Models with Led Channel Indicator
Led no.6 will turn solid orange when you press any button.
Models with Display
The battery icon will be shown on the display when you press any button.
Remote Low Battery Notification
The remote shows a notification when its battery is below 2.7V DC
Moving the Shade to a Percentage Opening
Hiding the Unused Channels
The following functions are only available for Bidirectional Motors and Remotes with
Display. Applies to models: 6-800-AT-ESB16 & 6-800-AT-ESBT6
Make sure you are not in a channel group before the step no.1.
100% Shade completely close. 0% Shade completely open.
Only the desired quantity channels will be visible. Repeat the same procedure to set a new
quantity of active channels.
Press and hold for about 5 secons the RIGHT (>) button and the FAV button together until
the display shows C 16 (for a 16 channel remote) or C6 (for 6 channel remote).
Press the RIGHT button ( > ) to scroll through the desired quantity channels.
Press the STOP button when you see the desired number of channels you wish to keep
displayed on the remote. All others will be hidden.
1.
2.
3.
Select the desired channel and press the FAV button for 3 seconds (The screen will show
50%).
Press the select channel buttons ( < / > ) to change from 50% to the desired percentage in
10 percent increments. Then, wait 3 seconds. The shade(s) will move to the chosen
percentage position.
1.
2.
Adding Channels to Groups
Select the Group Number you would like to set.
Press and hold the RIGHT ( > ) and FAV button together until the screen shows G1 if you
are in Group 1, G2 if you are in Group 2, etc.
Press the RIGHT ( > ) and FAV button. C 1 will be flashing. If you want to add C 1 in the
group, press FAV button. C 1 will no longer be flashing meaning it has been added to the
group selected.
Use the LEFT/RIGHT ( < / > ) buttons to move to the next Channel (C2). If you want C2 in
the Group, press FAV button.
Continue with Steps 3 and 4 until you have selected all the Channels you would like to add
on the group selected.
Press STOP button. Display will show “OK”.
1.
2.
3.
4.
5.
6.
