VX-261
oPerating manual

 
 
 
 
 BatteryPackInstallationandRemoval....................... 6
 BatteryCharging......................................................... 6
 LowBatteryIndication................................................ 7
 BeltClipInstallationandRemoval............................. 8
 MIC/SPCapInstallation............................................. 8
 
 
 PreliminarySteps...................................................... 10
 OperationQuickStart................................................ 10
 AutomaticTime-OutTimer....................................... 12
 
 ProgrammableKeyFunctions.................................. 13
 DescriptionofOperatingFunctions......................... 14
 
 
 
contents

Younowhaveatyourngertipsavaluablecommunicationstool,aVertexStandardtwo-wayradio!Rugged,reliableand
easytouse,yourVertexStandardradiowillkeepyouinconstanttouchwithyourcolleaguesforyearstocome,withnegli-
giblemaintenancedown-time.Pleasetakeafewminutestoreadthismanualcarefully.Theinformationpresentedherewill
allowyoutoderivemaximumperformancefromyourradio,incasequestionsariselateron.

r Therearenoowner-serviceablepartsinsidetheradio.AllservicejobsmustbereferredtoanauthorizedVertex
StandardServiceRepresentative.
r Inordertomaintainthespeciedwaterintegrityperformance,periodicmaintenanceisrecommended.
r Shouldtheradiosustainasevereshock(e.g.ifitisdropped),thewaterintegritymaybecompromised,requiring
service.Shouldthisoccur,contactyourAuthorizedVertexStandardDealer.

VX-261 Operating Manual 1

TheU.S.CoastGuardandNationalOceanographicandAtmosphericAdministrationhaverequestedthecooperation
oftheU.S.FederalCommunicationsCommissioninpreservingtheintegrityoftheprotectedfrequencyrange406.0
to406.1MHz,whichisreservedforusebydistressbeacons.Donotattempttoprogramthisapparatus,underany
circumstances,foroperationinthefrequencyrange406.0-406.1MHziftheapparatusistobeusedinornearNorth
America.
Warning-Frequencyband406-406.1MHzisreservedforuseONLYasadistressbeaconbytheUSCoastGuard
andNOAA.Undernocircumstanceshouldthisfrequencybandbepartofthepreprogrammedoperatingfrequencies
ofthisradio.
introduction
TheVX-261isfull-featuredHand-HeldAnalogTransceiverdesignedforbusinesscommunicationsintheVHF/UHFLand
Mobilebands.Thistransceiverisdesignedforreliablebusinesscommunicationsinawidevarietyofapplicationswitha
widerangeofoperatingcapabilityprovidedbytheirleading-edgedesign,andallowsupto16-channelcapacity.
Importantchannelfrequencydataisstoredintheashmemory,andiseasilyprogrammablebyaVertexStandardlicensed
dealersusingapersonalcomputerwithVertexStandardProgrammingequipment:FIF-12USBProgrammingInterface,and
CT-106ConnectioncablewithCE150PCProgrammingSoftware.Or,onceasingleradioisprogrammed,cloningcable
CT-27canbeusedtoprogramadditionalradiosdirectly.
ThismanualwilldescribethedetailsofthemanyadvancedfeaturesoftheVX-261.Afterreadingthismanual,youmay
wishtoconsultwithyourNetworkAdministratorregardingprecisedetailsofthecongurationofthisequipmentforusein
yourapplication.

2
VX-261 Operating Manual
Warning! Fcc rF exPosure requirements
ThisRadiohasbeentestedandcomplieswiththeFederalCommunicationsCommission(FCC)RFexposurelimitsforOc-
cupationalUse/Controlledexposureenvironment.Inaddition,itcomplieswiththefollowingStandardsandGuidelines:
r FCC96-326,GuidelinesforEvaluatingtheEnvironmentalEffectsofRadio-FrequencyRadiation.
r FCCOETBulletin65 Edition97-01(2001) SupplementC, EvaluatingCompliancewithFCCGuidelines forHuman
ExposuretoRadioFrequencyElectromagneticFields.
r ANSI/IEEEC95.1-1992,IEEEStandardforSafetyLevelswithRespecttoHumanExposuretoRadioFrequencyElec-
tromagneticFields,3kHzto300GHz.
r ANSI/IEEEC95.3-1992,IEEERecommendedPracticefortheMeasurementofPotentiallyHazardousElectromagnetic
Fields-RFandMicrowave.

