Vessel 220usb-1e Operator's manual

Thank you for purchasing our Rechargeable Ballgrip Screwdriver

No.220USB-1E.

Read this instruction manual before use.

Keep it in a safe handy place for future reference.

INSTRUCTION MANUAL

AND

SAFETY INSTRUCTIONS

FOR

RECHARGEABLE BALLGRIP S/D

(SCREWDRIVER)

No.220USB-1E

ENGLISH

Contents

───────────────────────────────

General power tool safety warnings-------------------------------------------------2

Safety warnings for screwdrivers----------------------------------------------------3

Package contents/ Intended use/ Features/ Speciﬁcations -----------------------4

Charging/ Changing the tool ---------------------------------------------------------5

Usage/ Maintenance and cleaning/ Disposal ---------------------------------------6

Troubleshooting/ After-sales service ------------------------------------------------7

Declaration of Conformity ------------------------------------------------------------8

S/D means “Screwdriver”.

DEFINITIONS: Safety Guidelines

The deﬁnitions below describe the level of

severity for each signal word. Please read the

manual and pay attention to these symbols.

WARNING: Indicates a potentially hazard-

ous situation which, if not avoided, could result

in death or serious injury.

CAUTION: Indicates a potentially hazard-

ous situation which, if not avoided, may result

in minor or moderate injury.

NOTICE: Indicates a practice not related to

personal injury which, if not avoided, may

result in property damage.

SYMBOLS

Use eye protection during operation.

Do not use a screwdriver as a pry bar,

chisel, punch or hammer.

Protect the battery against heat, e.g.,

against continuous intense sunlight.

Risk of electric shock.

WARNING: To reduce the risk of injury, read

the instruction manual.

GENERAL POWER TOOL SAFETY WARNINGS

WARNING: Read all safety warnings,

instructions, illustrations and speciﬁca-

tions provided with this power tool. Failure to

follow all instructions listed below may result in

electric shock, ﬁre and/or serious injury.

Save all warnings and instructions for future

reference. The term “power tool” in the warnings

refers to your mains-operated (corded) power tool

or battery- operated (cordless) power tool.

Work area safety

▶Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

▶Do not operate power tools in explosive

atmospheres, such as in the presence of

ﬂammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes.

▶Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical safety

▶

Power tool plugs must match the

outlet. Never modify the plug in any way.

Do not use any adapter plugs with earthed

(grounded) power tools.

Unmodiﬁed plugs and

matching outlets will reduce risk of electric shock.

▶

Avoid body contact with earthed or ground-

ed surfaces, such as pipes, radiators, ranges

and refrigerators.

There is an increased risk of

electric shock if your body is earthed or grounded.

▶Do not expose power tools to rain or wet

conditions. Water entering a power tool will

increase the risk of electric shock.

▶Do not abuse the cord. Never use the cord

for carrying, pulling or unplugging the power

tool. Keep cord away from heat, oil, sharp

edges or moving parts. Damaged or entangled

cords increase the risk of electric shock.

▶When operating a power tool outdoors, use

an extension cord suitable for outdoor use.

Use of a cord suitable for outdoor use reduces the risk

of electric shock.

▶If operating a power tool in a damp location

is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces

the risk of electric shock.

Personal safety

▶

Stay alert, watch what you are doing and

use common sense when operating a power

tool.

Do not use a power tool while you are

tired or under the inﬂuence of drugs, alcohol or

medication.

A moment of inattention while operat-

ing power tools may result in serious personal injury.

▶Use personal protective equipment.

Always wear eye protection. Protective

equipment such as dust mask, non-skid safety shoes,

hard hat, or hearing protection used for appropriate

conditions will reduce personal injuries.

▶Prevent unintentional starting. Ensure the

switch is in the off-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools with

your ﬁnger on the switch or energising power tools

that have the switch on invites accidents.

▶Remove any adjusting key or wrench

before turning the power tool on. A wrench or a

key left attached to a rotating part of the power tool

may result in personal injury.

▶Do not overreach. Keep proper footing and

balance at all times. This enables better control of

the power tool in unexpected situations.

▶Dress properly. Do not wear loose clothing

or jewellery. Keep your hair and clothing

away from moving parts. Loose clothes, jewel-

lery or long hair can be caught in moving parts.

▶

If devices are provided for the connection of

dust extraction and collection facilities, ensure

ignated battery packs. Use of any other battery

packs may create a risk of injury and ﬁre.

