Vido WD010611400 User manual

Angle polisher
WD010611400
1400W

WD010611400
Thank you for purchasing a VIDO product. We are confident that you will appreciate the quality
of the product and you will be entirely satisfied with your purchase. Please read carefully the
user safety and operating instruction on how to operate this product correctly within safety
norms and regulations.
2

WD010611400
1
2
3
5
4
6
7
8
3

WD010611400
6
5mm
5mm
4
2 31
7
65
10
9
12
8
11

1400W ANGLE POLISHER ENG
COMPONENT LIST
1) Spindle locking button
2) Auxiliary handle
3) Variable speed dial
4)
5)
6) Brush holder cap
7) Polishing plate
8) Polishing bonnet
NORMAL ACCESSORIES
1) Auxiliary handle: 1pc
2) Polishing plate: 1pc
3) Polishing bonnet: 1pc
4) Hex key: 1pc
5) Spare carbon brush: 1set
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type according to the
work you intend to undertake. Refer to the accessory packaging for further details. Store personnel can
assist you and offer advice.
Switch trigger
Lock-on button
5

1400W ANGLE POLISHER ENG
GENERAL POWER TOOL SAFETY WARNINGS
Warning: Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructionsfor future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.Use
of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication.A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection.Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will
reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times.This enables better control of
the power tool in unexpected situations.
6

1400W ANGLE POLISHER ENG
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off.Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in the
hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power tool
for operations different from those intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR POWER TOOL
1) Safety Warnings Common for Sanding, Wire Brushing, and Polishing Operations
a) This power tool is intended to function as a sander, wire brush or polishing tool. Read all safety
warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, fire and/or serious injury.
b) Do not use accessories which are not specifically designed and recommended by the tool
manufacturer. Just because the accessory can be attached to your power tool, it does not assure safe
operation.
c) The rated speed of the accessory must be at least equal to the maximum speed marked on the
power tool. Accessories running faster than their rated speed can break andfly apart.
d) The outside diameter and the thickness of your accessory must be within the capacity rating of
your power tool. Incorrectly sized accessories cannot be adequately guarded or controlled.
e) Threaded mounting of accessories must match the power tool spindle thread. For accessories
mounted by flanges, the arbour hole of the accessory must fit the locating diameter of the flange.
Accessories that do not match the mounting hardware of the power tool will run out of balance, vibrate
excessively and may cause loss of control.
7

1400W ANGLE POLISHER ENG
f) Do not use a damaged accessory. Before each use inspect the accessory such as abrasive wheels
for chips and cracks, backing pad for cracks, tear or excess wear, wire brush for loose or cracked wires.
If power tool or accessory is dropped, inspect for damage or install an undamaged accessory. After
inspecting and installing an accessory, position yourself and bystanders away from the plane of the
rotating accessory and run the power tool at maximum no-load speed for one minute. Damaged
accessories will normally break apart during this test time.
g) Wear personal protective equipment. Depending on application, use face shield, safety goggles or
safety glasses. As appropriate, wear dust mask, hearing protectors, gloves and workshop apron
capable of stopping small abrasive or workpiece fragments. The eye protection must be capable of
stopping flying debris generated by various operations. The dust mask or respirator must be capable of
filtrating particles generated by your operation. Prolonged exposure to high intensity noise may cause
hearing loss.
h) Keep bystanders a safe distance away from work area. Anyone entering the work area must wear
personal protective equipment. Fragments of workpiece or of a broken accessory may fly away and
cause injury beyond immediate area of operation.
i) Hold the power tool by insulated gripping surfaces only, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a “live” wire
may make exposed metal parts of the power tool “live” and could give the operator an electric shock.
j) Position the cord clear of the spinning accessory. If you lose control, the cord may be cut or
snagged and your hand or arm may be pulled into the spinning accessory.
k) Never lay the power tool down until the accessory hascome to a complete stop. The spinning
accessory may grab the surface and pull the power tool out of your control.
l) Do not run the power tool while carrying it at your side. Accidental contact with the spinning
accessory could snag your clothing, pulling the accessory into your body.
m) Regularly clean the power tool’s air vents. The motor’s fan will draw the dust inside the housing
and excessive accumulation of powdered metal may cause electrical hazards.
n) Do not operate the power tool near flammable materials. Sparks could ignite these materials.
o) Do not use accessories that require liquid coolants. Using water or other liquid coolants may result
in electrocution or shock.
2) Kickback and related warnings
Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or any other
accessory. Pinching or snagging causes rapid stalling of the rotating accessory which in turn causes
the uncontrolled power tool to be forced in the direction opposite of the accessory’s rotation at the point
of the binding.
For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge of the wheel that is
entering into the pinch point can dig into the surface of the material causing the wheel to climb out or
kick out. The wheel may either jump toward or away from the operator, depending on direction of the
wheel’s movement at the point of pinching. Abrasive wheels may also break under these conditions.
Kickback is the result of power tool misuse and/or incorrect operating procedures or conditions and can
be avoided by taking proper precautions as given below.
a) Maintain a firm grip on the power tool and position your body and arm to allow you to resist
kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or torque
reaction during start-up. The operator can control torque reactions or kickback forces, if proper
precautions are taken.
8

