Vicon CE202D-WN User manual

www.vicon-security.com
XX269-10-00
CE202D-WN Network Outdoor
Camera Dome
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
Vicon Industries Inc.
Tel: [phone] Fax: [phone] Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Document Number: 8009-8269-10-00
3URGXFWVSHFL¿FDWLRQVVXEMHFWWRFKDQJHZLWKRXWQRWLFH
Issued: 214
&RS\ULJKW9LFRQ,QGXVWULHV,QF$OOULJKWVUHVHUYHG
Quick Guide

2
1. Description
The information in this manual provides quick installation and setup procedures for the CE202D-WN
Camera Dome. These units should only be installed by a qualified technician using approved materials
in conformance with federal, state, and local codes. Read these instructions thoroughly before
beginning an installation. Always refer to Vicon’s website to assure you have the most up-to-date
manual, www.vicon-security.com.
The CE202D-WN is designed for demanding outdoor security installations. This cost-effective fixed
network camera includes an integral 3.7 mm megapixel fixed lens; the 1080p resolution delivers crisp
clear images. The CE202D-WN camera is fully compatible with all ViconNet® systems; its ONVIF
certification provides an open-platform for integration into other video management systems.
The network camera provides triple-streaming video and supports H.264 compression technology.
MPEG-4 and Motion JPEG (M-JPEG) compressions are also provided, as are privacy masking and
motion detection. Installation is made easy and cost-effective with Power-over-Ethernet (PoE); the
camera also accepts 12 VDC.
• Installation Steps
Follow these steps to install the network camera on your local network (LAN):
1. Check the package contents against the list that follows.
2. Connect the network camera.
3. Set an IP address.
4. Set the password.
1.1 Components
The system comes with the following components:
Camera Unit Installation CD Installation Guide
Accessory Kit Template Sheet Optional OSD Controller

3
Note 1: Check your package to make sure that you received the complete system, including all
components shown above.
Note 2: Adapter for 12 VDC is not supplied; the optional V920D-OSD Controller can be purchased
separately..
• Contents in the installation CD
1. The CE202D-WN User’s Manual
2. The SmartManager User’s Manual
3. The SmartManager Installation software

4
2. Installation
• Camera Installation
Carefully remove the contents from the box, and verity that nothing was damaged in shipment.
1) Using the template sheet provided, make screw holes for camera on the ceiling.
2) Disassemble the camera by loosening the four (4) captive screws securing the cover and removing
the camera cover.
3) Secure the dome camera to the ceiling using the anchors (2x) and screws (2x) provided in the
accessory kit.
Camera Dimension
The diagram below provides dimensions.
Dimensions Unit: mm

5
2.2 Connections
Connection Cable
NO Name Description
1 Audio Cable Audio line output, RCA Jack
2 Power Cable
Red: 12 VDC
White: GND
3 ALARM Cable
Blue: GND
Gray: ALARM INPUT
Brown: GND
Yellow : ALARM OUT
4 Ethernet Cable Ethernet, RJ-45 port compatible with 10/100Mbps having PoE
functionality. Modular Jack
NO Name Description
1
Micro-SD Slot
Micro-SD memory slot
2 Factory Default Button Button for the factory default setting
3
Mic Port
Microphone input.
4 Service Monitor Port
Service Monitor (set to NTSC by default; change video format
from Source menu); V920D-OSD Controller (option)
Communication Port, Mono Jack

6
• Connecting to the RJ-45
Connect a standard RJ-45 cable to the network port of the network camera. Generally a
cross-over cable is used for direct connection to a PC, while a direct cable is used for connection
to a hub.
Micro SD memory slot
Insert the SD memory card (customer supplied).
• Connecting the Power
Connect a 12 VDC power adaptor (customer supplied) to the camera.
• Connecting Service Monitor Port
The Service Monitor output port is located on the board of the dome camera and is used for easy
OSD setup.
▶ID & IP assignment
To make changes in the OSD menu, the optional V920D-OSD controller can be used to set
camera title and IP address.
1. Connect the OSD Controller to the Service Monitor port of the network camera.
2. Connect Service Monitor and the Video Output port of the OSD Controller.
3. Press the SET button on the controller to access the Main Menu.
4. Change camera ID and IP address as needed. Additionally, the Name (or title) of the camera
can be changed. Use the ↑↓←→ buttons on the controller to change the parameters.
5. Select SAVE or CANCEL to exit the Main Menu.
The Video Output can also be used for easy zoom and focus control when adjusting the lens.
Video Output is restricted to 704x480 (576) resolution.
▶Pan & Tilt Control
The camera enters Zoom and Focus control mode when the OSD Controller is connected to the
Service Monitor port.
-. Pan Control: ↑(Up), ↓(Down)
-. Tilt Control: ← (Left), → (Right)
Note: The optional V920D-OSD OSD Controller can be purchased separately.

7
2.3 Network Connection and IP assignment
The network camera is designed for use on an Ethernet network and requires an IP address for
access. Most networks today have a DHCP server that automatically assigns IP addresses to
connected devices. By the factory default, your camera is set to obtain the IP address automatically
via DHCP server. If your network does not have a DHCP server the network camera will use
192.168.1.100 as the default IP address.
If DHCP is enabled and the product cannot be accessed, run the “Smart Manager” utility on the CD to
search and allocate an IP address to your products, or reset the product to the factory default settings
and then perform the installation again.
1. Connect the network camera to the network and power up.
2. Start SmartManager utility (Start>All programs>SmartManager>SmartManager), the main
window displays. After a short while any network devices connected to the network will be
displayed in the list.
3. Select the camera on the list and click right button of the mouse. The pop-up menu below
displays.
4. Select Assign IP. The Assign IP window displays. Enter the required IP address.
Note: For more information, refer to the Smart Manger User’s
Manual.

