Verilux vt20 User manual

Model: VT20
Natural Spectrum® Energy Lamp
Liberty™Series

2
Dear Customer,
Thank you for purchasing the Verilux®HappyLight®
Liberty™ Series Energy Lamp. You now own an innovative
product, manufactured to the highest standards and
backed by a one-year limited warranty.
This product brings Natural Spectrum Daylight into your
home or office. Many other healthy-lighting products are
available through our catalog and online. Visit us on the
web at www.verilux.com to request a free catalog and
learn more about all of our quality Verilux products, or call
our toll-free number: 1-800-454-4408.
As a Verilux customer, your satisfaction means everything
to us. We look forward to serving you now and in the
future.
Have a Bright Day!
Nicholas Harmon
President
Verilux, Inc.

3
Important Safeguards .................................4
Features............................................5
Benefits ............................................6
Device Pretest .......................................6
Operation...........................................7
Selecting a Location ...............................7
Instructions for Use ...............................7
Recommended Program ...........................8
Bulb Removal and Replacement.........................8
Using the Tilt and Wall Hanging Options. . . . . . . . . . . . . . . . . . . 9
Changing the Lenses/Lens Replacement .................10
Care and Cleaning...................................10
Troubleshooting.....................................11
Technical Specifications ..............................11
Warranty ..........................................12
Contents

4
• Toavoidelectrocution,donotoperatethisdevicenearwater.
WARNING:
• Donotusewithpowersupplyvoltageotherthan120VAC.
• Donotdefeatthesafetypurposeofthepolarizedplug.Apolarizedplughastwo
blades with one wider than the other. The wider blade is provided for your safety. If
the provided plug does not fit in your outlet, consult an electrician for replacement of
the obsolete outlet.
• Closesupervisionisrecommendedwhentheselampsareusedbyornearchildren,
or others who may not understand the need for these precautions.
• Donotoperatethislampincloseproximitytoflammableorcombustiblevapors,
such as aerosol spray products, or where oxygen is being administered.
• Topreventriskofshockorpersonalinjurywhencleaningthislamp,makesureyouhave
turned off and unplugged the lamp and allowed sufficient time for the bulb to cool.
• Ifthislamphasbeendamagedinanyway,forexample,thepowersupplycord
or plug has been damaged, liquid has been spilled or objects have fallen onto the
lamp, the lamp has been exposed to rain or moisture, the lamp does not operate
normally or has been dropped, it should not be operated. There are no user
serviceable parts in this lamp.
• Donotblockvents.Ventsareneccessaryforproperfunctionoftheelectronicballast;
blocking them may cause overheating of the electronics and increase risk of fire.
• Thebulbinthisproductcontainsatraceamountofmercury,achemicalknown
to the state of California to cause birth defects or other reproductive harm. This
substance may also cause injury if inhaled or ingested from a broken bulb.
• Somepeoplemayexperiencelightsensitivitytofluorescentlighting.Discontinueuse
if you experience any discomfort. Follow directions for pretest on page 6 prior to use.
• Certaindrugsmayinducelightsensitivity(e.g.,anti-depressants)whichmayresult
in discomfort or a level of hyperactivity. Consult with your health care provider before
using this product.
• Ifyouhaveapre-existingeyecondition,consultwithyourhealthcareproviderbefore
using this product.
• Thisproductcontainsmagnets.Ifyouhaveapacemaker,implantabledebrillator,
insulin pump, any other type of electro-mechanical device, or brain shunts that contain
magnets,keepsufcientdistance(about6inches)betweenthedeviceandthelamp.
• ChokingHazard:Thislampcontainssmallparts.Closesupervisionisrecommended
when these lamps are used by or near children.
• Theselampsareforindooruseonly.
• Avoidplacingthislampinareasthatareexposedtodirectsunlightorclosetoheat-
radiating products such as heaters. Do not place the lamp on the top of appliances
that radiate heat.
• Protectthepowercordfrombeingwalkedonorpinched,particularlyatplugs,
convenience receptacles and the point where the power cord exits the lamp.
DANGER:
Important Safeguards
READ ALL INSTRUCTIONS BEFORE USING
CAUTION:

