Vidicode APRESA User manual

Call
Call Call
Call Recorder
RecorderRecorder
Recorder A
A A
APRESA
PRESAPRESA
PRESA
Installation Manual
Installation ManualInstallation Manual
Installation Manual
Version 2.4.12 © Vidicode 2012

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 2
Care and Maintenance
Keep the APRESA dry. If it gets wet, wipe
it dry immediately with a soft, clean cloth.
Liquids might contain minerals that
corrode the electronic circuits.
Use and store the APRESA only in
temperature conditions between 0 and 40
degrees Celsius. Temperature extremes
can shorten the life of electronic devices
and distort or melt plastic parts.
Keep the APRESA away from excessive
dust and dirt.
Do not use aggressive chemicals, cleaning
solvents or strong detergents to clean the
APRESA.
LICENSES
=
€
Store your APRESA licenses in a safe place
as you may need these in the future.

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 3
This manual was written to support and guide customers in the installation process of the hardware
and software of the:
C
CC
CALL REC RDER APRESA
ALL REC RDER APRESAALL REC RDER APRESA
ALL REC RDER APRESA
A product of VIDIC DE Datacommunicatie BV
How to use
How to use How to use
How to use this
this this
this manual
manualmanual
manual …..
….. …..
…..
You may want to install a complete “Vidicode made” APRESA server while others want to install
the APRESA software-only on their alternative hardware.
Also the expansion of existing APRESA systems may need some guidance. Expanding an APRESA
system involves adding recording channels, increasing storage capacity or adding/ changing a RAID
volume.
Connecting the APRESA to the telecommunication infrastructure (signal tapping) will be an issue
that most users will have to deal with.
The purpose of this manual is to support you in an effective way. The document starts by
presenting a road map that will guide you to the applicable sections for your situation. You will
easily find the chapters that are relevant for your situation by using the flowchart.
For a list of VIDIC DE APRESA Article codes refer to chapter 10.

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 4
C
CC
C
C
CC
C N
NN
N
N
NN
NT
TT
T
T
TT
TE
EE
E
E
EE
EN
NN
N
N
NN
NT
TT
T
T
TT
TS
SS
S
S
SS
S
ROAD MAP............................................................................................................................................................6
1.
1.1.
1. INSTALLATI N START
INSTALLATI N STARTINSTALLATI N START
INSTALLATI N START .......................................................................................................................................7
1.1. S ITUATI NS ...............................................................................................................................................7
1.1.1. The “made by Vidicode” APRESA Server. ............................................................................................7
1.1.2. Software only .....................................................................................................................................7
1.1.3. Upgrading an existing APRESA ............................................................................................................7
1.2. P ACKAGE C NTENTS , MATERIALS AND T LING ..................................................................................................8
1.2.1. Package contents ...............................................................................................................................8
1.2.2. Advised Materials ...............................................................................................................................9
1.2.3. Advised tooling ..................................................................................................................................9
2.
2.2.
2. INTR DUCTI N T THE
INTR DUCTI N T THE INTR DUCTI N T THE
INTR DUCTI N T THE APRESA SERVER
APRESA SERVERAPRESA SERVER
APRESA SERVER ........................................................................................................10
2.1. APRESA FR NT SIDE , D R CL SED ..............................................................................................................10
2.2. APRESA F R NT SIDE , D R PENED .............................................................................................................11
2.3. APRESA B ACK SIDE , STANDARD PSU ...........................................................................................................11
2.4. APRESA, B ACK SIDE , REDUNDANT PSU ........................................................................................................12
2.5. S PECIFICATI NS ‘ VIDIC DE MADE ’ APRESA SERVER .........................................................................................13
2.5.1. Enclosure .........................................................................................................................................13
2.5.2. Motherboard / CPU / RAM / PSU .......................................................................................................13
2.5.3. Hard drive (various configurations possible) ......................................................................................14
2.5.4. DVD r/w ...........................................................................................................................................14
2.5.5. Supported PCI interface card .............................................................................................................14
2.5.6. Supported PCIe interface card ...........................................................................................................14
2.5.7. Environmental specification ..............................................................................................................14
2.5.8. Approvals .........................................................................................................................................14
3.
3.3.
3. APRESA BASE S FTWARE
APRESA BASE S FTWAREAPRESA BASE S FTWARE
APRESA BASE S FTWARE...............................................................................................................................15
3.1. H ARDWARE REQUIREMENTS .........................................................................................................................16
3.2. I NTERFACE CARD INSTALLATI N PR CEDURE ....................................................................................................17
3.3. S FTWARE INSTALLATI N PR CEDURE FR M THE CD .........................................................................................18
3.3.1. Attach monitor & keyboard ...............................................................................................................18
3.3.2. BI S setup .......................................................................................................................................18
3.3.3. Prepare an installation CD ................................................................................................................19
3.3.4. Installation from CD ..........................................................................................................................19
3.3.5. System License Activation .................................................................................................................23
3.3.6. Base Software Update ......................................................................................................................28
3.3.7. Channel License Activation ...............................................................................................................29
3.3.8. Codec License Activation (optional) ...................................................................................................31
3.3.9. General APRESA configuration ..........................................................................................................31
4.
4.4.
4. M UNTING
M UNTINGM UNTING
M UNTING ....................................................................................................................................................32
4.1. L CATI N C NSIDERATI NS .........................................................................................................................32
4.2. M UNTING APRESA INT A 19 INCH RACK ....................................................................................................33
4.3. A PPLY P WER T THE APRESA....................................................................................................................33
5.
5.5.
5. TELEC M WIRING
TELEC M WIRINGTELEC M WIRING
TELEC M WIRING ..........................................................................................................................................34
5.1. I NTR DUCTI N .........................................................................................................................................34
5.2. C NNECT R L CATI NS .............................................................................................................................36
5.3. G ENERAL REMARKS AB UT WIRING ................................................................................................................36
5.4. W IRING AUDI TAP S .................................................................................................................................37
5.4.1. Balanced signals ...............................................................................................................................37
5.4.2. Un-balance signals ...........................................................................................................................38
5.4.3. Wiring using the RJ11 Patch Box .......................................................................................................39