ThisradiogeneratesRFelectromagneticenergyduringtransmitmode.Thisradioisdesignedforandclassiedas
Occupational Use Only,meaningitmustbeusedonlyduringthecourseofemploymentbyindividualsawareofthe
hazards,andthewaystominimizesuchhazards.ThisradioisnotintendedforusebytheGeneralPopulationinan
uncontrolledenvironment.

ToensurethatyourexposetoRFelectromagneticenergyiswithintheFCCallowablelimitsforoccupationaluse,
alwaysadheretothefollowingguidelines:
 


                   

 


VX-261 Operating Manual
3
Warning! Fcc rF exPosure requirements


 

 


 

 
 

 
 

 


4
VX-261 Operating Manual
Warning! ic rss general requirement
english
r UnderIndustryCanadaregulations,thisradiotransmittermayonlyoperateusinganantennaofatypeandmaximum(or
lesser)gainapprovedforthetransmitterbyIndustryCanada.Toreducepotentialradiointerferencetootherusers,the
antennatypeanditsgainshouldbesochosenthattheequivalentisotropicallyradiatedpower(e.i.r.p.)isnotmorethan
thatnecessaryforsuccessfulcommunication.
r Thisradiotransmitter(identifythedevicebycerticationnumber,ormodelnumberifCategoryII)hasbeenapproved
byIndustryCanadatooperatewiththeantennatypeslistedattheright
with the maximum permissible gain and required antenna impedance
foreachantennatypeindicated.Antennatypesnotincludedinthislist,
having a gain greater than the maximum gain indicated for that type,
arestrictlyprohibitedforusewiththisdevice.
                   

 

 


 

 

VhF model uhF model
 ATV-8A:−2.15dBi,50-ohm  ATU-6A:−2.15dBi,50-ohm
 ATV-8B:−2.15dBi,50-ohm  ATU-6B:−2.15dBi,50-ohm
 ATV-8C:−2.15dBi,50-ohm  ATU-6C:−2.15dBi,50-ohm
ATV-6XL:−2.15dBi,50-ohm  ATU-6D:−2.15dBi,50-ohm
 ATU-6F:−2.15dBi,50-ohm

VX-261 Operating Manual
5
French
r Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne
d’untypeetd’ungainmaximal(ouinférieur)approuvépourl’émetteurparIndustrieCanada.Danslebutderéduireles
risquesdebrouillageradioélectriqueàl’intentiondesautresutilisateurs,ilfautchoisirletyped’antenneetsongainde
sortequelapuissanceisotroperayonnéequivalente(p.i.r.e.)nedépassepasl’intensiténécessaireàl’établissementd’une
communicationsatisfaisante.
r Leprésentémetteurradio(identierledispositifparsonnumérodecerticationousonnumérodemodèles’ilfaitpar-
tiedumatérieldecatégorieI)aétéapprouvéparIndustrieCanadapour
fonctionneraveclestypesd’antenneénumérésdansledroitetayantun
gainadmissiblemaximaletl’impédancerequisepourchaquetyped’an-
tenne.Lestypesd’antenne noninclusdans cetteliste,ou dontlegain
est supérieur au gain maximal indiqué, sont strictement interdits pour
l’exploitationdel’émetteur.
 

