VENCO VAX General instructions

INSTALLATION –OPERATION -
MAINTENANCE USER MANUAL
AXIAL FANS
VENCO Havalandırma ve Makina San.ve Tic. A.Ş.
2004. Cad. No:5 45400 OSB Turgutlu –MANİSA / TÜRKİYE
Tel: [phone] Fax: [phone]
www.venco.com.tr [e-mail]
2018.02

2018.02 1 / 10
INDEX
1. INTRODUCTION..................................................................................................................................... 1
2. GENERAL IDENTIFICATION OF DEVICE TYPE and MODEL ............................................................... 2
3. TECHNICAL DATA ................................................................................................................................. 2
4. TECHNICAL SPECIFICATIONS ............................................................................................................. 3
5. INSTALLATION....................................................................................................................................... 4
6. OPERATION........................................................................................................................................... 7
7. HANDLING & STORAGE........................................................................................................................ 7
8. MAINTENANCE...................................................................................................................................... 7
9. FAULT DETECTION ............................................................................................................................... 7
10. WARRANTY........................................................................................................................................ 8
11. ANNEX................................................................................................................................................ 9
11.1. Annex-1: Electrical Wiring Diagrams ................................................................................................ 9
1. INTRODUCTION
Before operating VENCO branded VAX and VAX-S Axial Type Fans, please examine carefully the
instruction manual and keep it. Do not use devices as a workbench or a storage area. VENCO VAX and VAX-
S Axial Type Fans can only be operated in conditions of intended design and technical specifications.
BEFORE OPERATING READ THIS MANUAL and KEEP IT IN REACH OF A SERVICE
PERSONNEL.
THIS FAN CAN ONLY BE OPERATED IN CONDITIONS OF INTENDED DESIGN AND
TECHNICAL SPECIFICATIONS. OTHERWISE THE RESPONSIBILITY BELONGS TO
INSTALLER.
DO NOT USE THIS FAN IN EXPLOSIVE and CORROSIVE ENVIRONMENT.
RESPONSIBILITY OF THE DEFECTS WHICH CAN BE OCCURED AS A RESULT OF
UNAUTHORIZED PERSONNEL INTERVENTION TO FAN or TO BE USED NON-
ORIGINAL SPARE PARTS BELONGS TO THE INSTALLER.

2018.02 2 / 10
2. GENERAL IDENTIFICATION OF DEVICE TYPE and MODEL
VENCO VAX Type Axial fans are used in general ventilation projects and VAX-S Type Axial fans are
used in smoke exhaust fan and carpark ventilation. The Axial fans may not be used in areas in which an
explosion-capable atmosphere can be found. The motor is found combined with the impeller in canals where
the air circulation actualized and the air flowing is actualized by the way of impeller. The fan cannot be
installed outside without water precaution.
3. TECHNICAL DATA
The type key can be seen on the name plate. For Axial fans, it contains the following data

2018.02 3 / 10
4. TECHNICAL SPECIFICATIONS
VENCO VAX Type Axial Fans;
•Full size from Ø 400 mm to Ø 1600 mm diameter
•Hot deep galvanized sheet metal casing
•Cast aluminum adjustable blade angle impellers
•Aerodynamic profile impellers allow high efficiency and low noise
•Die cast aluminum alloy fan hubs
•Optimum capacity obtained hub combinations besides adjustable blade combination
•IP 67 terminal box is carried out of the casing
•Electrical motors with IP 55 and F class insulation
•230 V, 1 phaze, 50 Hz and 380 V, 3 phase, 50 Hz
•Operating temperature between -15°C and 45°C
VENCO VAX-S Type Axial Fans;
•F300 certificate harmonized with EN12101-3
•Full size from Ø400 mm to Ø1600 mm diameter
•Hot deep galvanized sheet metal casing
•Just aluminum adjustable blade angle
•Aerodynamic profile impellers allow high efficiency and low noise
•Die cast aluminum alloy fan hubs
•Optimum capacity obtained hub and adjustable blade combinations
•IP 67 terminal box is on the fan casing
•Electrical motors with IP55
•230 V, 1 phase, 50 Hz and 400 V, 3 phase, 50 Hz
•Operating temperature 300°C for 2 hours

2018.02 4 / 10
5. INSTALLATION
The fan must be installed according to the air direction label on the fan. Before the start of assembly,
examine manually whether the fan wheel runs freely. Before installation, check the minimum air gap between
the blade tip and the housing according to the following table. During assembly, secure the assembly area.
Take precautions for any access by unauthorized persons. The fan should be installed in a way that makes
service and maintenance easy. A wiring diagram is applied on the inside of the junction box or separately
enclosed. Electrical installations must be made by trained and authorized electrician.
Drawing 5.1
Drawing 5.1 illustrates the MFT, MSC, NRD/XS and MFL accessories that could be used with the fan.
The connection of MFT Mounting Bracket, MSC Wire Guard and NRD/XS Vibration Absorber Mounting to
the fan must be done as shown in the following drawing by screw, rondela and nut.
Drawing 5.2

2018.02 5 / 10
The vertical and horizontal installation of the NRDO accessory that could beused with the fan onthe Drawing
5.1 is illustrated in the following drawing.
Drawing 5.4 Drawing 5.3
The vertical and horizontal installation of the NRDO accessory;
Drawing 5.3 demonstrates horizontal installation of the NRDO accessory to the axial fan. When there is no air
flow; position of the wing must be as shown in the Drawing 5.3 in order to keep the wings closed.
Drawing 5.4 demonstrates vertical installation of the NRDO accessory to the axial fan. When the connection is
made properly and there is no air flow, the wings close down.
Drawing 5.5