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 5
5.4.4. Direct wiring (N T using the RJ11 Patch Box) ....................................................................................40
5.5. W IRING ANAL G TELEPH NY (P TS) TAPS..............................................................................................41
5.6. W IRING TDM T ELEPH NY TAPS ..................................................................................................................42
5.6.1. 2-Wire Vs. 4-Wire .............................................................................................................................42
5.6.2. Wiring schemes ................................................................................................................................42
5.7. W IRING ISDN2 T ELEPH NY TAPS (B ASIC RATE ISDN)......................................................................................45
5.8. W IRING ISDN E1/T1 T ELEPH NY TAPS.........................................................................................................46
5.9. C NFIGURATI N F V IP TELEPH NY REC RDING ............................................................................................48
5.9.1. Trunk Side Recording ........................................................................................................................48
5.9.2. Station Side Recording ......................................................................................................................48
5.9.3. VoIP topology 1 ................................................................................................................................51
5.9.4. VoIP topology 2 ................................................................................................................................52
5.9.5. VoIP topology 3 ................................................................................................................................53
5.9.6. VoIP topology 4 ................................................................................................................................54
5.9.7. VoIP topology 5 ................................................................................................................................55
5.9.8. VoIP topology 6 ................................................................................................................................56
5.9.9. VoIP topology 7 ................................................................................................................................57
5.10. C NFIGURATI N F TETRA C MMUNICATI N REC RDING .................................................................................58
5.11. P ATCH PANELS ..........................................................................................................................................58
5.11.1. RJ11 Patch panel .........................................................................................................................58
5.11.2. RJ45 Patch panel .........................................................................................................................59
6.
6.6.
6. EXPANDING APRESA
EXPANDING APRESAEXPANDING APRESA
EXPANDING APRESA ......................................................................................................................................60
6.1. A DDING REC RDING CHANNELS ....................................................................................................................60
6.1.1. Channel license upgrade ...................................................................................................................60
6.1.2. Installation of interface cards ............................................................................................................61
6.1.3. Installation of interface modules .......................................................................................................61
6.2. I NCREASING THE ST RAGE CAPACITY ..............................................................................................................61
6.3. B UILDING R CHANGING A RAID V LUME .......................................................................................................62
7.
7.7.
7. BACKUP AND REST RE B
BACKUP AND REST RE BBACKUP AND REST RE B
BACKUP AND REST RE BACKUP
ACKUPACKUP
ACKUP.....................................................................................................................63
8.
8.8.
8. MAINTENANCE
MAINTENANCEMAINTENANCE
MAINTENANCE ..............................................................................................................................................64
9.
9.9.
9. APPLICABLE VIDIC DE
APPLICABLE VIDIC DE APPLICABLE VIDIC DE
APPLICABLE VIDIC DE ARTICLE C DES
ARTICLE C DESARTICLE C DES
ARTICLE C DES ..........................................................................................................64
10.
10.10.
10. REDUNDANT P WER SUPL
REDUNDANT P WER SUPLREDUNDANT P WER SUPL
REDUNDANT P WER SUPLLY
LYLY
LY.....................................................................................................................66
11.
11.11.
11. RAID V LUMES
RAID V LUMESRAID V LUMES
RAID V LUMES .........................................................................................................................................68
11.1. N RAID ...............................................................................................................................................68
11.2. RAID1 ...................................................................................................................................................68
11.3. RAID5 ...................................................................................................................................................68
11.4. H W T REPLACE A FAILING HARD DRIVE IN A RAID ARRAY .................................................................................68
12.
12.12.
12. INTERFACE CARD SPECI
INTERFACE CARD SPECIINTERFACE CARD SPECI
INTERFACE CARD SPECIFICATI NS
FICATI NSFICATI NS
FICATI NS ............................................................................................................71
12.1. ATP-24A/PCI+/2.0 / ATP-24A/PCI E +/2.0.................................................................................................72
12.2. DST-24B/PCI+/2.0 / DST-24B/PCI E +/2.0 ..................................................................................................73
12.3. DTP-X0C/PCI+ / DTP-X0C/PCI E +.............................................................................................................74
13.
13.13.
13. GNU GENERAL PUBLIC L
GNU GENERAL PUBLIC LGNU GENERAL PUBLIC L
GNU GENERAL PUBLIC LI
II
ICENSE.
CENSE.CENSE.
CENSE. ................................................................................................................75
14.
14.14.
14. TERMIN L GY EXPLAINE
TERMIN L GY EXPLAINETERMIN L GY EXPLAINE
TERMIN L GY EXPLAINED
DD
D........................................................................................................................76

