Vicon S2000-UPM User manual

Vicon part number 8009-8038-00-00 Rev 300 Section 1
XX038
MODEL S2000-UPM OUTDOOR
PARAPET MOUNT FOR SURVEYOR2000
CAMERA DOME SYSTEMS
Copyright © 2000 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Surveyor and Omniscan are trademarks of Vicon Industries Inc.
Teflon is a registered trademark of E.I. duPont de Nemours & Co. Molykote is a registered trademark of Dow Corning.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com

XX038 Rev 300 S2000-UPM Parapet Mount Introduction •
••
•1
Introduction
The information in this manual covers the installation, operation, and maintenance of the S2000-UPM Parapet
Mount. This unit should only be installed by a qualified technician using approved materials in accordance with
national, state, and local codes. Read these instructions through completely before attempting installation.
The S2000-UPM is designed to allow the Surveyor2000 Camera Dome System to be mounted over a roof
parapet or similar structure. The parapet mount provides a sturdy installation capable of withstanding extreme
weather conditions. It allows the mounted equipment to be swiveled onto the roof for easy serviceability and
adjustment.
Installation
Installing the Mounts
The S2000-UPM Parapet Mount consists of the parapet mount neck, two wall bracket assemblies, a support
bracket, a cap, reducer coupling/nipple assembly, a coupling (optional), Teflon tape, and appropriate
hardware. See Table 1. The hardware used to secure the brackets to the mounting surface must be supplied
by the customer and appropriate for the type of mounting surface.

2 •
••
•Installation XX038 Rev 300 S2000-UPM Parapet Mount
TABLE 1
MOUNTING KIT COMPONENTS
Item No. Component Quantity Function
1 Wall bracket 2 Secures parapet
mount to mounting
surface
2 Wall bracket cover 2 Secures parapet
mount in wall
bracket
3 Support bracket 1 Secures bottom wall
bracket
4 Cap 1 Closes off bottom of
mount but allows
cabling to be routed
5 5/16-18x1 in. screw 4 Secures wall bracket
cover
6 5/16 lock washer 5 Secures item 5 and
8
7 5/16x5/8x0.062 flat
washer 5 Secures item 5 and 8
8 5/16-24x3 in. bolt 1 Prevents parapet
mount from spinning
9 5/16-24 nut 1 Secures item 8
10 Coupling (optional*) 1 Joins parapet mount
and parapet neck
11 Set screw 2 Secures item 10
12 Teflon tape 1 Seals pipe thread
13 Reducer coupling 1 Reduces the
diameter of the pipe
to accommodate the
S2000 housing
14 Nipple 1 Secures housing
*Some units may be shipped as one piece, eliminating the need for the coupling.
Note: The S2000-UPM is designed to support the weight of the Surveyor2000 Camera Dome. Refer to the
appropriate product specifications for the weights of these dome systems. Be sure that the mount is
installed in a location that can support the load. There should be a minimum parapet height of 18 inches
(46 cm).
Note: For outdoor installations, it is recommended that stainless steel hardware be used. All mounting
hardware MUST have a minimum pullout strength of 600 lb (272 kg) per bolt. When mounting to wood,
use screws long enough to penetrate at least 2.5 inches (6.4 cm). If mounting to a steel structure, drill
holes according to the mounting pattern. Screws should be long enough to accommodate lock washers
and nuts. In masonry or concrete, use lead anchors or expansion bolts installed according to the
manufacturer’s instructions.
Caution: Never mount the brackets directly into the end grain of wood.

