Veeder-Root TLS Series User guide

Manual No: 577013-401 ●Revision: K
Application Guide
TLS Consoles Point-of-Sale (POS)

ii
Notice
Veeder-Root makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in
connection with the furnishing, performance, or use of this publication.
The information contained in this publication may be subject to change without notice.
This publication contains proprietary information which is protected by copyright. All rights reserved. No part of this publication may be
photocopied, reproduced, or translated to another language without the prior written consent of Veeder-Root.
©Veeder-Root 2018. All rights reserved.

Table of Contents
iii
Introduction
Business Inventory Reconciliation (BIR) ...........................................................................1
In-Station Diagnostics (ISD) - TLS-350R Consoles Only .........................................1
TLS-350R BIR and ISD Capabilities .................................................................................1
TLS-350R with BIR only and TLS-350R with BIR and ISD ......................................1
TLS-350R with ISD only ...........................................................................................1
Manifolded Tank Applications for BIR ......................................................................1
TLS-350R System Requirements for BIR and ISD ..........................................................2
Business Inventory Reconciliation............................................................................2
In-Station Diagnostics...............................................................................................2
TLS-450/TLS-450PLUS BIR Capabilities .........................................................................2
Manifolded Tank Applications...................................................................................3
TLS-450/TLS-450PLUS System Requirements for BIR ...........................................3
Supported POS Systems ..................................................................................................3
Other Applications ....................................................................................................4
DIM Descriptions
Mechanical Dispenser Interface Module (MDIM) &
Low Voltage Dispenser Interface Module (LVDIM) ...........................................................5
Electronic Dispenser Interface Module (EDIM) .................................................................5
Current Loop Dispenser Interface Module (CDIM) ...........................................................5
LAN Dispenser Interface Module (LDIM) - TLS-350R only ...............................................5
International Forecourt Standards Forum Dispenser Interface
Module (IFSF) - TLS-350R, TLS-450PLUS ......................................................................6
TCP/IP DIM Module (TDIM) - TLS-350R ..........................................................................6
TCP/IP DIM (TDIM) - TLS-450/TLS-450PLUS .................................................................6
DIM And Installation Kit Ordering Guide ...........................................................................7
DIM Installation Examples
Bennett POS System ......................................................................................................16
Veeder-Root Software Requirements.....................................................................16
Veeder-Root Hardware Requirements (Ref. Table 2) ............................................16
Bennett System Limitations ....................................................................................16
Installation Notes ....................................................................................................16
Gilbarco TCRG, TCRG2, T-11, and T-12 POS Systems ................................................18
TLS Console Software Requirements ....................................................................18
Veeder-Root Hardware Requirements (Ref. Table 2) ............................................18
Specific Limitations.................................................................................................18
Wiring Diagram for a Transac Current Loop Interface............................................19
Wiring Diagram for an Excentus Current Loop Interface........................................20
Gilbarco TS-1000 POS and PAM Systems .....................................................................21
TLS Console Software Requirements ....................................................................21
Veeder-Root Hardware Requirements (Ref. Table 2) ............................................21
Gilbarco POS and Dispensing System Requirements ...........................................21
Specific Limitations.................................................................................................21
Wiring to a Universal Distribution Box Interface .....................................................21
Gilbarco G-Site™ POS Systems ....................................................................................23
TLS Console Software Requirements ....................................................................23
Veeder-Root Hardware Requirements (Ref. Table 2) ............................................23
Specific Limitations.................................................................................................23
Wiring Diagram.......................................................................................................23
AutoGas Storemaster and Gilbarco Dispenser Systems ................................................25
TLS Console Software Requirements ....................................................................25
Veeder-Root Hardware Requirements (Ref. Table 2) ............................................25

