Vicon V661V-Series Operating instructions

www.vicon-security.com
Installation and Operation Guide
XX236-00-01
V661V-Series Vandal-Proof
Day/Night Analog Camera Dome
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
Vicon Industries Inc., 89 Arkay Drive, Hauppauge, New York 11788
Tel: [phone] Fax: [phone] Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Document Number: 8009-8236-00-01
Product specications subject to change without notice.
Issued: 0911
Copyright © 2011 Vicon Industries Inc. All rights reserved.

- ii -
WARNING
CAUTION
CAUTIONCAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by the qualified
personnel before operating it any further.
Unplug the unit from the wall oulet if it is not going to
be used for several days or more. To disconnect the
cord, pull it out by the plug. Never pull the cord itself.
Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials(curtains, draperies)
that may block the ventilation holes.
Height and vertical linearity controls located at the
rear panel are for special adjustments by qualified
personnel only.
Do not install the unit in an extremely hot or
humid place or in a place subject to excessive
dust, mechanical vibration.
Clean the unit with a slightly damp soft cloth.
Use a mild household detergent. Never use
strong solvents such as thinner or benzine as
they might damage the finish of the unit.
Retain the original carton and packing
materials for safe transport of this unit in the
future.
Safety ----------------------------------------- Installation -----------------------------------
Cleaning --------------------------------------
PRECAUTIONS
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR
OTHER OPENINGS ON THE EQUIPMENT.

- iii -
FCC INFORMATION : THIS EQUIPMENT HAS BEEN TESTED
AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE
LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION
AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS
OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT
GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH
THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE
TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN
A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL
INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
CAUTION : CHANGES OR MODIFICATIONS NOT EXPRESSLY
APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE
COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN
ICES-003.
NORME NMB-003 DU CANADA.
WARNING
THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS
PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE
THE USER MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.
CE COMPLIANCE STATEMENT
FCC COMPLIANCE STATEMENT

- iv -
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4 . Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer,
or sold with the apparatus.
When a cart is used,use caution when moving
the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been moisture, does
not operate normally, or has been dropped.
15. CAUTION THESE SERVICING INSTRUCTIONS ARE FOR USE BY
QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE RISK
OF ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING OTHER
THAN THAT CONTAINED IN THE OPERATING INSTRUCTIONS
UNLESS YOU QRE QUALIFIED TO DO SO.
16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed
Class 2 power source only.
IMPORTANT SAFETY INSTRUCTIONS

1
The camera provides high-quality images using Sony CCD technology especially
applications.
designed for closed-circuit television (CCTV) and security surveillance
Features:
INTRODUCTION
TM Technology
High resolution and high performance Sony Super HAD
Excellent picture quality
600 lines(Color) of resolution
0.1 lux(Color), 0.04lux(B/W) @ F1.2 50IRE Sensitivity
Auto electronic shutter [1/60(1/50) ~ 1/100,000] and manual electronic
shutter modes
OSD (On Screen Display)
Auto and manual white balance modes
DWDR
OSD Font Color ( 16 Color)
BLC (Back Light Compensation)
Day&Night (Auto / DAY / NIGHT / EXT)
Private Mask (8 position, 16 Colors)
AGC (Auto Gain Control)
MIRROR (ON/OFF)
VIDEO OUT BNC
Motion Detection(4 point)
HLC (High Light Compensation)
DPC (Dead Pixel Cancellation)
2.8~12
~22
Operates in AC24V +/- 10% / DC12V +/- 10%
Use Certified / Listed Class 2 power source only
Test monitor Output
mm A/I Varifocal Lens F1.2
9 mm A/I Varifocal Lens F1.4
IMPORTANT : The user of this camera is responsible for
checking and complying with local, state, and federal laws
and statutes concerning the recording and monitoring of
audio signals.
(D&N Lens option)
(D&N Lens option)

CAMERA CONNECTIONS
2
2 3
1
REMINDER:
Never aim the camera directly into the sun.
1. Lens : 2.8~12mm or 9~22mm A/I Vari-focal lens for wide area monitoring.
2. Power : 24V AC input / 12V DC input
power source from a DC 12V or AC 24V ac +/-10% 60/50Hz +/-1Hz
Use Certified/Listed Class 2 power source only.
*If using DC 12V power adaptor,
use a power supply capable of supplying 5 Watts.
3. Video : BNC connector used to connect the camera to a monitor, switcher, etc.
(D&N with ICR model option)