▶When battery pack is not in use, keep it

away from other metal objects, like paper

clips, coins, keys, nails, screws or other

small metal objects, that can make a connec-

tion from one terminal to another. Shorting the

battery terminals together may cause burns or a ﬁre.

▶Under abusive conditions, liquid may be

ejected from the battery; avoid contact. If

contact accidentally occurs, ﬂush with water.

If liquid contacts eyes, additionally seek

medical help. Liquid ejected from the battery may

cause irritation or burns.

▶Do not use a battery pack or tool that is

damaged or modiﬁed. Damaged or modiﬁed

batteries may exhibit unpredictable behaviour result-

ing in ﬁre, explosion or risk of injury.

▶Do not expose a battery pack or tool to ﬁre

or excessive temperature. Exposure to ﬁre or

temperature above 130ﾟ

C may cause explosion .

▶Follow all charging instructions and do not

charge the battery pack or tool outside the

temperature range speciﬁed in the instruc-

tions. Charging improperly or at temperatures

outside the speciﬁed range may damage the battery

and increase the risk of ﬁre.

Service

▶Have your power tool serviced by a quali-

ﬁed repair person using only identical

replacement parts. This will ensure that the safety

of the power tool is maintained.

▶Never service damaged battery packs.Ser-

vice of battery packs should only be performed by the

manufacturer or authorized service providers.

SAFETY WARNINGS FOR SCREWDRIVERS

▶Do not use a screwdriver as a pry bar,

chisel, punch or hammer. Broken screw-

driver can cause injury.

▶Hold power tool by insulated gripping

surfaces, when performing an operation

where the fastener may contact hidden

wiring. Fasteners contacting a “live” wire may make

exposed metal parts of the power tool “live” and could

give the operator an electric shock.

▶Hold the machine with a ﬁrm grip. High

reaction torque can brieﬂy occur while driving in and

loosening screws.

▶Secure the workpiece. A workpiece clamped

with clamping devices or in a vice is held more secure

than by hand.

▶Always wait until the machine has come to

a complete stop before placing it down.

these are connected and properly used.

Use of

dust collection can reduce dust-related hazards.

▶

Do not let familiarity gained from frequent

use of tools allow you to become complacent

and ignore tool safety principles.

A careless

action can cause severe injury within a fraction of a

second.

Power tool use and care

▶Do not force the power tool. Use the correct

power tool for your application. The correct

power tool will do the job better and safer at the rate

for which it was designed.

▶Do not use the power tool if the switch does

not turn it on and off. Any power tool that cannot

be controlled with the switch is dangerous and must

be repaired.

▶Disconnect the plug from the power source

and/or remove the battery pack, if detach-

able, from the power tool before making any

adjustments, changing accessories, or stor-

ing power tools. Such preventive safety measures

reduce the risk of starting the power tool accidentally.

▶Store idle power tools out of the reach of

children and do not allow persons unfamiliar

with the power tool or these instructions to

operate the power tool. Power tools are danger-

ous in the hands of untrained users.

▶Maintain power tools and accessories.

Check for misalignment or binding of moving

parts, breakage of parts and any other condi-

tion that may affect the power tool’s opera-

tion. If damaged, have the power tool

repaired before use. Many accidents are caused

by poorly maintained power tools.

▶Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges are

less likely to bind and are easier to control.

▶Use the power tool, accessories and tool

bits etc. in accordance with these instruc-

tions, taking into account the working condi-

tions and the work to be performed. Use of the

power tool for operations different from those intend-

ed could result in a hazardous situation.

▶

Keep handles and grasping surfaces dry,

clean and free from oil and grease. Slippery

handles and grasping surfaces do not allow for safe

handling and control of the tool in unexpected situations.

Battery tool use and care

▶Recharge only with the charger speciﬁed

by the manufacturer. A charger that is suitable for

one type of battery pack may create a risk of ﬁre when

used with another battery pack.

▶Use power tools only with speciﬁcally des-

The tool insert can jam and lead to loss of control over

the power tool.

▶

Before any work on the machine (e. g.,

maintenance, tool change, etc.) as well as

during transport and storage, set the rotation-

al direction switch to the center position. Unin-

tentional actuation of the switch can lead to injuries.

▶Protect the battery against heat, e.g.,

against continuous intense sunlight, ﬁre,

water, and moisture. Failure to do so may result in

an explosion.

▶In case of damage and improper use of the

battery, vapours may be emitted. Ventilate the

area and seek medical help in case of complaints. The

vapours can irritate the respiratory system.

▶This product contains a lithium battery.

