Versahaul VH-SR User manual

BNK,Inc.9341S.StRd.39 Winamac,IN46996 Problems?Questions?Callusat(888)818-9915
WARNING
1. Read all instrucons for future reference.
2. Follow all warnings and instrucons marked on the
product.
3. Do not stand on the VersaHaul.
4. Do not ride any vehicle while loading onto the
VersaHaul.
5. Always store the VersaHaul in a safe place.
6. Never exceed vehicle tongue weight rangs.
7. Only use VersaHaul with Class 3 or 4 hitch. Most
Class 3 hitches limit the VersaHaul to 500 lbs. total
hauling capacity.
8. Improper use, storage or installaon of ramp could
result in death or serious injury.
9. Do not put any VersaHaul on a 5th wheel trailer or
any other kind of trailer.
10. VH-SR carrying capacity is limited to 300 lbs. max.
Your vehicle suspension and hitch may limit the
hauling capacity of the carrier. For more
informaon on vehicles and hauling capacies, visit
www.versahaul.com.
BNK, INC warrants the carrier and related components. This warranty applies to any part found to be defecve due to
material and/or workmanship when inspected at the factory of BNK, Inc., Winamac, IN. BNK Inc. will, at its opon,
repair or replace defecve parts to the original purchaser at no charge other than transportaon. Sale receipt as
proof of date of purchase is required, which will be returned. BNK, Inc. assumes no liabilty for labor charges made in
performance of this warranty.
The warranty periods are as follows from date of purchase:
CARRIER FOR 1 YEAR, VOID IF: frame is broken or bent due to abuse. example: (underside scraped abusively)
ALL WARRANTIES ARE VOID IF: the carrier has been rented, used under abnormal condions, or subjected to
abuse, misuse, neglect, or improper maintenance.
All warranes should be handled at point of purchase unless other arrangements are made.
BNK, Inc. is not liable for any damage claim or liability cliam, personal or otherwise resulng from operaon of this
carrier in any way. All transportaon charges for items returned for warranty evaluaon and/or replacement are to be
borne by the customer.
For one (1) year from the date of purchase, BNK, Inc. will repair or replace for the original purchaser, without charge,
any part or parts are manufactured by BNK, Inc. and found, upon examinaon at our factory in Winamac, to be
defecve in materials and/or workmanship.
All transportaon charges on parts submied for replacement under this warranty must be borne by the purchaser.
This warranty does not apply to parts not manufactured by BNK, Inc. Their manufacturer may warrant these items.
This warranty does not apply to any part which has been damaged by accident, alteraon, abuse, improper
adjustment, normal wear, or any other cause beyond our control.
Use of replacement parts other than genuine BNK, Inc. parts may impair the safety of your machine and void this
warranty.
THIS WARRANTY IS VOID UNLESS THE PRODUCT REGISTRATION CARD IS FILLED OUT COMPLETELY AND
RETURNED TO THE FACTORY AT WINAMAC, IN. WITHIN TEN (10) DAYS OF PURCHASE.
OUR WARRANTY COVERS OUR PRODUCT FOR ONE YEAR. WE ARE NOT ABLE TO EXCHANGE
USED VERSAHAUL CARRIERS FOR REFUNDS OR NEW CARRIERS.
IMPORTANT
LIMITED WARRANTY
The Limited Warranty on the VersaHaul Carrier.
½" Wrench 3 /8" Wrench 5
⁄₁₆" Wrench
TOOLS
(1) Angled Snger
VH027
(1) Adjustable Slider
VH035
(1) Ramp Base
VH034
(3) Pull Pin & Nut
VH300
VH310
(1) License Plate
Holder w/Light
VH093
(1) An-Tilt
Lock Bracket
VH070
(2) Ramp Handle
VH330
(1) Small Inner Ramp
VH046
VH047
(3) Bolt
3
/8” x 3 /4”
VH232
(2) Bolt
1
/2” x 21 /2”
VH241
(2) 5
/16” Washer
VH222
(2) 5
/16” Nut
VH223
(2) 1
/2” Washer
VH245
(2) 1
/2” Nut
VH242
(2) Bolt
5
/16” x 21 /2”
(1) Safety Lanyard
(1) Snger Cover
VH023B
(1) Eyebolt(1) Large Outer Ramp
VH042
NOTE: VersaHaul is aached
with your standard Hitch Pin
(not included).