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 6
ROAD MAP
AP RESA
INS T ALL AT ION
APRESA SERV ER
ART 010.04 601
AP RESA
BASE SOFT WARE
ART 0 10.04 602
APRESA CH-
EXP ANSION
ART 0.0 46XX
HARDWARE
REQUIREME NS
INT ERFACE CA RD
INS T ALL AT ION
INST A LLAT ION
OF APRES A
SOFT WARE
IM A E
ACTIVAT ION
OF APRES A
LICENSE
(ON LINE )
Y
VOIP
EXP ANSION
?
N
INT ERFA CE CARD OR
INT ERFACE M ODULE
INST A LL AT ION
O T HER
INT RODUCT ION
T O T HE
APRESA
SERVER
ACT IVAT E
CHANNEL /
CODEC L ICENS E
(ON LINE)
MOUNT IN O F APRESA AND ENERAL INSTALLAT ION
ISSUES
ST ART
CO NFI URE APRESA :
USERS / USER ROUPS/
I/F CARD SET T IN S
ET C
T EL ECOM WIRIN
CO M M ISS IONIN
END
ACT IVAT E CHANNEL / CODEC LICENSE
(ON L INE)
SOFTWARE
ONLY !
FULL
SYSTEM!
UP RADE
EXISTIN
SYSTEM
DW 1129 _0
2
3.1
3.2
3.3
3.3.5
3.3.6
3.3.7
3.3.8
4
3.3.6
3.3.7
3.3.8
AND
CHAPT ER 6
3.2
CO M M ISS IONIN
5
7
8
SEE A DM IN
M ANUAL

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 7
1.
1.1.
1. INSTALLATI N START
INSTALLATI N STARTINSTALLATI N START
INSTALLATI N START
Generally we distinguish 3 different situations of use of this document. You are advised to follow
the relevant path for your particular situation as indicated by the roadmap. The numbers in the
roadmap link to the chapters of interest, avoiding unnecessary reading of irrelevant chapters.
At the end of this chapter you find a list of required materials and tooling to do the job right.
1.1. Situations
SituationsSituations
Situations
1.1.1.
1.1.1.1.1.1.
1.1.1. The
The The
The “made by Vidicode” APRESA
“made by Vidicode” APRESA “made by Vidicode” APRESA
“made by Vidicode” APRESA Server
ServerServer
Server.
..
.
The APRESA is available on the market as a turn key, PC based rack-mount server.
You will find the APRESA software already installed and running on the product. Channel licenses
are activated and interface cards will be installed according to your purchase order by Vidicode.
You are advised to read the introduction and the go directly to the mounting, software
configuration, telecom wiring, and commissioning sections.
1.1.2.
1.1.2.1.1.2.
1.1.2. Software only
Software onlySoftware only
Software only
You prefer to use your own choice of hardware for a variety of reasons. In other words you have
the liberty to select your preferred server manufacturer like HP, Dell, etc.
As a guide, we have listed the (minimum) hardware requirements of such a system. Refer to the
chapter “Hardware requirements”. To install the APRESA software image and do the channel
licensing one is advised to follow the directions as described in the chapter “Software installation”.
For the installation of interface cards in your hardware you must follow the directions of the
manufacturer or vendor of that machine.
Finally process the software configuration, telecom wire tapping and commissioning section.
1.1.3.
1.1.3.1.1.3.
1.1.3. U
UU
Upgrad
pgradpgrad
pgrading an existing
ing an existinging an existing
ing an existing APRESA
APRESA APRESA
APRESA
If you want to upgrade an existing APRESA system with additional channels or interface card(s) you
can go to the “Upgrade existing installations” chapter.
Existing APRESA systems need channel upgrade when customer business expands after time and
more and more phones needs to be recorded. Adding and configuration of new channels in
software is easy, the main effort here is hardware installation

