VITOPEND 222 Type WHSA
Gas fired boiler with an integral primary cylinder
Fully automatic
With modulating atmospheric burner for open flue opera-
tion
or
With modulating pressure-jet burner for balanced flue
operation
Control unit for constant temperature or weather-compen-
sated operation is included in the equipment price
For natural gas and LPG
VIESMANN
Datasheet
Part numbers and prices: see pricelist
VITOPEND 222
Gas fired boiler with an integral primary cylinder for open or balanced flue
operation
10.5 to 24 (30) kW
File in: Vitotec folder, register 5
5822 335-1 GB 3/2006

&Attractively priced and compact gas fired wall mounted boiler
with integral stainless steel primary cylinder with 50 litres capa-
city for the highest DHW convenience –fully fitted
&Standard efficiency: up to 92 %
&Operating mode:
For balanced flue mode as low temperature boiler
&Automatic flue gas adaptation and multi-stage flue gas fan
ensure permanently high efficiency.
&High DHW convenience:
–50 litre stainless steel primary cylinder ensures constant
DHW availability
–Booster operation (30 kW) safeguards short heat-up times
–High draw-off rate, 20 litres per minute
–Modulating primary system with outlet temperature sensor for
constant water temperature
&Easy to service and maintain
–New space-saving and easily accessible AquaBloc hydraulic
unit
–Multi-connect system
–All components, including the heat exchanger, are accessible
from the front; side clearances are no longer required
AStainless steel primary cylinder
BDiaphragm expansion vessel
CModulating burner
DAqua-Block
EVitotronic control unit
Selection
Vitopend 222
Type WHSA
Vitopend 100
Type WHEA
Vitopend 200
Type WHKA
Vitopend 100
Type WH0A
Rated output 24 kW 24 kW 24 kW 24 kW
Booster 30 kW —29 kW —
DHW heating Integral primary cylinder:
50 litres
Cylinder installed below
the boiler: 120/150 litres
Cylinder installed adja-
cent to the boiler:
80 litres
Plate heat exchanger
with standby function:
2.5 litres
Plate heat exchanger
without standby function
Designation (stars) to
EN 13203
*** *** ** *
Peak output 200 litres/10 min 153 litres/10 min with
120 litre cylinder
140 litres/10 min 114 litres/10 min
5822 335-1 GB
2VIESMANN VITOPEND 222
Benefits

Vitopend 222
Type WHSA
Vitopend 100
Type WHEA
Vitopend 200
Type WHKA
Vitopend 100
Type WH0A
Simultaneous operation
5822 335-1 GB
VITOPEND 222 VIESMANN 3
Selection (cont.)

Specification
Gas fired wall mounted boiler Balanced flue opera-
tion
Open flue operation
Category II2H3P
Type C12,C
12x,C 32,C 32x,C 42x,
C52,C
62,C 82,C 82x
B22,B
32
B11BS
Product ID CE-0085 BP 0399
Rated output range for central heating/DHW heating kW 10.5-24/30
Rated thermal load kW 12.1-26.4/33.3 12.4-26.2/33.3
Gas supply pressure
Natural gas mbar 20/25 20/25
LPG mbar 30/50 30/50
Max. permissible gas supply pressure
Natural gas mbar 25 25
LPG mbar 57.5 57.5
Max. power consumption (incl. circulation pump) W 200 154
Protection IP X4D X4D
Weight kg 67 60
Content heat exchanger l 0.55 0.55
Heating water flow rate at 230 mbar residual head l/h 1000 1000
Nominal circulation water volume at ΔT = 20 K l/h 1035 1035
Permissible operating pressure bar 3 3
Connections to the gas fired boiler
Boiler flow and return G ¾" ¾"
Hot and cold water G ½" ½"
Gas connection G¾"¾"
Dimensions
Length mm 480 480
Width mm 600 600
Height mm 900 900
Diaphragm expansion vessel for heating water
Capacity l 8 8
Inlet pressure bar 0.8 0.8
DHW primary cylinder
Capacity l 50 50
Permissible operating pressure bar 10 10
Minimum pressure cold water connection bar 0.5 0.5
Continuous DHW output kW 30 30
for DHW heating from 10 to 40 °C l/h 860 860
Performance factor NL2.0 2.0
Max. DHW draw-off rate at the given DHW performance factor NL
and DHW heating from 10 to 40 °C (max. 10 min)
l/min 20 20
Connection values
Relative to the max. load
Gas HuB
Natural gas E 9.45 kWh/m3m3/h 3.52 3.52
34.01 MJ/m3
Natural gas LL 8.13 kWh/m3m3/h 4.10 4.10
29.25 MJ/m3
LPG 12.79 kWh/kg kg/h 2.58 2.58
46.04 MJ/kg
Flue gas values (calculation values for sizing the flue gas system
to EN 13384)
Natural gas LPG Natural gas LPG
Flue gas temperatures (measured at 20 °C combustion air tem-
perature)
–for DHW heating °C 146 159 135 128
–at the upper rated output °C 121 148 124 120
–at the lower rated output °C 105 117 98 94
Mass flow rate
–for DHW heating kg/h 56.7 59.5 80.1 78.0
at CO2content % 7.3 8.5 5.3 6.3
–at the upper rated output kg/h 43.9 61.1 77.8 74.6
at CO2content % 7.7 6.8 4.4 5.4
–at the lower rated output kg/h 49.7 52.0 69.1 71.0
CO2content % 3.1 3.7 2.2 2.6
Standard efficiency % upto94 upto92
5822 335-1 GB
4VIESMANN VITOPEND 222
Specification - Vitopend 222

