VDO360 VUSBEXT-U User manual

VUSBEXT-U
USB 2.0 Cat. 5/6 Extender - 50M
User Manual

INTRODUCTION
This USB.2.0 Extender is capable of sending USB signals across a Cat.5 cable or
higher up to 50 meters at a data rate of High Speed (480Mb/s), Full Speed (12Mb/s)
and Low Speed (1.5Mb/s). Plug the Cat 5/6 cable into the RJ-45 Connector to set
up the extender. It takes only minutes to do so, and there is no configuration or
drivers necessary. The USB 2.0 Extender is fully USB 2.0 compliant and it is
backward compatible with USB 1.1/1.0.
PACKAGE CONTENTS
Before installation, please check the items of the package：
⚫Transmitter Unit
⚫Receiver Unit
⚫USB AM-BM cable
⚫User Manual
⚫Power Adapter (24V/0.5A)
FEATURES：
⚫Supports data transfer rates of 1.5Mb/s, 12Mb/s, 480Mb/s
⚫Product consists of two electronic modules, a "Transmitter unit" and a
"Receiver unit".
⚫Transmitter unit connects to a USB 2.0 Camera/Device.
⚫Units can be connected by a standard Cat. 5 cable or higher, which can then
enable extension of USB devices up to 50m (164 feet).
⚫Wall mounting integrated in the metal housing
⚫Support Hot Plug & Play- no software driver is required
⚫Power supply for Receiver unit included

Receiver Unit (connected to the PC)

Transmitter Unit (connected to the camera)
ITEM
TYPE
DESCRIPTION
1
PWR LED (Red)
LED ON power supply is connected to
Receiver unit and wall outlet.
LED OFF no power is supplied.
2
LINK LED(Green)
LED ON Indicates a valid connection between
Transmitter Unit and Receiver Unit has been
established via Cat5/6 cables.
LED OFF is a bad Cat 5 cable or connector
3
ACT LED(Amber)
The LED FLASHING shows the extender is
linked to PC properly & Camera plugged in to
downstream Transmitter is sending data.
LED ON shows no data is being transmitted

INSTALLATION：
1. Connect the Receiver Unit to the PC via USB Cable (A Male to B Male).
2. Plug the 24V/0.5A DC Power Supply into the USB 2.0 Extender Receiver Unit.
Plug the AC power cord of power supply into an available electrical outlet.
3. Connect the USB 2.0 Extender Transmitter Unit and Receiver Unit together with
a Cat 5/6 Cable (supplied by user).
4. Connect USB Camera to the Transmitter Unit.
5. Check the LEDs on USB 2.0 Extender Transmitter Unit. Make sure that the Act.
LED is flashing which means the extender is powered and communicating.
System Requirements：
⚫Windows XP/7/Vista/8/8.1/10；Mac OS
Specifications：
Receiver Unit
Upstream Port
USB Type B Female
Downstream Port
RJ45 Jack
Power
Bus-Powered
Self-Powered 24V/0.5A
Dimensions
66 x 60 x 24 mm
Transmitter
Unit
Upstream Port
RJ45 Jack
Downstream Port
USB Type A Female
Dimensions
66 x 60 x 23 mm
Interconnect Cable
Standard LAN Cables
Max Cable Length
50m (164ft)
Operating Temperature
0°C～50°C

Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received. Including interference that
may cause undesired operation.
WEEE Information
For EU (European Union) member users:
According to the WEEE Directive, do not dispose of this product as household waste or
commercial waste. Waste electrical and electronic equipment should be appropriately
collected and recycled as required by practices established for your country. For
information on recycling of this product, please contact your local authorities, your
household waste disposal service or the shop where you purchased the product.