A lithium battery reaches its end of life after many

years of use. To protect the environment, follow the

treaties for ecological protection of local governments

of your country to properly dispose of this battery.

Lithium-ion batteries are recyclable

PACKAGE CONTENTS

1 Power tool

1 Bit

1 USB Charging cable(1m)

1 Instruction manual

NAME OF PARTS

INTENDED USE

The 220USB is used for tightening and loosening

screws. The 220USB is an electric screwdriver that

can be charged by connecting a USB charging cable.

FEATURES

・

Quick tightening can be performed efﬁciently with

the aid of an electric motor. The ﬁnal tightening is

automatically switched to manual operation.

・

The high-intensity LED light brightens the blade

edge even in dark places.

・

The switch is a slide switch that can be operated

forward and backward with light force.

・

Small and light with USB rechargeable Li-ion battery.

・

Various commercially available bits of 6.35 mm are

available.

1. Screwdriver handle

2. Driver bit holder

3. Sleeve

4. Switch

5. LED light

6. Charging lamp

7. Charging port

8. Screwdriver bit

TECHNICAL SPECIFICATIONS

- Rated voltage 3.6 V DC

- Capacity 800 mAh

No-load speed 280 min-1

Torque

- Electric power (Max.) 2 N･m

- Hand operation (Max.) 10 N･m

Weight (not including accessories) 160 g

Permitted ambient temperature

- during charging 0ﾟ

C - 40ﾟ

- operating* and storaging 0ﾟ

C - 45ﾟ

Battery Li-Ion

Number of battery cells 1

Charging time Approx. 60 min

Number of charges** Approx. 500 charges

Charging port micro USBType-B

Noise 66.1 dB

according to EN 62841-1 Annex I

Vibration values 0.421 m/s2

according to EN 62841-1 Annex I, EN 62841-2

Input power (maximum) - Volt 5 V

-Current 1 A

* limited performance at temperatures <0 °C

Actual battery life will vary depending on speciﬁcations.

Speciﬁcations and sizes are subject to change without notice.

REPLACEABLE PARTS

- END CAP - ALUMINIUM RING

TECHNICAL SPECIFICATIONS

- Rated voltage 3.6 V DC

- Capacity 800 mAh

No-load speed 280 min-1

Torque

- Electric power (Max.) 2 N･m

- Hand operation (Max.) 10 N･m

Weight (not including accessories) 160 g

Permitted ambient temperature

- during charging 0ﾟ

C - 40ﾟ

- operating* and storaging 0ﾟ

C - 45ﾟ

Battery Li-Ion

Number of battery cells 1

Charging time Approx. 60 min

Number of charges** Approx. 500 charges

Charging port micro USBType-B

Noise 66.1 dB

according to EN 62841-1 Annex I

Vibration values 0.421 m/s2

according to EN 62841-1 Annex I, EN 62841-2

Input power (maximum) - Volt 5 V

-Current 1 A

* limited performance at temperatures <0 °C

Actual battery life will vary depending on speciﬁcations.

Speciﬁcations and sizes are subject to change without notice.

CHARGING

Use a charger with the speciﬁed charging

capacity. (Output: 5 V-1 Amp)

If the current value is high, the life of the internal

battery will be shortened.

* This product does not come with a charger.

1) Open the protective cap

(see the ﬁgure on the

right) of the power tool

charging port and insert

the USB charging cable.

Charging may not be possible if

the USB charging cable is not

correctly inserted into the charging port.

- Open after pulling out the cap.

- Use the USB charging cable included with this product.

- Opening from the reverse direction will cause a damage.

Insert the other end of the USB charging

cable to a USB port designated in the speciﬁ-

cations (commercially available AC adapters,

PCs, mobile batteries, etc.). The charging lamp

lights up and the charging starts. While charging the

battery, the charging lamp lights red. When charging

is complete, the charging lamp lights green.

Note: The battery supplied is partially charged. To

ensure full capacity of the battery, completely

charge the battery in the battery charger before

using the product for the ﬁrst time. The lithium-ion

battery can be charged at any time without reducing

its service life. Interrupting the charging procedure

does not damage the battery. The Lithium-Ion

battery is protected against deep discharging.

Note: If the charge level of the battery is less than

15%, the battery charge lamp will ﬂash red during

operation. When the battery voltage drops to the

speciﬁed value, it cannot operate to protect the

product. Stop work and charge the battery.

Note: The product cannot be used during charging.

The screwdriver will not operate if the switch is

sliding during charging - this is not a breakdown.