5
Your new Verilux HappyLight Energy Lamp is a remarkable product with many
features and benefits. It:
• deliversNaturalSpectrum®Daylight to your home, office, dorm room or apartment
withnodangerousultraviolet(UV)waves.
• cuesyourbody’sownenergyenhancerstomakeyoumorealertandproductive.
• hasupto10,000LUX*ofbrightNaturalSpectrumlightwiththehigh-energylens
andupto5,000LUX**withthecomfortlenstoliftspirits,sharpenconcentrationand
improve energy levels.
• permitsacustomizedtherapyregimen,withtwolenses,ahigh/lowswitchandatilt
feature to put as much light as you want where you want it.
• isdesignedwithacompactshapeandsmallfootprinttomakeiteasytoplaceina
convenient location or hung on a wall.
• includesanenergyefcient,cool-burning36-wattbulbthatlasts10,000hours.
• includesabest-in-classpowersystemwithelectronicballastandpatentedFlicker
EliminationTechnology®toassureno-buzzoperationandinstant-on,flicker-free
illumination.
*10,000LUX(scotopicmeasurement)at12"to14"fromlamp;10,000LUX(photopic
measurement)at6"to8"
**5,000LUX(scotopicmeasurement)at12"to14"fromlamp;5,000LUX(photopicmeasurement)
at6"to8"
Features
— continued
CAUTION:
• Thislampmaycauseinterferencewithradios,cordlesstelephonesordevicesthat
use a wireless remote control, such as televisions. If interference occurs, move the
lamp away from the device, plug the lamp or the device into a different outlet or
move the lamp out of the line of sight of the remote control receiver.
• Unpluglampduringlightningstormsorwhenunusedforlongperiods.
• Avoidplacingthelampinareasthataredusty,humid/moist,lackventilationorare
subject to constant vibration.
• Thislampisnotforusewithlightdimmers,timers,motiondetectors,voltage
transformers or extension cords.
• Donotleavethelampunattendedduringuse.
• DoNOTusealubricatingagentinassembly;pleaseseetroubleshootingsectionif
you are having difficulty assembling your lamp.
• Lightbulbsgethotquickly!Donottouchthebulbwhilethelampison.
• UseonlythetypeofbulbandmaximumwattageindicatedbyVerilux.
• Nevercoverthelamporplaceanythingontopofitwhenitisinoperation.
• Alwaysunpluglampbeforeperformingbulbreplacement.
• Donotusesolventsorcleanerscontainingabrasives,orammonia-basedcleaners
on this product.
• Aftercleaningthelamp,allmoistureshouldbeproperlywipedawayanddried
before restoring power.
• Disposeofbulbsperlocalregulations.Formoreinformationonclean-upand
disposal, see www.lamprecycle.org.
SAVE THESE INSTRUCTIONS

6
To help determine if you have sensitivity to light treatment, we recommend that you
perform this pretest upon first use of this device:
Step 1 - Start this test with the comfort lens. Turn on the lamp and position it about
18inchesfromyourface.(Donotlookdirectlyintothelamp.)
Step 2 - Operate the lamp for approximately 10 minutes and turn it off. If the light
has caused any discomfort, stop using the lamp and consult a doctor.
If you have no discomfort, you may consider gradually decreasing the
distance from the lamp and increasing the use time, which results in
more lamp intensity and greater effect. You also may change from the
comfort lens to the high-energy lens and repeat the device pretest. For
your initial sessions, you should monitor the degree of any discomfort and
accordingly adjust the time used, lens used and lamp location.
WARNING:Somepeoplemayexperiencelightsensitivitytofluorescent
lighting. Discontinue use if you experience any discomfort.
WARNING:Certaindrugsmayinducelightsensitivity(e.g.,anti-
depressants)whichmayresultindiscomfortoralevelofhyperactivity.Consult
with your health care provider before using this product.
WARNING: If you have a pre-existing eye condition, contact your
health care provider prior to use.
Device Pretest
Benefits
Verilux Natural Spectrum
®
light is just the right kind of illumination, easily absorbed
by the eye, efficiently cueing the body to improve mood, energy and function while
reducing light sensitivity, eyestrain and fatigue.
Unlike most artificial light, Verilux Natural Spectrum light illuminates in the broader
scotopicrange,stimulatingmoreoftheeyes’photoreceptorswithoutextreme
brightness and glare. Like daylight, this scotopically enhanced light allows optimum
visual stimulation without oversaturation.
*VeriluxNaturalSpectrum®Light:Withhigh-energylens:10,000LUX(scotopicmeasurement)
at12"to14"fromlamp;10,000(photopicmeasurement)at6"to8".
Natural Spectrum®
Light Therapy
Intense Artificial
Light Therapy
Rods
Under-stimulated photoreceptors
Rods
Cones
Rods
Lens
Lens
Rods
Cones
Irritated
Eyes
Comfortable
Eyes
Well-stimulated photoreceptors
Balanced Broad
Spectrum Light
Intense Narrow
Spectrum Light