2018.02 6 / 10
Drawing 5.5 illustrates installation of the CAS- Vertical Autlet Roof Fans accessory and the MPT (Mounting
Plate) to the axial fan. Connection of them to the axial fan must be done as shown in the drawing by nut,
rondela and screw.
Fan Diameter
VAX
VAX-S
Min. (mm)
Max. (mm)
Min. (mm)
Max. (mm)
400
1
2
5,5
6,88
450
1,25
2,25
-
-
500
1,4
2,4
5,5
6,88
560
1,4
2,4
5,5
6,88
630
1,58
2,58
6
7,5
710
1,78
2,78
6
7,5
800
2
3
6,5
8,13
900
2,25
3,25
7
8,75
1000
2,5
3,5
8
10
1120
2,8
3,8
8,5
10,63
1250
3,13
4,13
10
12,5
1400
3,5
4,5
11
13,75
1600
4
5
12
15
ALL ELECTRICAL CONNECTIONS SHALL BE DONE ACCORDING TO EN 60204-1
BY TRAINNED AND AUTHORIZED PERSONNEL.
SWITCH THE ENERGY SUPPLY OFF BEFORE YOU BRING ABOUT THE
ELECTRICAL CONNECTION OF THE FAN. MAKE SURE THAT THE ENERGY
SUPPLY CANNOT BE SWITCHED ON AGAIN PREMATURELY. THE ELECTRICAL
CONNECTION MAY ONLY BE CARRIED OUT BY TRAINED PERSONNEL.
THE ELECTRICAL CONNECTION IS TO BE DONE ACCORDING TO VALID
DIRECTIVES AND ONLY BY A QUALIFIED FITTER WITH MATCHING SAFETY
DEVICES FOR THE PROTECTION OF THE MOTOR.
ALL COMPONENTS SHOULD BE EARTHED. DEVICE EARTH CONNECTION MUST
BE DONE ON TOP OF THE CONNECTOR IN JUNCTION BOX and FROM
GROUNDING SCREW WITHIN BODY.

2018.02 7 / 10
6. OPERATION
Before starting, check the followings; Be sure that foreign objects are removed from fan area and
connected duct system, check connection to the electrical installation, minimum air gap between the tip of the
blade and the housing and no noise appears when starting the fan. If the air gap is correct, switch the device
on and off briefly, in order to check the direction of rotation of the fan. The rotation direction of the fan must
match up with the direction of the arrow on the housing of the fan. If the direction of rotation is wrong,
interchange two phases in order to set the correct direction of rotation.
7. HANDLING & STORAGE
The fans are delivered on wooden pallets wrapped in plastic stretch. Transport the fan to the place of
assembly in its original packaging. During transport, connection cables, terminal box and wire connections
mustn’t be damaged. Load and unload the fan carefully, in order to avoid possible damage. Use suitable
lifting equipment. The fan should be stored in a safe, clean, dry, vibration free, location. A regular monthly
rapid spin of the impeller is recommended to prevent grease hardening and possible brinelling of the
bearings; the impeller should not be in the same angular position after rotation.
When dismantling the crate to gain access to the fan assembly care should be taken to avoid injury from
sharp edges, nails, staples, splinters, etc.
8. MAINTENANCE
Periodically check the screw connections, coil resistance, function of the safety components and control
elements. Only clean the fan manually, with a vacuum cleaner or with compressed air. Before service,
maintenance or repairing, disconnect the electrical connections and the impeller is stopped. The fan must be
cleaned when needed, at least once per year to maintain the capacity. The fan bearings are maintenance-
free and should be renewed only when necessary. Cleaning should be done without dislodging or damaging
the impeller. Make sure that there is no unexpected noise from the fan.
In addition to routine maintenance motor bearings will in the longer term require attention. If the motor
bearings are greased through extended lubricators, a quality of grease should be periodically applied in
accordance with the information on the fan or motor nameplate and/or instructions provided.
9. FAULT DETECTION
It is necessary to turn off the fan before checking the fan and the system. During maintenance, device
electrical connections should be cut entirely. All switches and circuit breakers should be locked by brought to
the OFF position. Also “DO NOT START” sign should be placed on the control panel that will consistently
stand.
Check that the electrical connections to the unit are secure. Check that the voltage applied at the fan
terminals is as specified on the motor nameplate, and is balanced. Measure the current on each phase (one
phase in the case of single-phase motors) of the motor in turn and check that the current consumption is
within the full load current specified on the motor nameplate.
Rotate the motor shaft by hand. Investigate any sound of grinding noises, internal chaffing, rubbing or
stiffness. Any observed defect may indicate that the bearings require lubrication or replacement. Ensure that
ALWAYS WEAR APPROPRIATE PROTECTIVE CLOTHING (INCLUDING HARD
HATS, EYE PROTECTORS AND EAR DEFENDERS) WHEN WORKİNG IN THE
VICINITY OF THE FAN ASSEMBLY

2018.02 8 / 10
all fixings are secure. Make sure that the fan blade is not blocked by an object, if fan is still not working,
contact your supplier.
10. WARRANTY
•The warranty period starts from the date of delivery and it is for 2 years.
•Including all parts of the entire fan is under warranty of our company.
•The maximum repairing period is 30 business days. This period starts from the date of
notification to us.
•Fan's warranty does not include electrical connection errors, failures that may arise due to
voltage and user errors.
•The warranty is only valid under condition that the fan is assembled, operated and periodic
maintenance to be made according to this manual.
11. ANNEX
11.1. Annex-1: Electrical Wiring Diagrams
11.1.1. Under 4 kW

2018.02 9 / 10
11.1.2. 4 kW and Above
11.1.3. Under 4 kW with Thermic

2018.02 10 / 10
11.1.4. 4 kW and Above with Thermic