(2) Safety U-Bolt
PARTS
(1) Alternave Lock
Bracket Assembly
VH073
Includes:
•(1) 7
⁄₁₆" x 2 3 /4” Bolt
VH235
•(1) 7
⁄₁₆" Lock Nut
VH236
•(1) 7
⁄₁₆" Washer
VH237
Outer Ramp
Inner Ramp
Ramp Base
Snger
Toward Vehicle
VH-SR
www.versahaul.com
mobilityscootersafetyramp

ATTACHINGYOURVERSAHAUL
Bolt Head Side View Top View
Hitch
Carrier Main Tube
If the An-Tilt Lock Bracket does not fit, use the An-Tilt Hitch Aachment Bolt. The An-Tilt Hitch Aachment
Bolt has a 7
/18” thread size, a 3 /8“ Allen Head size, and a 5 /8” outer
head size. Slide the Main Tube of the carrier into the hitch receiver.
Secure the Main Tube to the receiver with the An-Tilt Bolt, Washer
and Nut. The Bolt must be inserted into the 7
/16” hole, not the 5 /8”
hole. Note: Do not put a washer at the bolt head, but rather at the
nut. The bolt head should be recessed into the receiver hole and be
pung pressure on the Main Tube of the Carrier inside the receiver.
Mount the three 3
/8” bolts to the
included An-Tilt Lock Bracket.
Insert bracket to the main tube
as shown.
Insert main tube into vehicle’s
receiver hitch and install hitch pin
(not included).
Put the bracket flush against the hitch collar. Tighten the center bolt unl it fits snugly
against the receiver hitch underside. Tighten the two side bolts; then re-ghten the center
bolt. Make sure all bolts are ght enough such than no slack exists between the main tube
and the hitch. Note: Road vibraon may cause bolts to loosen over me. Test by rocking
the carrier from the sides. Minor deformaon is normal on the contact area between the
main tube and the an-lt bracket.
AlternativeInstructions
Step1 Step2
Step3
Step7
Run the latch end of the safety lanyard through
the loops and secure to the eye bolt.
Handle
Safety Loop
Safety Loop
Handle
Safety Lanyard
Eyebolt for securing
safety lanyard latch
Step6
Aach the large outer ramp to the ramp base using the
same method as in Step 5. Bolt on the handle and the
safety loop on the side of the ramp. The expanded metal
mesh ramp surface has been removed for illustrave
clarity.
Outer Ramp
Safety
Handle
Safety
Loop
21
Step5
Once in place, screw in the le two pull pins to
lock both ramps in place. On the rightmost pull
pin, remove the nut and place the lanyard look
around the pin. The loop will have to go over the
threads on the pull pin. Screw the pin in place to
secure the lanyard and fasten all pull pins with
nuts. Screw in eye bolt to secure safety lanyard.
Hole for Eyebolt
Pull Pins and Nuts
Eyebolt
Loop of Safety Lanyard
goes around this pin
Safety
Lanyard
Closeup of Ramp
Base Plate
Step4
Aach the smaller inner ramp on the snger side. The small
ramp must go on first. Slide the round pin through the hook
on the right side of the ramp and lt the ramp unl the le
hook aaches over the le flat pin. Bolt on the handle and
the safety loop to the inner ramp.
Inner Ramp
Safety Handle
& Loop
Placement
2
1
Step3
Insert the ramp base into the adjustable slider and line
up the holes on both pieces. Make sure the ramp base
plate with holes is facing you if the snger is poinng off
to your right. Place the license plate cover over the holes
and secure the three pieces together at the desired
height with the two 5
/16” X 2 1 /2” adjustable bolts, nuts,
and washers. License Plate Holder: Push the square
plasc grommets for mounng the license plate through
the square holes in the rounded tab. Pull the wires for
the light through the large hole and fasten the light to
the holder with the screws provided with the light. Make sure the light is facing towards the
license plate.
Ramp Base
Ramp Base Plate
with Holes
License
Plate
Holder
Light
Snger
5
/16” x 2 1 /2” Bolt
5
/16” Washer
5
/16” Nut
Step2
Insert the adjustable slider into the snger and secure at the
desired length with the three 3
/8” x 3 /4” snger lock bolts.
Make sure all three bolts are secure against the slider.
Adjustable Slider
Angled Snger
3
/8” x 3 /4” Snger
Lock Bolt
Step1
Place the snger cover over the end of the angled
snger and align the holes. Secure the two pieces
together with the two 1
/2” x 2 1 /2” bolts, washers,
and nuts.
ASSEMBLINGYOURVERSAHAUL
1
/2” Snger Bolt
1
/2” Washer
1
/2” Nut
Angled Snger Snger Cover
mobilityscootersafetyramp
VH-SRINSTRUCTIONDIAGRAM
FormoreinformationonyourVersaHaul,pleasevisitwww.versahaul.com Problems?Questions?Callusat(888)818-9915