 

  



 


 

Warning! ic rss general requirement
VhF modèle uhF modèle
 ATV-8A:−2.15dBi,50-ohm  ATU-6A:−2.15dBi,50-ohm
 ATV-8B:−2.15dBi,50-ohm  ATU-6B:−2.15dBi,50-ohm
 ATV-8C:−2.15dBi,50-ohm  ATU-6C:−2.15dBi,50-ohm
ATV-6XL:−2.15dBi,50-ohm  ATU-6D:−2.15dBi,50-ohm
 ATU-6F:−2.15dBi,50-ohm

6
VX-261 Operating Manual
beFore You begin
r To remove the battery, turn the radio off and remove
anyprotectivecases.SlidetheBatteryPackLatchon
the bottom of the radio toward the front panel while
slidingthebatterydownabout1/2inch(1.5cm).Then
liftthebatteryoutfromtheradio.




r Toinstallthebatterypack,alignthebatterypacktothe
radiowithanoffsetabout1/2inch(1.5cm)fromthe
topedgeofbatterycompartment,thenslidethebattery
packupwarduntilitlocksinplacewitha“Click.”

r RemovetheSpacerPlatefromthenestoftheoptional
CD-58 Desktop Charger, if the Battery Spacer is in-
stalled.
r InserttheDCplugfromtheoptionalPA-55AC
AdapterintotheDCjackontherearpaneloftheop-
tional CD-58 Desktop Charger, and then connect the
PA-55ACAdaptertotheAClineoutlet.
r InsertthebatterypackintotheCD-58DesktopChar-
gerwhilealigningtheslotsofthebatterypackwiththe
guides in the nest of the CD-58; refer to the follow-
ingillustrationfordetailsonproperpositioningofthe
PA-55
CD-58
SpacerPlate ACLineOutlet

VX-261 Operating Manual
7
beFore You begin
batterypack.Ifchargingwiththetransceiverattached,
turnthetransceiveroff.Theantennajackshouldbeat
theleftsidewhenviewingthechargerfromthefront.
rIf the battery pack is inserted correctly, the LED in-
dicatorwillglowred.Afully-dischargedbatterypack
will charge completely in 1.5 - 3.0 hours (depending
onthebatterypackbeingcharged).
r When charging is completed, the LED indicator will
changetogreen.
r DisconnectthebatterypackfromtheCD-58Desktop
Chargerand unplug the PA-55ACAdapter from the
AClineoutlet.
1) Always use the Vertex Standard FNB-V133LI-
UNI or FNB-V134LI-UNI Lithium-Ion Battery
Pack.
2) Use only the Vertex Standard CD-58 Desktop Charger
and the Vertex Standard PA-55 AC Adapter.
3) To reduce the risk of explosion, recharge the batteries
outside of hazardous locations.
4) Perform the battery charging where the ambient tem-
perature range +41 °F to +104 °F (+5 °C to +40 °C).
Charging outside of this temperature range could cause
damage to the battery pack.
5) Battery Pack should not be exposed to excessive heat
such as sunshine, re, or similar heat sources.
6) Risk of explosion exists if battery is replaced by an
incorrect type. Refer to the enclosed instructions for dis-
posal of used batteries.
7) For further details and cautions of the charging, refer
to the Operating Manual of the CD-58 Desktop Charger.

Asthebatterydischargesduringuse,thevoltagegradually
becomeslower.Whenthebatteryvoltagebecomestoo
low,substituteafreshlychargedbatteryandrechargethe
depletedpack.TheLEDindicatoronthetopoftheradio
willblinkredwhenthebatteryvoltageislow.
CAUTION
Dangerofexplosionifbatteryisreplacedwithan
incorrectbattery.Replaceonlywiththesame or
equivalenttype.

