Vertex SR Series User manual

VERTEX AQUARISTIK
Illumina
SR Series
Owner’s Manual

- 2 -
CONTENTS
Chapter 1: Getting Started
3 What You Need
3 Safety Considerations
4 IlluminaSRSpecications
5 LEDPadSpecications
6 Components
6 Out of the Box
Chapter 2: Basics
7 Getting to Know the Features
9 Installing Your Illumina SR
14 Operation
14 Button Controls
15 Menu Structure
Chapter 3: Advance Features
16 Light Manager
18 Quick Motion
18 Settings
19 Info
19 Updating Your Illumina Firmware
Chapter 4: Maintenance & LED
Module Guide
20 Considerations and Guidelines
21 Cleaning the Central Air Shaft
21 Removing Dust and Debris
22 LED Modules
23 Firmware Upgrade
Chapter 5: Additional Information
23 FAQ and Troubleshooting
24 Warranty Information
24 Contacts
WARNING: To avoid injury, read all the operang instrucons presented within this guidebook. When using
or installing electrical devices, take care and/or consult with a professional.
Be sure to follow all direcons carefully – failure to do so may result in damage to your Vertex® Illumina
and void the warranty
Dealers or the manufacturer are not responsible and cannot be held accountable for any personal/prop-
erty damage and/or loss of livestock resulng from the misuse of products.

- 3 -3
CHAPTER 1: Getting Started
What You Need
Thank you for your purchase of the Vertex Illumina SR LED Fixture.
This User-Manual is your guide to getting the most out of your product. Please be sure to read all of
theinstructionspresentwithinpriortoinstallingandoperatingyourxture.
Retain this manual in a safe place for later referral as required.
In order to properly use the Vertex Illumina, you will need:
lAn aquarium or illumination subject appropriately sized to the length of your Illumina.
lA mounting point above the tank able to support the weight of your respective Illumina.
(optional)
lThis mounting point will need to allow for two anchor points.
lYou will need to maintain at least 4” of height between the surface of the water/subject
and the bottom surface of the Illumina.
l
l
lGFCI protected electrical outlets for each Mean Well driver. The outlets required are as follows:
lSR 300 – One (1) outlet
lSR 600 – One (1) outlet
lSR 900 – Two (2) outlets
lSR 1200 – Two (2) outlets
lSR 1500 – Three (3) outlets
lSR 1800 – Three (3) outlets
* Please be sure to connect your Illumina only to electrical outlets of the proper voltage (110 or 220V).
Failure to do so will result in failure of the unit and is not covered by warranty.
Safety Considerations
Your Vertex Illumina has been designed to be used as a point source of illumination over an aquarium.
Please note that while the unit is humidity resistant, it is NOT waterproof. It is absolutely crucial to
mount the unit to a sturdy foundation. Direct contact with water will damage the unit and void war-
ranty.Westronglyrecommendthatinstallationonlybeperformedbyacertiedprofessional.
Similarly, measures must be taken to keep all of the power sources, splitter control box and cables dry
and protected from humidity. Exposure to water and/or salt will damage these components and void
warranty.
There must be at least 5-6” of ventilated space around the Illumina at all times to allow for
proper and thorough air circulation. The Illumina must, at no time, come into contact with
any of the mounting surfaces and/or water.
The Illumina must be suspended in such a way as to protect it from any water spray or
emergent plants or animals/objects.

CHAPTER 1: Getting Started
- 4 -4
CHAPTER 1: Getting StartedCHAPTER 1: Getting Started
SR 300 (260/360)
Dimensions
300mm x 300mm | 12” x 12” Footprint
32mm | 1.26” / 45mm | 1.77” Center Height
Weight
3.2 kg | 7.1 lbs
LED Modules
2
Auxiliary Slots
1
Mean Well Drivers
1
Fans
1 x SilenX Ixtrema Pro IXP-52-14
Performance
~96W/112W, 90-270 V / 50-60Hz
SR 900 (260/360)
Dimensions
900mm x 300mm | 12” x 12” Footprint
32mm | 1.26” / 45mm | 1.77” Center Height
Weight
10 kg | 22.5 lbs
LED Modules
6
Auxiliary Slots
5
Mean Well Drivers
2
Fans
2 x SilenX Ixtrema Pro IXP-52-14
Performance
~289W/335W, 90-270 V / 50-60Hz
SR 600 (260/360)
Dimensions
600mm x 300mm | 12” x 12” Footprint
32mm | 1.26” / 45mm | 1.77” Center Height
Weight
6.6 kg | 14.55 lbs
LED Modules
4
Auxiliary Slots
3
Mean Well Drivers
1
Fans
1 x SilenX Ixtrema Pro IXP-52-14
Performance
~193W/224W, 90-270 V / 50-60Hz
SR 1200 (260/360)
Dimensions
1200mm x 300mm | 12” x 12” Footprint
32mm | 1.26” / 45mm | 1.77” Center Height
Weight
13.6 kg | 30.0 lbs
LED Modules
8
Auxiliary Slots
7
Mean Well Drivers
2
Fans
2 x SilenX Ixtrema Pro IXP-52-14
Performance
~385W/447W, 90-270 V / 50-60Hz
Illumina SR Specications