7
Instructions for Use
Use consists of sitting close to the HappyLight Energy Lamp with your eyes
open. While staying oriented toward the light, feel free to engage in other
activities such as reading, writing, hobbies and crafts, sewing, needlepoint,
applying make-up or working at your computer or desk. You may tilt the lamp
as required.
Selecting a Location
• PlaceyourVeriluxHappyLightEnergyLamponatableorotherflatsurface
above, at or below eye level depending on your desired result.
• Forbestperformance,placetheHappyLightascloseas6inchesbutwithin
24 inches of your face.
• If you have sensitive eyes or want to use the highest output settings and lens,
you may find it preferable to place the lamp above you and use the tilt feature.
WARNING: This product contains magnets. If you have a pacemaker,
implantable defibrillator, insulin pump, any other type of electro-mechanical
device,orbrainshuntsthatcontainmagnets,keepsufcientdistance(about
6inches)betweenthedeviceandthelamp.
WARNING: Do not block vents. Vents are necessary for proper
function of the electronic ballast. Blocking them may cause overheating of the
electronics and increase risk of fire.
CAUTION :
Avoid placing this lamp in areas that are exposed to direct
sunlight or close to heat-radiating products such as heaters. Do not place the
lamp on top of appliances that radiate heat.
1. Turn on the lamp and allow a few minutes for the bulb
to achieve full brightness.
2. The HappyLight Energy Lamp should be positioned as
close as 6 inches, but within 24 inches of your face and
shouldbeslightlyoff-center.(Seediagram.)Note: Do
not look directly into the lamp.
3. Consider using the lamp on the high setting in the
morning and on the low setting in the afternoon.
The light from the HappyLight Energy Lamp must be
directedatyoureyes;therefore,youreyesmustbe
open to achieve the full benefit. Note: Tinted glasses reduce the amount of light
reaching your eyes.
When you are feeling sluggish and lethargic, spend more time with the light,
sit closer to it or adjust the settings to increase the intensity. If you experience
edginess or are over-stimulated, move the light farther away or reduce session
times.
Operation

8
Your HappyLight uses a bulb manufactured only by Verilux. To order a
replacement bulb, please call Verilux, toll-free, at 1-800-454-4408.
To Replace the Bulb:
1. Unplug the lamp from power outlet.
2. Remove the lens cover by inserting a coin or your finger into the
openingbetweenthelensandthelampbodyatthetopofthelamp(A).
3. Gently pull the lens away from the lamp body, lifting slowly as you
pull(B).Placethelensaside–outofharm’sway.
Bulb Removal and Replacement
Operation — continued
Researchers at the National Institute of Health demonstrated that white light, in a
rangeof2,500to10,000LUX(ameasurementoflightintensity),helpedtoreversethe
symptoms of “Winter Blues.”
Exposure strategies affect people differently. We all have different reactions to our
environment. It is important to establish a distance and schedule that is comfortable for
you. We recommend you use the light regularly and at about the same time each day.
It is not necessary to sit in front of the lamp continuously. You can divide the time into
several mini-sessions. Continue to use the HappyLight daily to feel an improvement in
your mood and activity level.
When you are feeling sluggish and lethargic, spend more time with the light, sit closer
to it or increase the light intensity by switching to the high-energy lens. If you feel a sort
of edginess, as though you have consumed too much coffee, it may be time to turn off
the unit or reduce the intensity of the light.
*Recommendedexposuretimeisafunctionofoutputanddistance.Individualresults
may vary. Also, refer to the warnings at the bottom of page 6 of this manual.
WARNING:Somepeoplemayexperiencelightsensitivitytofluorescent
lighting. Discontinue use if you experience any discomfort. Follow directions
for pretest on page 6 prior to use.
WARNING:Certaindrugsmayinducelightsensitivity(e.g.,anti-
depressants)whichmayresultindiscomfortoralevelofhyperactivity.Consult
with your health care provider before using this product.
WARNING: If you have a pre-existing eye condition, contact your
health care provider prior to use.
Minimum Recommended Program
to
30 minutes
1hour*/Day
A
B