INSTALLATION
Figure 1
Torx screws
M5x10 (4x)
Figure 2
Seal around
the housing
base tightly using
the silicon rubber
Drilling
Guide Label
3
1. Loosen the four Torx screws located midway up the front of the housing.
Leave the screws intact.(Fig. 1)
2. Drill the mounting location using the supplied drill guide label. (Fig. 3)
3. Attach the housing to the ceiling using suitable fasteners, M6x35 tapping screws are
supplied. Only use if they are suitable. (Fig. 3)
4. Reattach the housing and tighten the Torx screws. (Fig. 2)
CEILING / WALL
Plastic Anchor(4x)
Rubber Washers(4x)
Mounting Screw
M6X35(4x)
Figure 3

4
The housing can also
be mounted on a 4 x 4 or 4 x 2
electrical box.
MOUNTING HOUSING TO
AN ELECTRICAL BACK BOX
Electrical box
Rubber
Washers(4x)
- Video out check-
Test Monitor
Joystick Switch Board
SPOT VI EO D
CN2
R GI HT
LEFT
UP
DOWN
R1
R2
R3
R4

5
0.1 in. (3.0mm thick),
impact-resistant P.C(LEXAN)
3.9in (9.9cm)diameter
Unit: mm (inches)
1.89 Ib (0.86Kg)
2.33 Ib (1.06Kg)
115 (4.3)
59 (2.3)
56.4 (2.2)
146.4 (5.7)
R49.5 (1.9)
17.5 (0.6)

THE DEFINITION OF TERMS
White Balance
Compensates for deviations in the white color caused by changes in the color
temperature of the light source so that the colors are reproduced correctly.
Exposure
Adjusts the images to the optimum brightness.
SHUTTER (Electronic Shutter)
Controls the integration time (exposure) of the photodiode array and reduces blooming,
overexposure, and smear when capturing moving objects.
Flicker (FLC)
Avoids image flicker when there is a discrepancy between current and frequency
AGC (Automatic Gain Control)
Automatically adjusts (boosts) the video signal to the required level to produce a quality
image in low light situations
Back Light Compensation (BLC)
Compensates for the brightness of the subjects with a large amount of background light
that would make it practically impossible to see any details of the subjects. Adjusts the
iris so that a distinctive subject and the background are delivered at the same time.
HLC (High Light Compensation)
When a high-brightness subject is shot, it may not be brought into focus because of the
large surface area over which the high-brightness pixels are spread.
In cases like this, the high-brightness subject can be brought into focus by using this
function.
LENS SHAD. (Lens Shading)
This function is the make brighter image of corner of screen.
Mask
Hides one or more areas that the user does not want to be displayed on screen.
Masks can be set with their own display area, color, darkness and mosaic processing.
Detection
Detects motion within the scene using one of the available methods.
Some methods trigger the Alarm output.
Sharpness
Reducing this parameter adjusts the noise level to smooth out the "noise" caused by
the compression.
Caution should be taken not to reduce it too much, which may result in a blurred image.
6

Resolution
Controls the display of fine details. The higher the resolution, the higher level of
details can be seen.
2D-NR (Digital Noise Reduction)
Adjusts the illuminance noise level in low light situations by reducing image noise in
order to improve the image.
Nega
Reverses the color signals for the Chroma signal so the image looks like a “negative.”
DPC(Dead Pixel Cancellation)
white pixels whose frequency of occurrence varies in proportion to the temperature
are sometimes observed when the devices are used under the influence of external
factors or especially high temperatures. The white pixel detection and compensation
function can automatically detect and compensate up to 64 white pixels with the highest
detection level in sequence so as to maintain the image quality.
MIRROR
Reverses the image on the screen left to right or right to left
(as it would be seen in a mirror.)
DWDR
When the camera looks at a dark area, there may be loss of dark detail in the
low-brightness subjects.
Using DWDR (on) may produce a higher quality image.
PARK. LINE
Using the camera to look out the rear of a vehicle, a lane can be viewed on the video
image to see anything directly behind the vehicle. The location and size of the lane can
be adjusted through the menu: LT/LB: left top/bottom; RT/RB: right top/bottom;
F: far; N: near; T: thickness of the line.
FONT COLOR
Adjust OSD menu color from a choice of 16 different colors.
7

