Versitron VersiVision FVTM4CCx User manual

VersiVision
FVTM4CCx / FVRM4CCx
4-CHANNELSDIGITALLY ENCODED VIDEO,
4-CHANNELSBI-DIRECTIONAL DATA
AND
4-CHANNELSBI-DIRECTIONAL AUDIO
MULTIPLEXER
USER’S MANUAL
Revision C
©April 2007
VERSITRON, Inc.
83 Albe Drive / Suite C
Newark, DE 19702
www.versitron.com

1
www.versitron.com FVxM4CCx
PROPRIETARY DATA
All data in this manual is proprietary and may not be disclosed,
used or duplicated, for procurement or manufacturing purposes,
without prior written permission by VERSITRON.
WARRANTY
All VERSITRON products purchased after January 2001 carry a limited lifetime warranty
against defects in materials and workmanship for the lifetime of the product. Purchases made
prior to January 2001 are warranted for a period of one year from date of delivery. VERSITRON
reserves the right to repair or, at our option, replace parts which during normal usage prove to be
defective during the warranty period provided that:
1. You call VERSITRON at [phone] or [phone] and obtain a (RMA) Return
Authorization Number. Please reference your RMA number on the outside of the box in which the
item is returned.
2. Shipping charges are pre-paid.
No other warranty is expressed or implied and we are not liable for consequential damages.
For repairs outside of the warranty period, the same procedure must be followed.

2
www.versitron.com FVxM4CCx
Table Of Contents
General Information……………………………………………. 3
Introduction……………………………………………….…3
Technical Specifications………………………………….. 3
Installation Instructions………………………………………... 6
Installation Procedure……………………………………... 6
Indicator LEDs ………………….......................................... 7
System Terminal Block Connections………………....... 8
Troubleshooting………………………………………………… 14

3
www.versitron.com FVxM4CCx
GENERAL INFORMATION
Introduction:
The VERSITRON VersiVision FVTM4CCx and FVRM4CCx Series video, audio and data
transmitter and receiver support simultaneous transmission of four channels of 8-bit digitally
encoded video, four channels of 24-bit bi-directional digitally encoded audio and four channels
of bi-directional data over one single-mode or multi-mode optical fiber. The units are
universally compatible with major camera systems and support RS-485 data protocol. Plug
and Play design ensures ease of installation and electronic and optical adjustments are never
required.
Technical Specifications:
VIDEO
Video Input 1 volt pk-pk (75 ohms)
Bandwidth 5 Hz -8 MHz
Bit Resolution 8-bit
Differential Gain < 2%
Differential Phase < 0.6°
Tilt < 1%
S/N Ratio 67dB (Weighed)
DATA
Data Interface RS-485
Data Rate 100Kbps
Bit Error Rate 10-9
AUDIO
Audio Impedance 600 ohms
Input/output Level 0dBm(typical)
Frequency Response 10Hz-20KHz
Bit Resolution 24-bit
S/N Ratio 88Db
WAVELENGTH 850/1310nm Multimode
1310/1550nm Singlemode
Unit Type Model Number
4-Channel Digitally Encoded Video/4-Channel Bi-Directional Data/
4-Channel Bi-Directional Audio Transmitter FVTM-4CCx
4-Channel Digitally Encoded Video/4-Channel Bi-Directional Data/
4-Channel Bi-Directional Audio Receiver FVRM-4CCx

4
www.versitron.com FVxM4CCx
Technical Specifications (cont):
OPTICAL EMITTER Laser Diode
NUMBER OF FIBERS 1
CONNECTORS
Optical ST
Video BNC
Data/Audio ShieldedRJ-45 Plug
GENERAL
Power Supply 90V-260V AC 50-60Hz
Dimensions 18.98 x 9.76 x 1.77 Inches
Construction Aluminum
MTBF > 100,000 hours
Operating Temp -30° C to +50° C
Storage Temp -40° C to +85° C
Relative Humidity 0% to 95% (non-condensing)
INDICATOR
Module
Blue Video Sync Present
Blue Data Sync Present
Orange Power On