- 5 -
CHAPTER 1: Getting Started
SR 1500 (260/360)
Dimensions
1500mm x 300mm | 12” x 12” Footprint
32mm | 1.26” / 45mm | 1.77” Center Height
Weight
15.5 kg | 34.17 lbs
LED Modules
10
Auxiliary Slots
9
Mean Well Drivers
3
Fans
3 x SilenX Ixtrema Pro IXP-52-14
Performance
~482W/559W, 90-270 V / 50-60Hz
SR 1800 (260/360)
Dimensions
1800mm x 300mm | 12” x 12” Footprint
32mm | 1.26” / 45mm | 1.77” Center Height
Weight
19 kg | 41.9 lbs
LED Modules
12
Auxiliary Slots
11
Mean Well Drivers
3
Fans
3 x SilenX Ixtrema Pro IXP-52-14
Performance
~578W/670W, 90-270 V / 50-60Hz
I-260 (June 2012)
LED Make
Cree
CHANNELS
White
XTE - 130lm/W
Royal Blue
XTE - 475mV
Blue
XTE - 30.6m/W
LEDs per Module
16
Performance / Module
43,78W, 90-270 V / 50-60Hz
50,000hours@≤135°Fcore
diode temperature
I-360
LED Make
Cree
CHANNELS
White
XTE - 148lm/W
Royal Blue
XTE - 550mV
Blue
XPG - 39,8lm/W
LEDs per Module
16
Performance / Module
50,82W, 90-270 V / 50-60Hz
50,000hours@≤135°Fcore
diode temperature
LED Pad Specications
Illumina Specications

- 6 -
CHAPTER 1: Getting Started
Your Vertex Illumina SR will include the following components:
l Illuminaxture
l Mean Well Driver(s) and their respective power cables:
l SR 300-600 includes one Driver and Power Cable
l SR 900-1200 includes two Drivers and two Power Cables
l SR 1500-1800 includes three Drivers and three Power Cables
l Vertex Illumina Splitter Box (900, 1200, 1500 & 1800 models only)
l Manual
Optional Parts not Included, please ask your dealer for more information.
l Suspension Kit
l Illumina Alu-Mounting Braket AX + 2x Illumina Acrylic Holders (various sizes)
l Auxiliary Pads in different Collors
Out of the Box
Your Vertex Illumina SR will come out of the box with the main body preassembled. You will not be re-
quired to install any LED Pads or electronics. Do not attempt to open your Illumina SR. Any installations
requiringdisassemblyofthextureshouldonlybedonebyanauthorizedVertexdealer.
UponremovingyourVertexIlluminafromitspackage,examinethextureandallofitscomponentsfor
any damages. After carefully inspecting the components and reading this guide, you will ready to begin
installation.
Components
Note:Pleasetakethefollowinginstructionintoconsiderationbeforeattemptingtooperateyourxture.
WhenattemptingtoconnectthepowercablestoeachoftheMeanWellDrivers,ensurethatthet-
tingsformarmunion.DO NOT CONNECT THE FIXTURE CABLE TO THE SPLITTER BOX YET.
1. Plug each of the power cables into a GFCI/Surge Protected electrical outlet.
2.ConnecttheMeanWellDriverstotheVertexIlluminaSplitterBox,ensuringrmunion.
3.PlugtheIlluminaxturecabletotheSplitterBox.ThislaststepwillactivateyourIlluminaand
ready it for programming.