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 8
1.2. Package contents,
Package contents,Package contents,
Package contents, materials
materials materials
materials and Tooling
and Toolingand Tooling
and Tooling
1.2.1.
1.2.1.1.2.1.
1.2.1. Package
PackagePackage
Package contents
contents contents
contents
pen the package carefully, and make sure that none of the items that are listed below are missing .
This product has a very high level of flexibility and inherently there is no standard package content.
To help you in checking the delivery read the following:
Package
Package Package
Package = “Vidicode made server”
= “Vidicode made server”= “Vidicode made server”
= “Vidicode made server”
1x APRESA SERVER
2x KEY (F R D R L CK)
1x P WER C RD 2x with optional redundant power supply
1x QUICK GUIDE F R INSTALLATI N
1x GUARANTEE / REGISTRATI N F RM
1x VIDIC DE APPLICATI N CD NLY for the manuals
1x APRESA BASE SW INSTALLATI N CD
1x APRESA BASE S FTWARE LICENSE
1x APRESA CLIENT S FTWARE LICENSE
?x CHANNEL / C DEC LICENSE Acc. to the channels/codec ordered.
1x PATCHB X RJ11/RJ21 For every ATP / DST interface card installed
1x RJ21/RJ21 CABLE , LENGTH=1M For every ATP / DST interface card installed
Package = “software only”
Package = “software only”Package = “software only”
Package = “software only” (e
(e (e
(e-
--
-mail or postal package)
mail or postal package)mail or postal package)
mail or postal package)
1x QUICK GUIDE F R INSTALLATI N Image from Vidicode WEB-site
1x VIDIC DE LICENCING TERMS
1x GUARANTEE / REGISTRATI N F RM
1x APRESA BASE S FTWARE LICENSE
1x APRESA CLIENT S FTWARE LICENSE
?x CHANNEL / C DEC LICENSE Acc. to the channels/codec ordered.
?x INTERFACE CARD ATP/DST/DTP Depends on the channels ordered.
1x PATCHB X RJ11/RJ21 For every ATP / DST interface card installed
1x RJ21/RJ21 CABLE , LENGTH=1M For every ATP / DST interface card installed
Note that the last 3 items may be drop shipped directly from the factory.
Package = “upgrade”
Package = “upgrade”Package = “upgrade”
Package = “upgrade”

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 9
?x CHANNEL LICENSE Depends on the channels ordered.
?x INTERFACE CARD ATP/DST/DTP Depends on the channels ordered.
1x PATCHB X RJ11/RJ21 For every ATP / DST interface card
installed
1x RJ21/RJ21 CABLE , LENGTH=1M For every ATP / DST interface card
installed
Note that the last 3 items may be drop shipped directly from the factory.
If any it
If any itIf any it
If any item is missing or damaged, please contact your local resellers for
em is missing or damaged, please contact your local resellers forem is missing or damaged, please contact your local resellers for
em is missing or damaged, please contact your local resellers for replacement or other
replacement or other replacement or other
replacement or other
service.
service.service.
service.
1.2.2.
1.2.2.1.2.2.
1.2.2. Advised Materials
Advised MaterialsAdvised Materials
Advised Materials
We advise you to check the following list of materials before you start installing the system.
19”Rack screws and cage nuts
Modular wire 4P/6P/8P
Modular plugs
RJ45 T-splitter(s)
RJ12 T-Splitter(s)
RJ21 cable(s) 3,5 or 10m length
RJ45 patch panel
RJ48C to BNC adapter
Coaxial T-Splitter(s)
1.2.3.
1.2.3.1.2.3.
1.2.3. Advised tooling
Advised toolingAdvised tooling
Advised tooling
We advise you to check the following list of tooling of before you start installing the system:
- Standard installers tooling kit;
- RJxx modular connector crimp tool

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 10
2.
2.2.
2. INTR DUCTI N T THE
INTR DUCTI N T THE INTR DUCTI N T THE
INTR DUCTI N T THE APRESA SERVER
APRESA SERVERAPRESA SERVER
APRESA SERVER
The APRESA hardware is based on industrial PC server components and is built in a 19 inch rack-
mount housing. It is fully compatible with 19 inch server racks and will take 4U height space in the
rack.
All APRESA-options ordered for this machine are pre-installed by VIDIC DE:
You will find APRESA license, CHANNEL licenses, C DEC licenses, etc and the APRESA
software on CD in the delivery. These are just for your safekeeping. You need these items
when you want to re-install the software.
Interface card(s) that are ordered for this machine will be pre-installed.
All basic controls, indicators and the DVD are safely placed behind a lockable door. Please note that
the lock-keys are universal.
The sole purpose of the DVD is to accommodate software installation. Because the software is pre-
installed by VIDIC DE, the DVD has no immediate function. The DVD is used when software must
be re-installed in the future for whatever reason.
2.1. APRESA
APRESA APRESA
APRESA front side, door closed
front side, door closedfront side, door closed
front side, door closed
Call Recor derSi lver Line
Apr esa
vidicode
LOCK DOOR
MOUNTING HOLES
2 USB 2.0
(NOT USED)
VENTILATON
DWW11 30_0
HANDLE
BAR
HANDLE
BAR
MOUNTING HOLES