Gas fired wall mounted boiler Balanced flue opera-
tion
Open flue operation
Required draught Pa —1.5
coaxial parallel
Flue outlet Ø mm 60 / 80 80 140/150
Ventilation air inlet Ø mm 100 / 125 80
Note
If the gas supply pressure is higher than the maximum permitted value, install a separate gas governor upstream of the system.
Balanced flue operation
AArea for electrical supply cables
EDrain
GA Gas connection
HR Heating return
HV Heating flow
KW Cold water
WW DHW
Note
For dimensions of on-site pipe connections, see from page 10
5822 335-1 GB
VITOPEND 222 VIESMANN 5
Specification - Vitopend 222 (cont.)

Dimensions
a (External Ø) mm 100
b
–Boiler flue connection, coaxial 60/100 mm 70
–Boiler flue connection, parallel 80/80 mm 133
–Boiler flue connection, coaxial 60/100 –80/125 mm 136
c
–Flue outlet bend 90° coaxial 60/100 mm 95
–Boiler flue connection and boiler flue connection
bend 90° parallel 80/80
mm 228
–Boiler flue connection and boiler flue connection
bend 90° coaxial 60/100 –80/125
mm 246
Installation location - parallel adaptor
5822 335-1 GB
6VIESMANN VITOPEND 222
Specification - Vitopend 222 (cont.)

AArea for electrical supply cables
EDrain
GA Gas connection
HR Heating return
HV Heating flow
KW Cold water
WW DHW
Note
For dimensions of on-site pipe connections, see from page 10
Dimensions
a (External Ø) mm 100
b
–Boiler flue connection, coaxial 60/100 mm 70
–Boiler flue connection, coaxial 60/100 –80/125 mm 136
c
–Flue outlet bend 90° coaxial 60/100 mm 95
–Boiler flue connection and boiler flue connection
bend 90° coaxial 60/100 –80/125
mm 246
5822 335-1 GB
VITOPEND 222 VIESMANN 7
Specification - Vitopend 222 (cont.)

Open flue operation
AElectrical connections
EDrain
GA Gas connection
HR Heating return
HV Heating flow
KW Cold water
WW DHW
Note
For dimensions of on-site pipe connections, see from page 10
5822 335-1 GB
8VIESMANN VITOPEND 222
Specification - Vitopend 222 (cont.)

Circulation pump
Residual head (with integral overflow valve)
Pre-installation
Clearance for maintenance work
Maintain a clearance of 700 mm in front of the Vitopend for main-
tenance work.
Maintenance clearances to the l.h. or r.h. side of the Vitopend are
not required.
5822 335-1 GB
VITOPEND 222 VIESMANN 9
Specification - Vitopend 222 (cont.)

