Vecom ECX-2600A PEG User manual

USER
Manual
USER
Manual
1.0.0 Edition 20221104
10th Gen Intel®Xeon®/Core™ i9/i7/i5/i3 AI Computing System
Workstation-grade, NVIDIA®Tesla®/Quadro®/GeForce®Graphics
ECX-2600A/2400A/2300A PEG

ii
©Vecow ECX-2600A/2400A/2300A PEG User Manual
Version Date Page Description Remark
0.10 2022/10/20 All Preliminary Release
1.00 2022/11/04 All O󰀩cial Release
Record of Revision

iii
©Vecow ECX-2600A/2400A/2300A PEG User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
Vecow Co., Ltd. is under no legal commitment to the details of this document.
Vecow shall not be liable for direct, indirect, special, incidental, or consequential
damages arising out of the use of this document, the products, or any third party
infringements, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual comply with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Vecow ECX-2600A/2400A/2300A PEG User Manual
Part Number Description
ECX-2600A-PEG
ECX-2600A, 6 GigE LAN with 4 PoE+, 2 PCIe x8, 1 PCIe x4,
4 SSD Tray, 6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO,
with System Fan
ECX-2600AF-PEG
ECX-2600A, 6 GigE LAN with 4 PoE+, 2 PCIe x8, 1 PCIe x4,
4 SSD Tray, 6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO,
with Fan Sink and System Fan
ECX-2400A-PEG
ECX-2400A, 6 GigE LAN with 4 PoE+, 1 PCIe x16, 1 PCIe x4, 4 SSD
Tray, 6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO, with System
Fan
ECX-2400AF-PEG
ECX-2400A, 6 GigE LAN with 4 PoE+, 1 PCIe x16, 1 PCIe x4,
4 SSD Tray, 6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO,
with Fan Sink and System Fan
ECX-2300A-PEG ECX-2300A, 2 GigE LAN, 1 PCIe x16, 1 PCIe x4, 4 SSD Tray,
6 USB 3.2, 4 COM, 3 Nano SIM, 16 GPIO, with System Fan
ECX-2300AF-PEG
ECX-2300A, 2 GigE LAN, 1 PCIe x16, 1 PCIe x4, 4 SSD Tray,
6 USB 3.2, 4 COM, 3 Nano SIM, 16 GPIO, with Fan Sink and
System Fan
Order Information

v
©Vecow ECX-2600A/2400A/2300A PEG User Manual
CPU List
Series CPU Cores TDP Cache Max.
Frequency
ECC
Memory
Intel®
Xeon®
W-1290E 10 95W 20M Up to 4.8GHz Y
W-1290TE 10 35W 20M Up to 4.5GHz Y
W-1270E 8 80W 16M Up to 4.8GHz Y
W-1270TE 8 35W 16M Up to 4.4GHz Y
W-1250E 6 80W 12M Up to 4.7GHz Y
W-1250TE 6 35W 12M Up to 3.8GHz Y
Intel®
Core™
i9-10900E 10 65W 20M Up to 4.7GHz NA
i9-10900TE 10 35W 20M Up to 4.5GHz NA
i7-10700E 8 65W 16M Up to 4.5GHz NA
i7-10700TE 8 35W 16M Up to 4.4GHz NA
i5-10500E 6 65W 12M Up to 4.2GHz NA
i5-10500TE 6 35W 12M Up to 3.7GHz NA
i3-10100E 465W 6M Up to 3.8GHz Y
i3-10100TE 435W 6M Up to 3.6GHz Y

vi
©Vecow ECX-2600A/2400A/2300A PEG User Manual
Part Number Description
DDR4 32G Certied DDR4 32GB 3200MHz RAM
DDR4 16G Certied DDR4 16GB 3200MHz RAM
DDR4 8G Certied DDR4 8GB 3200MHz RAM
DDR4 4G Certied DDR4 4GB 3200MHz RAM
PWA-160WB-WT
160W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to
+70°C
PWA-280WB-WT
280W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to
+70°C
PWS-480W-WT 480W, 24V, 90V AC to 305V AC Power Supply, Wide-Temp,
IP65
VESA Mount VESA Mounting Kit
DIN-RAIL Kit DIN Rail and VESA Mounting Kit
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector and
DIN-Rail Mounting
M.2 Storage Module M.2 Key M/Key B PCIe Storage Module
5G Module 5G Module with Antenna
4G Module 4G/GPS Module with Antenna
WiFi & Bluetooth WiFi & Bluetooth Module with Antenna
Optional Accessories