Table of Contents
iv
Gilbarco POS and Dispensing System Requirements ...........................................25
System Limitations .................................................................................................25
Installation Notes ....................................................................................................25
Gilbarco SmartCrind Dispenser Systems .......................................................................30
TLS Console Software Requirements ....................................................................30
Veeder-Root Hardware Requirements (Ref. Table 2) ............................................30
System Limitations .................................................................................................30
Installation Notes ....................................................................................................30
Tokheim Dispensing Systems .........................................................................................31
TLS Console Software Requirements ....................................................................31
Veeder-Root Hardware Requirements ...................................................................31
Tokheim DHC Requirements..................................................................................31
Specific Limitations.................................................................................................31
Other POS Consoles ..............................................................................................31
Installation Notes ....................................................................................................31
Wayne Dispensing Systems ...........................................................................................34
TLS Console Software Requirements ....................................................................34
Veeder-Root Hardware Requirements ...................................................................34
POS System Requirements and Limitations ..........................................................34
Supported Wayne Systems ....................................................................................34
Supported Wayne POS Terminals .........................................................................34
Installation Notes ....................................................................................................35
Schlumberger POS Systems ..........................................................................................37
TLS Console Software Requirements ....................................................................37
Veeder-Root Hardware Requirements (Ref. Table 2) ............................................37
System Limitations .................................................................................................37
MicroMax/Allied Hardware Requirements ..............................................................37
Installation Notes ....................................................................................................37
GasBoy CFN Systems ....................................................................................................40
TLS Console Software Requirements ....................................................................40
Veeder-Root Hardware Requirements (Ref. Table 2) ............................................40
GasBoy System Requirements for BIR Interface ..................................................40
Connecting to the Site Controller II.........................................................................40
BIR Protocol DIM ............................................................................................................42
POS System Requirements and Limitations ..........................................................42
Mechanical Dispensers ...................................................................................................43
TLS-350 MDIM Applications...................................................................................43
TLS-450/TLS-450PLUS MDIM Applications...........................................................43
LVDIM Applications ........................................................................................................48
PetroVend System 2 Controller..............................................................................48
Kraus Micon 200 Electronic Dispensers.................................................................50
Wiring to GasBoy 9800 or Tokheim 2600 Series Electronic Dispensers................52
Figures
Figure 1. Simplified DIM Connections To Various Dispensing Systems ..............15
Figure 2. Bennett Pump Fuelomat Dispenser Interface Installation Diagram..........17
Figure 3. Transac Series Current Loop Interface .................................................19
Figure 4. Excentus Current Loop Interface ..........................................................20
Figure 5. Universal Distribution Box Interface ......................................................22
Figure 6. Example G-Site Installations .................................................................24
Figure 7. AutoGas 510 CRIND Controller With Current Loop Interface ...............26
Figure 8. AutoGas 510 CRIND Controller With Serial Interface ..........................27
Figure 9. AutoGas 510 CRIND Controller ............................................................28

Table of Contents
v
Figure 10. AutoGas 507 CRIND Controller ............................................................29
Figure 11. SmartCrind Installation .........................................................................30
Figure 12. Tokheim DHC Standalone Installation ..................................................32
Figure 13. Tokheim Vision 100/200 Installation .....................................................32
Figure 14. Tokheim Dispenser Controller With Single CAB Installation ................33
Figure 15. Wayne Dispenser Data Box Current Loop (TLS-350R and TLS-450)......35
Figure 16. Wayne IDPOS Dispensers (TLS-350R and TLS-450) ..........................35
Figure 17. Example CAB Connections In
Wayne Nucleus Data Box (TLS-350R Only) .........................................36
Figure 18. MicroMax POS W/Allied Station Site Controller Box
Current Loop Interface ..........................................................................37
Figure 19. MicroMax POS with Allied Protocol Box Current Loop Interface ..........38
Figure 20. Pro Series Or MicroMax POS With SAM Or XPIC Controller Box
And RS-232 CAB Interface ...................................................................38
Figure 21. MicroMax POS with Tokheim DCHC Controller Box and
RS-232 CAB Interface ..........................................................................39
Figure 22. Verifone With SAM And RS-232 CAB Interface ...................................39
Figure 23. Gasboy Console Loop Connection .......................................................41
Figure 24. Wiring Diagram Of TLS-350 MDIM Using Two 1871/7697 Series
Pulse Transmitters And Required Barriers ...........................................43
Figure 25. Wiring Diagram Of TLS-450/TLS-450PLUS MDIM Using
Two 1871/7697 Series Pulse Transmitters & Required Barriers..............44
Figure 26. Mechanical Dispenser Applications
Using 7874 Series Pulser/Totalizer ......................................................45
Figure 27. TLS-350 Meter Stand Application Using
1871/7697 Series Pulser/Totalizer ........................................................46
Figure 28. TLS-450/TLS-450PLUS Meter Stand Application Using
1871/7697 Series Pulser/Totalizer ........................................................47
Figure 29. TLS-350 LVDIM Installation With PetroVend
System 2 Site Controller .......................................................................48
Figure 30. TLS-450/TLS-450PLUS LVDIM Installation With
PetroVend System 2 Site Controller .....................................................49
Figure 31. TLS-350 LVDIM Installation Kraus Micon 200 Series
Electronic Dispensers (Not UL Approved) ............................................50
Figure 32. TLS-450/TLS-450PLUS LVDIM Installation
Kraus Micon 200 Series Electronic Dispensers (Not UL Approved) ........51
Figure 33. LVDIM Installation With GasBoy 9800 Or
Tokheim 2600 Series Electronic Dispenser Head ................................52
Figure 34. TLS-450/TLS-450PLUS LVDIM Installation With
GasBoy 9800 Or Tokheim 2600 Series Electronic Dispenser Head ........53
Tables
Table 1. Supported POS Systems ..........................................................................3
Table 2.- Dispenser DIM and Installation Kits ..........................................................7
Table 3. POS Systems Supporting BIR Protocol DIM ..........................................42

