VeGue VS-0808 User manual

VS-0808
Please read the user manual carefully before using the machine

1. Please use original charging cord for charging. The charging voltage requires 90V to 240V.
2. Do not use the machine while charging. Do not keep charging for a long time, especially no one
at home, you should plug off the power adapter and turn off the machine first, or it will cause
leakage of electricity, even a fire to make a big loss.
3. The charging cord cannot be squeezed, pulled, bent, knotted, hung heavy objects, or tampled to
prevent the insulaion layer of the cord from big damaged and causing electric shock.
4.To reduce the risk of fire or electric shock, do not expose the machine to rain or moisture. Do not
place objects filled with liquids, such as vases, on the machine.
5. The device is equipped with batteries, so do not expose it to the scorching sun for a long time.
not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers)that produce heat.
6. Do not block the heat radiation holes, otherwise, it will cause poor heat dissipation of the
machine and affect the service life of the machine.
7. When encourtering any issues with the battery or charging, do not disassemble the machine to
change the battery even though you are the experienced, please contact our customer service for a
replacement.
Important Safety Warning
To ensure personal security and property, please keep in mind the points as below

Package List -------------------------------------------------------------------- 1
Charging Instructions ------------------------------------------------------- 2
Technical Specifications --------------------------------------------------- 3
Description of Remote Control ------------------------------------------- 4
Description of Panel Function ------------------------------------------- 5
Main Features Instructions ------------------------------------------------ 6
Microphone Instructions --------------------------------------------------- 7
Trouble Shooting ------------------------------------------------------------- 8
Warranty ------------------------------------------------------------------------- 9
Contents

Package List
Karaoke Machine*1
Wireless Microphone*2 (Each requires 2 AA batteries, not included)
Remote Control*1 (Requires 2 AAA batteries, not included)
Charging Cord*1
3.5mm Audio Cable*1
3.5mm to RCA Cable*1
User Manual*1
Please use the charging cord included for charging.
The charging time is generally 5 to 8 hours. After fully charged, please plug off
the cord, or over charging will damage the battery.
There is an icon on the screen to show battery power. When in low power, the
icon will keep flashing until it is out of power. At this moment, please charge the
machine asap.
Note:
To prolong the battery life, there are 4 points as below you need to know.
1. If the machine is out of power, please charge it within 48 hours.
2. Do not use the machine while charging.
3. After fully charged, plug off the charging cord asap. It is very important to protect
your battery, safety and property.
4. The machine must be kept with enough power anytime. The battery life will be
reduced, if you seldom use the machine or don't use it for a long time, and keep it
without any power.
VS-1088
Charging Instructions

Technical Specifications
Karaoke Machine
Model: VS-0808
Peak Power: 250W
Sensitivity: 500±30mV
S/N Ratio: ≥65dB
Requency Response: 26Hz~18kHz
Input Voltage: DC 15V
Microphone
Requency: 261.5-268.5M
Operating Distance: 98FT（without any interference）
S/N Ratio: ＞98dB
T.H.D.: ＜0.5%
Microphone Input Sensitivity: 74DB SPL@1KHz
RF Sensitivity: 5dB UV
Working Temperature: -15~85℃

Description of Remote Control
VS-0808
Repeat
Repeat song in USB or
TFcard
Mute
Mute audio
Numberic Keypad
Select songs in USB
or TFcard
INPUT
Switch between Line
and Bluetooth mode
NEXT
Light Control
Turn on/off
the LED lights
Previous
Go to previous
song or FM channel
Volume Up
Increase the volume
Volume Down
Decrease the volume
Play/Pause
Play or pause the music
Recording
Rcord your voice
and the music
EQ
Choose from 5
EQ modes
REP
Repeat song in USB or TF card
Go to next song
or FM channel

Description of Panel Function
1. TF Card Slot
2. Bass Control (for music only)
3. USB Port
4. Treble Control (for music only)
5. Audio Output
6. Audio Input
7. Mic Volume Control
8. Musical Instrument Input (for most electronic musical instrument: piano/electronic guitar/
electronic piano/electronic drum and so on)
9. Echo Control (for mic only)
10. The 1st Wired Mic Input
11. Musical Instrument Volume Control
12. The 2nd Wired Mic Input
13. Recording/Recording Playback