- 7 -
CHAPTER 2: Basics
This section will detail help familiarize you with each of the Vertex Illumina’s aspects and components:
Getting to Know the Features
Vertex Illumina Fixture
The body of the Vertex Illumina is
constructed from anodized, extruded
aluminium and has been designed
with the following considerations:
l Thermovap heatsink design with a
high bypass airshaft exchange, central
to an oversized bilateral heat sink.
l SilenX Ixtrema Pro IXP-52-14 fans
produce less than 14dBm noise and
move up to 24 CFM each.
l Onboard, programmable control
panel with built-in wireless network
functionality (w/ V-Link accessory).
l Streamlinedone-cordconstructionforallxturelengthsandmodelsservingtoeffectivelyminimize
clutter,preservingtheaestheticsofthexture.
l Twoadjustablesuspensionbridgesallowformaximumsuspensionexibilityduringinstallationorthe
Alu-Mounting Braket, optional!
l Modular LED pad platform requires no wiring or soldering for any replacements or upgrades.
l Auxiliary slots located between each of the LED pads allow for nearly limitless spectral composi-
tions.
NOTES:
l The Vertex Illumina is meant to be suspended above a display. Though humidity resistant, it is not
waterproof.Besurethatitismountedandprotectedfromwaterspraycomingfromoverowsand/or
splashing and bubbling water.
l DonotattempttomovetheLEDpadswithinthexture.Theyaresetinplacetoallowforexact
placement of auxiliary LED pads and sealed with a thermal paste backside.
l Donotcleanwithharshacidicoralkalinecleaners/solventswhichmaydestroythenish.
l Donotsetthextureontopofanysurfaceswhileitisrunning-youwilldamageboththesurface
and the LED splash shield. These types of damages are not covered by the warranty.

- 8 -
CHAPTER 2: Basics
Getting to Know the Features
Mean Well AC Adapter / Driver Unit
l 160W / 220W AC-DC Single Output Desktop Adapt-
ers comply with worldwide energy regulations for exter-
nal power supplies, including ENERGY STAR, EISA 2007,
and MEPS.
l Very low No-Load power consumption (<0.5W) and
upto94%efciency;offersenergy-savingcharacteris-
tics in both standby and active modes.
NOTES:
l Non-waterproof part. Keep away from humidity.
Vertex Illumina Splitter Box
l ConnectionIndicatorconrmsoperatingconnection
betweenDriverandIlluminaxture.
NOTES:
l Non-waterproof part. Keep away from humidity.
Canbeafxedusingthesidebrackets.
l Be sure to follow the connection procedure be-
fore connecting the Control Cable of the Illumina to the
Splitter Box.
Vertex Illumina Suspension Kit (optional)
l High-tensile Steel Aircraft cables and cable clamp
ttings provide secure, durable suspension and maxi-
muminstallationexibility.
NOTES:
l As the unit is heavy, please note the weight of your
Illuminaxtureandconsultwithanexpertpriortoin-
stallation over the display.

- 9 -
CHAPTER 2: Basics
Installing Your Illumina SR
Please read the following instructions thoroughly and consult with an expert before installing your Il-
lumina.Thextureshouldalwaysbelocatedaboveyourdisplayinawell-ventilatedspaceandshould
not be touching any surfaces once suspended. Locate the unit away from areas of high humidity and/
or water and salt spray. The manual explains the installation with the optional Suspension kit, for the
Mounting Braket see the manual which is coming with the Braket.
Assembling the Suspension Kit (optional)
Locate the rubber O-rings and loop them over each of the threaded ends of the Cable Clamps.
TakeeachCableClampandinstalltotheIlluminaxturebythreadingtheboltsthroughtheadjustable
suspensionbridgesfoundinthecenterchannelofthexture.Hand-tightenonly.
Cables (optional)
Begin by noting the two different ends of the steel ca-
bles. One end will have steel bolt. This is the stopper
end and it goes anchor-side. The other will be a bare
line. This end threads through the cable clamp and is
xture-side.
At this point, do not attempt to trim/shorten or crimp
any of the cables.

- 10 -
CHAPTER 2: Basics
Installing Your Illumina SR
Next, take the bare end of the cable and thread it through the eye-hole of the male end of the Socket
Anchor.Pullituntilthecableisfullythreadedthroughthettingasshown.Thestopperwillholdonceit
reachestheeye-holeofthetting.
Now take the cable and thread it through the Cable Clamp. It will push out from the side wedge of the
ttingandcanbepulledthroughfromthere.Continuetopullthecablethroughthetting.Donotworry
if you draw too much length, as this can later be adjusted.
You can use the central channel to hide any excess cable.