1
Introduction
This guide provides assistance in selecting Dispenser Interface Modules (DIMs) that enable a properly fitted TLS
Console to interface supported Point-of-Sale (POS) devices and provide enhanced product inventory and/or
product vapor recovery monitoring. Veeder-Root offers two console upgrades that interface with POS devices:
Business Inventory Reconciliation (BIR)
Business Inventory Reconciliation is a console option that automatically collects dispensing data, in-tank
inventories and deliveries, and reconciles the totals at the end of each shift, day, and month. When used with
AccuChart™, an automatic tank calibration feature, BIR enhances reconciliation accuracy by comparing the tank’s
metered sales data to the tank’s probe data.
IN-STATION DIAGNOSTICS (ISD) - TLS-350R CONSOLES ONLY
In-Station Diagnostics (ISD) is an option that enables the TLS-350R Console to continuously monitor the vapor
recovery equipment and Enhanced Vapor Recovery (EVR) systems at gasoline dispensing facilities, maintain test
records, provide test reports, and generate warnings or alarms following equipment failures.
TLS-350R BIR and ISD Capabilities
TLS-350R WITH BIR ONLY AND TLS-350R WITH BIR AND ISD
• Support up to 36 fueling positions
• Support up to 6 meters (hoses) per fueling position
• Support manifolded tanks
• Support blending dispensers that separately meter each product prior to blending. Gilbarco, Tokheim, and
Wayne electronic blending dispensers are supported.
• Do not support dispensers that blend fuel prior to the metering process. Schlumberger electronic blending dis-
pensers, and mechanical dispensers fitted with fixed-ratio ratios are not supported.
TLS-350R WITH ISD ONLY
• Supports up to 36 fueling positions
• Supports up to 6 meters (hoses) per fueling position
• Supports manifolded tanks
• Supports all blending dispensers in this guide, including those in this guide labeled as not to be used with BIR.
• Must monitor all petrol fueling positions.
• Does not monitor diesel fueling positions.
MANIFOLDED TANK APPLICATIONS FOR BIR
The TLS-350R can perform automatic BIR on tanks in a siphon-manifolded set. However, to perform AccuChart,
the following requirements must be met:
1. Maximum of 2 tanks in a set.
2. Maximum of 4 sets of siphon-manifolded tanks.
3. The combined tank capacity of a set shall not exceed 30,000 gallons.
4. The diameters of the tanks in a set shall not differ by more than 6 inches.
5. The manifolding method must be siphon, not line, manifolding.

POS App Guide Introduction
2
Reconciliation reports will be generated for the manifolded set as a single product. Individual adjusted delivery
reports will be provided followed by an adjusted manifolded delivery report.
Both Version 310 software (or later), and a Memory Expansion Module are required to perform BIR for manifolded
tanks.
TLS-350R System Requirements for BIR and ISD
BUSINESS INVENTORY RECONCILIATION
•TLS-350R with BIR option
•A Mag 1 (0.1 gph) magnetostrictive (standard or Mag Plus) probe is required for each tank that will be
monitored and reconciled. The Mag 1 probe for alternative fuels is also supported.
•ECPU board with the following software versions;
- w/106 [or later] software for BIR,
- w/311 [or later] software and a Memory Expansion Module for BIR with manifolded tanks, or
- w/116 or 316 [or later] software for BIR with variance analysis
•Dispenser Interface Module
For electronic dispensers, one DIM is required for each TLS-350R. Up to 3 DIMs can be installed to support
sites with multiple POS systems. For mechanical dispensers, the TLS-350R can support up to 8 mechanical
DIMs. Each mechanical DIM supports up to 4 mechanical dispensers.