5
www.versitron.com FVxM4CCx
OPTICAL POWER BUDGET
Optical transmission distance is limited to optical loss of the fiber and any additional loss
caused by connectors, splices, and patch panels.
Transmitter ReceiverFiber Wavelength Model Output Model Sensitivity Optical
Power
Budget
Max
Distance
Multimode
Singlemode 850/1310nm FVTM 4CCx -5dBm
FVRM
4C Cx -26 dBm 21 dB 30km
Receiver TransmitterFiber Wavelength Model Output Model Sensitivity Optical
Power
Budget
Max
Distance
Singlemode 1310/1550nm FVRM
4CCx -10 dBm
FVTM
4CCx -22 dBm 12 dB 30km
CAUTION!
The transmitter unit contains alaser-emittingdiode located in the optical connector.
This device emits invisible infrared electromagneticradiation that can be harmful to
human eyes.The radiation from this optical connector, if viewed closely without any
protection,maycauseinstantaneous damage to the retina of the eye. Direct viewing
of this LED should be avoided at all times.

6
www.versitron.com FVxM4CCx
INSTALLATION INSTRUCTIONS
InstallationProcedure
The VERSITRON VersiVision FVTM4CCx and FVRM4CCx video transmission systems
series are preset for immediate use. There are indicator LEDs on the units for monitoring the
real-time status of video, data and power. The following instructions describe the typical
installation procedure and the function of the LED indicators located on each unit.
1. Connect the video source (camera) to the video input BNC connector on the transmitter unit
(FVTM4CCx) using coaxial cable.
2. Connect the video output BNC connector on the receiver unit (FVRM4CCx) to the video
monitor using coaxial cable.
3. Connect the fiber optic cable between the transmitter and receiver units.
4. Apply the power supply to both the transmitter and receiver units.
5. When the power is applied, the orange POWER LED will light, indicating the presence of
operating power. The blue VIDEO LED and the blue DATA LED will give an indication as
stated on the following pages.
6. The system should now be operational.

7
www.versitron.com FVxM4CCx
IndicatorLEDs
The stand-alone units have integral LEDs that are used to monitor the state of the unit. There
are four video LEDs, one power LED and one data LED on each unit. The indicator LEDs
function as follows:
TRANSMITTER and RECEIVER:
Power: ON: (Orange) Indicates that correct power has been applied
Transmitter:
Video: OFF: Indicates no video detected on input BNC connector
(No Video present on input BNC)
ON: (blue) Indicates video detected on input BNC connector
(Video present on input BNC)
Data: OFF: Indicates no data detected on the transmit data cable
Blinking: (Blue) Indicates data transmitted at the rate of the operation data.
Receiver:
Video: OFF: Indicates no video present on output BNC connector
(No Video present on output BNC)
ON: (Blue) Indicates video detected on output BNC connector
(Video present on input BNC)
Data: OFF: Indicates no data detected on the receive data cable
Blinking: (Blue) Indicates data received at the rate of the operation data.

8
www.versitron.com FVxM4CCx
System Terminal Block Connections (Transmitter)
The various input and output connections for the transmitter are as follows:
*Front Panel ofFVTM4CCx (Transmitter)
Data RS-485 Connection (Transmitter):
(Upper Data RJ45 Port)
RS-485 (Channel 1)
Terminal No.1—— RS-485 (+)
Terminal No.2—— RS-485 (-)
RS-485 (Channel 2)
Terminal No.3—— RS-485 (+)
Terminal No.4—— RS-485 (-)
RS-485 (Channel 3)
Terminal No.5—— RS-485 (+)
Terminal No.6—— RS-485 (-)
RS-485 (Channel 4)
Terminal No.7—— RS-485 (+)
Terminal No.8—— RS-485 (-)
RS485 Connection
Terminal Block for Data Connections
NOTE: Only the upper row of RJ-45 ports is used for these units. The lower row of
ports is for expanded models and is not used on these units. In addition, the two ports
above the label “TD”are used for VERSITRON testing.