vii
©Vecow ECX-2600A/2400A/2300A PEG User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of ECX-2600A PEG 3
1.3.2 Specications of ECX-2600AF PEG 5
1.3.3 Specications of ECX-2400A PEG 7
1.3.4 Specications of ECX-2400AF PEG 9
1.3.5 Specications of ECX-2300A PEG 11
1.3.6 Specications of ECX-2300AF PEG 13
1.4 Supported CPU List 15
1.5 Mechanical Dimension 16
1.5.1 Dimensions of ECX-2600A PEG 16
1.5.2 Dimensions of ECX-2600AF PEG 16
1.5.3 Dimensions of ECX-2400A PEG 17
1.5.4 Dimensions of ECX-2400AF PEG 17
1.5.5 Dimensions of ECX-2300A PEG 18
1.5.6 Dimensions of ECX-2300AF PEG 18
CHAPTER 2 GETTING TO KNOW YOUR
ECX-2600A/2400A/2300A PEG 19
2.1 Packing List 19
2.1.1 ECX-2600A/2400A PEG Packing List 19
2.1.2 ECX-2300A PEG Packing List 20
2.2 Front Panel I/O Functions 21
2.3 Rear Panel I/O & Functions 28
2.4 Main Board Expansion Connectors 35
2.5 Main Board Jumper Settings 49
2.6 Ignition Control 55

viii
©Vecow ECX-2600A/2400A/2300A PEG User Manual
CHAPTER 3 SYSTEM SETUP 58
3.1 How to Open Your ECX-2600A/2400A/2300A PEG 58
3.2 Installing CPU 61
3.3 Installing DDR4 SO-DIMM Modules 62
3.4 Installing Mini PCIe Card 64
3.5 Installing Nano SIM Card 67
3.6 Installing Micro SD Cards 68
3.7 Installing PCI/PCIe Card 69
3.8 Installing SSD/HDD 72
3.9 Installing M.2 73
3.10 Installing Antenna Cable 80
3.11 Mounting Your ECX-2600A/2400A/2300A PEG 83
CHAPTER 4 BIOS SETUP 88
4.1 BIOS Setup 88
4.2 Main 89
4.3 Advanced 90
4.4 Chipset 106
4.5 Security 112
4.6 Boot 115
4.7 Save & Exit 116
APPENDIX A : Isolated DIO/GPIO Guide 117
APPENDIX B : Software Functions 121
APPENDIX C : RAID Functions 125
APPENDIX D : Power Consumption 131
APPENDIX E : Supported Memory & Storage List 137
APPENDIX F : Install Win11 (BIOS TPM Setting) 142

1
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
Vecow ECX-2600A/2400A/2300A PEG is a rugged AI Computing System.
Featuring a new generation workstation-grade platform : 10-core 10th Gen
Intel® Xeon®/ Core™ processor which provides a 45% increase in system
performance and 87% improvement in graphics performance over Vecow
previous generation embedded system. By integrating with powerful NVIDIA®
Tesla®/Quadro®/ GeForce® Graphics, ECX-2600A/2400A/2300A PEG is taking
AI Computing Systems to the next level. This series provides workstation-grade
computing capability and brings balance between reliability and power budget
for the innovation applications of edge computing. It also supports an array of
high-speed congurations, including USB 3.2 (10G), PCIe 3.0 (8GT/S), SATA III
(6G) and GigE LAN (1G).
The ECX-2600A/2400A/2300A PEG provides rich I/O interfaces including
6 GigE LAN with 4 IEEE 802.3at PoE+, 4 COM, 6 USB, 32 Isolated DIO, 3
external Nano SIM card socket. Complete with integrated congurations, ECX-
2600A/2400A/2300A PEG provides 4 front-access SSD/HDD trays, 2 PCIe
(ECX-2600A PEG with 3 PCIe) expansion slots for dedicated graphics cards
including NVIDIA Tesla/Quadro/GeForce with up to 2560 CUDA cores for
advanced AI computing.
Powered by 10th Gen Intel® Xeon®/Core™ i9/i7/i5/3 Processor and includes
industrial-grade features of PoE+ GigE LAN port, 12V to 50V DC-in with 80V
surge protection and -20°C to 45°C extended operating temperature supported,
Vecow ECX-2600A/2400A/2300A PEG provides high-performance computing
and reliable configurations for mission-crucial applications at the edge and is
ideal for Robotic Control, Traffic Vision, Public Surveillance, Smart Vending,
Automatic LPR, AMR/AGV, and any AIoT/Industry 4.0 applications.
1