8
VX-261 Operating Manual

beFore You begin
r ToinstalltheBeltClip:alignthe
BeltCliptothegrooveoftheBat-
terypack,thenpresstheBeltClip
downward until it locks in place
witha“Click.”
r To remove the Belt Clip: use a
atheadscrewdrivertopressthe
BeltClipTabawayfromthebat-
terypacktounlocktheBeltClip,
thenslidetheBeltClipupwardto
removeit.

r    
MIC/SP 
r

MIC/SP
MIC/SP
InstalltheMIC/SPcapwiththesup-
pliedscrews.
Belt Clip Tab

VX-261 Operating Manual
9
MIC/SPJack
(ExternalMIC/SP)
controls & connectors
LEDIndicator(Programmable)
 Defaultsettingsare:
 SteadyRed: Transmittinginprogress
 BlinkingGreen:BusyChannel
 SteadyGreen: ToneSquelchindefeatedcondition
PTTSwitch
SIDE-1Button
SIDE-2Button
SpeakerMicrophone
BatteryPackLatch
AntennaJack
CH(Channel)Selector VOL(Volume)/PWR(Power)Knob

10
VX-261 Operating Manual
oPeration

r Installachargedbatterypack ontothe transceiver, as
describedpreviously.
r Screwthesuppliedantenna
ontotheAntennajack.
 It is not recommended to oper-
atethistransceiverwithoutan
antennaconnected.
r IfyouhaveaSpeaker/Micro-
phone,werecommendthatit
not be connected until you are
familiarwiththebasicopera-
tion of the VX-261. Refer to
nextpageformoreinformation
aboutSpeaker/Microphoneus-
age.
IMPORTANT NOTE
Thewaterresistanceratingofthetransceiver(IP55)
isassuredonly whenthe followingconditions are
met:
r Batterypackisattachedtothetransceiver;
r Antennaisconnectedtotheantennajack;
r
MIC/SPcapisinstalledintheMIC/SPjack.
r Useofaspeakermicrophone intheMIC/SP
jacknegatestheIP55rating.

r Tu r n th e t o p p a n e l’s
VOL/PWR knob clock-
wisetoturntheradioon.
r Turn thetoppanel’s CH
Selector knob to choose
thedesiredoperating
channel.
r RotatetheVOL/PWR
knobto set thevolume
level.Ifnosignalis
present,press(orpress
and hold) the Program-
mablekey(assignedto
the “sql oFF” func-
tion:NormallySIDE-1button);backgroundnoisewill
nowbe heard, and youmayuse this to setthe VOL/
PWRknobforthedesiredaudiolevel.Press(orpress
andhold)theProgrammablekeyagaintoquietthe

VX-261 Operating Manual
11
oPeration
noiseandresumenormal
(quiet)monitoring.
r To transmit, monitor the
channelandmakesureit
isclear.
 Press and hold the PTT
switch.Speakintothe
microphoneareaofthe
front panel grille in a
normalvoicelevel.ToreturntotheReceivemode,re-
leasethePTTswitch.
r Press(orpressandhold)
the SIDE-1 or SIDE-
2 button to activateone
of the pre-programmed
functionswhichmay
havebeenenabledatthe
timeofprogrammingby
the dealer. See the next chapter for details regarding
featureavailabilityforthisradio.
r IfaSpeaker/Microphone
is available, remove the
plasticcapanditstwo
mountingscrewsfrom
therightsideofthe
transceiver,thenalign
theconnectorofthe
Speaker/Microphoneon
theradio;securethecon-
nectorpinusingthescrewssuppliedwiththeSpeaker/
Microphone. Hold the speaker grille up next to your
earwhilereceiving.Totransmit,pressthePTTswitch
ontheSpeaker/Microphone,justasyouwouldonthe
maintransceiver’sbody,andspeakintothemicro-
phoneonanormalvoicelevel.
Note 1): Save the original plastic cap and its mount-
ing screws. They should be reinstalled when not us-
ing the Speaker/Microphone.
2) When you press the PTT switch on the Speaker/
Microphone, it disables the internal microphone, and
vice versa.
r IftheBCLO(BusyChannelLockout)featurehasbeen
programmedonachannel,theradiowillnottransmit
whenacarrierispresent.Instead,theradiowillgener-
ateshortbeepthreetimes.ReleasethePTTswitchand
waitforthechanneltobeclearofactivity.

