Chapter 1 Introduction
The network camera is a kind of embedded digital surveillance product that combines the
features of both traditional analog camera and the encoder. With a built-in video server, the
network camera is capable of providing real-time video stream compression, processing,
video analysis and transmission simultaneously. Adopting the latest processing chip and
hardware platform, the network camera can be widely applied to various surveillance and
image processing systems with high reliability andstability.
1.1 Applications
The network camera can be used in many surveillance scenes., e.g.:
Network surveillance for over-the-counter activities in the banks, ATMs, supermarkets
and factories.
Remote surveillance systems for nursing homes, kindergartens and schools.
Artificial Intelligent access control systems .
Artificial Intelligent office building/residential compounds management systems.
Unguarded power station and telecommunication base station surveillance systems.
Pipelining and warehousing monitoring systems.
Surveillance systems for airports, railway stations, bus stops, etc.
1.2 Preparations
Make sure the device in the package is in good condition and all the assembly parts are
included.
Make sure all the related equipment is power-off during theinstallation.
Check the specification of the products for the installation environment.
Make sure the power supply is matched with your required voltage to avoid damage.
If the product does not function properly, please contact your dealer or the nearest
service center. Do not disassemble the camera for repair or maintenance by yourself.

Installation Manual of Network Camera
7
Make sure that the wall is strong enough to withstand three times the weight of the
camera.
For the camera that supports IR, you are required to pay attention to the following
precautions to prevent IR reflection:
Dust or grease on the dome cover will cause IR reflection. Please do not remove the
dome cover film until the installation is finished. If there is dust or grease on the dome
cover, clean the dome cover with clean soft cloth and isopropyl alcohol.
Make sure that there is no reflective surface too close to the camera lens. The IR light
from the camera may reflect back into the lens causing reflection.
The foam ring around the lens must be seated flush against the inner surface of the
bubble to isolate the lens from the IR LEDS. Fasten the dome cover to camera body
so that the foam ring and the dome cover are attachedseamlessly.

Installation Manual of Network Camera
8
Chapter 2 Bullet Camera Installation
2.1 Type I Bullet Camera
2.1.1 Camera Description
The overview of the network bullet camera is shown below.
14 1
13
12
11 3
10
9 4
5
6
8 7
Figure 2-1 Overview (1)
15
Figure 2-2 Overview (2)
Table 2-1 Description
2

Installation Manual of Network Camera
9
No.
Description
1
Sun Shield
2
Camera Body
3
Bracket Tray
4
Bracket Hinge
5
Bracket Bearing
6
Mounting Base
7
Seal Ring
8
Junction Box
9
Network Cable Interface
10
Power Cable Interface
11
Alarm Interface IN, G: Alarm In 1A,1B: AlarmOut
12
RS-485 Communication Interface
13
Audio Input
14
Audio Output
15
SD Card Slot
Press RESET about 10s when the camera is powering on or rebooting to restore the default
settings, including the user name, password, IP address, port No., etc.
2.1.1 Installation
Ceiling Mounting
Steps:
1.Drill the screw hold and the cable hole according to the supplied drill template.

Installation Manual of Network Camera
10
Figure 2-3 Drill Template
2.Fix the junction box to the ceiling with the suppliedscrews.
Please insert the expansion screws first if the camera is mounted to the cement ceiling. And
you can use the self-tapping screws directly if camera is mounted to the wooden ceiling.
Figure 2-4 Install Junction Box
3.Route the cables.
1
Drill Template
1 1:Screw Hole for Mounting Base 1
1

Installation Manual of Network Camera
11
4.Align the screw holes on the mounting base to those on the junction box, and tighten
the camera with screws.
Figure 2-5 Install Camera
5.Tighten the lock screw on the camera to completeinstallation.
Figure 2-6 Tighten the Lock Screw
Wall Mounting
1.Drill the screw hold and the cable hole according to the supplied drill template.

Installation Manual of Network Camera
12
Figure 2-7 Drill Template
2.Fix the junction box to the wall with the suppliedscrews.
Please insert the expansion screws first if the camera is mounted to the cement wall.
And you can use the self-tapping screws directly if camera is mounted to the wooden
wall.
Figure 2-8 Install Junction Box
3.Route the cables.
4.Align the screw holes on the mounting base to those on the junction box, and fix the
camera to the wall with screws.
1
Drill Template
1 1:Screw Hole for Mounting Base 1
1

Installation Manual of Network Camera
13
Figure 2-9 Install Camera
5.Tighten the lock screw on the camera to completeinstallation.
Figure 2-10 Tighten the Lock Screw
3-axisAdjustment
This series of camera supports 3-axis adjustment, and you can follow the steps below to
adjust the camera to the desired surveillance angle.

Installation Manual of Network Camera
14
Steps:
1.Loosen No.1 lock screw to adjust the pan angle [±180°].
1
-180°~+180°
Figure 2-11 Adjust Pan Angle
2.Loosen No.2 lock screw to adjust the tilt angle [±180°].
Figure 2-12 Adjust Tilt Angle
-180°~+180°
2

Installation Manual of Network Camera
15
3.Loosen No.3 lock screw, and rotate the camera body [0°~105°] to adjust the camera to
the desired angle of view.
Figure 2-13 Adjust the Rotation Angle
4.Tighten the screws after the adjustment is completed.
3