9
4. Unscrew the two blue thumb screws that hold
theblackbulbholderandthebulbitself(C).
5. Gently pull up the black bulb holder to expose
thebaseofthebulb(D).
6. Holding the bulb at its base, gently lift out the
old bulb, pulling it slowly and gently away from
thelampbodyasyouliftitupward(E).
7. Remove the black bulb holder by lifting it over
the top of the old bulb.
8. Place the black bulb holder over the top of the
new bulb.
9. Gently insert the new bulb into the receptacle
fromwhichyouremovedtheoldbulb(F).A
“click” sound will indicate the bulb is properly installed.
10. Lower the black bulb holder onto the bulb base. Reinstall the two
blue thumb screws.
11. Replace the lens, first by inserting its base into the opening in the
lamp base and then by aligning its top with that of the lamp base
(G).Snaplensintoplace.
WARNING: This product contains magnets. If you have
a pacemaker, implantable defibrillator, insulin pump, any other
type of electro-mechanical device, or brain shunts that contain
magnets,keepsufcientdistance(about6inches)betweenthe
implanted device and the lamp.
The HappyLight Liberty Series Energy Lamp offers
several ways to direct light where you want it, so you can
have more freedom of movement without compromising
the quality of the therapy:
1. Your HappyLight has a tilt range of 15° forward and
15°backward(H):Simplyloosenthetwobluethumb
screwsonthebackofthelamp(I),adjustthelamp
to the position you want, and re-tighten the thumb
screws.
2. For wall hanging, the back of your HappyLight has
twoopeningsdesignedtoreceivescrewheads(J).
Simplydrilltwoholes,leveland3½”(9cm)apartat
the location you desire, install the screws, hang the
lamp and plug it in. Install the screws into studs or
use screw anchors as required.
Bulb Removal and Replacement — continuedBulb Removal and Replacement — continued
Using the Tilt and Wall Hanging Options
E
F
D
C
G
2
1
H
15º 15º
I
J

10
Your lamp is made from high quality materials that will last for many years with
minimum care. You may want to periodically clean the lamp using a mild non-
abrasive cleaner and soft cloth. When cleaning, make sure you have turned off
and unplugged the unit and allowed sufficient time for the unit to cool.
WARNING: To prevent risk of shock or personal injury when cleaning
lamp, make sure you have turned off and unplugged the lamp and allowed
sufficient time for the bulb to cool.
CAUTION :
Cleanonlywithasoftdrycloth–donotusesolventsor
cleaners containing abrasives or ammonia.
CAUTION :
After cleaning the lamp, wipe away all moisture and let the
lamp dry completely before restoring power.
Care and Cleaning
Your HappyLight Liberty Series Energy Lamp comes with interchangeable comfort and
high-energy lenses, inserted in a bezel and held with magnets to the lamp body, that
regulate the light intensity, reduce glare and provide your eyes with
evenstimulation.Youcanchoose–orchange–the
covers to get the amount of light you want for your light
therapy program:
1. Remove the lens by inserting a coin or your finger
into the opening between the lens bezel and the
lampbody(A).
2. Gently pull the lens and bezel away from the lamp
body,liftingslowlyasyoupull(B).
3. Holdthebezelatthetopandpullawaythelens(C).
4. To install the other lens, work from the underside of
the bezel and lens. Align the six cutouts in the lens
(D)withthesixmagnetclips(E).Lowerthelens,
and slide it back into position.
WARNING: This product contains magnets. If you have a pacemaker,
implantable defibrillator, insulin pump, any other type of electro-mechanical
device,orbrainshuntsthatcontainmagnets,keepsufcientdistance(about
6inches)betweenthedeviceandthelamp.
Your lenses will yellow over time and should be replaced annually. Contact Verilux
customer service at 1-800-786-6850 or order online at www.verilux.com.
Changing the Lenses/Lens Replacement
A
B
C
Bezel
Lens
Bezel
Lens
D
D
3/4"
E
E