1400W ANGLE POLISHER ENG
b) Never place your hand near the rotating accessory. Accessory may kickback over your hand.
c) Do not position your body in the area where power tool will move if kickback occurs. Kickback will
propel the tool in direction opposite to the wheel’s movement at the point of snagging.
d) Use special care when working corners, sharp edges, etc. Avoid bouncing and snagging the
accessory. Corners, sharp edges or bouncing have a tendency to snag the rotating accessory and
cause loss of control or kickback.
e) Do not attach a saw chain woodcarving blade or toothed saw blade. Such blades create frequent
kickback and loss of control.
3) Safety Warnings Specific for Sanding Operations
Do not use excessively oversized sanding disc paper. Follow manufacturer’s recommendations, when
selecting sanding paper. Larger sanding paper extending beyond the sanding pad presents a
laceration hazard and may cause snagging, tearing of the disc or kickback.
4) Safety Warnings Specific for Polishing Operations
Do not allow any loose portion of polishing bonnet or its attachment string to spin freely. Tuck away or
trim any loose attachment strings. Loose or spinning attachment strings can entangle your fingers or
snag on the workpiece.
5) Safety Warnings Specific for Wire Brushing Operations
a) Be aware that wire bristles are thrown by the brush even during ordinary operation. Do not
overstress the wires by applying excessive load to the brush. The wire bristles can easily penetrate light
clothing and/or skin.
b) If the use of a guard is recommended for wire brushing, do not allow any interference of the wire
wheel or brush with the guard. Wire wheel or brush may expand in diameter due to work load and
centrifugal forces.
6) Additional Safety and Working Instructions
a) Keep handles dry, clean and free from oil and grease. Slippery hands cannot safely control the
power tool.
b) Only use "wrap around" control handle, supplied with tool. Use of an auxiliary side handle will
cause the hand to be within reach of the spinning accessory.
c) Use clamps or other practical way to secure and support the workpiece to a stable platform.
Holding the work by hand or against your body is unstable and may leadto loss of control.
d) Ensure that the tool is tightened before use and run the tool at no-load for 30 seconds in a safe
position. Stop immediately if there is considerable vibration or if other defects are detected. If this
condition occurs, check the machine to determine the cause.
e) Do not leave the tool running. Operate the tool only when hand-held.
ARNING
DOUBLE INSULATION
The power tool is double insulated. This means that all the external metal parts are electrically insulated
from the main power supply. This is done by placing insulation barriers between the electrical and
mechanical components making it unnecessary for the power tool to be earthed.
9