One installation kit may be required for each DIM (ref. Table , “,” on page 7). The installation kits vary for each
DIM and include all required adapter boxes and cables.
IN-STATION DIAGNOSTICS
•TLS-350R with ISD option
•ECPU2 board with 325 or later software and a NVMEM203 board.
•A Mag 1 (0.1 gph) magnetostrictive (standard or Mag Plus) probe is required for each gasoline tank. The Mag 1
probe for alternative fuels is also supported.
•Dispenser Interface Module - For electronic dispensers, one DIM is required for each TLS-350R. Up to 3 DIMs
can be installed to support sites with multiple POS systems. For mechanical dispensers, the TLS-350R can
support up to 8 mechanical DIMs. Each mechanical DIM supports up to 4 mechanical dispensers.
•DIM installation kit - One installation kit may be required for each DIM (ref. Table , “,” on page 7). The installation
kits vary for each DIM and include all required adapter boxes and cables.
•Additional ISD monitoring equipment as defined by the site’s requirements, e.g., dispenser mounted Air Flow
Meters and Pressure Sensor, console Smart Sensor Modules, etc. - refer to appropriate ISD Installation Manual
for specifics.
TLS-450/TLS-450PLUS BIR Capabilities
•Support for up to 72 fueling positions
•Support for up to 6 meters (hoses) per fueling position
•Support for manifolded tanks
•Support for blending dispensers that separately meter each product prior to blending. Gilbarco, Tokheim, and
Wayne electronic blending dispensers are supported. Dispensers that blend fuel prior to the metering process,

POS App Guide Introduction
3
such as Schlumberger electronic blending dispensers and mechanical dispensers fitted with fixed-ratio blenders
are not supported.
MANIFOLDED TANK APPLICATIONS
•Maximum number of tanks in a set: unlimited
•Maximum number of siphon manifold tanks: number of tanks divided by 2. Limit: 8
•Manifolded set tank capacity: unlimited
•No requirements on diameter differences, no 6 inch limit.
Reconciliation reports will be generated for the manifolded set as a single product. Individual adjusted delivery
reports will be provided followed by an adjusted manifolded delivery report.
TLS-450/TLS-450PLUS SYSTEM REQUIREMENTS FOR BIR
The following components are required to perform BIR:
•TLS-450/TLS-450PLUS with BIR option
•Version 2.X or higher software (TLS-450), Version 6.X or higher software (TLS-450PLUS)
•Mag 1 (0.1 gph) magnetostrictive (standard or Mag Plus) probe in each tank. The Mag 1 probe for alternative
fuels is also supported.
•A Dispenser Interface Module (DIM) - The DIM allows the TLS-450 to interface to most Gilbarco, Wayne, and
3rd Party POS systems that implement the VR BIR Protocol (ALLIED ANDI, EXCENTUS, BENNETT). For
electronic dispensers, one DIM is required for each TLS-450. Up to 3 DIMs can be installed to support sites
with multiple POS systems.
•DIM installation kit - One installation kit may be required for each DIM (ref. Table , “,” on page 7). The installation
kits vary for each DIM and include all required adapter boxes and cables.
Supported POS Systems
The TLS-350R, TLS-450 and TLS-450PLUS consoles can interface to many POS terminals as well as the Veeder-
Root mechanical dispenser (TLS-350R only). This guide provides specific information on each application. The
supported POS systems are shown in Table 1.
Table 1. Supported POS Systems
Manufacturer POS/Dispensing System TLS-350R TLS-450 TLS-450PLUS
Gilbarco
TCRG, TCRG2, T-11, T-12, TS-1000, PAM,
G-Site, Passport, Storemaster, SmartCrind, ANDI,
CFN2, Excentus
X X X
Tokheim
MEMS IV, MEMS V, Vision 100/200, DHC with all
other POS, CFN2, ANDI, Columbus, Schlumberger
MicroMax XPIC/DHC, 67/A - 98, 67/B
X
Wayne
Wayne Site Controller, Excentus, ANDI X X X
IDPOS X X X
Schlumberger MicroMax/Pro series, MicroMax/Allied, SAM/XPIC,
ANDI X
GasBoy CFN2 & ProfitPoint, CFN1, ANDI X

POS App Guide Introduction
4
OTHER APPLICATIONS
Many POS / dispenser systems are similar to those identified in this guide. Veeder-Root is constantly evaluating
and supporting new applications. If your application is not listed in this guide, contact your Veeder-Root Sales
Representative.
Bennett 92D X
Mechanical, Mechanical
noncomp, or Mechanical
V-R meter
CFN2, Petrovend, ANDI X X X
Table 1. Supported POS Systems (Continued)
Manufacturer POS/Dispensing System TLS-350R TLS-450 TLS-450PLUS