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 11
2.2. APRESA
APRESA APRESA
APRESA Front side
Front sideFront side
Front side, door opened
, door opened, door opened
, door opened
2.3. APRESA
APRESA APRESA
APRESA Back side, standard PSU
Back side, standard PSUBack side, standard PSU
Back side, standard PSU
1
0
RE S E T
KB -LK
KB -LK
P OW E R
H.D .D
DVD
RESET
BUTTON
NUM LOCK BUTTON
(NOT USED)
POW ER LED
HARD DISC
ACTIVITY LED
NUM LOCK LED
(NOT USED)
DOOR (OPENED)
DW 1131_0
POW ER
SW ITCH
DVD
I/F CARDS
SLOTS
DW 1 132_0
NOT USED
I/F CARD#1 I/F CARD#2 I/F CARD#3 I/F CARD#4
NOT USED NOT USED
0
1
PC ETHERNET VOIP ETHERNET
6 USB2.0
(NOT USED)
3 PC SOUND CARD
(NOT USED)
KEYBOARD AND MOUSE
(NOT USED)
DISPLAY
(NOT USED
SERIAL RS232
(NOT USED)
MAINS POWER
ENTRY
POW ER SW ITCH
(NOT ON ALL MODELS)

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 12
2.4. A
AA
APRESA
PRESAPRESA
PRESA,
, ,
, Back side, redundant PSU
Back side, redundant PSU Back side, redundant PSU
Back side, redundant PSU
DW 1 133_0
MAINS POW ER
ENTRIES
NOT USED
I/F CARD#1 I/F CARD#2 I/F CARD#3 I/F CARD#4
NOT USED NOT USED
0
1
POWER PACK
STATUS LED
POWER SW ITCH
PSU ALARM
MUTE BUTTON

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 13
2.5. S
SS
Specifications ‘
pecifications ‘pecifications ‘
pecifications ‘ vidicode made
vidicode madevidicode made
vidicode made ’
’ ’
’ APRE
APREAPRE
APRES
SS
SA
A A
A server
serverserver
server
2.5.1.
2.5.1.2.5.1.
2.5.1. Enclosure
EnclosureEnclosure
Enclosure
TYPE : KI-N407
C L R : Black (Textured)
WEIGHT : 15 Kg (approximately, varies with different models)
DIMENSI NS
-Height : 177 mm ( 4U )
-Width : 482 mm (19” RACK mounting brackets standard)
440 mm ( desktop , 19” brackets removed)
-Depth : 510 mm (Inclusive handle bars, exclusive cables)
SLIDING RAIL : ptionally available
# 3.5” DRIVES : 5 INTERNAL
# 5.25” DRIVES : 3 EXTERNAL
# USB : 2pcs n front / 6pcs at the back (Not used)
C LING : Front 120mm chassis FAN 1600 RPM
ACCESS CTRL : Controls / indicators are placed behind a lockable door
C NTR LS : -RESET Button
- N/ FF Switch
-NUML CK Switch (Not used)
-PSU Alarm mute button(models with redundant PSU only)
INDICAT RS : -Power
-Hard drive ACTIVITY
-NUML CK SWITCH INDICAT R (N T USED)
2.5.2.
2.5.2.2.5.2.
2.5.2. M
MM
Motherboard
otherboardotherboard
otherboard / CPU
/ CPU / CPU
/ CPU / RAM / PSU
/ RAM / PSU / RAM / PSU
/ RAM / PSU
M THERB ARD : SUPER MICR C2SBC-Q- (Socket 775)
(for all specifications : www.supermicro.com)
CPU : INTEL PENTIUM E6600/2C RE/FSB1066/2MB Cache or
INTEL PENTIUM E5700/2C RE/FSB 800/2MB Cache or equivalent
(for all specifications: www.intel.com)
RAM : DDR2 4GBYTE @ 800MHZ Standard
DDR2 8GBYTE @ 800MHZ Max.
PSU : 400W Standard
500W ptional
(for all specifications: www.supermicro.com)
ptional: 1+1 redundant power supply

