VeGue VS-1088 User manual

VS-1088
Please read the user manual carefully before using the machine

1. Please use original power adapter for charging. The charging voltage requires 90V to 240V.
2. Do not use the machine while charging. Do not keep charging for a long time, especially no one
at home, you should plug off the power adapter and turn off the machine first, or it will cause
leakage of electricity, even a fire to make a big loss.
3. The power adapter cannot be squeezed, pulled, bent, knotted, hung heavy objects, or tampled to
prevent the insulaion layer of the power adapter from big damaged and causing electric shock.
4.To reduce the risk of fire or electric shock, do not expose the machine to rain or moisture. Do not
place objects filled with liquids, such as vases, on the machine.
5. The device is equipped with batteries, so do not expose it to the scorching sun for a long time.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers)that produce heat.
6. Do not block the heat radiation holes, otherwise, it will cause poor heat dissipation of the
machine and affect the service life of the machine.
7. When encourtering any issues with the battery or charging, do not disassemble the machine to
change the battery even though you are the experienced, please contact our customer service for a
replacement.
Important Safety Warning
To ensure personal security and property, please keep in mind the points as below

Package List -------------------------------------------------------------------- 1
Charging Instructions ------------------------------------------------------- 1
Technical Specifications --------------------------------------------------- 2
Description of Remote Control ------------------------------------------- 3
Description of Panel Function ------------------------------------------- 4
Main Features Instructions ------------------------------------------------ 5
Microphone Instructions --------------------------------------------------- 7
Trouble Shooting ------------------------------------------------------------- 8
Warranty ------------------------------------------------------------------------- 9
Contents
-6

Package List
Karaoke Machine*1
Wireless Microphone*2 (Each requires 2 AA batteries, not included)
Remote Control*1 (Requires 2 AAA batteries, not included)
Power Adapter*1
Phone/Tablet Holder*1
Microphone Holder*3
3.5mm to RCA Cable*1
12V External Charging Cord*1
User Manual*1
Charging Instructions
Please use the power adapter included for charging.
The charging time is generally 5 to 8 hours. After fully charged, please plug off
the power adapter, or over charging will damage the battery.
There is an icon on the screen to show battery power. When in low power, the
icon will keep flashing until it is out of power. At this moment, please charge the
machine asap.
When charging, the power indicator will show red and keep solid. After fully
charged, it will turn to blue.
Note:
To prolong the battery life, there are 4 points as below you need to know.
1. If the machine is out of power, please charge it within 48 hours.
2. Do not use the machine while charging.
3. After fully charged, plug off the power adapter asap. It is very important to protect
your battery, safety and property.
4. The machine must be kept with enough power anytime. The battery life will be
reduced, if you seldom use the machine or don't use it for a long time, and keep it
without any power.
VS-1088

Technical Specifications
Karaoke Machine
Model: VS-1088
Peak Power: 200W
Sensitivity: 500±30mV
S/N Ratio: ≥70dB
Requency Response: 50Hz~20kHz
Input Voltage: DC 15V
Adapter: 15V/2.4A
Microphone
Requency Response: 40Hz~18kHz
Operating Distance: 98FT（without any interference）
S/N Ratio: ＞80dB
T.H.D.: ＜0.5%
Microphone Input Sensitivity: -50dB
RF Sensitivity: ＞12dBu (S/N=20dB)
Working Temperature: -10~50℃

Description of Remote Control
VS-1088
Power
Turn on/off the
machine
Mode
Switch between Bluetoothe,
Line and FM mode
Numberic Keypad
Select songs in USB
or TFcard
EQ Mute
Mute the audio
Choose from 5 EQ modes
Repeat song in USB or
TF card
REP
Decrease the volume
Volume Down Volume Up
Increase the volume
Previous
Go to previous
song or FM channel
NEXT
Go to next song
or FM channel
SCAN
Select one of the
saved channels
Play or pause the music
Play/Pause

Description of Panel Function
1. LED Digital Display
2. Main Features (Line/Bluetooth/FM
mode switch, Record, TWS, etc.)
3. USB or TF Card Slot
4. Mic Volume Control
5. 3.5mm Audio Input
6. Treble Control (for music only)
7. Bass Control (for music only)
8. Musical Instrument Volume Control
9. Main Volume Control
10. Echo Control (for mic only)
11. Charging Indicator
12. Wired Mic Input
13. Musical Instrument Input (for most electronic musical instrument: piano/electronic
guitar/electronic piano/electronic drum and so on)
14. 15V DC Input (for power adapter)
15. External 12V DC Input (for storage battery)
16. LED Light Button
17. Power Button