5
DIM Descriptions
Mechanical Dispenser Interface Module (MDIM) & Low Voltage Dispenser Interface
Module (LVDIM)
•The mechanical dispenser interface modules enable the TLS console to monitor either high voltage (MDIM), or
low voltage (LVDIM) volume pulses and calculate dispensed volume.
•MDIM and LVDIM terminal connections are on the front of the modules’s bracket.
Electronic Dispenser Interface Module (EDIM)
•Installs in a communication slot of TLS-350R or TLS-450/TLS-450PLUS. EDIMs are used to communicate via
RS-232 to point of sale or system controllers.
•More than one EDIM can be installed in any combination with other DIM types.
•EDIMs have one 25-pin D connector (TLS-350R), or one 9-pin D connector (TLS-450/TLS-450PLUS) outside
of the port.
•TLS-350R EDIMs only - when onboard red LED is turned On, EDIM is transmitting to external device; when
onboard green LED is turned On, external device is transmitting to EDIM.
•TLS-450 and TLS-450PLUS hardware is standard equipment.
•TLS-450 requires BIR to activate DIM.
Current Loop Dispenser Interface Module (CDIM)
•TLS-350R console - Installs in comm slots 1, 2, or 3; TLS-450 console - installs in comm slots 1, 2, or 4
(preferred); TLS-450PLUS console - installs in comm slots 1 or 2. Factory installed in TLS4 console.
•TLS-450 and TLS-450PLUS require module kit P/N 330020-665.
•Various CDIM monitoring applications include current loop, RS-232, and RS-422.
•More than one CDIM can be installed in combination with other DIM types.
•CDIMs have three RJ-45 modular connectors (TLS-350R) or 2 to 3 RJ-45 modular connectors (TLS-450/TLS-
450PLUS).
•CDIMs cannot transmit to external device.
•Connects via 4-wire cable to cable adapter box. Adapter box converts target communication format to RS-422
format for CDIM. Adapter boxes are configured with 2-wire flying leads, 25-pin D or 9-Pin D, T-cable connectors
for various applications.
•TLS-450 requires BIR to activate DIM.
LAN Dispenser Interface Module (LDIM) - TLS-350R only
•Installs in a communication port of TLS-350R to communicate with or monitor POSs, dispensers or system
controllers using RS-485 communication standard.
•An LDIM can be installed in combination with other DIM types.
•LDIMs have a 5-wire phoenix connector.
•Red and green LEDs are on this board. When red LED is turned On, LDIM is transmitting to external device;
when green LED is turned On, external device is transmitting to LDIM.
•Can be used in 4-wire or 2-wire, RS-485 and RS-422 applications.
- DIP switch default in OPEN position, loopback jumper on LED side for RUN mode
- R1 - 331076-001 - RS-485 two wire

POS App Guide DIM Descriptions
6
- R2 - 331076-002 - RS-422 four wire
- R3 - 331076-003 - DIM RS-485 two wire (install in TLS-350R only)
- R4 - 331076-004 - DIM RS-422 four wire (install in TLS-350R only)
International Forecourt Standards Forum Dispenser Interface Module (IFSF) - TLS-
350R, TLS-450PLUS
•Required for TLS consoles that are connected to IFSF networks.
•Uses Echelon 2-wire FTT10-A medium, as defined by the IFSF standards.
•There are 3 LEDs on this board:
- Green LED On when IFSF board is transmitting information to the TLS.
- Red LED On when TLS is transmitting information to the IFSF board.
- Amber LED Off indicates normal state of the IFSF board processor.
•There are no LED indicators for network communication.
TCP/IP DIM Module (TDIM) - TLS-350R
•Installs in a communication port of the TLS-350R to communicate with or monitor the Wayne IDPOS dispenser.
•Minimum system requirements for TDIM Module operation:
- Console system software: Version 15 or higher - Version 21 or higher is recommended
- Network connection to a PC requires a hub. Connecting to a hub requires a straight CAT 5 cable
- Direct connection to a PC requires an Ethernet crossover cable
- Connection to a LAN or WAN
•There are 2 LEDs on the PC board of this module:
- Green LED indicates that the TDIM module is transmitting information to the TLS.
- Red LED indicates the TLS is transmitting information to the TDIM module.
•There is no communication alarm for this module.
TCP/IP DIM (TDIM) - TLS-450/TLS-450PLUS
•Installs in a communication port of the TLS-450/TLS-450PLUS to communicate with or monitor the Wayne
IDPOS dispenser.
•Minimum system requirements for TDIM module operation:
- Console system software: Version 4H or higher
- Network connection to a PC requires a hub. Connecting to a hub requires a straight CAT 5 cable
- Direct connection to a PC requires an Ethernet crossover cable
- Connection to a LAN or WAN
•There is no communication alarm for this module.
•TLS-450 and TLS-450PLUS hardware is standard equipment.
•TLS-450 requires BIR to activate DIM.