9
www.versitron.com FVxM4CCx
Audio Input/Output Connection (Transmitter)
*Front Panel ofFVTM4CCx (Transmitter)
“A-IN” Connection
(Upper A-IN Port)
Channel 1
Terminal No.1—— Audio Input 1
Terminal No.2—— Ground
Channel 2
Terminal No.3—— Audio Input 2
Terminal No.4—— Ground
Channel 3
Terminal No.5—— Audio Input 3
Terminal No.6—— Ground
Channel 4
Terminal No.7—— Audio Input 4
Terminal No.8—— Ground
Audio Input ConnectionAudio Output Connection
Terminal Block for Audio Connections

10
www.versitron.com FVxM4CCx
“A-OUT” Connection
(Upper A-OUT Port)
Channel 1
Terminal No.1—— Audio Output 1
Terminal No.2—— Ground
Channel 2
Terminal No.3—— Audio Output 2
Terminal No.4—— Ground
Channel 3
Terminal No.5—— Audio Output 3
Terminal No.6—— Ground
Channel 4
Terminal No.7—— Audio Output 4
Terminal No.8—— Ground
Terminal Block for Audio Connections

11
www.versitron.com FVxM4CCx
System Terminal Block Connections (Receiver)
The various input and output connections for the receiver are as follows:
*Front Panel of FVRM4CCx (Receiver)
Data RS-485 Connection (Receiver):
(Upper RJ-45 Port)
RS-485(Channel1)
Terminal No.1—— RS-485 (+)
Terminal No.2—— RS-485 (-)
RS-485 (Channel 2)
Terminal No.3—— RS-485 (+)
Terminal No.4—— RS-485 (-)
RS-485 (Channel 3)
Terminal No.5—— RS-485 (+)
Terminal No.6—— RS-485 (-)
RS-485 (Channel 4)
Terminal No.7—— RS-485 (+)
Terminal No.8—— RS-485 (-)
RS485 Connection
NOTE: Only the upper row of RJ-45 ports is used for these units. The lower row of
ports is for expanded models and is not used on these units. In addition, the two ports
above the label “TD”are used for VERSITRON testing.
Terminal Block for Data Connections

12
www.versitron.com FVxM4CCx
Audio Input/Output Connection (Receiver)
*Front Panel of FV RM4CCx (Receiver)
“A-IN” Connection
(Upper A-IN Port)
Channel 1
Terminal No.1—— Audio Input 1
Terminal No.2—— Ground
Channel 2
Terminal No.3—— Audio Input 2
Terminal No.4—— Ground
Channel 3
Terminal No.5—— Audio Input 3
Terminal No.6—— Ground
Channel 4
Terminal No.7—— Audio Input 4
Terminal No.8—— Ground
Audio Input ConnectionAudio Output Connection
Terminal Block for
Audio
Connectio
n
s

13
www.versitron.com FVxM4CCx
“A-OUT” Connection
(Upper A-OUT Port)
Channel 1
Terminal No.1—— Audio Output 1
Terminal No.2—— Ground
Channel 2
Terminal No.3—— Audio Output 2
Terminal No.4—— Ground
Channel 3
Terminal No.5—— Audio Output 3
Terminal No.6—— Ground
Channel 4
Terminal No.7—— Audio Output 4
Terminal No.8—— Ground
Terminal Block for Audio Connections

14
www.versitron.com FVxM4CCx
TROUBLESHOOTING
Optical Fiber
The VERSITRON VersiVision FVTM4CCx and FVRM4CCx Series is available with most
applications using multi-mode or single-mode optical fibers. Please be certain that the correct
size and type of the fiber is being used for the particular mode transmitter/receiver combination.
Also be certain that the attenuation and bandwidth of the fiber optic cable being used is within
the range of the system’s loss budget specifications.
General
Any dirt or dust may easily pollute or block the fiber from accepting or radiating light.
Therefore, please try to keep the optical connector clear and always use the dust caps whenever
the connector is exposed to air. It is suggested that the tip of the optical connected should be
carefully cleaned with a lint-free cloth moistened with alcohol from time to time.
The status of any of the VIDEO LED should provide the first clue as to the origin of any
operational failure. If the VIDEO LED on the receiver unit is off, it usually means that the fiber
is broken or has too much attenuation.
Please also make sure that the transmitter and the receiver are not used in opposite position
If the system is still not working after examining the above possibilities, please contact our
Customer Service Department for further assistance
DataLink
Even when installed exactly as directed, it is possible that the data/audio function may fail to
operate properly. If this problem occurs, first please check the data cable, and then check
whether the data cable connector is firmly inserted into the RJ-45 port.
If the system is still not working after examining the above possibilities, please contact our
Customer Service Department for further assistance.