Pre-installation: finished walls
Required accessories for installation in unfinished buildings:
&Installation template or installation frame
incl. fixing parts, valves, gas stop cock and pipe bends.
Installation template for finished walls
AInstallation template
BVitopend position
CArea for electrical supply cables.
Allow all cables/leads to protrude approx. 1300 mm from the
wall.
EDrain
GA Gas connection G ¾"
HR Heating return G ¾"
HV Heating flow G ¾"
KW Cold water G ½"
SIV Connection options for safety valve (secondary side)
WW Hot water G ½"
Note
For on-site connection dimensions for pipes, see page 13
5822 335-1 GB
10 VIESMANN VITOPEND 222
Pre-installation (cont.)

Mounting frame for finished walls
AInstallation template
BVitopend position
CArea for electrical supply cables.
Allow all cables/leads to protrude approx. 1300 mm from the
wall.
EDrain
GA Gas connection G ¾"
HR Heating return G ¾"
HV Heating flow G ¾"
KW Cold water G ½"
SIV Connection options for safety valve (secondary side)
WW Hot water G ½"
Note
For on-site connection dimensions for pipes, see page 14
5822 335-1 GB
VITOPEND 222 VIESMANN 11
Pre-installation (cont.)

Pre-installation: unfinished walls
Required accessories for installation in unfinished buildings:
&Installation template
incl. fixing parts, valves, gas stop cock and pipe bends.
Installation template for installation on unfinished walls
AInstallation template
BVitopend position
CArea for electrical supply cables.
Allow all cables/leads to protrude approx. 1300 mm from the
wall.
EDrain
GA Gas connection R ½"
HR Heating return R ¾"
HV Heating flow R ¾"
KW Cold water R ½"
SIV Connection options for safety valve (secondary side)
WW Hot water R ½"
Electrical connection
Power supply
Ensure the power supply connections comply with the require-
ments of your local electricity supply company and current VDE
[or local] regulations.
Protect the power supply cable with a fuse with a maximum rating
of 16 A.
Provide the power supply (230 V~/50 Hz) via a permanent con-
nection.
Connect the supply cables and accessories at the terminals inside
the boiler.
5822 335-1 GB
12 VIESMANN VITOPEND 222
Pre-installation (cont.)

Power supply for accessories
The power supply of accessories can be connected directly to the
control unit. This connection is controlled with the system ON/OFF
switch (max. 4 A).
Where the boiler is installed in a wet area, the power supply con-
nection of accessories must not be carried out at the control unit.
AReference point Vitopend top edge
BArea for electrical supply cables
Allow all cables/leads to protrude approx. 1300 mm from the wall
in area B.
Cables
NYM-J
3×1.5mm
2
2-core min.
0.75 mm2
NYM-O 3 x 1.5 mm2
–Power supply
cables (also for
accessories)
–Fault notification
–External exten-
sion H1 and H2
(KM BUS)
–Outside tempera-
ture sensor
–Vitotronic 050
(LON)
–Extension kit for
heating circuit with
mixer (KM BUS)
–Vitotrol 100, type -
UTD
–Vitotrol 200
–Vitotrol 300
–Vitotrol 100, type -
UTA
Interlocking circuit
Install an interlock for open flue operation if required, if an extrac-
tor (e.g. cooker hood) is fitted in the room providing the boiler air
supply.
For this, the internal extension H2 (accessories) can be used.
This switches the extractors OFF when the burner is started.
Accessories for Vitopend installation
Installation template for finished walls
Part no. 7186 957
&Wall mounting fixture
&Installation brace
&Mounting panel with shut-off valves and boiler fill & drain valve
&Pipe bends Ø 15/22
&Gas stop cock G ¾"
Part no. 7186 958
&Wall mounting fixture
&Installation brace
&Mounting panel with shut-off valves and boiler fill & drain valve
&Pipe bends Ø 16/22
&Gas stop cock G ¾"
Part no. 7186 959
&Wall mounting fixture
&Installation brace
&Mounting panel with shut-off valves and boiler fill & drain valve
&Pipe bends Ø 16/20
&Gas stop cock G ¾"
5822 335-1 GB
VITOPEND 222 VIESMANN 13
Pre-installation (cont.)