1400W ANGLE POLISHER ENG
IMPORTANT NOTE
Be sure the supply is the same as the voltage given on the rating plate. The power tool is fitted with a
two-core cable and plug.
Remove the main plug from socket before carrying out any adjustment or servicing.
SYMBOLS
To reduce the risk of injury, user must read instruction manual
Double insulation
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice
TECHNICAL DATA
Note: For power tool specifications refer to the nameplate on your power tool.
Model WD010611400
Voltage 110-120V AC 220-240V AC
Frequency 50-60Hz 50-60Hz
Power input 1400W 1400W
No load speed 1000-3300/min 1000-3300/min
Spindle size M14 or 5/8″M14
Max. polishing disc 7″Φ180mm
Max. sanding disc 7″Φ180mm
Max. wire cup brush 4″Φ100mm
Protection class
Machine weight 2.9kg 2.9kg
10

1400W ANGLE POLISHER ENG
OPERATING INSTRUCTIONS
Note: Before using the power tool, readthe instruction manual carefully.
1. Intended use
The machine is intended for sanding, polishing and brushing metal and coated surfaces as well as for
polishing stone without the use of water.
2. Before using your power tool
1) Inspect tools before use. The tools must be free of cracks, chips and breaks. If there are any signs of
damage, discard the tools and replace immediately.
2) Ensure that the power switch is in the off position. If the plug is connected to a power receptacle
while the power switch is in the on position, this power tool will start operating immediately, inviting
serious accident.
3. Installing the auxiliary handle
An auxiliary handle is supplied and can be fixed into one of the two positions on the gear case (See Fig
1).
Note: This handle should be used at all times to maintain complete control of the power tool.
4. Installing polishing bonnet
1) Clean the power tool spindle. Press in the spindle lock button and rotate the spindle by hand until it is
locked. Keeping the lock button pressed in, screwing the polishing plate onto the power tool spindle in
clockwise and tighten the polishing plate fully (See Fig 2).
2) When the polishing plate is tight, release the spindle lock button and fit the polishing bonnet over the
polishing plate.Bends back the polishing bonnet,put the polishing plate on it and assure their center
alignment (See Fig 3).Tie a bow knot (See Fig 4) and then tuck the knot and any loose strings between
the wool bonnet and the polishing plate (See Fig 5).
Warning: Never pressthe spindle lock button when the power tool isrunning.
5. Switching on and off
1) To start the power tool, simply depress the trigger switch. Release the trigger switch to stop your
power tool.
2) For continuous operation, depress trigger switch and then push in lock-on button (See Fig 6), release
trigger switch first and lock-on button second. Your switch is now locked on for continuous use.
3) To switch off your power tool, just depress fully and release the trigger switch. The switch will return
to "off" position automatically.
Warning: Hold the power tool with both hands while starting the tool, since torque from
the motor can cause the power tool to twist.
6. Variable speed dial
The power tool speed can be changed by turning the variable speed dial to a given number setting from
1 to 6 (At the time when the switch trigger is fully pulled.) Higher speed is obtained when the dial is
11