POS App Guide DIM Descriptions
7
DIM And Installation Kit Ordering Guide
Table 2.- Dispenser DIM and Installation Kits
Dispenser
Dispenser
Controller/
POS Type
TLS-350R
DIM P/N
w/Console
TLS-450
DIM P/N
w/Console
TLS-450PLUS
DIM P/N
w/Console
DIM Install Kit
P/N
Console
Compati-
bility
Notes
TLS-350R TLS-450 TLS-450PLUS
Bennett 92D 330404-040 None 848705-XXX Y N N
For Bennett 92D con-
trollers. DIM kit has 2
CABs in it. One CAB is
needed per current
loop. Only one or two
dispensers are on one
current loop.
Gasboy
CFN2 &
Profit Point 331001-003 None 331088-XXX Y N N
A Gasboy site control-
ler version 2.0 or later
is required. A Gasboy
junction box Gasboy
part # C05020 should
be ordered for installa-
tion. No Blending. Net-
work POS Required.
ANDI,
ALLIED
ANDI,
ALLIED
NEXTGEN
330280-001 Standard In Gauge None
required Y Y Y
Allied ANDI. Gilbarco
dispenser with T-14
(Australia). PEC with
8850. POSTEC with
RCC. Wayne with Mar-
keter 2000 (Sweden).
CFN1 331001-002 None 331088-XXX Y N N
This is a TLS-350 RS-
422 interface to the
Network. NOT to be
used for BIR or ISD
applications.
Radiant 330280-001 Standard In Gauge None
required Y Y Y
Radiant Systems
Series P1550 set-up
on the TLS must have
a DIM string pro-
grammed in. The DIM
string is B9DNHG and
needs to be pro-
grammed in DIM Diag-
nostics. You will need
to use a twisted pair
RJ-11 cable to the port
on the POS with the
pin outs of 2,3,7.

POS App Guide DIM Descriptions
8
Gilbarco
TCRG
330404-020 330020-665 848702-XXX
Y Y Y Model TCRG
PA0180-121
TCRG2 Y Y Y Model TCRG2
PA0180-121
T-11 Y Y Y
Model T-11 PA0132-
XXXX and PA0141-
XXXX
T-12 Y Y Y Model T-12 PA0188-
XXXX
Excentus Y Y Y
Excentus Dispenser
Tank Monitor Interface
Kit (Excentus P/N 080-
Veeder Root Kit) is
required.
TS-1000
330404-020 330020-665 848722-XXX
Y Y Y One kit is needed per
dispenser current loop.
For controller with a
RS-485 Distribution
Box, use kit P/N
848741-XXX.
PAM Y Y Y
G-Site
330280-401 Standard In Gauge 331063-XXX
Y Y Y
To support this DIM
and the TLS-350R, the
G-site must be
upgraded to include
the EMC interface.
Uses Controller types
C2, C15, 486 and Pen-
tium Site controllers.
Passport,
Passport/
EDH
Y Y Y
Verify BIR protocol is in
version of Passport
software used at cus-
tomer’s site.
Storemas-
ter 330404-020 330020-665 848741-XXX Y Y Y
One Gilbarco Dis-
penser Distribution Box
PA0133000 should be
available. Up to 12
Highliner/MPD Fueling
positions are sup-
ported. An Autogas
Storemaster POS and
Autogas 507 controller
are required.
Table 2.- Dispenser DIM and Installation Kits
Dispenser
Dispenser
Controller/
POS Type
TLS-350R
DIM P/N
w/Console
TLS-450
DIM P/N
w/Console
TLS-450PLUS
DIM P/N
w/Console
DIM Install Kit
P/N
Console
Compati-
bility
Notes
TLS-350R TLS-450 TLS-450PLUS

POS App Guide DIM Descriptions
9
Gilbarco
(Cont’d.)
Smart-
Crind 330020-538
Standard In Gauge
None
required Y Y Y
TCPIP Interface for Gil-
barco SmartCrind dis-
pensers only. Wal-Mart
is currently the only
customer ordering this
interface for this dis-
penser.
ANDI,
ALLIED
ANDI,
ALLIED
NEXTGEN
330280-001 None
required Y Y Y
Allied ANDI. Gilbarco
dispensers with T-14
(Australia). PEC with
8850. POSTEC with
RCC. Wayne with Mar-
keter 2000 (Sweden)
CFN2 331001-003 None 331088-XXX Y N N
A Gasboy site control-
ler version 2.0 or later
is required. A Gasboy
junction box Gasboy
part # C05020 should
be ordered for installa-
tion. Single product
dispensers only. No
Blending.
Wayne
Nucleus 330404-200 330020-665 848722-XXX Y Y Y
Wayne Nucleus POS
with Gilbarco Dispens-
ers.
Radiant 330280-001
Standard In Gauge
None Y Y Y
Radiant Systems
Series P1550 set-up
on the TLS must have
a DIM string pro-
grammed in. The DIM
string is B9DNHG and
needs to be pro-
grammed in DIM Diag-
nostics. You will need
to use a twisted pair
RJ-11 cable to the port
on the POS with the
pin outs of 2,3,7.
Verifone
Com-
mander
330280-001 None Y Y Y
Requires Verifone
13652-01 Connec-
tor(450) or Verifone
13581-01 Connector
(350) & V/R 331134-
xxx cable.
Wayne
Fusion 330280-001 None None Y N N
Table 2.- Dispenser DIM and Installation Kits
Dispenser
Dispenser
Controller/
POS Type
TLS-350R
DIM P/N
w/Console
TLS-450
DIM P/N
w/Console
TLS-450PLUS
DIM P/N
w/Console
DIM Install Kit
P/N
Console
Compati-
bility
Notes
TLS-350R TLS-450 TLS-450PLUS

