Ventamatic Maxx Air HVPF 30 User manual

Ventamatic, Ltd. P.O. Box 728, Mineral Wells, TX 76068-0728
1-800-433-1626 Fax: [phone] www.BVC.com
QTY Printed
SKU / Document #
©2018 VENTAMATIC, LTD. 2018 HVPF 30 & HVPF 30 OSC INSTRUCTIONS 0818/0000
2018 HVPF 30 & HVPF 30 OSC Instructions 0000
30-INCH PEDESTAL FAN
OPERATNG INSTRUCTIONS
High Velocity Air Movement from Ventamatic, Ltd.
Owner’s Manual
READ AND SAVE THESE
INSTRUCTIONS
For models HVPF 30 and HVPF 30 OSC
CAUTION: Read and follow all
instructions before operating fan. Do
not use fan if any part is damaged or
missing.
WARNING: Do not use this fan with
any solid state speed control device.
This appliance has a 3-prong plug. To
reduce the risk of electrical shock, this
plug is intended to t in an outlet only
one way. If this plug does not t the
outlet, contact a qualied electrician.

Ventamatic, Ltd. P.O. Box 728, Mineral Wells, TX 76068-0728
1-800-433-1626 Fax: [phone] www.BVC.com
2
UNPACK YOUR FAN AND CHECK THE CONTENTS (numbers below refer to diagram at right)
• Fan Base (1)
• Base Screws, Base Collar (2, 3)
• Outer Pole & Spring (4)
• Inner Extension Pole & Height Adjustment Collar (5, 6, 7, 8)
• Motor, Motor Flanges, Mounting Hardware Assembly (9, 10, 11, 12)
• Rear/Front Grille & Blades (14, 15, 16)
• Allen Wrench, zip tie, Grille Screws (Not Shown)
• This Owner’s Manual
STAND & BASE ASSEMBLY
1. Remove 5 screws (2) from hardware box.
2. Place Outer Pole w/spring (4) on base frame (1) and align holes in bottom of outer pole
with holes in base frame (1).
3. Insert screws (2) removed in Step 1 and tighten securely with 3/8” wrench or driver.
4. Slide Base Collar (3) down over the bottom of outer pole.
OUTER POLE
1. Make sure spring is in Outer Pole (4).
2. Remove 2 screws (5) from Adjustment Collar (6) of inner pole (8).
3. Insert inner pole (8) into outer pole (4).
4. Align 2 holes on outer pole (4) with holes in Adjustment Collar (6), secure Adjustment
Collar with 2 screws (5) removed in Step 2 using #2 Phillips screwdriver.
5. Adjust inner pole (8) to desired height.
6. Tighten Height Adjustment Knob (7) to set height.
STAND/MOTOR ASSEMBLY
1. Remove bolt, at washer, spring washer, nut (for motor position) (10) and square neck
bolt, at washer, spring washer and nut (for angle setting) (9) from hardware bag.
1A. For oscillating models, use the 4 screws and washers provided in the bottom of the
motor and attach motor anges to motor using an M10 wrench or driver.
2. Align upper round hole on Inner Pole Extension (8) with upper round hole in motor ange
on motor assembly (11).
3. Insert bolt and replace at washer, spring washer and nut (10) removed in Step 1 using a
3/4” wrench or driver.
4. Adjust tilt to desired position, insert square neck bolt and replace at washer, spring
washer and nut (9) and tighten to set angle.
5. Tighten position bolt and nut (10).
REAR GRILLE & BLADE ASSEMBLY
1. Remove 4 nuts, spring washers and at washers (12) from around motor shaft.
2. Carefully slide rear grille (14) over motor shaft.
3. Secure with at washers, spring washers and nuts (12) removed in Step 1 using an 11/32”
wrench or driver.
4. Carefully slide blade assembly (15) over shaft and align inner Allen head screw with slot
on motor shaft. Blade assembly should be ush with end of motor shaft.
5. Tighten Blade assembly using included Allen wrench.
6. CAUTION: Do not alter angle of blades.
FRONT GRILLE ASSEMBLY
1. Align front and rear grilles. Slide zip tie through top hole of front grille (16) and top hole
of rear grille. Tighten zip tie to secure grilles together.
2. Use 7 of the 8 black screws provided and a 5/16 driver to secure front and back grilles
together.
3. Remove zip tie from top hole of grille assembly. Use remaining black screw on top hole to
complete assembly.

