Vello Lens Adapter User manual

LENS
ADAPTER
MANUAL
FOR T MOUNT & M42

2
Thank you for choosing a Vello Lens Adapter. Vello Lens Adapters allow you to mount a
camera body to a telescope, spotting scope, microscope, or certain lenses. You must also have
an SLR camera adapter that fits your telescope. You’ll also need to minimize shutter release
vibrations that can cause blurring during the long exposures typical with these optics. Vello
makes a wide range of remotes and shutter release cables to control your shutter. Telescopes
and microscopes are not built to support heavy SLRs. Make certain your setup is secure. Please
follow the instructions below to mount and remove your Vello Lens Adapter.
Automatic diaphragm (AE metering), and other functions dependent on communication between the
camera body and lens, will be disrupted by a lens adapter. You must set exposures manually or meter in
aperture priority (stop-down) mode. If the lens does not have a manual aperture collar, the aperture will
be stopped to its smallest f/stop. Focusing to innity is retained.
INTRODUCTION
All images are for illustrative purposes only.

3
1. You must have an SLR camera adapter.
Screw the lens adapter onto the SLR
adapter.
2. Line up the alignment dots on the lens
adapter and camera. Rotate the assembly
until it locks.
TO MOUNT THE LENS ADAPTER

4
3. Remove the eyepiece from your telescope,
spotting scope, or microscope.
4. Mount the camera/adapter assemblies to
your optic device. Make certain the setup
is stable.

5
1. If you prefer, you can leave the lens
adapter attached to your SLR adapter.
Release the camera/adapter assemblies
from the telescope.
TO REMOVE THE LENS ADAPTER
5. If desired, you can re-align the lens to a
specific position. To re-align the lens, use a
2 mm flat-head screwdriver to loosen the
three screws on the lens mount. Rotate
the lens to the desired position, and
tighten the three screws.

6
2. Press the lens release on the camera,
rotate the adapter assembly to release and
remove.
3. Unscrew the SLR camera adapter from the
lens adapter. Replace all protective covers.