12
VX-261 Operating Manual
oPeration
r If the BTLO (Busy Tone Lockout) feature has been
programmedonachannel,theradiocantransmitonly
when there is no carrier being received or when the
carrierbeingreceivedincludesthecorrecttone(CTCSS
toneorDCScode).

Iftheselectedchannelhasbeenprogrammedforauto-
matic time-out, you must limit the length of each trans-
mission.Whiletransmitting,abeepwillsound10seconds
before time-out.Another beep will sound just before the
deadline; the top panel’s red LED (“TX” indicator) will
disappearandtransmissionwillceasesoonthereafter.To
resumetransmitting,youmustreleasethePTTswitchand
waitforthe“penaltytimer”toexpire.

VX-261 Operating Manual
13
adVanced oPeration

TheVX-261 provides two Programmable Function (PF)
keys:SIDE-1andSIDE-2keys.
BothPF keyscan becustomized,viaprogrammingby
your Vertex Standard dealer, to meet your communica-
tions/networkrequirements.
ThepossiblePFkeyprogrammingfeaturesareillustrated
at the right, and their functions are explained beginning
after next page. For further details, contact yourVertex
Standarddealer.
Forfuturereference,checktheboxnexttoeachfunction
that has been assigned to the PF key on your particular
radio,andkeepithandy.
Function
Programmable KeY
(Press KeY / Press and hold KeY)
SIDE-1 SIDE-2
None / /
Monitor / /
Monitor-Momentarily- /--- /---
LowPower / /
SQLOFF / /
SQLOFF-Momentarily- /--- /---
BeepOFF / /
Whisper / /
VOX / /
VOXAnti-Trip / /
Emergency ---/ ---/
LoneWorker / /
PRI / /
Scan / /
DualWatch / /
Follow-MeScan / /
TA(TalkAround)Scan / /
TalkAround / /
Reset / /
Call1 / /
Call2 / /
Call3 / /
SpeedDial / /
Call / /
Duty / /
TXSaveDisable / /
Lock / /

14
VX-261 Operating Manual
adVanced oPeration

WhisPer
Press,(orpressandhold),theassignedPFkeytoincrease
themicrophonegain;allowingtheoperatortospeakina
lowvoice(whisper)temporarilywhentransmitting.Press
again,(or press and hold again), the assigned PF key to
resumenormalmicrophonegain.
Vox (requires Vox comPatible headset)
Press,(orpressandhold),theassignedPFkeytoactivate
theVOXfunction;allowinghands-free,automaticactiva-
tionofthetransmitter,initiatedby voiceinputintothe
microphone.YoumaydisabletheVOXfunctiontempo-
rarilybypressingthePTTswitch.
Press again, (or press and hold again), the assigned PF
keytoresumenormaloperation.
Vox anti-triP
Press,(orpressandhold),theassignedPFkeytotoggle
theVOXAnti-Tripfeature“On”and“Off”.
WhentheVOXAnti-Tripfeatureissetto“On”,thetrans-
ceiverdoesnotactivateaVOXtransmissionfrompicking
upreceiveaudioorfromaradioalerttone(beepsound).
monitor
Press,(orpressandhold),theassignedPFkeytocancel
anysignalingfeatures;theLEDindicatorwillglowgreen.
monitor -momentarilY-
Cancelanysignalingfeatureswhilepressingtheassigned
PFkey.
loW PoWer
Press,(orpressandhold),theassignedPFkeytosetthe
radio’stransmitterto“LowPower”mode,thusextending
battery life. Press, (or press and hold), the assigned PF
keyagain toreturn to“Normal” transmitpower whenin
RFimpedingenvironments.
sql oFF
Press,(orpressandhold),theassignedPFkeytoopenthe
SQLtohearbackgroundnoise(unmutetheaudio).
sql oFF -momentarilY-
OpenstheSQLtohearbackgroundnoise(unmutetheau-
dio)whilepressingtheassignedPFkey.
beeP oFF
Press, (or press and hold), the assigned PF key to dis-
able any radio beeps temporarily. Press again, (or press
andholdagain),theassignedPFkeytoenableanyradio
beeps.

