Vertex Standard VX-131 Series User manual

FM Business Two-Way Radio
VX-131/132 Series
BRSBusiness Radio Service
Light Weight and Compact Size
2 Watts Power Output
1 and 2 Channel Models Available
*VX-131: 1 channel model
VX-132: 2 channel model
Super Rugged and Durable, Ergonomic Design
Meet Military Standards (810 C/D/E)
157 Programmable Private Codes* per Channel
*Continuous Tone Controlled Squelch System (CTCSS)
and Digital Code Squelch (DCS) for Silent Monitoring in
crowded RF environments
Battery Saver Circuit for Long Life Operation
3-minute Time-Out Timer (TOT)
Loud, Clear 500 mW Audio Output
ARTS™(Auto Range Transponding System)
Low Battery Indication
Desktop Overnight Charger
Durable and Flexible Antenna
MULTI-PURPOSE BUSINESS PORTABLE FOR
VX-132
VX-131
1 ch 2 ch
Actual Size

2004.1205NA(U) B9200476 Printed in Japan
Vertex Standard
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
Phone : [phone] ; Fax [phone]
http://www.vertexstandard.com
Accessories & Options
Included Accessories
MIL-SPEC TESTS and PROCEDURES
Compact Size and Light Weight
The high performance of the VX-131/132 is packed into a compact
(2.3" x 4.7" x 1.2" WHD) case, yielding a package that is small
enough to be unobtrusive yet large enough to provide a large
speaker and easy access to controls and switches. And the light
weight (less than 0.18 lb) of the VX-131/132 ensures that this
radio won’t weigh the user down!
2 Watts Power Output
Ideal for local-area communications, the 2-Watt power of the VX-
131/132
ensures long battery life, while providing outstanding
communications
range. Combined with Vertex’s legendary audio
quality, the robust power
output will get your message through!
One and Two Channel Versions Available
Choose the ultimate simplicity of the single-channel VX-131, or
the added flexibility of the two-channel VX-132, to meet your
custom communication needs.
157 Programmable Private Codes per Channel
Continuous Tone Controlled Squelch System (CTCSS) and
Digital Code Squelch (DCS) for Silent Monitoring in crowded RF
environments.
Battery Saver Circuit for Extended Operation
The VX-131 and VX-132 provide an innovative battery saver
feature that requires no user action to activate, yet it yields a
significant extension of operating time. The battery saver, after
a short period of not receiving signals, will periodically shut itself
down for short time intervals, while "polling" itself rapidly so as not
to miss incoming calls. The result is greatly reduced battery drain,
for more hours of operating between battery charges.
•Low Battery Indication •Durable and Flexible Antenna
Loud, Clear Receiver Audio
Providing up to a half Watt of crisp, clear audio from its receiver
section, the VX-131/132 is ideal for use in real-world working
environments. The careful design and large speaker ensure very
low distortion of received audio, for great user satisfaction.
Rugged and Durable, with Superb Ergonomics
Built to exceed the exacting ruggedness specifications of the U.S.
military, the VX-131/132 are constructed using a die-cast aluminum
chassis, along with an impact-resistant composite plastic case
to ensure years of reliable operation. Knobs and switches are
crafted for easy access, yet immunity from accidental bumping
of critical controls.
ARTS™(Auto Range Transponding System)
Included in the VX-131/132 is Vertex Standard’s exclusive ARTS™
feature,
which can be critically important in search-and-rescue
applications.
ARTS™provides a "hand-shake" with other ARTS™-
equipped transceivers,
and the display indicates if an "Out of
Range" condition exists. The base station can then alert the field
unit to move to a better location.
FNB-V67LI
7.4V 1600 mAh
Lithium-Ion Battery
FBA-25A
Alkaline Battery Case
(6 X AA)
FNB-V57
7.2 V 1100 mAh Ni-Cd
Battery Pack VAC-6800/6810
6-unit Multi Charger
VCM-1
Mobile Mounting Bracket
for VAC-800
Speaker/Microphone
MH-360S
Miniature type
MH-450S
Small type MH-37A4B
Earpiece/Microphone VC-25 VOX Headset
VAC-800B/C*
Desktop Rapid Charger
(for FNB-64/-V57)
VAC-810B/C*
Desktop Rapid Charger
(for FNB-67LI)
*B for 120 VAC/C for 230 VAC
VX-131/132 Series
FM Business Two-Way Radios
Standard
MIL 810C
Methods/Procedures
MIL 810D
Methods/Procedures MIL 810E
Methods/Procedures
Low Pressure
High Temperature
Low Temperature
Temperature Shock
Solar Radiation
Rain
Humidity
Salt Fog
Dust
Vibration 514.2/Procedure 8
Shock 516.2/Procedure 1
500.2/Procedure 1
501.2/Procedure 1, 2
502.2/Procedure 1, 2
503.2/Procedure 1
505.2/Procedure 1
506.2/Procedure 2
507.2/Procedure 2
509.2/Procedure 1
510.2/Procedure 1
514.3/Procedure 1 Cat. 10
516.3/Procedure 1, 4
500.3/Procedure 1
501.3/Procedure 1, 2
502.3/Procedure 1, 2
503.3/Procedure 1
505.3/Procedure 1
506.3/Procedure 2
507.3/Procedure 2
509.3/Procedure 1
510.3/Procedure 1
514.4/Procedure 1 Cat. 10
516.4/Procedure 1, 4
Measurements per EIA standards unless noted above. Specifications subject to change without notice or obligation.
General Specifications
Frequency Range 150-174 MHz 450-470 MHz
Number of Channels VX-131 1 ch / VX-132 2 ch
Channel Spacing 12.5/15/25/30 kHz 12.5/25 kHz
PLL Steps 2.5/5/6.25 kHz 5/6.25 kHz
Power Supply Voltage 7.5 VDC ±20 %
Operating Temperature Range –22°Fto +140°F (–30°Cto +60°C)
Frequency Stability ±2.5 ppm
Dimensions 2.3" (W)X4.7" (H)X1.2" (D)(58X120X31 mm)
Weight (Approx) 0.81 lb. (365 g) w/FNB-64
Specifications
Receiver Specifications Measurements made per EIA standard TIA/EIA-603
Sensitivity
EIA 12 dB SINAD 0.20 µV 0.25 µV
20 dB Quieting 0.30 µV 0.35 µV
Adjacent Channel Selectivity 65 dB (25 kHz) / 60 dB (12.5 kHz)
Intermodulation 65 dB
Spurious and Image Rejection 65 dB
Hum & Noise 45 dB
Audio Output 500 mW @4 Ohms, 5 % THD
Transmitter Specifications Measurements made per EIA standard TIA/EIA-603
Power Output 2 W
Modulation 16K0F3E, 11K0F3E
Conducted Spurious Emissions 60 dB Below Carrier
FM Hum & Noise 40 dB (25 kHz) / 35 dB (12.5 kHz)
Audio Distortion
(
@1 kHz
)<5 %
And more....
BRS Business Radio Service
•FNB-64
7.2 V 700 mAh Ni-Cd Battery Pack •NC-77B/C
Wall Charger
(B for 120 VAC/ C for 240 VAC)
VHF UHF VHF UHF
•Spring Belt Clip •Antenna