Installation template for unfinished walls
Part no. 7186 960
Components:
&Wall mounting fixture
&Installation brace
&Mounting plate
&Mounting panel with shut-off valves and boiler fill & drain valve
&Pipe Ø 15/18
&Gas stop cock G ¾"
Mounting frame
Part no. 7186 961
&Mounting panel with shut-off valves and boiler fill & drain valve
&Pipe bends Ø 15/22
&Gas angle valve G ¾"
Part no. 7186 962
&Mounting panel with shut-off valves and boiler fill & drain valve
&Pipe bends Ø 16/20
&Gas angle valve G ¾"
Part no. 7186 963
&Mounting panel with shut-off valves and boiler fill & drain valve
&Pipe bends Ø 16/22
&Gas angle valve G ¾"
Fitting cover
Part no. 7192 890
Filling facility with shut-off device
Part no. 7189 502
5822 335-1 GB
14 VIESMANN VITOPEND 222
Accessories for Vitopend installation (cont.)

Diaphragm expansion vessel for DHW
Part no. 7824 494
Capacity 2 litres
Inlet pressure 5.2 bar
Drain plug for filling equipment
Part no. 7824 521
Drain outlet kit
Part no. 7189 014
Drain outlet with siphon and rose.
Safety valve
&Part no. 9572 227
6 bar
&Part no. 9572 228
10 bar
Vitotronic 100, type HC1 (constant temperature mode)
Structure and functions
Modular design
The control unit is integrated into the boiler.
The control unit comprises a basic unit, electronic modules and a
programming unit.
Basic unit:
&ON/OFF switch
&Optolink laptop interface
&Operating and fault display
&Reset button
&Fuses
Programming unit:
&Display
&Adjustment and display of temperatures and codes
5822 335-1 GB
VITOPEND 222 VIESMANN 15
Accessories for Vitopend installation (cont.)

&Fault message display
&Keys:
–Program selection
–Boiler water temperature
–DHW temperature
–DHW convenience function
–Emissions test function
Functions
&Electronic boiler control unit for operation at a constant boiler
water temperature
&Room temperature-dependent operation requires a Vitotrol 100,
type UTA or UTD (according to EnEV [Germany])
&Heating system frost protection
&Integral diagnostics system
&Integral cylinder thermostat
Control characteristics
PI characteristics with modulating output.
Setting the heating programs
The heating system frost protection (see frost protection function)
applies to all heating programs.
You can select the following heating programs with the program
keys:
&Heating and DHW
&DHW only
&Standby mode
Frost protection function
The burner is switched ON when the boiler water temperature
reaches 5 °C and will be switched OFF again, when the boiler
water temperature reaches 40 °C.
The circulation pump will be switched ON simultaneously with the
burner and switched OFF after a delay.
To protect the system against frost, the circulation pump can be
started at certain intervals (up to 24 times per day) for periods of
approx. 10 minutes.
Summer mode
Heating program "w"
The burner starts only when the DHW cylinder needs to be heated
up again.
Boiler water temperature sensor
The boiler water temperature sensor is connected to the control
unit and built into the boiler.
Specification
Permissible ambient temperature
–during operation 0 to +130 °C
–during storage and transport -20 to +70 °C
Cylinder temperature sensor
The cylinder temperature sensor is integrated into the boiler.
Specification
Protection IP 32
Permissible ambient temperature
–during operation 0 to +90 °C
–during storage and transport -20 to +70 °C
Outlet temperature sensor
The outlet temperature sensor is integrated into the boiler.
Specification
Protection IP 32
Permissible ambient temperature
–during operation 0 to +90 °C
–during storage and transport -20 to +70 °C
Internal extension H1
The internal extension H1 is integrated into the control unit.
Function:
&Switches the cylinder primary pump
&Optional connection of an external safety solenoid valve (LPG)
Rated breaking capacity of the relay output: 1(0.5) A 250 V~
Specification
Rated voltage 230 V~
Rated frequency 50 Hz
Specification Vitotronic 100, type HC1
Rated voltage 230 V~
Rated frequency 50 Hz
Rated current 6 A
Protection class I
Function Type 1 B to EN 60730-1
Permissible ambient temperature
–during operation 0 to +40 °C
Installation in living spaces
or boiler rooms (standard
ambient conditions)
–during storage and transport -20 to +65 °C
Electronic control thermostat set-
ting:
76 °C (fixed)
Electronic temperature limiter set-
ting (heating mode)
84 °C (fixed)
Temperature limiter setting 100 °C (fixed)
Setting range for the DHW tem-
perature
10 to 60 °C
AccessoriesfortheVitotronic100,typeHC1
Vitotrol 100, type UTA
Part no. 7170 149
Room thermostat
&With switching output (two-point output)
&With analog time switch
&With adjustable individual day program
&Standard switching times are factory-set (individually program-
mable)
&Shortest switching interval 15 minutes
Install the Vitotrol 100 in the main living room on an internal wall
opposite radiators, but not inside shelf units, recesses, immedi-
ately by a door or a heat source (e.g. direct sunlight, fireplace, TV
set, etc.).
Control unit connection:
3-core cable with a cross-section of 1.5 mm2(without green/yel-
low) for 230 V~.
5822 335-1 GB
16 VIESMANN VITOPEND 222
Vitotronic 100, type HC1 (constant temperature mode) (cont.)