STRUCTURE OF THE SETUP MENU
<SETUP>
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT
<LENS>
DC
MANUAL
<EXPOSURE>
SHUTTER
BRIGHTNESS
AGC
DWDR
RETURN
<WHITE BAL> <DAY NIGHT>
AUTO
COLOR
B/W
EXT
<SPECIAL>
CAM TITLE
MOTION
PRIVACY
PARK.LINE
LANGUAGE
RETURN
<IMAGE ADJUST>
LENS SHAD.
2 DNR
MIRROR
FONT COLOR
CONTRAST
SHARPNESS
DISPLAY
NEG.IMAGE
RETURN
<RESET>
FACTORY
RETURN
ATW1
ATW2
AWC -> SET
MANUAL
<BACKLIGHT>
OFF
BLC
HLC
<DPC>
COVER THE LENS
THEN
PRESS ENTER KEY
8

This function is used to adjust the brightness of the screen.
1. When the SETUP menu is displayed on the screen, please position the arrow to point to
'LENS' by using the UP and DOWN buttons.
2. Please select the type of the lens you wish to use by pressing the LEFT or RIGHT button.
LENS (Selection)
►
Note The brightness of the screen can be adjusted in DC mode.
EXPOSURE
EXPOSURE
SHUTTER AUTO
BRIGHTNESS IIIIIIIIIIIIIIIIII 50
AGC ----
D-WDR OFF
RETURN RET
The EXPOSURE menu is used to set the automatic light control method for this camera.
(Xtended Dynamic Range)
1) SHUTTER Select the shutter mode.(Auto,1/60(50), FLK~ 1/100,000 sec)
Can be changed while in shutter mode.
2) BRIGHTNESS Adjust BRIGHTNESS level (0 ~ 255)
Can be adjusted while in DC/ manual lens mode.
3) AGC Auto gain control (OFF / LOW / MIDDLE / HIGH)
4) DWDR Digital Wide dynamic range
OFF / ON
9
ATW1
AUTO
►MANUAL
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT
ATW1
AUTO
OFF
►
ATW1
AUTO
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT

WHITE BAL
<WHITE BAL MANUAL MODE>
WHITE BAL MANUAL
COLOR TEMP OUTDOOR
BLUE ------------
RED ------------
RETURN RET
►
The screen color can be adjusted by using the WHITE BALANCE function.
o o
1) ATW1 Set the color temperature 2500 K 10000 K
o o
2) ATW2 Set the color temperature 2000 K 13000 K
3) AWC -> SET Please press the ENTER button white the camera is directed
at a piece of white paper to obtain the optimum state under
current illumination. if the environment including the light source
is changed, you have to adjust the white balance again.
4) MANUAL Manual mode. User can change R and B Gain manually.
o
INDOOR Set the color temperature to 3200 K
o
OUTDOOR Set the color temperature to 6300 K
BACKLIGHT BLC
AREA SEL AREA1
AREA STARE ON
GAIN IIIIIIIIIIIIIIIIII042
IIIIIIIIIIIIIIIIII
HEIGHT 005
WIDTH
IIIIIIIIIIIIIIIIII004
LEFT/RIGHT IIIIIIIIIIIIIIIIII005
TOP/BOTTOM IIIIIIIIIIIIIIIIII005
RETURN RET
BACKLIGHT HLC
LEVEL IIIIIIIIIIIIIIIIII 200
MODE NIGHT ONLY
RETURN RET
< MODE> BACKLIGHT
BACKLIGHT
1) BLC Prevents such a back light effect to secure a clear image under all
illumination environments
2) HLC The function improves the identification capability of subjects facing a
brightly lit situation by filtering out the strength of the light
10
►ATW1
AUTO
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT
►
ATW1
AUTO
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT

