Verilux Original VD01 User manual

Model: VD01
VD01-Man-Rev16.indd 1 6/5/13 3:26 PM

Dear Customer,
Thank you for purchasing the Verilux Original Natural
Spectrum®Desk Lamp. You have received a quality
product, backed by a one-year limited warranty. As a
Verilux customer, your satisfaction means everything
to us. We look forward to serving you now and in the
future.
Many other healthy lighting products are available
through our catalog and online. Visit us on the web at
www.verilux.com to request a free catalog and learn
more about all our quality Verilux products, or call us
toll-free at 1-800-454-4408.
Have a bright day!
Nicholas Harmon
President, Verilux, Inc.
2
VD01-Man-Rev16.indd 2 6/5/13 3:26 PM

3
• Donotoperatethislampnearawatersourcetoavoidelectrocution.
• DoNOTdismantle.
• Donotusewithpowersupplyvoltageotherthan120VAC.
• Donotoperatelampincloseproximitytoflammableorcombustiblevapors,
such as aerosol spray products, or where oxygen is being administered.
• Donotcutorshortenthepowercord.
• Closesupervisionisrecommendedwhentheselampsareusedbyornear
children, or others who may not understand the need for these precautions.
• Topreventriskofshockorpersonalinjurywhencleaningthislamp,make
sure you have turned off and unplugged the lamp and allowed sufficient time
for the bulb to cool.
• Ifthislamphasbeendamagedinanyway,forexample,thepowersupply
cordorplughasbeendamaged,liquidhasbeenspilledorobjectshavefallen
onto the lamp, the lamp has been exposed to rain or moisture, the lamp does
not operate normally or has been dropped, it should not be operated. There
are no user serviceable parts in this lamp.
• Lightbulbsgethotquickly!Donottouchthebulbwhilethelampison.
• Donotcutorshortenthepowercord.
• ThisproductcontainsachemicalknowntotheStateofCaliforniatocause
birth defects or other reproductive harm.
• Thisbulbcontainsatraceamountofmercury.Formoreinformationonclean-
up and disposal, see www.epa.gov/cfl.
• Forindooruseonly.
• Avoidplacingthislampinareasthatareexposedtodirectsunlightorcloseto
heat radiating products such as heaters.
• Protectthepowercordfrombeingwalkedonorpinched,particularlyat
plugs, convenience receptacles and the point where the power cord exits the
lamp.
• Alwaysunpluglampbeforeperformingbulbreplacementorinstallation.
• Thislampisnotforusewithlightdimmers,timers,motiondetectors,voltage
transformers or extension cords.
DANGER:
Important Safeguards
READ ALL INSTRUCTIONS BEFORE USING
WARNING:
CAUTION:
VD01-Man-Rev16.indd 3 6/5/13 3:26 PM

4
• Thisproductmaycauseinterferencewithradios,cordlesstelephonesor
devices that use a wireless remote control, such as televisions. If interference
occurs, move the product away from the device, plug the product or device
into a different outlet or move the lamp out of the line of sight of the remote
control receiver.
• Avoidplacingthelampinareasthataredusty,humid/moist,lackventilation
oraresubjecttoconstantvibration.
• Unpluglampduringlightningstormsorwhenunusedforextendedperiodsof
time.
• Donotliftthelampbythegooseneck.Thelampshouldbeliftedbytheshaft
on the base.
• Beverycarefulnottopinchanypartofthecordbetweenanymetalpieces.
• Nevercoverthelamporplaceanythingontopofitwhenitisinoperation.
• Donotusesolventsorcleanerscontainingabrasives,orammoniabased
cleaners on this product.
• Aftercleaningthelamp,allmoistureshouldbeproperlywipedawayand
dried before restoring power.
• DoNOTuselubricatingagentinassembly;pleaseseetroubleshooting
section if you are having difficulty assembling your lamp.
Important Safeguards — continued
SAVE THESE INSTRUCTIONS
— continued
CAUTION:
VD01-Man-Rev16.indd 4 6/5/13 3:26 PM

