Videcon VHD-CAT5-CONV User manual



 UserManual 

SDIVideoExtenderoverCAT5/6

VHD-CAT5-CONV









NOTE:Thecasingdesign
issubjecttochange
withoutnotice.





This kit allows HD-SDI to be transmied up to 45m / 147ft via CAT5/CAT6 cab le in a point-to-point
configuraon. The SDI-UTP Extender supports transmission of up to 1.485 Gbps uncompressed,
un-encrypted digital video (oponally including embedded Audio and/or Time Code) within television
facilies and between professional video equipment.
C
M
Y
CM
MY
CY
CMY
K
Acr2872899118632-28187.pdf 1 19/02/2013 09:23


Features ..

•Upto35m/114ftvia CAT5ecable
•Upto45m/147ftvia CAT6cable
•SupportsSDI‐SMPTE259M‐C(270Mbps);
•HD‐SDI‐SMPTE292M(1.485,1.485/1.001Gbps)
•LEDdiagnostics:sync,SDIdetect
•5V~24VDC



ND11 
R201209‐V2.1


Please read the Manual before attempting to use this product.
Specifications and appearance are subject to change without notice.







DisposalofOldElectrical&ElectronicEquipment(ApplicableintheEuropean
UnionandotherEuropeancountrieswithseparatecollectionsystems).
Thissymbolontheproductoronitspackagingindicatesthatthisproductshallnotbetreated
ashouseholdwaste.Insteaditshallbehandedovertotheapplicablecollectionpointforthe
recyclingofelectricalandelectronicequipment.Byensuringthisproductisdisposedof
correctly,youwillhelppreventpotentialnegativeconsequencesfortheenvironmentand
humanhealth,whichcouldotherwisebecausedbyinappropriatewastehandlingofthis
product.Therecyclingofmaterialswillhelptoconservenaturalresources.Formoredetailed
informationaboutrecyclingofthisproduct,pleasecontactyourlocalcityoffice,your
householdwastedisposalserviceortheshopwhereyoupurchasedtheproduct.





 Caution ..
1.Handlethisproductwithcare
Avoidanyshockorbumpingoftheproduct.Improperhandlingcoulddamagetheproduct.Do
nothandletheunitwithwethands.Provideproperventilationandaircirculationanddonot
usenearwater.
2.Requiresaproperoperatingenvironment
Thisproductisnotwaterproofandisdesignedforindooruse.Theallowabletemperature
rangeforoperationofthisproductisbetween0°C~40°C/32°F~104°F.
3.Checkthepowersourcevoltage
Thepowersourcevoltageshouldbewithinthespecifiedrange.(Productmustmeetthe
specifications).
2


4.Objectsandliquidentry
Neverpushobjectsofanykindintothisproductasthismaytouchdangerousvoltage
pointsofshortoutpartsthatcouldresultinafireorelectricshock.Neverspillany
kindofliquidontheproduct.
5.Cleaning
Donotuseliquidoraerosolcleanerstocleanthisunit.Alwaysunplugthepowerto
thedevicebeforecleaning.
6.Servicing
Donotattempttoservicethisproductbyyourselfasopeningorremovingcovers
mayexposeyoutodangerousvoltageorotherhazards.Referallservicetoqualified
servicingpersonnel.

PackageContents ..

1. One(1)VHD-CAT5-CONV-TX
2. One(1)(VHD-CAT5-CONV-RX
3. One(1)UserManual
4.One(1)ACAdapter

1. 2.3.   4









ApplicationDiagram ..
*InordertoachievetheBestQualityandLongRangecablerunofupto35m/114ft forCAT5e
and45m/147ft forCAT6,youwillneedGoodQualityCable,GoodQualityRJ45Jack,andGood
QualityInstallation.Allthese3pointsareimportantbecauseitaffectsthetransmissiondistance.


3




Parts&Functions ..


VHD-CAT5-CONV SDI Extender over CAT5/6 (TXside)
VHD-CAT5-CONV SDI Video Extender over CAT5/6 (RX side)


NameColorStatusDescription
FlickerSDIsignalisactivestatus.
ACTGreenOFFSDIsignalisinactivestatus.
ONPowersourcehasbeenconnected.
PWRGreenOFFPowersourcehasn’tbeenconnected.

HardwareInstallation ..

1. To open the box, then checking the quality, model no. and quanty of the
equipments and accessories according to the picking list, if there were any
quesons, just feel free to contact your service provider
2. Connect SDI signal source to SDI IN of VHD-CAT5-CONV-TX via coaxial cable.
3. Connect Cable to RJ-45port of VHD-CAT-CONV-TX，and connect another side
Cable to RJ-45 port of VHD-CAT5-CONV-RX
4. Connect the SDI OUT port of VHD-CAT5-CONV-RX to display device by coaxial cable
4


5


TechnicalSpecifications ..
ModelVHD-CAT5-CONV-TXVHD-CAT5-CONV-RX
TypeTransmitter R ece i ver
Standa
r
dSupportedSMPTE 259M(270Mb/s), SMPTE 292M
Speed270Mb/s,1.485Gb/s(automaticselection)


SupportInputFormat

HD:720p@23.98Hz,720p@24Hz,720p@25Hz,
[email protected]Hz,720p@30Hz,720p@50Hz,
72[email protected]Hz,720p@60Hz;1080i@50Hz,1080i
@59.94Hz,1080i@60Hz;1080[email protected]Hz,1080p
@24Hz,1080p@25Hz,1080p@29.97Hz,1080p@30Hz

Indicators
Poweron(onboth
e nd)
Synchronisationdetect(onboth e nd)
Linkbetweenthetwounitworking(onboth e nd)

Connectors
1xBNC75ohmf
ema l e 
1xRJ45SforCAT5e/6unshieldedorshieldedtwistedpair
1xpowerconnector,
2.1mm 

MaximumDistance
All
re solutions
CAT5eUTP/STP:35m/ 114
ft
CAT6 UTP/STP:45m/
147ft

PowerSupplyTwo100‐240V/12VDC1.25Apowersupplies
PowerConsumption 6W
Dimensions98 x65 x28mm/3.85x2.55 x1.1 inches

*Specificationsaresubjecttochangewithoutnotice

AbsolutelyMaximumRatings ..

V alu e s 

Parameter

SymbolMin.Max.

Units 
PowerInputVoltageVCC 5  24 VoltsDC
OperatingTemperatureTop0/3275/167°C/°F
StorageTemperatureHs t ‐20/‐460/140°C/°F
OperatingAmbientHumidity Hop 10  90 %R H
StorageHumidityHs t10  90 %R H

KeyComponents ..
ComponentsMadeinUSAforthisproduct:
NameofComponentManufacturer
Multi‐RateSDIAdaptiveCableEqualizer Mindspeed&Gennum
Multi‐RateSDIAutomaticReclockerMindspeed&Gennum
Multi‐RateDualSlew‐RateCableDriver Mindspeed&Gennum&NationalSemiconductor
DataCommunicationICMAXIM

ComponentsMadeinChinaforthisproduct:
NameofComponentManufacturer
DC/DCConverterRichtek

*Keycomponentsarelistedbythemanufacturerandaresubjecttochange
withoutnotice
EyeDiagram&JitterPerformance ..

SDMode


6


HDMode


7


8

8


















MADEIN CHINA 
VHD-CAT5-CONV 
R201210‐V1

8