11
Technical Specifications
HappyLight Liberty Series Natural Spectrum Energy Lamp
Environment
OperatingTemperature:15to35°C(56to95°F)
StorageTemperature:0to40°C(32to104°F)
Relative Humidity: 5 to 95% non-condensing
Bulb
Replacement bulb: 36 watt 10,000-hour bulb.
ReplacewithVeriluxbrandonly,ModelnumberCFML36VLXbycalling
1-800-454-4408 or visiting www.verilux.com.
Power
Input Power: 120 VAC, 60Hz, 0.50 A
UL Listed in Canada and the USA
Before requesting service on your Verilux lamp, please:
• Makesureallpowerconnectors,cordsandplugsareinsertedfullyandsecurely.
• Besurethebulbissecurelyseatedinthesocket.(Seepages8and9.)
• Makesurethereispowertothewalloutlet,ortryanotheroutlet–onethatisnot
connected to a dimmer.
Troubleshooting
PROBLEM CHECK SOLUTION
Light Won’t
Come On
Blackening/Darkening
at Ends of Bulb
Light Flickers
Has the plug come
loose?
Is the bulb old?
Is the bulb connected
securely into socket?
Is the bulb new?
Is the bulb old?
Has the plug come
loose?
Is the bulb connected
securely to the socket?
Is the lamp connected
to a dimmer switch?
Insert plug securely into wall outlet.
Check bulb for blackening/darkening at bottom of spiral where it joins the
base (an indicator of bulb life) and replace bulb.
Be sure the bulb is securely seated into socket. Repeat the bulb
installation process.
DISCONNECT LAMP FROM OUTLET
PRIOR TO REPEATING THE BULB INSTALLATION PROCESS.
Sometimes when a new bulb is turned on for the first time the tube will
darken, but this will fade after a few minutes.
With older bulbs, darkening of the tube indicates end of bulb life. (This
doesn’t affect operation except to reduce the amount of light available
since the phosphor in that area has become inactive.) Bulb replacement
is recommended.
Insert plug securely into wall outlet.
Connect lamp plug only to wall outlet without dimmer switch.
Light won’t tilt Are the thumb screws
too tight?
Loosen the two blue thumb screws on the back of the unit, adjust the lamp
to the desired angle and re-tighten the two thumb screws.
Be sure the bulb is securely seated into the socket. Repeat the bulb
installation process. DISCONNECT LAMP FROM OUTLET
PRIOR TO REPEATING THE BULB INSTALLATION PROCESS.
CAUTION:
CAUTION:

12
Please visit our website at: www.verilux.com or call our Customer Service Department at
1-800-786-6850
Representatives are available Monday — Friday, 9am — 5pm EST
340 Mad River Park, Waitsfield, VT 05673
VT20-MAN-Rev9
Printed in China for: Verilux, Inc.
© Copyright 2012 Verilux, Inc. All rights reserved.
One-Year Limited Warranty
ATTENTION! ONCE OPENED, PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
WHERE IT WAS PURCHASED FOR REPAIR OR REPLACEMENT!
Many questions can be answered by visiting www.verilux.com, or you may call our
Customer Service Department at 1-800-786-6850 during normal business hours.
This limited warranty is provided by Verilux, Inc., 340 Mad River Park, Waitsfield, VT 05673
Verilux warrants this product to be free from defects in material and workmanship for a
period of one year from the date of the original retail purchase from Verilux or an authorized
Verilux distributor. Proof of purchase is required for all warranty claims. During the
limited warranty period, Verilux, Inc., will, at its option, repair or replace defective parts of
this product at no charge to the customer, subject to these limitations: This limited warranty
does not include any postage, freight, handling, insurance or delivery fees. This warranty
does not cover damage, defect or failure caused by or resulting from accident, external
destruction, alteration, modification, abuse, misuse or misapplication of this product.
This warranty does not cover damage to the product resulting from return shipping or
handling. Shipping insurance is recommended to help protect your product.
Return Authorization is required for all returns. To obtain a Return Authorization, please
contact the Verilux Customer Service Department at 1-800-786-6850.
If, during the first year of ownership, this product fails to operate properly, it should be
returned as specified at www.verilux.com/warrantyreplacement or as instructed by a Verilux
customer service representative at 1-800-786-6850.
Note: Verilux recommends using a quality surge suppressor on all electronic equipment.
Voltage variations and spikes can damage electronic components in any system. A quality
suppressor can eliminate the vast majority of failures attributed to surges. Suppressors
may be purchased at electronics stores.
Due to ongoing improvements, actual product may have slight variations from the product described in this manual.
