Victor Tools K762 User manual

Solar LED Spotlight
K762 v01: 09/03/22
Please read and retain these instructions for future reference
The Enterprise
Department
UK Head Office, 11 Bridge Street, Bishop’s Stortford, CM23 2JU
Tel: [phone]*, Fax: [phone]
www.coopersofstortford.co.uk
EU address: D.S.B. LD, 160 Bd. de Fourmies, 59100 Roubaix, France
Tel: [phone]
*UK Calls cost around 7 pence per minute plus your telephone company’s network access.
Please check with your telephone supplier.
Always position in direct sunlight
Dimensions
11.5 x 17 x 9cm
•WATERPROOF IP65 RATED
•8 BRIGHT WHITE LEDS (not replaceable)
•WHEN MOTION IS DETECTED IS AUTOMATICALLY
POWERS OUT 200 LUMENS OF LIGHT AND THEN
ONCE MOTION HAS STOPPED IT WILL
AUTOMATICALLY TURN OFF TO AVOID LIGHT
POLLUTION
•FIXINGS ARE SUPPLIED
•LARGE AND ADJUSTABLE SOLAR PANEL FOR
OPTIMAL SUN ABSORPTION
•MOTION ACTIVATED
•GREAT FOR PORCHES, BACKYARDS, PATIOS,
DRIVEWAYS, SHEDS.
•SOLAR POWERED
•360 DEGREE ROTATION MOUNTING PLATE
•ALSO COMES WITH A GROUND STAKE SHOULD
YOU WISH TO USE A GROUND LIGHT RATHER
THAN WALL MOUNTED
•BUILT IN PIR MOTION SENSOR DETECTS MOTION
UP TO 10 METERS AWAY.
•NO CABLES OR RUNNING COSTS
•NOT ONLY WILL IT PROVIDE AS A SECURITY LIGHT
BECAUSE IT LOOKS LIKE A SECURITY CAMERA IT
CAN ALSO FOOL INTRUDERS AND DETER THEM
Parts
1. Adjustable solar panel
2. Adjustment knob
3. Swivel arm
4. Mounting plate
5. 8 LED lights
6. Motion sensor
7. Sensor mode/OFF Switch
Battery
Contains 1x Lithium-ion cell rechargeable
battery, 3.7V, 1800mAh

Solar LED Spotlight K762 Instructions for Use
Please read and retain these instructions for future reference v001: 09/03/22
The Enterprise
Department
UK Head Office, 11 Bridge Street, Bishop’s Stortford, CM23 2JU
Tel: [phone]*, Fax: [phone]
www.coopersofstortford.co.uk
EU address: D.S.B. LD, 160 Bd. de Fourmies, 59100 Roubaix, France
Tel: [phone]
*UK Calls cost around 7 pence per minute plus your telephone company’s network access.
Please check with your telephone supplier.
INSTALLATION
PLEASE READ THIS MANUAL CAREFULLY BEFORE USE AND KEEP IT FOR FUTURE USE.
Find an ideal Place for the Solar Light.
Place the solar light in an area where it will receive direct sunlight for at least 8 hours per day. The number
of hours the light will illuminate is directly proportional to the hours of sunlight it receives. If the light is
placed in a shaded area, it will not be able to fully charge and its illumination time will be limited. Do not
place the light near other outdoor lighting like porch or streetlights. These may fool the sensor and keep
the light from coming on, or cause it to turn off automatically
To easily insert stakes into the ground, it is recommended to wet the ground first. To avoid damaging
garden stakes when inserting into the ground, select a spot in soft, rock-free soil. Insert the base of the
stake first then gently insert the rest of the stake into the base. After inserting the stake into the ground,
place the spotlight over the stake.
Mounting the spotlight
1. Remove the mounting plate
from the spotlight by
twisting the dial anti-
clockwise.
2. Choose a locatoin with
maximum sun exposure.
Drill holes matching the
pattern on the mounting
plate and install plastic
anchors (included). Attach
the mounting plate using 3
screws (included)
3. Align the arm of the spotlight
with the opening of the
mounting plate. Twist the
dial clockwise to tighten and
secure it.
ADJUSTING ANGLES
1. To adjust the angle of the Solar Panel, loosen the Adjustment Knob (2) Once desired angle has been
selected, tighten the knob.
1. Swivel the arm (3) of spotlight to direct the light where needed

Solar LED Spotlight K762 Instructions for Use
Please read and retain these instructions for future reference v001: 09/03/22
The Enterprise
Department
UK Head Office, 11 Bridge Street, Bishop’s Stortford, CM23 2JU
Tel: [phone]*, Fax: [phone]
www.coopersofstortford.co.uk
EU address: D.S.B. LD, 160 Bd. de Fourmies, 59100 Roubaix, France
Tel: [phone]
*UK Calls cost around 7 pence per minute plus your telephone company’s network access.
Please check with your telephone supplier.
For in-ground installation
USAGE
2. Make sure you read and follow the installation directions prior to use.
3. When using for the first time, turn the Spotlight ON by sliding the switch located on the back of the
solar panel to Sensor Mode position.
2. Leave the unit under direct sunlight for solar charging at least 5-6 hours.
UNIT NEEDS TO BE FULLY CHARGED BEFORE INITIAL USE.
4. If there is insufficient sunlight, it may take longer for the batteries to charge.
5. Once it gets dark, the Spotlight will turn on automatically when it detects motion. The light will stay on
for 30 seconds and then will go off if no motion has been detected.
6. The Spotlight will turn off during the day or if unit runs out of battery.
7. Security Camera likeness: Once the unit is in Sensor Mode (ON) position, red LED light will blink on the
front of the spotlight. The red light will remain blinking until motion is detected and spotlight turns on.
Care and Maintenance Recommendations
1. Clean solar panel with a soft sponge every couple of weeks.
2. Make sure all connectors are still tight and no water getting in.
3. In frosty and freezing weather conditions we recommend you remove any frost from the spotlight and
solar panel to ensure continued function.
BATTERIES
•Keep batteries away from children and pets.
•Do not mix used and new batteries.
•Remove the batteries if left for long periods.
•Never dispose of batteries in a fire.
Make sure the
mounting plate is
attached to the
swivel arm of the
unit.
Insert ground spike
into stake.
Make sure the soil
is softened. Insert
stake into the
ground.
Insert spotlight
over the stake.

Solar LED Spotlight K762 Instructions for Use
Please read and retain these instructions for future reference v001: 09/03/22
The Enterprise
Department
UK Head Office, 11 Bridge Street, Bishop’s Stortford, CM23 2JU
Tel: [phone]*, Fax: [phone]
www.coopersofstortford.co.uk
EU address: D.S.B. LD, 160 Bd. de Fourmies, 59100 Roubaix, France
Tel: [phone]
*UK Calls cost around 7 pence per minute plus your telephone company’s network access.
Please check with your telephone supplier.
•Battery disposal, spent or expired batteries must be properly disposed of and recycled in compliance
with local regulations. For detailed information, contact your local authority.
•Follow the battery manufacturer’s safety, usage, and disposal instructions.
DISPOSAL
•Coopers of Stortford use recyclable or recycled packaging where possible.
•Please dispose of all packaging, paper, cartons, packaging in accordance with your local
recycling regulations.
•Plastics, polybags –Contains the following recyclable plastic.
Code & Symbol
Type of Plastic
ABS
Commonly used for
CD’s, crisp packets, various flexible packaging, baby bottles, sunglass lenses
Notes
Not often or widely recycled
•At the end of the product’s lifespan please check with your local council authorised household waste
recycling centre for disposal.