11
<DAY NIGHT AUTO MODE>
DAY NIGHT
DAY NIGHT AUTO
D -N LEVEL IIIIIIIIIIIIIIIIII128
D-N DELAY 5 SEC
N-D LEVEL IIIIIIIIIIIIIIIIII 003
N-D DELAY 5 SEC
RETURN RET
►
DAY NIGHT B/W
BURST OFF
IR SMART ON
IR LEVEL HIGH
RET
RETURN
►
IR SMART
IR GAIN IIIIIIIIIIIIIIIIII 074
HEIGHT IIIIIIIIIIIIIIIIII 007
WIDTH IIIIIIIIIIIIIIIIII 008
LEFT/RIGHT IIIIIIIIIIIIIIIIII 003
TOP/BOTTOM IIIIIIIIIIIIIIIIII 004
RETURN RET
►
<DAY NIGHT B/W MODE>
DPC
DPC Auto setting (Dead pixels are automatically removed)
DPC
COVER THE LENS
THEN
PRESS ENTER KEY
►PROCESSING NOW
►
ATW1
AUTO
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT
►
ATW1
AUTO
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT
►
ATW1
AUTO
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT
The DAY/NIGHT menu is used to configure the day and night related setting for this camera.
This camera can turn the IR(infrared)filter on or off.
Mode : AUTO / COLOR / B/W / EXT (The EXT is not operating in this mode)
*The IR LEVEL is not operating in DAY NIGHT B/W mode.

1) CAM TITLE
2) MOTION
AREA SELECT Select MD area number. (AREA1 ~AREA4)
AREA STATE Select MD ON/OFF
HEIGHT Adjust height of MD area
WIDTH Adjust width of MD area
LEFT/RIGHT Adjust the location of the MD area with boundary LEFT and RIGHT.
TOP/BOTTOM Adjust the location of the MD area with boundary TOP and BOTTOM
DEGREE Adjust sensitivity of MD area.(0~255)
VIEW The screen displays with pink dots. When a motion is detected
in the selected area, the pink dots are displayed on the screen.
A. CAM TITLE
B. Character Table
C. Command Line
← : Move to left
→ : Move to right
CLR : Erase all characters
POS : Move the position of title
END : Save and End
SPECIAL
►
MOTION
AREA SELECT AREA1
AREA STATE ON
HEIGHT IIIIIIIIIIIIIIIIII 4
WIDTH IIIIIIIIIIIIIIIIII
4
LEFT/RIGHT IIIIIIIIIIIIIIIIII
2
TOP/BOTTOM IIIIIIIIIIIIIIIIII
2
IIIIIIIIIIIIIIIIII 38
DEGREE
OFF
VIEW
RET
RETRURN
►
A
B
C
CAM TITLE
←→ CLR POS END
SPECIAL
CAM TITLE
MOTION
PRIVACY
PARK.LINE
LANGUAGE
RETURN
ON
ON
OFF
OFF
ENGLISH
RET
.
►
ATW1
AUTO
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT
12

3) PRIVACY
AREA SELECT Select MASK area number.(Area 1 ~ Area 8)
AREA STATE Select MASK ON/OFF
HEIGHT Adjust height of MASK area
WIDTH Adjust width of MASK area
LEFT/RIGHT Adjust the location of the MASK area with boundary LEFT and RIGHT
TOP/BOTTOM Adjust the location of the MASK area with boundary
TOP and BOTTOM.
COLOR Select MASK color. (0~15)
RETURN
4) PARK.LINE Select Pacring area
5) LANGUAGE ENGLISH or CHINESE
6) RETURN RET
PRIVACY
AREA SELECT AREA1
ON
AREA STATE
HEIGHT IIIIIIIIIIIIIIIIII 032
WIDTH IIIIIIIIIIIIIIIIII 032
LEFT/RIGHT IIIIIIIIIIIIIIIIII 020
IIIIIIIIIIIIIIIIII
TOP/BOTTOM 030
COLOR IIIIIIIIIIIIIIIIII 000
RET
RETURN
►
<PRIVACY MODE>
►
SPECIAL
CAM TITLE
MOTION
PRIVACY
PARK.LINE
LANGUAGE
RETURN
OFF
OFF
ON
OFF
ENGLISH
RET
PARK. LINE
LT 077
LB 029
RT
RB
F
N
T
RET
►
122
170
013
058
009
►
ATW1
AUTO
LENS
EXPOSURE
WHITE BAL
BACKLIGHT
DAY NIGHT
DPC
SPECIAL
IMAGE ADJ
RESET
E XIT
►
SPECIAL
CAM TITLE
MOTION
PRIVACY
PARK.LINE
LANGUAGE
RETURN
OFF
OFF
ON
OFF
ENGLISH
RET
13