- 11 -
CHAPTER 2: Basics
Installing Your Illumina SR
SOCKET ANCHOR (CEILING/FEMALE)
The Female side of the Socket Anchor is the
basepointforsuspendingthexture.Inorderto
mount this part, you will need a sturdy surface
(such as a wooden crossbeam – please refer to
the weight chart and consult with an expert prior
to installation) and an appropriate screw/bolt of
at least 2” in length.
Be sure that the head of the fastener is not larg-
er than the inner diameter of the anchor and
afxasshown.
When setting the anchors, consideration must
betakenintoaccountforthelengthofthextureandthewidthbetweenthe(adjustable)suspension
bridges. See the following table for optimal spacing between each suspension bridge:
MODEL
SR 300
SR 600
SR 900
SR 1200
SR 1500
SR 1800
SUSPENSION BRIDGE SPACING
(Centered Positioning)
110mm 4.25”
410mm 16.1”
610mm 24.0”
1010mm 39.75”
1310mm 51.5”
1610mm 63.4”
With the female Socket Anchors properly spaced
and installed, you will now be able to thread the
male adapters in, completing the mounting pro-
cess.
Draw the cables through the cable clamps as de-
sired. A leveling ruler is recommended to achieve
perfect horizontal balance.
Beforepoweringupthexture,ensurethatthe
unit and surrounding area are free of dust and
humidity.

- 12 -
CHAPTER 2: Basics
Installing Your Illumina SR
TobeginpoweringupyourVertexIllumina,rstplugallthepowercablestotheirrespectiveMeanWell
AC Adapter / Driver Units. Then connect each of the power cables into a GFCI/Surge Protected electri-
cal outlet.
Once all of the Drivers are assembled and plugged to a power source, you can proceed to connecting
thecontrolcableoftheIlluminaxture.
Depending on which model you have, the process will differ slightly.
Before plugging the xture into an wall outlet,
arrange the cord in an anti-drip loop as pictured
to the left.
This arrangement will prevent any dripping wa-
ter from entering the electrical socket.
Failure to accomodate for this simple measure
canleadtoarehazzard.Thisistrueofallelec-
trical appliances within the vicinity of the aquari-
um or any body of water.

- 13 -
CHAPTER 2: Basics
Installing Your Illumina SR
SR 300 & 600
To power up these models, connect the Control
CablefromthexturetotheACAdapter/Driver
connector cable.
Once properly connected, the display module on
your Illumina should light up and begin Initial-
izing. After a few moments, you will be ready to
begin programming your lights.
SR 900 - 1800
Begin by plugging the AC Adapter / Driver con-
nector cables to each of the slots in the Splitter
Box. Plug each connecter in sequentially. See im-
age below for details per model.
ConnecttheControlCableofthexturetothe
splitter box. The Illumina will begin initializing
and, after a few moments, be ready for pro-
gramming.

- 14 -
CHAPTER 2: Basics
Operation
With your Vertex Illumina is powered up, you will now be able to program your lighting spectrum and
schedule.
Button Controls
4. ESC: Cancels selection to previous screen within main menus. Scrolls to the previous parameter/op-
tion within submenus. Press once to select previous, hold to exit submenu without saving settings.
System Interface
Use the following table to familiarize yourself with the functions of the Illumina interface:
The Vertex Illumina interface consists of a view-
ing screen and four control buttons.
The fuction of each of the buttons is as follows:
1. SELECT / OK:Conrmsselectionwithinmain
menus. Scrolls to next parameter/option within
submenus. Press once to select next, hold exit
submenu and save settings.
2. ▲ / + :Next selection within menus. Param-
eter value up within submenus.
3. ▼ / – : Previous selection within menus. Pa-
rameter value up within submenus.
REF.
1
1-1
1-2
1-3
1-3-1
1-3-2
1-4
1-4-1
1-4-2
1-4-3
1-4-4
1-4-5
1-4-5-1
1-4-5-2
1-4-5-3
FUNCTION
LIGHT MANAGER
OFF
DEMO
DEFAULT
NO MOON
MOON LIGHT
CUSTOM
LIGHT COMPOSER
WHITE
ROYAL BLUE
BLUE
MOON SELECTION
NO MOON
MOON LIGHT
MOON CYCLE
REF.
2
3
3-1
3-1-1
3-1-2
3-1-3
3-1- 4
3-1-5
3-2
3-2-1
3-2-2
3-3
3-4
3-4-1
3-4-2
FUNCTION
QUICK MOTION
SETTINGS
LANGUAGE
ENGLISH
DEUTSCH
ITALIANO
FRANCAIS
ESPANOL
TIME FORMAT
24 HOURS
AM/PM
TIME AND DATE
DISPLAY MODE
NORMAL
INVERSE
REF.
3-5
3-5-1
3-5-2
3-5-3
3-6
3-7
3-7-1
3-7-2
4
FUNCTION
FAN
OFF
AUTO
ON
MISC
FUNCTIONS
SPARE MODULES
FACTORY RESET
INFO

