊飛鏢盤或對其施加力量，以免其掉下。否則可能會損壞產品、
造成故障或變形。
■健康方面的注意事項
-長時間使用有可能會導致手或手腕出現疲勞，對健康不利，請儘量避免。
-如果手或手腕部有傷痛，使用前要和醫生商量，以免造成傷勢惡化。
-使用時要保持室內光線明亮，長時間使用過程中請注意適度休息。
■關於使用物件的年齡
-本產品適用於16歲或以上的人士使用。
■關於安裝場所
-本產品為室內專用。
18
VDarts H2. H2L. H3L 全球聯網飛鏢靶

OK
Vdarts H3L
飛鏢靶的安裝
20 118
4
13
6
10
15
2
17
3
19
7
16
8
11
14
9
12
5
VDarts H2L
飛鏢靶的安裝位置
飛鏢靶的安裝方法
173cm
244cm
投擲線
飛鏢靶
請把飛鏢靶安裝在以中心點(正黑心)
距離地板173cm高度的位置。
高度
距離飛鏢靶表面垂直距離為244cm的地方
為投鏢線(投擲飛鏢的距離)。
距離
1.請使用木螺釘安裝飛鏢靶。
2.如安裝在混泥土牆上面，請配合使用螺栓。
！
1.請準備四枚螺絲；
2.確定飛鏢靶的中心到地面的距離為173cm，將螺絲釘在合適的位置。
螺絲的頭部露出牆壁5mm左右；
3.將飛鏢靶背面的四個釘孔對準螺絲的頭部掛住，固定下來；
4.請確認四個釘孔是否牢牢掛在了螺絲頭上，並嘗試左右輕輕搖動，
確認不會脫落。
釘孔
牆壁
飛鏢靶
19
VDarts H2. H2L. H3L 全球聯網飛鏢靶