Ventamatic, Ltd. P.O. Box 728, Mineral Wells, TX 76068-0728
1-800-433-1626 Fax: [phone] www.BVC.com
3
RULES FOR SAFE OPERATION
• Do not insert ngers or any objects through grille guard when fan is in operation.
• Disconnect fan when moving from one location to another.
• Disconnect fan when removing guards for cleaning.
• Make sure fan is on a stable, at surface when in operation.
• Rain and moisture may create an electrical hazard.
• In order to prevent extension pipe spring from projecting up, do not release 2 adjusting
screws (6) when extension pipe is all the way down.
OPERATION INSTRUCTIONS
TO ADJUST AIRFLOW UPWARD OR DOWNWARD: (Unplug unit rst!)
Loosen position bolt (10), then loosen pivot bolt (9). Tilt motor to desired angle, and tighten
pivot bolt. Tighten position bolt.
SPEED CONTROL: Pull chain on motor assembly to set to desired setting: high, medium, or low.
OSCILLATION (limited models): Pull the oscillation knob up or down on motor to control oscilla-
tion function as desired.
CLEANING
WARNING: Unplug from electrical supply source before cleaning. After servicing, any safety
device (including grilles and blades) must be reinstalled or remounted as previously installed.
Use a soft, damp cloth, then wipe with a dry cloth. Do not use harmful cleaners. Do not bend
blades.
FAN COMPONENTS
1. Base Frame
2. 5 Screws
3. Base Collar
4. Outer Pole with Spring
5. 2 Screws and Washers
6. Adjustment Collar
7. Height Adjustment Knob
8. Inner Pole Extension
9. Pivot Bolt, Spring Washer
and Nut
10. Position Bolt, Spring
Washer and Nut
11. Motor Assembly
12. 4 Nuts, Spring Washers
and Flat Washer
13. Allen Wrench, zip tie, 8
grille screws (not shown)
14. Rear Grille
15. Blade Assembly
16. Front Grille

Ventamatic, Ltd. P.O. Box 728, Mineral Wells, TX 76068-0728
1-800-433-1626 Fax: [phone] www.BVC.com
©2018 VENTAMATIC, LTD. 2018 HVPF 30 & HVPF 30 OSC INSTRUCTIONS 0818/0000
LIMITED WARRANTY
Ventamatic, Ltd. extends this warranty to the original retail purchaser of this fan
against defects in materials and workmanship for a period of two (2) years from
the date of purchase. There is no warranty for defects caused by abuse. Repairs or
replacement parts supplied under this warranty are warranted only for the period
of this warranty: that is two years from the date of the original retail purchase of this
fan.
In the event of a defect or malfunction, we will replace the defective part or
component only and return the new repaired part to you freight prepaid. You
must bear all other expenses incurred including labor required for eld repair or
replacement and the cost of shipping the defective part or component to us.
You must also bear the cost of replacement of any part or component and the
shipping charges incurred for the replacement and return to you of any part or
component not covered by this warranty, including parts or components damaged by
you.
The company reserves the right to demand and receive written evidence of the date
of purchase before undertaking to perform its obligations under this warranty. You
should, therefore, retain your sales slip and attach it to the warranty claim.
In order to obtain the replacement parts or components, you must select one of the
following two methods:
A: RETURN TO FACTORY
Return postage prepaid the fan or only the part of fan which you believe to be
defective to the following address:
Ventamatic, Ltd.
100 Washington Street
Mineral Wells, TX 76067
*Complete and enclose a written claim to which you should attach a copy of
your sales slip or other proof of purchase.
B. RETURN TO RETAILER DEALER
There is no informal dispute setting mechanism available in the event of a
controversy involving this warranty.
Any and all implied warranties which may exist terminate upon the expiration of this
written warranty, two years from the date of original retail purchase. Some states do
not allow limitations on how long an implied warranty lasts, so these limitations may
not apply to you.
Ventamatic, Ltd. Is not liable to you for incidental or consequential damages arising
out of a defect or malfunction of this fan or out of any alleged breach of this warranty.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, so this limitation or exclusion may not apply to you.
This warranty gives you specic legal rights and you may also have other rights which
may vary from state to state.