VX-261 Operating Manual
15
adVanced oPeration
emergencY
TheVX-261includesan“Emergency”featurewhichmay
be useful for alerting another party monitoring on the
samefrequencyasyourtransceiver’schannel.Pleasecon-
tactyourVertexStandarddealerforfurtherdetails.
PressandholdtheassignedPFkeyforapre-programmed
periodtoinitiateanemergencycallonthepre-defined
channel.
TorevivetheradiofromtheEmergencymode,justpress
andholdagaintheassignedPFkeyorturnofftheradio.
lone WorKer
Press,(orpressandhold),theassignedPFkeytoactivate
theLoneWorkerfeature.The LoneWorkerfeatureis
designedtoemitanalarmfor30secondswhentheLone
Worker Timer (programmed by your Vertex Standard
dealer)hasexpired.
Press again, (or press and hold again), the assigned PF
key,theLoneWorkerfeatureisdisabled.Iftheuserdoes
notresetthetimerbypressingthePTTswitch,theradio
switchestoEmergencymode.
Pri
Press,(or press and hold), the assigned PF key to recall
thepre-programmedPriorityChannelbyyourVertex
Standarddealerdirectly.
scan
The Scanning feature is used to monitor multiple chan-
nelsprogrammedintothetransceiver.Whenscanning,the
transceiverwillcheckeachchannelforthepresenceofa
signalandwillstoponachannelifasignalispresent.
To activate scanning:
r Press,(orpressandhold),theassignedPFkeytoacti-
vatescanmode.
r The scanner will search the channels of the pre-pro-
grammedscanlist,lookingforanactivechannel.The
radiowillpauseeachtimeitndsachannelonwhich
someoneisspeaking.
r Pressagain,(orpressandholdagain),theassignedPF
keytodisablescanningandreceivethechannelwhich
waschosenwhenpressedthePFkey.
Note:Your dealer may have programmed your radio to
stayononeofthefollowingchannelsifyoupressthe
PTTswitchduringscanningpause:
“ScanPause”channel(“TalkBack”)
“LastBusy”channel
“Priority”channel
“UserProgrammed”channel(“SelectChannel”)
ThechannelwhichdefinedintheCHSelector
knob.

16
VX-261 Operating Manual
adVanced oPeration
dual Watch
The Dual Watch feature is similar to the SCAN feature,
exceptthatonlytwochannelsaremonitored:
 Thecurrentoperatingchannel
 ThePrioritychannel.
To activate Dual Watch:
r Press,(orpressandhold),theassignedPFkeytoacti-
vatetheDualWatchfeature.
r The scanner will search the two channels and pause
whenitndsatransmissiononeitherchannel.
To stop Dual Watch:
r Press,(orpressandhold),theassignedPFkeytodis-
abletheDualWatch feature.Theradioreceivesthe
channelwhichwasselectedbytheCHSelectorknob.
FolloW me scan
The Follow Me Scan feature checks a user-assigned pri-
ority channel in addition to the channels previously pre-
programmedintoaradio’sscanlist.Forexample,ifonly
Channels1,3,and5(ofthe8availablechannels)are
designatedfor“Scanning”,theusermayassignChannel2
asthe“user-assigned”prioritychannelviatheFollowMe
Scan.
ToactivateFollowMe Scan, rstselectthe channel you
wanttodesignateas the“user-assignedprioritychannel”
bypositioningtheCHSelectorknobonthedesired“pri-
ority” channel. Next, press, (or press and hold), the as-
signedPFkey.Finally,rotatetheCHSelectorknobtothe
desired“operatingchannel”.
The scanner will search the two channels (user-assigned
prioritychannelandoperatingchannel)andpausewhenit
ndsatransmissiononeitherchannel.