5
• N’utilisezpascetappareilàproximitéd’unearrivéed’eaupouréviter
toutrisqued’électrocution.
• Avantdebrancherlalampe,vérierquelatensiondelaprisemuralene
dépassepas120volts.
• NePASutiliserdeproduitlubriantlorsdel’assemblage;voirlasection
dedépannageencasdedifcultélorsdel’assemblagedelalampe.
• Nepasutiliserlalampeàl’extérieuroudansdesendroitshumides,telle
qu’unesalledebain.Lalampedoitêtreuniquementutiliséeàl’intérieur
et dans un endroit sec.
• Pourusageintérieurseulement.
• Nepasutiliseravecdesgradateursdelumière,desminuteries,des
détecteursdemouvementoudesrallonges.
• Ceproduitpeutcauserdesinterférencesavecdesradios,des
téléphonessansloudesappareilsutilisantunetélécommandesansl,
tellequ’unetélévision.
• Sidesinterférencesseproduisent,éloignerleproduitdel’appareil,
brancherleproduitoul’appareildansuneautrepriseouencore
déplacerlalampehorsdelalignedeviséedudétecteurde
télécommande.
• Débrancherdelapriseélectriquelorsqueleproduitnesertpaspendant
delonguespériodesoulorsd’oragesélectriquesand’assurerla
protectiondespiècesélectroniques.
• Ceproduitcontientdumercuredanssonampoule.Suivreles
règlementslocauxpourlamiseaurebutdel’ampoule.
• Prendresoindenepaspincerlecordondansdespiècesmétalliques.
• Toujoursdébrancherlalampeavantderemplaceroudeposer
l’ampoule.
• Nepasutiliserdesolvantsnidenettoyantscontenantdesabrasifsou
del’ammoniaque.
• Toutehumiditédoitêtreessuyéeetséchéeavantderemettrelalampe
sous tension.
• Débrancherlalampeavantd’effectuersonalignement.
DANGER :
Mesures de sécurité importantes
CAUTION :
AVERTISSEMENT :
CONSERVEZ CES INSTRUCTIONS
VEUILLEZ LIRE L’INTÉGRALITÉ DES INSTRUCTIONS AVANT TOUTE UTILISATION
VD01-Man-Rev16.indd 5 6/5/13 3:26 PM

Getting Started
Main Parts & Controls
A. Lamp Head
B. Gooseneck
C. LampBase
D. Power Cord
E. PolarizedPlug
F. Parabolic Grid Diffuser
G. Bulb
H. High/Off/LowSwitch
A
CE
D
B
G
Close-up of Lamp Head
H
F
A
VD01-Man-Rev16.indd 6 6/5/13 3:26 PM

Set-up Instructions
To prevent damage during shipping, the Verilux®bulb is surrounded
by protective padding. Carefully remove and dispose of the protective
padding. Check to ensure that the bulb is fully seated and has not
come loose from the socket during shipping. There should be no gap
between the bulb and socket.
Attaching the Parabolic Grid Diffuser:
1. Remove grid diffuser from protective plastic bag.
2. Insert plastic pegs at bottom of grid diffuser into openings near the
bulb socket.
3. Snap tab into place.
4. Plug lamp into an outlet and turn it on. If bulb does not illuminate
instantly, please refer to the troubleshooting section of this manual.
VD01-Man-Rev16.indd 7 6/5/13 3:26 PM

Bulb Replacement Instructions
Correctly seated bulb Incorrectly seated bulb
C
B
A
C
B
A
No
gap
Notice
large gap
D
Installation
1.Unplugthelampfrompowersource.
2.Firmlyholdthebase(B)andpushbulb(C)
intothesocket(A).
3.Besurethebulbisrmlyseatedinthe
socket(seebelow)andsnappedintothe
metalbulbclip(D).
4. Replace grid diffuser.
Removal
1. Unplugthelampfromthepowersource.
2. To access to the bulb, remove the grid
diffuser by depressing the tab and lifting it
out(seepage6).
3. Firmlyholdthebulbbase(B)andpull
thebulb(C)fromthesocket(A)in
an outward motion.
NOYES
CAUTION:ALWAYSUNPLUGLAMPBEFOREPERFORMING
BULBREPLACEMENTORINSTALLATION.
MISE EN GARDE :TOUJOURSDÉBRANCHERLALAMPEAVANTDE
REMPLACEROUDEPOSERL’AMPOULE.
CAUTION:
VD01-Man-Rev16.indd 8 6/5/13 3:26 PM

