Verilux Troika VD10 User manual

VD10

2
Dear Customer,
Thank you for purchasing the Troika™ LED Desk Lamp. You have
received an innovative and quality manufactured product, backed by a
one-year limited warranty.
Many other healthy lighting products are available through our catalog
and online. To request a free copy of our catalog, call our toll-free
number 1-888-544-4865. You may also visit us on the web at
www.verilux.com to learn more about all our quality Verilux®products.
As a Verilux®customer, your satisfaction means everything to us. We
look forward to serving you now and in the future.
Have a bright day!
Nicholas Harmon
President, Verilux, Inc.

3
Table of Contents
Warnings and Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Set-up Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Care and Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4
Warnings and Precautions
• Please read these instructions before using this lamp.
• For indoor use only.
• Do not place near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
• Do not block any ventilation openings.
• Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where the power cord exits the lamp.
• Unplug this lamp during lightning storms or when unused for long periods.
• There are no user serviceable parts in this lamp. Do not dismantle. If the lamp
has been damaged in any way, such as power cord or plug is damaged, liquid
has been spilled or objects have fallen onto the lamp, the lamp has been
exposed to rain or moisture, does not operate normally, or has been dropped,
it should not be operated.
• Lamp to be operated only with 100-240 VAC, 50/60Hz power.
• Avoid placing the lamp in areas that are dusty, humid/moist, lack ventilation or
are subject to constant vibration.
• Not for use with light dimmers, timers, motion detectors, voltage transformers
or extension cords.
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR
PERSONAL INJURY:
• Turn off/unplug before cleaning.
• Do not look directly at the lighted LED’s without the diffuser being in place.
• Do not operate the lamp in close proximity to flammable or combustible
vapors, such as aerosol spray products, or where oxygen is being
administered.
• Never cover the lamp when it is in operation.
• To prevent risk of shock or personal injury when cleaning lamp, make sure
you have turned off and unplugged the lamp.
SAVE THESE INSTRUCTIONS

5
Features
• Ultra energy efficient LED lamps help save up to 40% on electricity
consumption.
• Flicker Elimination Technology®reduces eyestrain and fatigue.
• Optix®Filtering System provides glare-free and balanced illumination.
• Natural Spectrum®light improves color and clarity of reading materials.
• Lamp head adjusts 180° for precise placement of light or for discreet, ambient
lighting.
• Built-in night light.
Set-up Instructions
What’s included
Please remove all packaging material. Check the carton for the following items:
• LED lamp
• Power plug, cord and connector
• User manual
Introduction
Your new Troika™ LED Desk Lamp consists of:
1. 3-position Switch
2. LED lights
3. Arm
4. Base
5. Power plug, cord and connector
6. Hinge
1
6
2
3
4
5

6
Your Verilux®lamp is made from high quality materials that will last for many years
with a minimum of care.
Clean only with a soft dry cloth – DO NOT USE SOLVENTS OR CLEANERS
CONTAINING ABRASIVES OR AMMONIA.
WARNING: TO PREVENT RISK OF SHOCK OR PERSONAL INJURY
WHEN CLEANING LAMP, MAKE SURE YOU HAVE TURNED OFF AND
UNPLUGGED THE LAMP.
Care and Cleaning
Instructions for use
1. Thread power cord through clips at the back of the lamp.
2. Plug connector into the receptacle on the lamp.
3. Place the lamp and position to proper angle.
4. Slide the power switch to:
• Solid orange spot: Off
• Center (no spot): Nightlight
• Orange open circle: On
Unplug the power connector if the lamp will not be used
for long periods.
Operation

7
Troika™ LED Desk Lamp
Input voltage: 100-240 VAC, 50/60Hz
Output voltage: 12.8 VDC, 0.48A
Power consumption: 7 Watts (day mode); 0.25 Watts (night mode)
Operating temperature: 0°C – 40°C
Service lifetime: > 36,000 hours
Technical Specifications
Before requesting service on your Verilux®lamp, please read the
following:
• Make sure all power plugs, cords and connectors are inserted fully and
securely.
• Make sure there is power to the wall outlet or try another outlet.
CAUTION: Only use the power plug, cord and connector supplied with your
Troika LED Desk Lamp. If other power plugs, cords or connectors are used,
damage to your lamp may occur.
Problem Check Solution
Light won’t come on.
Has the power plug come
loose from the wall outlet?
Insert plug securely into
wall outlet.
Be sure the connector
plug is securely seated
into the plug receptacle
on the back side of the
lamp.
Is the connector plug
securely connected to
lamp?
Only one LED turns on.
Is the on/off switch
pushed so that the
orange open circle can
be seen?
Be sure the switch is
pushed all the way to the
end until all LEDs are on.
Lamp arm does not stay
in position.
Is hinge screw securely
fastened?
Use screwdriver to
tighten hinge screw.
Troubleshooting

VD10-MAN-Rev3
Please visit our web site at: www.verilux.com
340 Mad River Park, Waitsfield, VT 05673
Printed in China for Verilux, Inc.
© Copyright 2010 Verilux, Inc. All rights reserved.
One Year Limited Warranty
ATTENTION! ONCE OPENED, PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
WHERE IT WAS PURCHASED FOR REPAIR OR REPLACEMENT!
Many questions may be answered by visiting www.verilux.com, or you may call our Customer
Service Department at 802-496-3101 during normal business hours.
This limited warranty is provided by: Verilux, Inc., 340 Mad River Park, Waitsfield, VT 05673
Verilux warrants this product to be free from defects in material and workmanship for a period
of one year from the date of the original retail purchase from Verilux or an authorized Verilux
distributor. Proof of purchase is required for all warranty claims. During the limited warranty
period, Verilux, Inc. will, at its option, repair or replace defective parts of this product, at no
charge to the customer, subject to the following limitations: This limited warranty does not
include any postage, freight, handling, insurance or delivery fees. This warranty does not cover
damage, defect or failure caused by or resulting from accident, external destruction, alteration,
modification, abuse, misuse or misapplication of this product.
This warranty does not cover damage to the product resulting from return shipping or handling.
The use of shipping insurance is recommended to help protect your product.
Return Authorization is required for all returns. To obtain a Return Authorization, please
contact the Verilux Customer Service Department at 802-496-3101.
If, during the first year of ownership, this product fails to operate properly, it should be returned
as specified at www.verilux.com/warrantyreplacement or as instructed by a Verilux customer
service representative at 802-496-3101.
Note: Verilux recommends using a quality surge suppressor on all electronics equipment.
Voltage variations and spikes can damage electronic components in any system. A quality
suppressor can eliminate the vast majority of failures attributed to surges and may be
purchased at electronics stores.
Due to ongoing improvements, actual product may have slight variations from the product described in this manual.
