Venture Measurement Genuine Bindicator VRF-2000 Series User manual

SAFETY INFORMATION
Before installing the VRF-2000 model, please read these
instructions and familiarize yourself with the requirements
and functions. If any questions or problems arise during the
installation, please contact Bindicator®Applications at
1-800-778-9242.
The VRF-2000 model must only be installed and operated
as described in this operating instruction. Please note that
other action can cause damage for which Bindicator®does
not take responsibility. If the model is not installed correctly
or used in approved applications, dangers may arise such
as product overflow.
Ensure that all personnel installing, wiring, and calibrating this device are
suitably qualified.
Observe all local and national electrical codes for the wiring of this device.
IMPORTANT!
Either AC or DC power is to be connected to the power input depending on
the model. Consult the nameplate of the unit. Models beginning with
VRF2A are AC powered units and accept any voltage between 85 VAC and
265 VAC. Models beginning with VRF2D are DC powered units and accept
any voltage between 9 VDC and 36 VDC.
IMPORTANT!
An electrical earth ground connection must be made to the housing input
ground screw. See Figure 1 for location. This connection is needed for both
electrical safety and proper operation of the unit. This is required for both
AC and DC units.
External ground wire must be connected to tank wall or top of tank.
VRF-2000 Series
of Variable Radio Frequency
Point Level Sensors
Integral Electronics with Opti-SenseTM
Quick-Start Guide
150 Venture Boulevard
Spartanburg, SC 29306
Phone: [phone], Fax: [phone]
Customer Care: [phone]
Internet: http://www.bindicator.com
email: [e-mail]
© 2006 All rights reserved.
All data subject to change without notice. VRF 180401 Rev. C 12/06
Please see VRF180001 for complete installation guidelines.
Dimensional and electrical drawings of the VRF-2000 models are available in
various formats from Bindicator's website; www.Bindicator.com
From the home page, click on the link Installation Manuals/VRF180001 to obtain
the applicable drawing.
If access to the internet is not available, please contact Bindicator®Customer
Care Department at 1-800-778-9242 for assistance in obtaining these drawings.
Start-up & Operation
The VRF-2000 will automatically begin operation when powerd up. It should be
initially powered after it is installed in the application and with material below the
probe. When initially powered up, the VRF-2000 will automatically begin a 3
second calibration operation. If the unit is powered on the bench prior to instal-
lation, or moved from one installation to another, recalibration is required.
Momentarily press the recalibration pushbutton. The green calibration indication
LED will go off, and after 3 seconds illuminate to indicate calibration is complete.
The VRF-2000 is shipped from the manufacturer with the automatic
calibration/recalibration feature enabled. If only manual pushbutton
calibration/recalibration is desired, set SW5 DIP switch position 4 to off.

Input
Ground
Connection
Input
L1 Hot on AC Models
(+) on DC Models
Input
L2 Neutral on AC Models
(-) On DC Models
Recalibration
Pushbutton
Power Indication LED
Calibration Indication LED (Green)
Material Sensing LED (Red)
NO1 C1 NC1 NO2 C2 NC2
Output Relay Connections
Calibration De-Sense
Relay Connections
C NC NO
Serial Communications not
used on this version
Serial Communication Setting
Not used on this version
SW5 DIP Switch
SW4 Time
Delay
SW3 Sensitivity
Setting
Figure 2. High/Low Level Failsafe
SW3
Position
Sensitivity
0 .5 pF, Very High
1 1 pF, High
22pF
33pF
4 5 pf, Medium
58pF
6 10 pF, Low
7 15 pF, Very Low
SW5
Position 2
Time Delay Mode
On The delay set on SW4 is applied when material touches the probe
Off There is no delay when material touches the probe
SW5
Position 3
Time Delay Mode
On The delay set on SW4 is applied when material leaves the probe
Off There is no delay when material leaves the probe
Figure 3. Sensitivity Settings
Figure 5. Time Delay Mode Settings
(See Fig. 2)
Figure 1. VRF-2000 Electronics
Failsafe Selection
High Level Failsafe Operation
· DIP Switch SW5 position 1 is on.
· If the electrical power fails, the relay turns off. This indicates material as if the
tank were full.
Low Level Failsafe Operation
· DIP Switch SW5 position 1 is off.
· If the electrical power fails, the relay turns off. This indicates material as if the
tank were empty.
SW4
Position
Time Delay
0 200 mSec
11Sec
22Sec
35Sec
4 10 Sec
5 20 Sec
6 30 Sec
7 60 Sec
Figure 4. Time Delay Settings
(See Fig. 5)
(See Fig. 4)
(See Fig. 3)
The output relay contacts are labeled in the un-powered alarm state. The relay is energized
when the VRF-2000 is not alarmed. This status may be opposite that of other Bindicator®
brand units. If the VRF-2000 is replacing an older Model RF8000 or RF9000 unit,
connections will need to be opposite. If a connection was made to NC1 terminal of the
RF 8/9000, connect now to the NO1 terminal of the VRF-2000. C1 and C2 connections
would remain the same.