XX038 Rev 300 S2000-UPM Parapet Mount Installation •
••
•3
Before beginning installation of the parapet mount, run all necessary cabling to the location selected for the
installation. Cables are routed up through the mount to the dome system.
1. Attach one wall bracket and the support bracket to the parapet surface using appropriate hardware for the
material of the parapet. Be sure that the wall bracket is against the parapet surface and the support
bracket is on top of the wall bracket, with the stop on the support bracket facing out from the parapet.
Refer to Figure 1.
2. Attach the second wall bracket to the parapet in the selected location, using appropriate hardware. The
suggested minimum distance between the wall brackets is 12.0 inches ( 30.5 cm).
3. Insert the cap supplied into the bottom opening of the parapet mount.
4. Place the parapet mount in the cutout contour of the wall brackets, align the wall bracket covers and
secure with the 5/16-18 x 1 inch screws, lock washers and flat washers supplied. To prevent the parapet
mount from spinning, secure it to the bottom wall bracket through the hole in the mount with the 5/16-24x3
inch bolt, lock washer, flat washer, and nut provided.
Note: Lubricating the Threads: Before joining the two sections of the parapet mount with the coupling
(optional), verify that either the male or female threads are coated with lubricant. If no lubricant is
present, spread a thin coating of lubricant such as Dow Corning Molykote on the threads to ease
assembly. Optionally, Teflon tape is supplied to secure a tight fit and ensure that the seal is watertight.
5. Some units may be shipped with the parapet mount in one piece. If that is the case, skip this step.
Attach the parapet neck to the mount with the coupling provided. Screw the coupling onto the parapet
mount first, making sure the holes for the set screws are on the end closest to the parapet neck. Screw
the neck in as tightly as possible while having it remain parallel with the mount.
6. Route the cables through the cap and up the mount to where the dome system is installed. Apply caulk or
RTV sealant around entrance opening in cap.
7. Install the reducer coupling/nipple assembly into the opening in the top of the Surveyor2000 housing.
Screw the housing directly onto the parapet mount. Use the Teflon tape to secure the fit and make it
watertight. Refer to the instruction manual for installation of the domed housing for specific installation
instructions.
8. To swivel the dome system out over the parapet, loosen the bolts just enough to allow movement and
position the unit. Tighten the bolts to secure the mount into position.

4 •
••
•Installation XX038 Rev 300 S2000-UPM Parapet Mount
Figure 1
S2000-UPM Installation

XX038 Rev 300 S2000-UPM Parapet Mount Operation •
••
•5
Operation
To swivel the mount in from the parapet for access to the dome system, loosen the bolts enough to allow
movement. Swing the unit in from the parapet. Tighten the bolts. After servicing or adjustment is complete,
loosen the bolts, position the mount, and tighten bolts.
Maintenance
The S2000-UPM Parapet Mount requires no maintenance.

6 •
••
•Shipping Instructions XX038 Rev 300 S2000-UPM Parapet Mount
Shipping Instructions
Use the following procedure when returning a unit to the factory:
1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name
of the Vicon employee who issued the R.A.
Vicon Industries Inc.
89 Arkay Drive
Hauppauge, NY 11788
Phone: 631-952-CCTV (2288); Toll-Free: 1-800-645-9116; Fax: 631-951-CCTV (2288)
For service or returns from countries in Europe, contact:
Vicon Industries (U.K.) Ltd
Brunel Way
Fareham, PO15 5TX
United Kingdom
Phone: [phone]; Fax: [phone]
2. Attach a sheet of paper to the unit with the following information:
a. Name and address of the company returning the unit
b. Name of the Vicon employee who issued the R.A.
c. R. A. number
d. Brief description of the installation
e. Complete description of the problem and circumstances under which it occurs
f. Unit’s original date of purchase, if still under warranty
3. Pack the unit carefully. Use the original shipping carton or its equivalent for maximum protection.
4. Mark the R.A. number on the outside of the carton on the shipping label.

XX038 Rev 300 S2000-UPM Parapet Mount Technical Information •
••
•7
Technical Information
MECHANICAL
Load Rating: Accommodates the Surveyor2000 Camera Dome System.
Dimensions: Height: 30 in. (76 cm).
Width: 34 in. (86 cm).
Construction: Mount: aluminum pipe.
Braces and supports: steel.
Hardware: stainless steel.
Finish: White or light gray paint.
ENVIRONMENTAL
Wind: Withstands winds up to 80 mph.