1400W ANGLE POLISHER ENG
turned in the direction of 6. And lower speed is obtained when it is turned in the direction of 1 (See Fig
7). The required speed depends on the material and the working conditions and can be determined
through practical testing.
7. Polishing and sanding operations
Hold your power tool with one hand on the rear handle and other hand firmly around the auxiliary
handle. Turn the power tool on and then apply the polishing bonnet to the workpiece (See Fig 8).
Always maintain an angle between the polishing bonnet and work surface of approximately 15owhen
polishing (See Fig 9
12
) or maintain an angle between the sanding disc and work surface of approximately
10owhen sanding. Apply slight pressure only. Excessive pressure will result in poor performance and
premature wear to polishing bonnet.
Warning: Never use tools with the Max specified rotational/circumferential speedon the
label of the tools smaller than the values given inthe nameplate of power tool.
WORKING HINTS FOR YOUR POWER TOOL
1. Use caution when working into corners as contact with the intersecting surface may cause the
power toolto jump or twist.
2. At all times, let the power tool do the work, do not force it or apply excessive pressure to the tools.
3. For the polishing of weathered paint or buffing out scratches (e.g., acrylic glass), the power tool may
be fitted with appropriate polishing accessories such as lamb’s wool bonnet, polishing felt or sponge
(optional accessories). Select a low speed for polishing in order to avoid excessive heating of the
surface.
4. Do not allow the polishing agent to dry out on the surface. Otherwise the surface can become
damaged. Do not subject the surface to be polished to direct sunlight.
5. When sanding guide the sanding disc with crosswise strokes. Do not use a circular motion, as this
makes swirl marks. Test before use on scrap stock.
6. For sanding applications on soft materials, e. g., gypsum or paint, it is recommended to use the
rubber sanding plate with sanding sheet. Cup brushes and wheel brushes are suitable for rust removal.
MAINTENANCE
Warning: Remove the plug from the socket before carrying out any adjustment, servicing
or maintenance.
1. Keep the power tool ventilation slots clean and free from obstructions. If available, blow compressed
air into the vents to clear any internal dust (safety goggles must be worn when undertaking this
process).
2. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth.
3.Clean the polishing accessories regularly to ensure good polishing results. Wash out polishing
accessories with mild detergents and warm water. Do not use solvents.
4. Your power tool requires no additional lubrication.
5. Always store your power tool in a dry place.
6. If you see some sparks flashing in the ventilation slots, this is normal and will not damage your power
tool.
7. The motor employs carbon brushes which are consumable parts. Since an excessively worn carbon

1400W ANGLE POLISHER ENG
brush results in motor trouble. To inspecting or replacing the carbon brushes, use a screwdriver to
remove the brush holder caps (See Fig10). Take out the carbon brushes(See Fig 11). If it becomes
worn to or near “wear limit” (See Fig 12), replacing the new ones, reinstall the holder cap firmly.
Note: Both carbon brushes should be replaced at the same time. Use only identical carbon brushes.
Keep the carbon brushes clean and free to slip in the holders.
8. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
TROUBLESHOOTING
1. If your power tool will not operate, check the power at the mains plug, or check the carbon brushes.
2. If your polishing plate wobbles or vibrates, check that polishing plate is tight.
3. If afault can’t be rectified,return the power tool to an authorized dealer for repair.
ENVIRONMENT PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice.
13

1400W ANGLE POLISHER ENG
EXPLOSIVE VIEW
14

1400W ANGLE POLISHER ENG
PART LIST
NO DESCRIPTION Q’TY NO DESCRIPTION Q’TY
1
Polishing plate
1
24
Stator
1
2 Spindle 1 25 Motor housing 1
3
Woodruff key
1
26
Screw
2
4 Dust cap 1 27 Brush holder cap 2
5
Screw
4
28
Carbon brush
2
6 Gear box cover 1 29 Brush holder 2
7
Bearing
1
30
Decorating ring
1
8 Circlip 1 31 Right handle 1
9
Gear
1
32
Screw
4
10 Sleeve bearing 1 33 Switch trigger 1
11
Circlip
1
34
Variable speed controller
1
12 Gear case 1 35 Switch 1
13
Spring
1
36
Cable clamp
1
14 Spindle lock button 1 37 Screw 2
15
Screw
4
38
Left handle
1
16 Circlip 1 39 Cable protector 1
17
Bearing
1
40
Cable and plug
1
18 Support of bearing 1 41 Auxiliary handle 1
19
Rotor
1
42
Washer
2
20 Dustproof ring 1 43 Bolt 2
21
Bearing
1
44
Allen key
1
22 Bearing sleeve 1 45 Polishing bonnet 1
23
Air deflector
1
15

MADE IN CHINA
Copyright @ WIDO Machinery Co., Ltd. All rights reserved. www.widopt.com