POS App Guide DIM Descriptions
10
Mechanical CFN2 331001-003 None 331088-XXX Y Y Y
A Gasboy site control-
ler version 2.0 or later
is required. A Gasboy
junction box Gasboy
part # C05020 should
be ordered for installa-
tion. Single product
dispensers only. No
Blending. Network
POS required.
Mechanical
Mechanical
non-comp, or
Mechanical
V-R meter
Petrovend 331214-001 330020-800 None Y Y Y
One or more pulser/
totalizer kits are
needed PN 787491-
003. Each mech DIM
supports up to 4 mech
dispensers. Up to 8
may be installed in the
high power compart-
ment of the TLS-350R.
Other modules
installed will reduce the
number of slots avail-
able.
Table 2.- Dispenser DIM and Installation Kits
Dispenser
Dispenser
Controller/
POS Type
TLS-350R
DIM P/N
w/Console
TLS-450
DIM P/N
w/Console
TLS-450PLUS
DIM P/N
w/Console
DIM Install Kit
P/N
Console
Compati-
bility
Notes
TLS-350R TLS-450 TLS-450PLUS

POS App Guide DIM Descriptions
11
Mechanical
None 331214-001 330020-800 None Y Y Y
One or more pulser/
totalizer kits are
needed PN 787491-
003. Each mech DIM
supports up to 4 mech
dispensers. Up to 8
may be installed in the
high power compart-
ment of the TLS-350R.
Other modules
installed will reduce the
number of slots avail-
able.
ANDI 330280-001 Standard In Gauge None Y Y Y
Allied ANDI. Gilbarco
dispensers with T-14
(Australia). PEC with
8850.POSTEC with
RCC. Wayne with Mar-
keter 2000 (Sweden).
Radiant 330280-001 Standard In Gauge None Y Y Y
Radiant Systems
Series P1550 set-up
on the TLS must have
a DIM string pro-
grammed in. The DIM
string is B9DNHG and
needs to be pro-
grammed in DIM Diag-
nostics. You will need
to use a twisted pair
RJ-11 cable to the port
on the POS with the
pin outs of 2,3,7.
Table 2.- Dispenser DIM and Installation Kits
Dispenser
Dispenser
Controller/
POS Type
TLS-350R
DIM P/N
w/Console
TLS-450
DIM P/N
w/Console
TLS-450PLUS
DIM P/N
w/Console
DIM Install Kit
P/N
Console
Compati-
bility
Notes
TLS-350R TLS-450 TLS-450PLUS

POS App Guide DIM Descriptions
12
Schlum-
berger
ANDI,
ALLIED
ANDI,
ALLIED
NEXTGEN
330280-001 Standard In Gauge None Y Y Y
Allied ANDI. Gilbarco
with T-14 (Australia).
PEC with 8850. POS-
TEC with RCC. Wayne
with Marketer 2000
(Sweden).
Radiant 330280-001 Standard In Gauge None Y Y Y
Radiant Systems
Series P1550 set-up
on the TLS must have
a DIM string pro-
grammed in. The DIM
string is B9DNHG and
needs to be pro-
grammed in DIM Diag-
nostics. You will need
to use a twisted pair
RJ-11 cable to the port
on the POS with the
pin outs of 2,3,7.
Table 2.- Dispenser DIM and Installation Kits
Dispenser
Dispenser
Controller/
POS Type
TLS-350R
DIM P/N
w/Console
TLS-450
DIM P/N
w/Console
TLS-450PLUS
DIM P/N
w/Console
DIM Install Kit
P/N
Console
Compati-
bility
Notes
TLS-350R TLS-450 TLS-450PLUS