Note: If not used for a long time, disconnect the

charger from main power.

When charging is complete, remove

the USB

charging cable and close the protective cap.

Dirt

and foreign matter may cause malfunction.

CHANGING THE TOOL

Only use the speciﬁed bits. If you use bits other than

those speciﬁed, bits may not be possible to be removed.

- Bits that can be used are limited to products with

the following mounting dimensions.

- Inserting bit: Slide the sleeve forward, insert the bit

all the way in, and release the sleeve. Move the bit

back and forth to make sure it is locked. Risk of

injury if the bit comes off while operating.

- Removing bit: Slide the sleeve forward, pull out the

bit and release the sleeve. Be careful not to drop

bits or the power tool when operating at height.

CAUTION: Do not slide the switch when

inserting or removing bits. The power tool

may operate and cause injury.

LED indication

lights up in red while charging.

lights up green when complete.

13mm

14mm

Charging port

(MicroUSB-typeB)

Charging port (USB-typeA)

Φ16

140

Φ45

SIZE

NORMAL ROTATION/

REVERSE ROTATION SWITCH

CAUTION:

Do not keep pressing the switch

after the power tool turns off automatically.

Internal parts may be damaged.

The sliding direction of the switch on this product

allows it to rotate in the desired rotation.

- CW: To rotate the spindle clockwise, slide the switch

forward to rotate it, and the LED light will turn on at

the same time. When you release your hand from

the switch, the switch returns to the neutral position

and rotation stops, but the LED light will turn off

after 5 seconds.

- CCW: To rotate the spindle counterclockwise, slide

the switch backward to rotate it, and the LED light

will be turned on at the same time. When you

release your hand from the switch, the switch

returns to the neutral position and rotation stops,

but the LED light will turn off after 5 seconds.

Grip for switching

LED lighting

CAUTION: Do not look directly into the

LED light. Your eyes could be damaged.

CAUTION: Continually carrying out heavy

loads may cause malfunctions. If the work

load is too heavy, the product protection function

will be activated. When the product protection func-

tion is activated, the charging lamp blinks and the

product does not operate.

Fully automatic spindle locking (Auto-lock):

When the switch is in neutral position, turning the

power tool manually will lock the spindle and tight-

en the screw. It allows the screw to be tightened

even when the battery is empty, which allows the

power tool to be used as a manual screwdriver.

Grip for hand tightening

CAUTION:

Do not slide the switch while the

spindle is locked and the screw is manually

tightened.

The power tool may be damaged.

- Working advice:

Apply the power tool to the screw only when it

is switched off. Rotating tool inserts can slip off.

MAINTENANCE AND CLEANING

Periodic inspection

- Loose screws, damage or malfunction.

CAUTION:

Before any work (e. g., mainte-

nance, tool change,etc.) as well as during

transport and storage, set the rotational

direction switch to the neutral position. Unin-

tentional actuation of the switch can lead to injuries.

For safe and proper working,

always keep the tool

clean.

CAUTION: A reinforced plastic cover is

used. Do not use detergents or the follow-

ing chemicals to wipe the surface. Risk of

cracks, electric shock, or failure. - Benzine,

Thinner, Ketone, Ether and other similar chemicals

DISPOSAL

Do not dispose the power tool in your house-

hold waste! Take your tool to an authorized

VESSEL agent where it will be disposed of in

an environmentally safe way.

WARNING: Risk of ﬁre or injury. Do not

attempt to disassemble the battery or remove any

component.

CCW

Sliding Direction CCW

Possible causes

Battery is not sufﬁciently charged

Breakdown of the switch, motor or circuit

board

Breakdown of internal parts

Battery is not sufﬁciently charged

The power tool stops working due to

protection circuit activation.

Breakdown of motor and gear

Temperature increase due to overload

Breakdown of motor and circuit board

Temperature increase due to charging in

progress

The bits do not ﬁt

Breakdown of internal parts

Charger problem

Battery is not sufﬁciently charged

Breakdown of internal parts

Product speciﬁcation

Breakdown of internal parts

Problem

No rotation

The power tool

stops working

during operation

Abnormal noise

Heat generation

of power tool

Bits cannot be

inserted

Idling of the chuck

Working LED

does not light up

Can't charge

Slow speed

When charging

is complete, the

green light and

the red light are

turned on

alternately.

Solution

Charge battery.

Contact the distributor where you

made the purchase.

Contact the distributor where you

made the purchase.

Charge battery.

Increase the pause time.

Contact the distributor where you

made the purchase.

Increase the pause time.