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 14
2.5.3.
2.5.3.2.5.3.
2.5.3. H
HH
Hard
ardard
ard drive
drivedrive
drive (
((
(various configurations possible
various configurations possiblevarious configurations possible
various configurations possible)
))
)
INTERFACE : SATA 3GBIT/SEC
SIZE : 3.5 INCH
RPM : 7200
CACHE : 16MByte
QUALITY GRADE : 24/7
CAPACITY : 1TBYTE (standard configuration)
ptional 1or 2 TBYTE
RAID V LUMES : ptional, RAID1 or RAID5 (Software RAID)
2.5.4.
2.5.4.2.5.4.
2.5.4. DVD
DVD DVD
DVD r/w
r/wr/w
r/w
INTERFACE : SATA 3GBit/SEC
SIZE : 5.25“
SPEED : 22X
MANUFACTURER : LG
2.5.5.
2.5.5.2.5.5.
2.5.5. S
S S
Supported
upported upported
upported PCI
PCI PCI
PCI interface
interface interface
interface card
cardcard
card
ANAL G : SYNWAY TYPE ATP- 24A/PCI+/2.0 : 8CH / 16CH or 24CH
TDM : SYNWAY TYPE DST- 24B/PCI+/2.0 : 8CH / 16CH or 24CH
ISDN E1/T1 : SYNWAY TYPE DTP- 30C/PCI+/2.0 : 30CH / 1TRUNK
ISDN60 (E1) : SYNWAY TYPE DTP- 60C/PCI+/2.0 : 60CH / 2TRUNK
ISDN120(E1) : SYNWAY TYPE DTP-120C/PCI+/2.0 : 120CH / 4TRUNK
2.5.6.
2.5.6.2.5.6.
2.5.6. S
SS
Supported PCIe interface card
upported PCIe interface card upported PCIe interface card
upported PCIe interface card
All cards below are designed for the PCIe X1 card slot.
note : All interface cards mentioned will work fine in PCIe X4/X8/X16/X32.
ANAL G : SYNWAY TYPE ATP- 24A/PCIe+/2.0 : 8CH / 16CH or 24CH
TDM : SYNWAY TYPE DST- 24B/PCIe+/2.0 : 8CH / 16CH or 24CH
ISDN E1/T1 : SYNWAY TYPE DTP- 30C/PCIe+/2.0 : 30CH / 1TRUNK
ISDN60 (E1) : SYNWAY TYPE DTP- 60C/PCIe+/2.0 : 60CH / 2TRUNK
ISDN120(E1) : SYNWAY TYPE DTP-120C/PCIe+/2.0 : 120CH / 4TRUNK
2.5.7.
2.5.7.2.5.7.
2.5.7. Environmental specification
Environmental specificationEnvironmental specification
Environmental specification
TEMPERATURE RANGE : +10 - +35 °C ( perating) or - 10 - + 65 °C (Storage)
HUMIDITY : 8%-90% No condensing, operating and storage.
2.5.8.
2.5.8.2.5.8.
2.5.8. A
AA
Approvals
pprovalspprovals
pprovals
EMC APPR VAL : EN55022 / EN55024 / FCC15
SAFETY : EN60950

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 15
3.
3.3.
3. APRESA BASE
APRESA BASE APRESA BASE
APRESA BASE S FTWARE
S FTWARES FTWARE
S FTWARE
This chapter describes the complete procedure for installing the APRESA software from a CD.
Pre-requisites: - M NIT R + KEYB ARD + ETHERNET
- APRESA license, Channel license, G.729 license etc.
- W RK-PC (processing the licenses / WEB configuration APRESA)
- Interface cards as applicable.
If you have purchased the complete “Vidicode
made” APRESA server can skip this chapter. Your
product will be delivered with software installed
and all purchased channel licenses nicely activated.
This procedure will also be use full to re-install the
APRESA software for whatever reason.
Typically, this procedure is typically written to
support you if you have purchased the APRESA
Base Software license (inherently without server
hardware). This chapter contains all the supporting
information that is needed to implement the
APRESA software package on the server hardware
of your choice.
The APRESA software runs under the LINUX Debian
operating system and needs X86/PC compatible
environment. (Note : 64Bit only)
Because APRESA offers great flexibility in number
of recording channels, digital taps, analog taps etc.,
the hardware requirements depend mainly on the
scale of the recording system to build. Also, the
spare capacity issue for future expansion must be
taken in consideration.

An APRESA that records only VoIP channels is a truly “Software
only” solution Recording POTS, ISDN, TDM etc however require
interface card(s) built in your targe
t machine
INST ALLAT ION ST ART
DW 1 1 54_00
INT ERFA CE
CARDS ?
INST ALL T HE
INT ERFA CE
CA RDS P RIOR
T O SOFWARE
IN ST A LL AT ION
YES
NO
INST ALL
APRESA
BASE SW
BASE SW
L ICE NSE
ACT IVA T ION
CHANNEL
L ICENSE(S)
ACT IVA T ION
CODEC
L ICENSE(S)
ACT IVA T ION
ENE RAL
APRESA
CO NFI URAT IO N
3.3 .2
3.3 .3
3.3 .4
3.3 .5
3.3 .6
3.3 .7
3.3 .8
3.2
WEB BASED
ACCESS V IA
WORK PC
WEB BASED
ACCESS V IA
WORK PC
ADM IN M ANUALADMIN M A NUAL
INST ALLAT ION
END
CO NFI URAT IO N
ST ART
CD
-NO RAID
or RAID1
or RAID5
BIOS SET UP
PREPARE
INST ALLAT ION
CD
SOFT WARE
UP DA T E
3.3 .9

