Vicon V960-N Series Instruction manual

Quick User Guide V960-N Series Network Camera
1
Warning before installation
-Power off the Network camera if it is found to be smoking or smells unusual.
-Keep the Network camera away from water. If the Network camera gets wet, power
off immediately.
-Do not place the Network camera near heat sources, such as a television or oven.
-Refer to your instruction manual for the operating temperature.
-Keep the Network camera away from direct sunlight.
-Do not place the Network camera in high humidity environments.
-Do not place the Network camera on unsteady surfaces.
-Do not touch the Network camera when there is lightning present.
-Do not disassemble the Network camera.
-Do not drop the Network camera.
-Do not insert any object into the Network camera, such as a screwdriver.
For other safety and regulation information, please refer to User’s manual.
1. Check Contents
No.
Item
Description
1
Network Camera
V960-N Series (V960-N, V961-N, V962-N)
2
Software CD
User’s Manual, Utility software
3
Quick User Guide
This document
4
Accessories
Mounting bracket
Screws for mounting bracket
C-mount adapter ring
DC jack adapter
Dust protection cap
Terminal block connector
Allen wrench
2. Physical Description
Rear View
1. Alarm In/Out, Audio In/Out (use terminal block connector)
2. Video Out
3. Micro SD card (SDHC supported)

Quick User Guide V960-N Series Network Camera
2
4. Network (RJ-45 PoE supported)
5. Reset Button
6. Power (DC12V / AC24V)
7. Status LED
8. DC Iris
Front View
9. Flange back locking screw
3. Making Connection
1. If you have external devices such
as sensor or alarms, make connection
from terminal block connector.
2. Connect Ethernet cable to make connection
to the network hub.
3. Connect power cable to the camera.
When you use PoE function, you don’t
need to connect power.

Quick User Guide V960-N Series Network Camera
3
4. Assign IP Address
Default setting is set to “DHCP” and “UPnP” function is set to ON. If your network
has a DHCP server and the UPnP function is enabled on your PC, you can find the
camera in “My Network”. Refer to the Multi Upgrade Tool manual for detailed
instructions.
Execute the Multi Upgrade Tool (from the Installation CD); it will search cameras on
the network automatically.
1) After the list of detected devices appears, select the camera you are trying to
configure.
2) Select the Network type as Static or DHCP. If Static is selected, enter all of the
network information for your camera.
3) Select the “Change IP Address” button. The message “Do you want to change IP
address?” will display; select “Yes” from the pop-up window.
4) Check the Type as Static or DHCP from the list.
Then double click the camera in the list; Internet Explorer® will open
automatically.

Quick User Guide V960-N Series Network Camera
4
5. Web Browser Connection
Note : The Network camera supports Internet Explorer® 7 or above.
Please check version of your browser and update it if necessary.
When you first access the camera you need to download and install an
Active X control from the camera to display a Live image.
Default User and Password are set to “ADMIN” and “1234”. Please type in
the user ID and password to connect the network camera.
Note: By Default the cameras come with “Installation Mode” set to “ON” to
enable Analog output. Additionally, all installation setup must be done prior to
the camera being used with a VMS, including ViconNet; the VMS forces the
Installation Mode to OFF. You must turn installation mode off to use 720p or
1080p streaming.
For further information for setup, refer to User’s manual on the software CD.