<IMAGE ADJUST MODE>
LENS SHAD
LEVEL IIIIIIIIIIIIIIIIII 006
RETURN RET
►
►LENS SHAD
2DNR
MIRROR
FONT COLOR
CONTRAST
SHARPNESS
DISPLAY
NEG.IMAGE
RETURN
IIIIIIIIIIIIIIIIII 122
IIIIIIIIIIIIIIIIII 21
ON
ON
OFF
IMAGE ADJUST
OFF
CRT
FONT COLOR
FONT
IIIIIIIIIIIIIIIIII 003
ID&TITLE IIIIIIIIIIIIIIIIII 003
RETURN RET
►
►
LENS SHAD
2DNR
MIRROR
FONT COLOR
CONTRAST
SHARPNESS
DISPLAY
NEG.IMAGE
RETURN
IIIIIIIIIIIIIIIIII 122
IIIIIIIIIIIIIIIIII 21
ON
ON
OFF
IMAGE ADJUST
OFF
CRT
IMAGE ADJUST
1) LENS SHAD Adjust Lens shading level (0~255)
Select 2DNR ON/OFF
2) 2DNR
Select MIRROR ON/OFF
3) MIRROR
4) FONT COLOR Select FONT COLOR level (0~15)
Select IDR TITLE level (0~15)
Adjust CONTRAST level (0~255)
5) CONTRAST
6) SHARPNESS
Adjust SHARPNESS level (0~31)
7) DISPLAY
Select DISPLAY mode (CRT /LCD/USER)
Select Negative image mode ON /OFF
8) NEG. IMAGE
RET
RET
14

1) FACTORY Returns to the level which was set by the manufacturer for shipment.
RESET
EXIT
1) EXIT Saves all setting and exits.
CRT ADJUST
PED LEVEL IIIIIIIIIIIIIIIIII 022
COLOR GAIN IIIIIIIIIIIIIIIIII 192
RETURN RET
►
►
LENS SHAD
2DNR
MIRROR
FONT COLOR
CONTRAST
SHARPNESS
DISPLAY
NEG.IMAGE
RETURN
IIIIIIIIIIIIIIIIII 122
IIIIIIIIIIIIIIIIII 21
ON
ON
OFF
IMAGE ADJUST
OFF
CRT
LCD AJUST
GAMMA 0.50
PED LEVEL IIIIIIIIIIIIIIIIII
028
COLOR GAIN IIIIIIIIIIIIIIIIII 160
RET
RETURN
►
USER AJUST
GAMMA 0.45
PED LEVEL IIIIIIIIIIIIIIIIII 028
COLOR GAIN IIIIIIIIIIIIIIIIII 160
RETURN RET
►
RET
15

LENS ADJUSTMENT (OPTIONAL VARIFOCAL LENS)
N
TW
Adjust Focus
Adjust Angular Field View
Field of view: Adjust setting from Tele (T)
to Wide (W) field of View.
Focus: Adjust lens focus from near
(N) to infinity ( ).
DC AUTO IRIS LENS
Image Size 1 / 3 " C C D
Focal Length
Aperture Ratio
Angular
Field of View
2.8-12mm
DIAGONAL
o
2.8mm : 119.9
o
12mm : 28.80
2.8-12mm 5%
1 : 1.2 5%
Control ( - )
Control ( + )
Drive ( + )
Drive ( - )
LENS
9-22mm
DIAGONAL
o
9mm : 40.2
o
22mm : 16.1
9-22mm 5%
1 : 1.4 5%
1 / 3 " C C D
16