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 16
3.1. H
HH
Hardware requirements
ardware requirementsardware requirements
ardware requirements
To support customers in the selection of the server hardware we present a guiding list below.
 Note that APRESA requires
Note that APRESA requires Note that APRESA requires
Note that APRESA requires a
a a
a 64bit hardware
64bit hardware64bit hardware
64bit hardware platform
platform platform
platform.
Systems built according to the basic hardware requirements should perform well. When the system
is large in terms of the amount of network traffic anticipated or the number of channels
implemented/ simultaneous calls that have to be recorded please ask Vidicode for advice.
CPU : INTEL PENTIUM 64 BIT, E5700 or E6600 or better;
(3 GHz, dual core, 4M cache, 800 or 1066 MHz FSB )
RAM : 4 GBYTE 800 MHz DDR2 or better;
ETHERNET : 1x standard, 1x extra when using V IP
HARD DRIVE : 1 ( r more with RAID1 or RAID5) 500GBYTE or larger;
N hardware RAID controller required as the system uses software RAID.
DVD DRIVE : 22X speed
PCI/SL TS : 1 PCI (1 PCIe X1) slot for every interface card to be installed.
PSU : 400W
Note 1:
No special requirements regarding peripheral interfaces like USB, C M, LPT
etc.
2:
The display adapter is used for text-only and is only used during software
installation. There are no special requirements.

We advice you to connect the DVD drive to the highest
numbered SATA interface on the mother board The
hard drive(s) must be connected from SATA-0 and up

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 17
3.2. Interface card
Interface cardInterface card
Interface card installation
installation installation
installation procedure
procedure procedure
procedure
(Skip this chapter if you are working on a VoIP-only system inherently without interface cards)
The interface cards are all PCI (PCI-e) based PC expansion cards.

Procedure in detail :
- Shutdown the APRESA by using the WEB page(L G N,->T L->SYSTEM->SHUTD WN
(The shutdown may take some time so wait patiently until the red power LED turns off).
- After this controlled power down, disconnect the mains power plug (note : in case the
APRESA is equipped with redundant power facility, remove B TH mains power plugs)
- pen the chassis by removing the 2 screws of the top cover plate to gain excess to the
PCI(PCIe) expansion slots. (only for Vidicode, other vendors hardware may be opened
differently, refer to the documentation supplied by your typical hardware vendor)
- Locate a free PCI or PCI-e slot to accommodate the interface card you want to install.
- Unscrew the blind plate bracket that corresponds with the PCI expansion slot to use.
- Mark the type of card (like P TS, TDM etc.) for future reference.
- Carefully insert the interface card accurately in the PCI (PCIe) expansion slot and lock the
card-bracket using the screw. In case the interface card has a RJ21 type connector check
both its bail locks to move freely outside the housing prior to fixation.
- ptionally you can add the top-bracket to secure the interface card firmly in the PCI socket.
Doing this is important with the (older) long interface cards. All new interface cards are
quite short and will be mechanically fixed stable enough by only the card-bracket screw.
- Reposition the top cover and fixate the screws.
APRESA can take a number of interface cards depending on the specifications of the motherboard
and the chassis.
F.i. Supermicro C2SBC 4 PCI + 2 PCI+, totals to 6 cards.
BEFORE INSTALLATION
OF THE
INTERFACE CARD
(S)
ALWAYS
:
• SHUT DOWN THE SYSTEM
• REMOVE MAIN CORD (-s)
• DISCONNECT ALL PERIPHERALS
• WORK IN AN ESD SAFE ENVIRONMENT

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 18
3.3. Software i
Software iSoftware i
Software installation
nstallationnstallation
nstallation procedure
procedure procedure
procedure from the CD
from the CD from the CD
from the CD


FIX
FIXFIX
FIX :
If the APRESA base software is already installed without interface cards for whatever reason, run
from the WEB-interface: Tools->System->Install Driver.
3.3.1.
3.3.1.3.3.1.
3.3.1. Attach moni
Attach moniAttach moni
Attach monitor & keyboard
tor & keyboard tor & keyboard
tor & keyboard
Always attach a monitor & keyboard to follow the progress of the software installation and to:
• Change BI S settings;
• Give a confirmation to overwrite current hard drive content if the hard drive you want to
use is not empty;
• Type the pass phrase, if the hard drive is to be encrypted during installation and at each
reboot;
3.3.2.
3.3.2.3.3.2.
3.3.2. BI S setup
BI S setup BI S setup
BI S setup
(Note : Controls used below refer to Phoenix BI S, other BI S manufacturers may be different)
Enter the BI S configuration menu by pushing DEL repeatedly, directly after power on. This can
take up to 1 minute.
Select: ” GENERAL SETTINGS
GENERAL SETTINGSGENERAL SETTINGS
GENERAL SETTINGS ” :
- SET: DATE & TIME;
- SET: HARD DRIVE Pre-Delay to 6 seconds.
Select : “ B T SETTINGS
B T SETTINGSB T SETTINGS
B T SETTINGS ” :
- SET : boot-sequence to: 

 DVD , 

 IDE0, and if more HD-s 

 IDE1 and further. .