- 15 -
CHAPTER 2: Basics
Menu Structure
Use the following table to orient yourself within the menus:

- 16 -
CHAPTER 3: Advanced Features
Light Manager (Main Menu 1)
The Light Manager is the main interface from which you will program your Vertex Illumina.
Withinit,youwillndthefollowingfunctions:
Functions
1-1 OFF: Select this function and hold the SELECT button to turn the unit off.
1-2 DEMO: Select this function and hold the SELECT button to begin a preprogrammed demo mode.
1-3 STANDARD: Make Moon Light selections here:
1-3-1 NO MOON: No Moon Light cycle.
1-3-2 MOON LIGHT: Standard Moon Light function. See Section 1-4-5-2 on the following page.
1-4 CUSTOM:ThisSubmenucontainsalloftheUsercongurablelightsettings:
1-4-1 LIGHT COMPOSER:Thisapplicationallowsyoutocreateandtestspeciclightoutputsand
uses the following interface:
Use the ◄/OK and ESC/►buttons to scroll between the channels. Use the +and – buttons to adjust the
values to the desired level. Press and hold ◄/OK to exit the Light Composer while retaining your color
composition (no lighting schedule). Press and hold ESC/► exit without saving any settings.
SELECT ▲ ▼ ESC
1-1 OFF ○
1-2 DEMO ○
1-3 DEFAULT ○
1-4 CUSTOM ○
◄/OK + – ESC/►
LIGHT COMPOSER
WHITE: 00-100%
ROYAL BLUE: 00-100%
BLUE: 00-100%

- 17 -
CHAPTER 3: Advanced Features
Light Manager (Main Menu 1)
◄/OK + – ESC/►
CHANNEL NAME
INTENSITY: 00-100%
SUNRISE: 00:00AM
RISETIME: 00:00H
SUNSET: 00:00PM
DAWNTIME: 00:00H
Functions cont.
1-4-2 WHITE / 1-4-3 ROYAL BLUE / 1-4-4 BLUE: TheseoptionsallowyoutocongureeachLED
colorchannelindependantly.Withintheselections,youwillndthefollowinginterface:
Press and hold ◄/OK to exit each channel while retaining your color composition (no lighting schedule).
Press and hold ESC/► exit without saving any settings.
1-4-5 MOON SELECTION: Use this Submenu to control the Moon Light behavior of your Illumina
within the your light schedule.
1-4-5-1 NO MOON: No Moon Light cycle.
1-4-5-2 MOON LIGHT: Standard Moon Light with intensity adjustment:
1-4-5-3 MOON CYCLE: Use this option if you want the Moon Light to operate on a montly Lunar Cycle.
The Illumina will simulate the natural wax and wane phases of the moon:
◄/OK + – ESC/►
LUNAR CYCLE
INTENSITY: 00-100%
FULL MOON IN: 00-28DAYS
◄/OK + – ESC/►
MOONLIGHT
INTENSITY: 00-100%