VS-0808
14. Previous Song or FM Channel
15. Play/Pause
16. Next Song or FM Channel
17. Mode Switch
18. Light Control
19. Microphone Priority
20. Repeat Songs
21. Main Volume Control
22. LED Digital Display
1 2 43
Risk of electric shock do not open.
It is a normal phenomenon that the machine is
heated during operation hot surface do not touch.
WARNING
1. Power Button
2. Charging Port
3. Light Button
4. External 12V DC Input (for storage battery)

Main Features Instructions
Bluetooth Mode
Press "M" till the screen shows "BLUE". Turn on Bluetooth of your device and start to
search. Then click the named "VS-0808" to pair. If it fails to pair, please reboot the
machine or your device, and try it again. The working range for bluetooth is 32FT
without any interference.
Note: The machine does not have a screen to show lyrics. Just connect the speaker to
an ipad/computer/tv/phone and follow along with the lyrics on your ipad/computer/tv/
phone while the sound plays through the speaker.
Line Mode
Press "M" till the screen shows "LINE". Then you can connect to your phone via
3.5mm audio cable or a TV via 3.5mm to RCA cable. This mode is mainly used for
those devices that don't have Bluetooth. Besides, you can plug into a USB/TF card to
record your voice or play the music in this mode.
Recording
Switch the mode to "LINE", plug into a USB/TF card and press "REC" to start recording.
When first recording, a file folder named with "RECORD" is created in the card. All your
recording files will be named with REC0001,REC0002,REC0003 in order and saved in
this folder.
Note:
1. Recording is only available under "LINE" mode, so Bluetooth will not work while
recording.
2. The machine only accepts the music with MP3, WAV and WMV formats.
3. The type of USB or TF card must be FAT and the largest capacity is no more than
32GB.
4. Both USB and TF card cannot be plugged into simultaneously.

VS-0808
Microphone Instructions
A. Digital Display
B. Power Button
C. Tail Tube
Battery Installation
1. Unscrew the tail tube(C) of mic.
2. Put 2 AA batteries(not included) into "C".
Please make sure batteries are put in a correct
way(both positive and negative poles).
3. Slide the power button(B) to turn on the mic.
Microphone Instructions
Microphone Priority
When playing music and singing into the mic, the music goes mute and you can
only hear vocal with mic. In this case, press the 'MIC PRIORITY' button if you'd
like sing along with music, otherwise music stops when you use the mic.

Trouble Shooting
We hope all your problems will be solved here! If the issue is still the same
through the trouble shooting, please feel free to contact our customer service.
There is no sound
from microphone 1. Battery is under lower power.
2. Microphone fails to pair with
the machine.
Problem Possible Cause Solution
1. Battery is under lower power.
2. Forgot to adjust the volume. 1. Try the fresh batteries.
2. Turn up the volume(both panel
and remote).
Hissing sound
from the mic or
the machine
1. Volume is too high.
2. The mic is too close to the
machine.
1. Turn down the volume(both
panel and remote).
2. Have the mic get far away from
the machine, especially not aim
the top the mic to the machine.
The mic or the
machine sounds so
staticy and muffled
The static noise is due to different
reasons. Hope you contact our
customser service and we will
offer you the best solution.
When recording,
the Bluetooth fails
to connect
Recording is only available under
"LINE" mode, so Bluetooth will
not work while recording.
-
-
Bluetooth
stopped working 1. Signal is bad or lose
2. Bluetooth has been
connected by other device.
1. Reboot both the machine and
your device.

2. To get the better signal here.
3. The machine only connects to
one device once. You need to
delete the old device from Bluetooth
and pair with the new one.
If you encounter any other problems, like parts missing or broken, not the new
product and so on, please feel free to contact our customer service for a replacement.
The volume of
the mic or the
machine is low
Try the fresh batteries.

Warranty

VeGue provides 2 years of after-sales service,free replacement to products
that are NOT damaged resulting from accident, alteration, misuse,
negligence, or abuse. If exceeding 30 days of Amazon return policy, you
can still contact us through the email. We will serve you with full sincerity!
Email: [email protected]