Select : “ SAVE & EXIT ” (enter : F10 & Y )
THE IMAGE CD USED BY THIS INSTALLATION PROCEDURE
CONTAINS THE LINUX 64BIT OPERATING SYSTEM AND THE
PROPRIETARY APRESA APPLICATION SOFTWARE
IF THE SYSTEM USES
IF THE SYSTEM USES IF THE SYSTEM USES
IF THE SYSTEM USES ONE
ONEONE
ONE R M RE INTERFACE
R M RE INTERFACE R M RE INTERFACE
R M RE INTERFACE CARDS ALWAYS INSTALL
CARDS ALWAYS INSTALL CARDS ALWAYS INSTALL
CARDS ALWAYS INSTALL
THESE CARDS
THESE CARDS THESE CARDS
THESE CARDS
PRIOR TO SOFTWARE INSTALLATION
When installing the RAID1 or RAIID5 version of APRESA you must set the BI S
When installing the RAID1 or RAIID5 version of APRESA you must set the BI SWhen installing the RAID1 or RAIID5 version of APRESA you must set the BI S
When installing the RAID1 or RAIID5 version of APRESA you must set the BI S-
--
-
setting for RAID to
setting for RAID tosetting for RAID to
setting for RAID to
NO RAID
( RAID is handled by software )

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 19
3.3.3.
3.3.3.3.3.3.
3.3.3. Prepa
PrepaPrepa
Prepare
rere
re an installation
an installation an installation
an installation CD
CDCD
CD
The quick guide lists the links to the 5 different APRESA images. Ask Vidicode sales for a quick
guide if you don’t have one at hand. The various images supports different hard drive
configurations and the encryption feature. According to your requirements, select one of the images
for download, burn it to a CD and to start the installation as described further in this chapter.
Use any CD writer software to burn the image to create an APRESA installation CD.
( a nice freeware CD-burner-tool can be downloaded from http://www.imgburn.com )
Note if you are installing a RAID image:
HARD DRIVE C NFIGURATI N
HARD DRIVE C NFIGURATI NHARD DRIVE C NFIGURATI N
HARD DRIVE C NFIGURATI N N F HARD DRIVE REQUIRED
N F HARD DRIVE REQUIREDN F HARD DRIVE REQUIRED
N F HARD DRIVE REQUIRED
N RAID 1
RAID 1 2
RAID 5 3
3.3.4.
3.3.4.3.3.4.
3.3.4. I
II
Install
nstallnstall
nstallation
ationation
ation from CD
from CDfrom CD
from CD
Insert the APRESA installation CD into the APRESA and restart the system. The installation process
should start automatically. If installation does not start, make sure the CD drive is in the bootable
devices list. (Check in the BI S). When asked for, select a hard drive for installation and confirm the
partitioning of that hard drive. From this point on the installation should proceed automatically
without further user interaction. The installation process usually takes less than 30 minutes. The
end of the installation is signaled by the ejection of the installation CD and the ‘System Halted’
message.
Initial start
Initial startInitial start
Initial start-
--
-up
upup
up
Connect the APRESA system to Ethernet. n the Vidicode-made APRESA hardware, this slot is
marked with “PC”. Remove the installation CD, and restart the APRESA system by pushing the
‘RESET’ button. The system should now boot the newly installed APRESA application. If the system
uses RAID, the hard drives synchronizing process will start. Depending on the size and speed of the
hard drives, synchronization may take several hours to complete. Allow the hard drive
synchronization to finish without power interruption. The system can be accessed during
synchronization.

APRESA INSTALLATI N MANUAL VIDIC DE ©2012 20
TO ACCESS THE WEB-INTERFACE OF THE APRESA YOUR PC MUST HAVE
AN IP-ADDRESS IN THE SAME IP-SUBNET AS THE APRESA
Accessing APRESA for the first time
The complete control over the APRESA is by WEB interface only. The next section helps you in
setting up the web connection with the APRESA by the use of web browser on your work PC.

The WEB interface is for normal use and configuration. nly under special circumstances the user
may need access to the system shell. This is achieved by connecting a monitor & keyboard directly
to the APRESA.
After the software installation the APRESA has a STATIC IP address:
Static settings make it easy to find the APRESA on Ethernet but note:
Define the APRESA IP on the
Define the APRESA IP on the Define the APRESA IP on the
Define the APRESA IP on the work
work work
work PC
PCPC
PC
To access the APRESA web interface, you need to configure your work PC to have an IP address in
the same subnet as the APRESA system. This means that your work PC should have an IP address in
the range from 192.168.55.0 to 192.168.55.255, for example 192.168.55.10. This can be done as
follows:
- pen the list of Network Connections (Windows Control Panel)
- Select your network connection, right-click and select Properties
- Select "Internet Protocol Version 4 (TCP/IPv4)", and click "Properties".
You should see something like the screen displayed on the right.
A. If “ btain an IP address automatically” is enabled, then it is
necessary to switch temporarily to a static IP address, as follows:
- Enable “Use the following IP address”
- As IP address, fill in: 192.168.55.10.
- As Subnet mask, fill in: 255.255.255.0
B. If the PC was already set to a static IP address, but in another
subnet, then it is possible to add an extra IP address to the PC
configuration.
IP (STATIC) = 192.168. 55. 55
SUBNET MASK = 255.255.255. 0
APRESA IS ACCESSED BY WEB INTERFACE