- 18 -
CHAPTER 3: Advanced Features
Quick Motion (Main Menu 2)
TheQuickMotionfeatureallowsyoutoquicklytestandadjustanyCustomsettingsyouhavedened
and saved using the Light Manager. Once selected, the Quick Motion will quickly run the Illumina through
an accelerated light cycle. You can exit at any time by pressing any of buttons on the control console.
Settings (Main Menu 3)
UsethismenutoconguretheinterfacefunctionalityoftheIllumina:
Functions
3-1 LANGUAGE: Select from a list of languages:
Press and hold ◄/OK to select and save your language. Press and hold ESC/► exit without saving any
settings.
3-2 TIME FORMAT: Use this menu to select between 24 Hour mode (3-2-1) and AM/PM mode (3-2-2).
3-3 TIME AND DATE: Set the time by using the ◄/OK and ESC/►buttons to toggle between the time
values. Use the +and – buttons to adjust each value. Press and hold ◄/OK to select and save your time
settings. Press and hold ESC/► exit without saving any settings.
SELECT ▲ ▼ ESC
3-1 LANGUAGE
3-2 TIME FORMAT
3-3 TIME AND DATE
3-4 DISPLAY MODE
3-5 FAN
3-6 MISC
3-7 FUNCTIONS
SELECT ▲ ▼ ESC
3-1-1 ENGLISH ○
3-1-2 DEUTSCH ○
3-1-3 ITALIANO ○
3-1-4 FRANCAIS ○
3-1-5 ESPANOL ○

- 19 -
CHAPTER 3: Advanced Features
Settings (Main Menu 3)
Functions cont.
3-4 DISPLAY MODE: Toggling the display mode will change backlighting of the interface display. Make
your selection by pressing and holding ◄/OK to select and save the setting. Press and hold ESC/► exit
without saving any settings.
3-5 FAN: The fan settings can be adjusted to OFF (3-5-1), AUTO (3-5-2, recommended), or ON
(3-5-3).
3-6 MISC: Use this setting to adjust the Radio Channels between 01-15 to compensate for any interfer-
ence between the Vertex Illumina, the V-Link accessory and other remote devices.
3-7 FUNCTIONS: This menu has the optional SPARE MODULES (3-7-1) and FACTORY RESET (3-7-2)
selections. SPARE MODULES is initially deactivated, but can be accessed with the installation of optional
AuxiliaryModulesandtheirsupportrmware.Furtherdetailsregardingtheseitemsareavailablefrom
authorized Vertex Aquaristick dealers.
Use FACTORY RESET to clear user-programmed settings from the unit. Make your selection by holding
◄/OK. WARNING - Settings, once reset, are deleted permanently.
Info (Main Menu 4)
4 INFO:Thisselectiondisplaystheserialnumbersandcurrentsoftwareversionsinstalledonyourx-
ture. It is recommended that you keep your Illumina up to date with the latest software which can be
found on the Vertex Aquaristik website: www.vertexaquaristik.com.
Updating Your Illumina Firmware
In order to update your Fixture, you will require a V-Link USB Stick. This accessory can be purchased at
your authorized Vertex Aquaristik retailer.

- 20 -
CHAPTER 4: Maintenance
Considerations and Guidelines
Your Vertex Illumina must be routinely maintenanced to keep it performing optimally. Be sure to unplug
all power to the unit (by disconnecting the control cable from the Splitter Box). For thorough cleaning,
youwillalsowanttodismountthexturefromthehangingkit.
Before you beging with any further maintenance operations, be mindful of the following points:
l DonotattempttodisassembleyourVertexIlluminawithoutspecicinstruction.Thisactionshould
only be done by an authorized Vertex technician and any failure caused by user error will void the war-
ranty of the unit.
l Donotcleanwithharshacidicoralkalinecleaners/solventswhichmaydestroythenish.
l Do not power the unit during the cleaning process.
l The Illumina is humidity resistant, but not waterproof. Do not immerse or attempt to cleanse the
xturewithwaterorsolvents.Alwaysapplyanycleanserstoasoftcloth(Microberorcommercially
availabledustingmaterials)andneverdirectlytothebodyofthexture.
l Always take your Illumina to an authorized Vertex dealer for any concerns regarding the maintenance
and/or replacement of internal components. Damages caused by user error will void the warranty of the
unit.
l Alwaysmounttheelectricalcomponentsofthextureawayfromhumidityandmoisture.
l Only plug the Illumina into a GFCI and surge protected power supply. Failure to do so will void the
warranty of the unit
To extract the Steel Cables from the Cable
Clamps,youwillrstwanttoensurethattheIl-
luminaxtureissupportedand/orremovedfrom
its position over the display.
Begin by rmly depressing the lock tting into
the body of the Cable Clamp. This will loosen
the binding mechanism and allow you to pull the
Steel Cable away from the Cable Clamp.
Repeat with the other Cable Clamp and you will
not be ready to perform routine maintenance on
yourxture.
