Vicon V1110B-THM-TEMP User manual

User Manual
Blackbody Temperature Calibrator for
V1110B-THM-TEMP Thermal Body Temperature
Measurement Camera
XX300-35-00
Vicon Industries Inc. does not warrant that the functions contained in this equipment
will meet your requirements or that the operation will be entirely error free or perform
precisely as described in the documentation. This system has not been designed to be
used in life-critical situations and must not be used for this purpose.
Vicon Industries Inc.
Tel: [phone]
Fax: [phone]
Toll Free: 800-645-9116
24-Hour Technical Support:
800-34-VICON (800-348-4266) UK:
44/(0) 1489-566300
www.vicon-security.com
Document Number: 8009-8300-35-00 Product specifications
subject to change without notice. Issued: 6/2020
Copyright © 2020 Vicon Industries Inc. All rights reserved.

Blackbody
User Manual
Precautions
i
Precautions
Precautions
Read this document completely before using this device, and strictly observe rules in
this document when using this device. If you install this device in public places,
provide the tip "You have entered the area of electronic surveillance" in an eye-
catching place. Failure to correctly use electrical products may cause fire and severe
injuries. To prevent accidents, carefully read the following context:
Symbols
This document may contain the following symbols whose meanings are described
below.
Symbol
Description
Alerts you to fatal dangers which, if not avoided, may
cause deaths or severe injuries.
Alerts you to moderate dangers which, if not avoided,
may cause minor or moderate injuries.
Alerts you to risks. Neglecting these risks may cause
device damage, data loss, device performance
deterioration, or unpredictable results.
Provides a tip that may help you resolve problems or
save time.
Provides additional information.
Disclaimer
This manual may contain misprints or product function and operation descriptions that are
slightly inconsistent with the actual product. The manufacturer will update this manual
according to product function enhancement or changes and regularly update the software
and hardware described in this manual. Updated information will be added to new versions
of this manual without prior notice.
This manual is for reference only and does not ensure that the information is totally
consistent with the actual product.

Blackbody
ii
Precautions User Manual
Contents
Precautions .............................................................................................................. i
1 Overview...............................................................................................................1
1.1 Introduction .............................................................................................................. 1
1.2 Unpacking ................................................................................................................ 1
1.3 Environmental Conditions ......................................................................................... 1
1.4 Safety Information..................................................................................................... 2
2 Device....................................................................................................................3
3 Operation ..............................................................................................................7
3.1 Procedure.................................................................................................................. 7
3.2 Set Temperature ........................................................................................................ 8
3.3 Calibration................................................................................................................ 8
3.4 Maintenance.............................................................................................................. 8
4 Troubleshooting...................................................................................................9

Blackbody
User Manual
Precautions
iii

Blackbody
User Manual
Overview
1
1Overview
1.1 Introduction
The precision Blackbody is used as a temperature calibrator for adjusting no-contact
(point) IR thermometers or thermal imagers in the lab. The instrument’s features are:
⚫Temperature is accurately and stably controlled by intelligent temperature
controller.
⚫Special high-emissivity coating is used on target surface.
⚫Rapid heating.
1.2 Unpacking
⚫Unpack the Blackbody carefully and inspect it for any damage that may have
occurred during shipment. If there is shipping damage, notify the carrier
immediately.
⚫Put the Blackbody on a steady workbench and DO NOT touch the target surface.
Always carry the Blackbody in an upright position.
1.3 Environmental Conditions
⚫DO NOT operate the Blackbody in excessively wet, oily, dusty, or
dirty environments. DO NOT operate near flammable materials.
⚫Allow at least 5.9 in. (15 cm) of clearance around the Blackbody.
⚫The Blackbody operates safely under the following conditions:
➢Ambient temperature range: 32º F –104 º F (0º C - 40º C).
➢Ambient relative humidity: maximum 80%.
➢Vibrations in the calibration environment should be minimized.

Blackbody
Overview
1.4 Safety Information
User Manual
⚫DO NOT use this Blackbody for any application other than calibration work. The
Blackbody was designed for temperature calibration. Any other use of the Blackbody
may cause unknown hazards to the user.
⚫This Blackbody is intended to operate at ambient temperature 32º F –104 º F
(0º C - 40º C). DO NOT put the Blackbody in the high/low temperature chamber.
⚫Calibration equipment should only be used by trained personnel.
⚫The power cord of the Blackbody is equipped with a three-pronged grounding plug
for your protection against electrical shock hazards. It must be plugged directly into
a properly grounded three-prong receptacle.
⚫DO NOT touch the IR target surface or areas surrounding the target of the instrument
to avoid harm to the target surface.
⚫DO NOT change the values of the calibration constants from the factory set values.
The correct setting of these parameters is important to the safety and proper operation
of the calibrator.

3
Blackbody
User Manual
Device
2 Device
Figure 2-1 shows the device.
Figure 2-1 Appearance
Mounting screw hole
IR target surface

Blackbody
User Manual
Device
Figure 2-2 Installation dimensions
[in. (mm)]