VX-261 Operating Manual
17
ta (talK around) scan
Press,(orpressandhold),theassignedPFkeytotoggle
theTAScanfeature“On”and“Off”.
Whenoperatingonaduplexchannelsystem(forexample,
a repeater station), TA Scan allows the transceiver to
searchbothtransmitandreceivefrequenciesonyourdu-
plexsystem.
When a signal is encountered on the receive frequency,
thetransceiver willpauseuntilthesignaldisappears.
When a signal is encountered on the transmit frequency,
thetransceiver willcheck foractivity onthe receive fre-
quencyeveryfewseconds(intervalprogrammedbyyour
VertexStandarddealer).
Note:TheTAScanfeaturedoesnotactivateonaSimplex
Channel.
talK around
Press,(orpressandhold),theassignedPFkeytoactivate
theTalkAroundfeaturewhenyouareoperatingonduplex
channel systems (separate receive and transmit frequen-
cies,utilizinga“repeater”station).TheTalkAround
featureallowsyoutobypasstherepeaterstationandtalk
directlytoastationthatisnearby.Thisfeaturehasnoef-
fectwhenyouareoperatingon“simplex”channels,where
thereceiveandtransmitfrequenciesarealreadythesame.
Notethatyourdealermayhavemodeprovisionfor“Talk
Around” channels by programming “repeater” and “Talk
Around”frequenciesontwoadjacentchannels.Ifso,the
keymaybeusedfor oneoftheotherPre-Programmed
Functions.
Note:TheTalkAroundfeaturedoesnotactivateonaSim-
plexChannel.
reset
Press(orpressandhold)theassignedPFkeytoresetthe
RFC(ReadyforCommunication)condition.
call 1 to call 3
Press,(orpressandhold),theassignedPFkeytosenda
pre-programmed5-Tonecallsignal.
adVanced oPeration

18
VX-261 Operating Manual
adVanced oPeration
sPeed dial
Your Vertex Standard dealer may have pre-programmed
Auto-Dialtelephonenumbermemoriesintoyourradio.
Todialanumber:
Press,(orpressandhold),theassignedPFkeytosenda
pre-denedDTMFtone.TheDTMFtonessentduringthe
dialingsequencewillbeheardinthespeaker.
call
Press,(orpressandhold),theassignedPFkeytosenda
pre-programmed2-Toneencodecode.
dutY
Press,(orpressandhold),theassignedPFkeytotoggle
theDutyfunctionofthe2-Toneor5-Tone“On”and“Off”.
When the Duty function is set to “On”, the user will al-
wayshear(dependingonthesub-audiosignaling)alltraf-
conthepagingchannel.Theradiowillsoundthepaging
alertwhenitreceivestheprogrammed2-Toneor5-Tone.
WhentheDutyfunctionissetto“Off”,theuserwillNOT
hearnormalradiotrafconthepagingchannel.Theradio
will sound the paging alert and unmute only when it re-
ceivestheprogrammed2-Toneor5-Tone.
tx saVe disable
The Transmit Battery Saver helps extend battery life by
reducingtransmit power when a very strong signal from
anapparentlynearby stationis beingreceived.Caution
is advised when using this feature, as your transmission
powercoulddegradetheaudioheardbythereceivingra-
diosinyourcommunicationpath.
Press,(orpressandhold),theassignedPFkeytodisable
theTransmitBatterySaver,ifyouareoperatinginaloca-
tionwherehighpowerisalmostalwaysneeded.
Press again, (or press and hold again), the assigned PF
key, the Transmit Battery Saver activates to reduce the
transmitpowerwhenaverystrongsignalfromanappar-
entlynearbystationisbeingreceived.
locK
Press(orpressandhold)theassignedPFkeytolockthe
CHSelectorknob,Programmablekeys,andPTTswitch.