VS-1088
Main Features Instructions
Bluetooth Mode
Press "MODE" till the screen shows "BLUE". Turn on Bluetooth of your device and start
to search. Then click the named "VS-1088" to pair. If it fails to pair, please reboot the
machine or your device, and try it again. The working range for bluetooth is 32FT
without any interference.
Note: The machine does not have a screen to show lyrics. Just connect the speaker to
an ipad/computer/tv/phone and follow along with the lyrics on your ipad/computer/tv/
phone while the sound plays through the speaker.
Line Mode
Press "MODE" till the screen shows "LINE". Then you can connect to your phone via
3.5mm audio cable(not included) or a TV via 3.5mm to RCA cable. This mode is mainly
used for those devices that don't have Bluetooth. Besides, you can plug into a USB/TF
card to record your voice or play the music in this mode.
Recording
Switch the mode to "LINE", plug into a USB/TF card and press "REC" to start recording.
When first recording, a file folder named with "RECORD" is created in the card. All your
recording files will be named with REC0001,REC0002,REC0003 in order and saved in
this folder.
Note:
1. Recording is only available under "LINE" mode, so Bluetooth will not work while
recording.
2. The machine only accepts the music with MP3, WAV and WMV formats.
3. The type of USB or TF card must be FAT and the largest capacity is no more than
32GB.
4. Both USB and TF card cannot be plugged into simultaneously.

FM Mode
Press "MODE" till the screen shows "87.5". Hold "SCAN" button and the machine will
automatically search the channel from CH1 to CH6. When finished, press |◄◄ or ►►|to
chooset the channel you want.
Note: It is very helpful to receive FM when the signal here is very good.
TWS Feature
It is only used for having 2 VS-1088 karaoke machines.
How to use:
1. Turn on the Bluetooth of both machines.
2. Connect one of machines with your phone via Bluetooth.
3. When connection is finished, hold "TWS" button till both machines
work as stereo.

VS-1088
Microphone Instructions
A. Digital Display
B. Power Button
C. Tail Tube
D. Setting Button
Battery Installation
1. Unscrew the tail tube(C) of mic.
2. Put 2 AA batteries(not included) into "C".
Please make sure batteries are put in a correct
way(both positive and negative poles).
3. Hold the power button(B) to turn on the mic.
Operating Instructions
1. Each mic has 50 requencies/channels:
Mic A: CHA a-01~a-50
Mic B: CHB b-01~b-50
2. Both mics will automatically pair with the
machine when power is on.
3. If it fails to pair, press setting button(D) to
adjust any requencies till it works.
4. Please make sure both mics are in the
different group:one shows CHA and other one
shows CHB. If they are in the same groups,
turn off one of mics first, then hold both power
button and setting button to switch the group.
Microphone Instructions

Trouble Shooting
We hope all your problems will be solved here! If the issue is still the same
through the trouble shooting, please feel free to contact our customer service.
Problem Possible Cause Solution
There is no sound
from mic
1. Battery is under lower power.
2. Both mics are in the different
gourps.
3. Mic fails to pair with the
machine.
1. Try the fresh batteries.
2. Turn off one of mics, then hold
both power button and setting
button to switch the group.
3. Press setting button to adjust
the channels
The volume of
the mic or the
machine is low 1. Battery is under lower power.
2. Forgot to adjust the volume. 1. Try the fresh batteries.
2. Turn up the volume(both panel
and remote).
Hissing sound
from the mic or
the machine
1. Volume is too high.
2. The mic is too close to the
machine.
1. Turn down the volume(both
panel and remote).
2. Have the mic get far away from
the machine, especially not aim
the top the mic to the machine.
The mic or the
machine sounds so
staticy and muffled
The static noise is due to different
reasons. Hope you contact our
customser service and we will
offer you the best solution.
When recording,
the Bluetooth fails
to connect
Recording is only available under
"LINE" mode, so Bluetooth will
not work while recording.
-
-
Bluetooth
stopped working 1. Signal is bad or lose
2. Bluetooth has been
connected by other device.
1. Reboot both the machine and
your device.

2. To get the better signal here.
3. The machine only connects to
one device once. You need to
delete the old device from Bluetooth
and pair with the new one.
If you encounter any other problems, like parts missing or broken, not the new
product and so on, please feel free to contact our customer service for a replacement.

Warranty

VeGue provides 2 years of after-sales service,free replacement to products
that are NOT damaged resulting from accident, alteration, misuse,
negligence, or abuse. If exceeding 30 days of Amazon return policy, you
can still contact us through the email. We will serve you with full sincerity!
Email: [email protected]
Web: https://www.vuigue.com/