2
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
1.2 Features
• Workstation-grade Platform : 10-core 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3
Processor (CML-S) running with Intel® W480E chipset supports max 95W TDP
CPU
• Supports up to 250W NVIDIA® or AMD Graphics card
• NVIDIA®Tesla®/Quadro®/GeForce® graphics card delivers leading AI
computing productivity by advanced NVIDIA® CUDA® cores
• 12V to 50V wide range DC Power Input with 80V Surge Protection
• 6 Independent GigE LAN with 4 IEEE 802.3at PoE+
• 6-port USB 3.2 support up to 10Gbps data transfer
• Storage : 4 2.5" SSD Tray, 1 Micro SD Card, 1 M.2 Key M, 4 SATA III
• Expansion : 2 PCIe (ECX-2600A PEG with 3 PCIe), 1 M.2 Key B, 1 M.2 Key E, 2
Mini PCIe
• Multiple VGA, DVI, HDMI and DisplayPort display interfaces support max 7
independent displays, up to 8K Resolution
• 32 Isolated DIO, 4 COM RS-232/422/485
• External Nano SIM Sockets for 5G/WiFi 6/4G/3G/LTE/GPRS/UMTS
• Supports Configurable Software Ignition Power Control and TPM 2.0
• Optimized user-friendly design for easier system maintenance
• Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI
accelerator and advanced Edge AI applications

3
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of ECX-2600A PEG
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB • 6 USB 3.2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM
Card/mSATA
PCI/PCIe • 2 PCIe x16 Slot with x8 signal
• 1 PCIe x8 Slot with x4 signal
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor • Intel® UHD Graphics 630
• Independent Graphics : By request
Interface Up to 7 independent displays :
• 1 VGA : Up to 1920 x 1080 @60Hz
• 1 DVI-D : Up to 1920 x 1080 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
• By requested graphic card
Storage
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x2)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 4 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out

4
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Input Voltage 12V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 260.0mm x 240.0mm x 123.0mm (10.24" x 9.45" x 4.84")
Weight 6.5 kg (14.33lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
Environment
Operating Temperature 35W, 65W TDP CPU : -20°C to 45°C (-4°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 45°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

5
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
1.3.2 Specications of ECX-2600AF PEG
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB • 6 USB 3.2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM
Card/mSATA
PCI/PCIe • 2 PCIe x16 Slot with x8 signal
• 1 PCIe x8 Slot with x4 signal
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor • Intel® UHD Graphics 630
• Independent Graphics : By request
Interface Up to 7 independent displays :
• 1 VGA : Up to 1920 x 1080 @60Hz
• 1 DVI-D : Up to 1920 x 1080 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
• By requested graphic card
Storage
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x2)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 4 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out

6
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Input Voltage 12V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 260.0mm x 240.0mm x 123.0mm (10.24" x 9.45" x 4.84")
Weight 6.5 kg (14.33lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
Environment
Operating Temperature 35W, 65W, 80W, 95W TDP CPU : -20°C to 45°C (-4°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 45°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

7
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
1.3.3 Specications of ECX-2400A PEG
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB 6 USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM
Card/mSATA
PCI/PCIe • 1 PCIe x16 Slot
• 1 PCIe x4 Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor • Intel® UHD Graphics 630
• Independent Graphics : By request
Interface Up to 7 independent displays :
• 1 VGA : Up to 1920 x 1080 @60Hz
• 1 DVI-D : Up to 1920 x 1080 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
• By requested graphic card
Storage
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x2)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 4 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN

8
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Input Voltage 12V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 260.0mm x 240.0mm x 104.0mm (10.24" x 9.45" x 4.09")
Weight 5.5 kg (12.13 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
Environment
Operating Temperature 35W, 65W TDP CPU : -20°C to 45°C (-4°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 45°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

9
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
1.3.4 Specications of ECX-2400AF PEG
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB 6 USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM
Card/mSATA
PCI/PCIe • 1 PCIe x16 Slot
• 1 PCIe x4 Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor • Intel® UHD Graphics 630
• Independent Graphics : By request
Interface Up to 7 independent displays :
• 1 VGA : Up to 1920 x 1080 @60Hz
• 1 DVI-D : Up to 1920 x 1080 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
• By requested graphic card
Storage
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x2)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 4 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN

10
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Input Voltage 12V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 260.0mm x 240.0mm x 104.0mm (10.24" x 9.45" x 4.09")
Weight 5.5 kg (12.13 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
Environment
Operating Temperature 35W, 65W, 80W, 95W TDP CPU : -20°C to 45°C (-4°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 45°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

11
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
1.3.5 Specications of ECX-2300A PEG
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB 6 USB 3.2 (External)
Isolated DIO 16 GPIO
LED Power, HDD, Wireless
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM
Card/mSATA
PCI/PCIe • 1 PCIe x16 Slot
• 1 PCIe x4 Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor • Intel® UHD Graphics 630
• Independent Graphics : By request
Interface Up to 7 independent displays :
• 1 VGA : Up to 1920 x 1080 @60Hz
• 1 DVI-D : Up to 1920 x 1080 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
• By requested graphic card
Storage
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x2)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 4 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN

12
©Vecow ECX-2600A/2400A/2300A PEG User Manual GENERAL INTRODUCTION
Power
Input Voltage 12V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 260.0mm x 240.0mm x 104.0mm (10.24" x 9.45" x 4.09")
Weight 5.5 kg (12.13 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
Environment
Operating Temperature 35W, 65W TDP CPU : -20°C to 45°C (-4°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 45°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