8
3. Operation
The network camera can be used with Windows® operating system and browsers. The recommended
browsers are Internet Explorer®, Safari®, Firefox®, Opera® and Google Chrome® with Windows.
Note: To view streaming video in Microsoft® Internet Explorer, set your browser to allow ActiveX
controls.
Note: Some screens may appear different (i.e., color scheme) depending on the firmware version, but
the functionality is the same or similar.
3.1 Access from a browser
1. Start a browser (i.e., Internet Explorer).
2. Enter the IP address or host name of the network camera in the Location/Address field of your
browser.
3. A starting page displays. Click Live View, Playback or Setup to enter web page.
4. Click Live View for the network camera’s Live View page to appear in the browser.

9
3.2. Access from the internet
Once connected, the network camera is accessible on your local network (LAN). To access the
network camera from the Internet you must configure your broadband router to allow incoming data
traffic to the network camera. To do this, enable the NAT-traversal feature, which will attempt to
automatically configure the router to allow access to the network camera. This is enabled from Setup
> System > Network > NAT.
For more information, refer to “3.5.6 System>Network>NAT”of User’s Manual.
3.3 Setting the admin password over a secure connection
To gain access to the product, the password for
the default administrator user must be set. This
is done in the “Admin Password” dialog, which is
displayed when the network camera is accessed
for the setup at the first time. Enter your admin
name and password, set by the administrator.
Note:
The default administrator username is
“ADMIN” and password is “1234”. If the
password is lost, the network camera must be
reset to the factory default settings. See section
“3.8 Resetting to the Factory Default Settings” for
more details.
3.4 Live View Page
The live view page comes in several screen
modes: 1920x1080, 1280x1024, 1280x720,
704x480 (576), 640x480, 352x240 (288)
and 320x240. Select the most suitable
mode in accordance with your PC
specifications and monitoring purposes.
1) General controls
Live View Page Search & Playback Page Setup Page Help Page
The video drop-down list allows you to select a customized or pre-programmed
video stream on the live view page. Stream profiles are configured under Setup > Basic
Configuration > Video & Image. For more information, see section “3.5.1 Basic Configuration >
Video & Image”of User’s Manual.
The resolution drop-down list allows the selection of the most suitable
video resolutions to be displayed on Live View page.

10
The protocol drop-down list allows the selection of the combination of
protocols and methods to use depending on your viewing requirements and on the properties of
the network.
2) Control toolbar
The live viewer toolbar is available on the web browser page only. It displays the following
buttons:
The Stop button stops the video stream being played. Pressing the key again toggles the
start and stop. The Start button connects to the network camera to start playing a
video stream.
The Pause button temporarily stops (pauses) the video stream being played.
The Snapshot button takes a picture (snapshot) of the current image. The location where
the image is saved can be specified.
The digital zoom activates a zoom-in or zoom-out function for video image on the live
screen.
The Full Screen button causes the video image to fill the entire screen area. No other
windows will be visible. Press the 'Esc' button on the computer keyboard to cancel full
screen view.
The Manual Trigger button activates a pop-up window to manually start or stop the event.
The PT button activates a pop-up window for Pan and Tilt control.
Use the speaker icon scale to control the volume of the speakers.
Use the microphone icon scale to control the volume of the microphone.
3) Video Streams
The network camera provides several images and video stream formats. Your requirements and
the properties of your network will determine the type you use.
The Live View page in network camera provides access to H.264, MPEG-4 and Motion JPEG video
streams and to the list of available video streams. Other applications and clients can also access
these video streams/images directly, without going via the Live View page.
4) Pan and Tilt Control
You can control Pan and Tilts from the live view screen. Press the button on the left top in
the live view screen to activate the control panel.

11
•Adjusting Pan and Tilt:
Click the navigation button in the PT control panel.
Pan Control: ►(Right), ◄(Left)
Tilt Control: ▲(Up), ▼(Down)
3.5 Network Camera Setup
This section describes how to configure the network camera and is intended for product
Administrators, who have unrestricted access to all the Setup tools, and Operators, who have access
to the settings for Basic, Live View, Video & Image and System Configuration.
The network camera is configured by clicking Setup in the top right-hand corner of the Live View
page. Click on to access the online help that explains the setup tools.
When accessing the network camera for the first time, the
“Admin Password” dialog appears. Enter your admin name and
password, set by the administrator.
Note: If the password is lost, the network camera must
be reset to the factory default settings. See “3.6
Resetting to the Factory Default Settings”. The default
administrator username is “ADMIN” and password is
“1234”.

12
3.6 Resetting to the factory default settings
To reset the network camera to the original factory settings, go to the Setup>System> Maintenance
web page (described in “3.5.6 System > Maintenance”) or use the Reset button on the network
camera, as described below.
• Using the Reset Button
Follow the instructions below to reset the Network Camera to the factory default settings using
the Reset button.
1. Power off the network camera by disconnecting the power adapter.
2. Remove lower dome, if not already done so.
2. Press and hold the Reset button with a straightened paperclip while reconnecting the power.
3. Keep the Reset button pressed for about 2 seconds.
4. Release the Reset button.
5. The network camera resets to factory defaults and restarts after completing the factory
reset. The unit now obtains the IP address automatically via DHCP
6. Reattach the dome.
3.7 More Information
For more information, refer to the network camera User’s manual, which is available on the CD
included in this package.

SN663V IP Camera Dome
Rev.A
Vicon Industries Inc.
Internet Address: www.vicon-security.com