POS App Guide DIM Descriptions
13
Tokheim
MEMS IV,
MEMS V,
Vision 100/
200,
DHC with
all other
POS
330280-201 None 331390-XXX Y N N
Use 331354-001 for
67A/B or 98 instead.
This DIM is being
phased out. A Tokheim
Dedicated Hose Con-
troller (DHC) is
required, and should
have software version
5.6 dated 11/89 or
later.
CFN2 331001-003 None 331088-XXX Y N N
A Gasboy site control-
ler version 2.0 or later
is required. A Gasboy
junction box Gasboy
part # C05020 should
be ordered for installa-
tion. Single product
dispensers only. No
Blending1
ANDI,
ALLIED
ANDI,
ALLIED
NEXTGEN
330280-001 Standard In Gauge None Y Y Y
Allied ANDI. Gilbarco
dispenser with T-14
(Australia). PEC with
8850. POSTEC with
RCC. Wayne with Mar-
keter 2000 (Sweden).
67/A - 98
331354-001 None
331391-XXX
Y N N Tokheim controller
only.
67/B 848744-XXX
Columbus 330280-001 Standard in Gauge None Y Y Y
For Rockport cable kits
order Quantity (2)
320449-18 from
Tokheim. For Digi/Star-
gate order Quantity (2)
320449-9 Cable kits
from Tokheim.
Radiant 330280-001 Standard in Gauge None Y Y Y
Radiant Systems
Series P1550 set-up
on the TLS must have
a DIM string pro-
grammed in. The DIM
string is B9DNHG and
needs to be pro-
grammed in DIM Diag-
nostics. You will need
to use a twisted pair
RJ-11 cable to the port
on the POS with the
pin outs of 2,3,7.
Table 2.- Dispenser DIM and Installation Kits
Dispenser
Dispenser
Controller/
POS Type
TLS-350R
DIM P/N
w/Console
TLS-450
DIM P/N
w/Console
TLS-450PLUS
DIM P/N
w/Console
DIM Install Kit
P/N
Console
Compati-
bility
Notes
TLS-350R TLS-450 TLS-450PLUS

POS App Guide DIM Descriptions
14
Wayne
Wayne Site
Controller 330404-010 330020-665 848703-XXX Y Y Y
A Wayne site controller
and Wayne dispens-
ers are required. Any
POS may be con-
nected to the Wayne
site controller.
ANDI,
ALLIED
ANDI,
ALLIED
NEXTGEN
330280-001 Standard in Gauge None Y Y Y
Allied ANDI. Gilbarco
dispenser with T-14
(Australia). PEC with
8850. POSTEC with
RCC. Wayne with Mar-
keter 2000 (Sweden).
Excentus 330404-010 330020-665 848702-XXX Y Y Y
Excentus Dispenser
Tank Monitor Interface
Kit (Excentus P/N 080-
Veeder Root Kit) is
required.
IDPOS 330020-501 Standard in Gauge None Y Y Y
TCPIP interface for
Wayne IDPOS dis-
pensers only
Radiant 330280-001 Standard in Gauge None Y Y Y
Radiant Systems
Series P1550 set-up
on the TLS must have
a DIM string pro-
grammed in. The DIM
string is B9DNHG and
needs to be pro-
grammed in DIM Diag-
nostics. You will need
to use a twisted pair
RJ-11 cable to the port
on the POS with the
pin outs of 2,3,7.
Verifone
Com-
mander
330280-001 None None Y N N
Wayne
Fusion 330280-001 None None Y N N
1This restriction does not apply to ISD only installations.
Table 2.- Dispenser DIM and Installation Kits
Dispenser
Dispenser
Controller/
POS Type
TLS-350R
DIM P/N
w/Console
TLS-450
DIM P/N
w/Console
TLS-450PLUS
DIM P/N
w/Console
DIM Install Kit
P/N
Console
Compati-
bility
Notes
TLS-350R TLS-450 TLS-450PLUS

15
DIM Installation Examples
Various example DIM installation diagrams are shown in Figure 1 below for reference only. For specific DIM
installation details, refer to the appropriate Veeder-Root DIM installation manual.
Figure 1. Simplified DIM Connections To Various Dispensing Systems
Mechanical
Dispenser
Dispenser
Controller
Network
Junction
Box
Distribution Box
Cable Adaptor
Box
CDIM
LVDIM
MDIM
EDIM
LDIM, IFSF,
& TDIM
Dispenser
Dispenser
Electronic
or
Mechanical
Dispenser
Comm Bay
installed DIMs
TLS-350 Power Bay installed DIMs
TLS-450 Model Bay installed DIMs
Barrier
401-6.eps
TLSConsole
(TLS-350 only)
