Video Devices SpeedDrive User manual

Welcome
Thank you for purchasing Video Devices
SpeedDrive high-speed storage device.
The SpeedDrive is a portable enclosure
for a Mini-SATA (mSATA) drive with a USB
3.0 interface.
When purchased with a PIX-E kit, the,
SpeedDrive ships with an mSATA drive
installed.
Sold separately, it is available in 2 forms:
• Enclosure only
• Enclosure with mSATA drive
LA small screw driver and stickers
are included for installing and
labeling your own drive.
To install your own mSATA drive:
1. If enclosure is assembled, use
notches on either side of the USB
plug to carefully pry open the case.
2. Properly position the mSATA drive
into the enclosure.
3. Snap the case back together.
4. Use the included screw driver and
fasten the back with the provided
screws.
High-Speed USB 3.0 Storage
SpeedDrive
To attach a SpeedDrive to any
PIX-E recording field monitor:
1. Place the SpeedDrive so that
the USB plug lines up to the USB
connector on the back panel of the
monitor.
2. Depress the spring-loaded retainer
clip, located at the back edge of
the monitor’s top panel. Only one of
two clips is used to hold the Speed-
Drive.
3. Slide the SpeedDrive into the USB
connector.
The retainer clip will spring up into the
notch on the SpeedDrive with a click to
let you know the SpeedDrive is securely
attached to the monitor.
Retainer
Clip
Before a SpeedDrive may be used for
recording, it must be formatted by the
PIX-E recording eld monitor.
To format a SpeedDrive:
1. Attach the SpeedDrive to the unit.
2. Press the MENU button.
3. Turn and press the Control knob to
select Recorder& Drives > Erase/
Re-format.
4. Turn and press the Control knob to
select the SpeedDrive sub-option
associated with the drive you want to
format.
⚠A cautionary conrmation dialog
will appear on screen: “All data
will be erased. Continue?”
5. Turn and press the Control knob to
select Yes to continue.
6. Accept the default volume name
(PIX-E) or enter a new volume label
for the drive by using the displayed
on-screen keyboard (or an external
USB keyboard, if attached)
7. Use the Control knob to select OK.
⚠Do not copy les from a
computer (or any host device)
to a drive intended to be used
by a PIX-E unit. If this occurs,
Sound Devices strongly advises
reformatting the drive with the
PIX-E unit before making new
recordings.
To remove a SpeedDrive from any
PIX-E recording field monitor:
1. Ensure the SpeedDrive LED is off.
2. Press down the proper retainer clip.
3. Carefully slide the SpeedDrive out.
Part # 5788.002
www.videodevices.com QUICK START GUIDE

Service
For all service, including warranty repair, please contact Sound Devices for a Return
Merchandise Authorization (RMA) number before sending your device in for repair.
Product returned without an RMA number may experience delays in repair. Sound Devices repairs
and replacements may be completed using refurbished, returned or used parts that have been
factory certied as functionally equivalent to new parts.
Sound Devices, LLC
Service Repair RMA #XXXXX
E7556 State Road 23 and 33
Reedsburg, WI 53959 USA
telephone: [phone]
Technical Support / Bug Reports
For technical support and bug reporting
on all Sound Devices products contact
Sound Devices, LLC at:
E-mail: suppor[email protected] Website: www.sounddevices.com/support/
Sound Devices hosts a user support forum. The URL is: http://forum.sounddevices.com
We’re on Facebook: www.facebook.com/videodevices www.facebook.com/sounddevices
Transferring Files
The SpeedDrive enables the easy
and efcient transfer of recorded
les from PIX-E devices to Mac or
Windows-based computers for post-
production editing.
To transfer files:
1. Remove the SpeedDrive from the
PIX-E unit.
2. Insert the SpeedDrive into a USB 3.0
compatible port on the computer.
3. Copy the les to your computer.
Sound Devices recommends rst
copying les from the storage device
to the computer and then editing the
copied les.
Specifications
• For mSATA Drives:
• USB 3.0
data transfer up to 5GB/s (625 MB/s)
• Size: 3.35” x 1.5” x 0.5”
• Weight: 1.2 Oz. (without Drive)
Register Your SpeedDrive
www.videodevices.com/
support/registration/
For more on this and other products, visit
us at: www.videodevices.com.