9
Troubleshooting
Before requesting service on your Verilux®lamp, please read the
following:
•Makesureallpowerconnectors,cordsandplugsareinsertedfully
and securely.
• Besurethebulbissecurelyseatedintothesocket(seepage9).
• Makesurethereispowertothewalloutletortryanotheroutlet.
• DISCONNECTLAMPBEFOREPERFORMING
ALIGNMENT ACTIVITY. MISE EN GARDE : DÉBRANCHERLA
LAMPEAVANTD’EFFECTUERSONALIGNEMENT.
Correct alignment with screw holes can be accomplished by following
these steps:
1. Always start with the base and work your way up the shaft and
attach the head last.
2. Placeyourfootonthebaseofthelamponthefloor.
3. While holding the shaft with your hand, gently rock the unit back
and forth.
4. Shaft should ease into socket and screw holes will align.
PROBLEM CHECK SOLUTION
Light Won’t
Come On
Blackening/Darkening
at Ends of Bulb
Light Flickers
Has the plug come
loose?
Is the bulb old?
Is the bulb connected
securely into socket?
Is the bulb new?
Is the bulb old?
Has the plug come
loose?
Is the bulb connected
securely to the socket?
Is the lamp connected
to a dimmer switch?
Insert plug securely into wall outlet.
Check bulb for blackening/darkening at bottom of spiral where it joins the
base (an indicator of bulb life) and replace bulb.
Be sure the bulb is securely seated into socket, repeat the bulb
installation process.
Sometimes when a new bulb is turned on for the first time the tube will
darken, but this will fade after a few minutes.
With older bulbs, darkening of the tube indicates end of bulb life (this
doesn’t affect operation except to reduce the amount of light available
since the phosphor in that area has become inactive). Bulb replacement
is recommended.
Insert plug securely into wall outlet.
Connect lamp plug only to wall outlet without dimmer switch.
Be sure the bulb is securely seated into the socket, repeat the bulb
installation process. ALWAYS UNPLUG LAMP BEFORE
PERFORMING BULB REPLACEMENT OR INSTALLATION.
CAUTION:
CAUTION:
VD01-Man-Rev16.indd 9 6/5/13 3:26 PM

10
Care & Cleaning
Your lamp is made from high quality materials that will last for many
years with minimum care. You may want to periodically clean the lamp,
using a mild non-abrasive cleaner and soft cloth. When cleaning, make
sure you have turned off and unplugged the unit, and allowed sufficient
time for the unit to cool. All liquid should be properly wiped away and
dried prior to restoring power.
DONOTUSESOLVENTSORCLEANERS
CONTAININGABRASIVES,ORAMMONIABASEDCLEANERSON
THISPRODUCT.
MISE EN GARDE :NEPASUTILISERDESOLVANTSNIDE
NETTOYANTSCONTENANTDESABRASIFSOUDEL’AMMONIAQUE.
ALLMOISTURESHOULDBEPROPERLYWIPED
AWAY AND DRIED PRIOR TO RESTORING POWER.
AVERTISSEMENT :TOUTEHUMIDITÉDOITÊTREESSUYÉEET
SÉCHÉEAVANTDEREMETTRELALAMPESOUSTENSION.
CAUTION:
CAUTION:
VD01-Man-Rev16.indd 10 6/5/13 3:26 PM

11
One Year Limited Warranty
ATTENTION! ONCE OPENED, PLEASE DO NOTRETURNTHISPRODUCTTOTHE
STOREWHEREITWASPURCHASEDFORREPAIRORREPLACEMENT!
Many questions may be answered by visiting www.verilux.com, or you may call our
Customer Service Department at 1-800-786-6850 during normal business hours.
This limited warranty is provided by: Verilux, Inc., 340 Mad River Park, Waitsfield, VT 05673
Verilux warrants this product to be free from defects in material and workmanship for a
periodofoneyearfromthedateoftheoriginalretailpurchasefromVeriluxoranauthorized
Verilux distributor. Proof of purchase is required for all warranty claims. During the
limited warranty period, Verilux, Inc. will, at its option, repair or replace defective parts of
thisproduct,atnochargetothecustomer,subjecttothefollowinglimitations:Thislimited
warranty does not include any postage, freight, handling, insurance or delivery fees. This
warranty does not cover damage, defect or failure caused by or resulting from accident,
external destruction, alteration, modification, abuse, misuse or misapplication of this
product.
This warranty does not cover damage to the product resulting from return shipping or
handling. The use of shipping insurance is recommended to help protect your product.
Return Authorization is required for all returns. ToobtainaReturnAuthorization,please
contact the Verilux Customer Service Department at 1-800-786-6850.
If, during the first year of ownership, this product fails to operate properly, it should be
returnedasspeciedatwww.verilux.com/warrantyreplacementorasinstructedbya
Verilux customer service representative at 1-800-786-6850.
Note: Verilux recommends using a quality surge suppressor on all electronics equipment.
Voltage variations and spikes can damage electronic components in any system. A quality
suppressor can eliminate the vast majority of failures attributed to surges and may be
purchased at electronics stores.
Due to ongoing improvements, actual product may have slight variations from the product described in this manual.
Please visit our website at www.verilux.com or call our Customer Service Department at
1-800-786-6850
RepresentativesareavailableMonday—Friday,9am—5pmEST
340 Mad River Park, Waitsfield, VT 05673
VD01-Man-Rev16.indd 11 6/5/13 3:26 PM

VD01-MAN-Rev16
Printed in China for Verilux, Inc.
© Copyright 2013 Verilux, Inc. All rights reserved.
VD01-Man-Rev16.indd 12 6/5/13 3:26 PM