Specification
Rated voltage 230 V/50 Hz
Rated breaking capacity of the con-
tact 6(1) A 250 V~
Protection IP 20 to EN 60529
safeguard through appropri-
ate design and installation
Permissible ambient temperature
–during operation 0 to +40 °C
–during storage and transport -20 to +60 °C
Set value range for standard and
reduced mode 10 to 30 °C
Set room temperature in standby
mode 6 °C
Vitotrol 100, type UTD
Part no. 7179 059
Room thermostat
&With switching output (two-point output)
&With digital time switch
&With individual day and 7-day programs
&With rotary selector for the following settings:
–Standard room temperature "Permanent comfort"
–Reduced room temperature "Permanent setback"
–Frost protection temperature "Frost"
–2 fixed time programs
–1 individually adjustable time program
–Holiday program
&With selector keys for party and economy mode
Install the Vitotrol 100 in the main living room on an internal wall
opposite radiators, but not inside shelf units, recesses, immedi-
ately by a door or a heat source (e.g. direct sunlight, fireplace, TV
set, etc.).
Operation without power supply (two 1.5 V round alkaline cells,
type LR6 (AA), which run for approx. 18 months)
Control unit connection:
2-core cable with a cross-section of 1.5 mm2for 230 V~
Connection via a LV cable is possible in conjunction with the
external extension H4 (accessories).
Specification
Rated voltage 3 V–
Rated breaking capacity of the zero
volt contact
–max. 6(1) A 230 V~
–min. 1 mA 5 V–
Protection IP 20 to EN 60529
safeguard through appropri-
ate design and installation
Function RS type 1B to EN 60730-1
Permissible ambient temperature
–during operation 0 to +50 °C
–during storage and transport -10 to +60 °C
Setting range
–Comfort temperature 10 to 30 °C
–Setback temperature 10 to 30 °C
–Frost temperature 6 to 10 °C
Power reserve during battery
change 10 min
Vitocom 100, type FA1
Part no. 7178 188
KM BUS user
&For remote reporting, remote monitoring and scanning of faults
via the telephone system
&For remote control of heating systems via the telephone system
Configuration:
&Telephone operating with the dual‐tone multi‐frequency (DTMF)
method
&D1/D2/E‐Plus/O2mobile phones
&Configuration tool (software for PC)
Fault messages are transmitted to the following communica-
tion services via the telephone system:
&Fax
&D1/D2 mobile phone
Standard delivery:
&Vitocom 100
&Power supply cable (2.0 m long)
&Connecting cable with RJ11 plug for telephone socket (3.0 m
long)
&Adaptor RJ11/TAE6N
&KM BUS cable with plug aVG (3.0 m long)
For accessories and further details, see the Viessmann technical
guide "Communication systems"
5822 335-1 GB
VITOPEND 222 VIESMANN 17
AccessoriesfortheVitotronic100,typeHC1 (cont.)

On‐site requirements:
&RJ11 socket or
&TAE socket, coding "6N"
Specification
Rated voltage: 230 V ~
Rated frequency: 50 Hz
Rated current : 15 mA
Safety class: II
Protection: IP 20 to EN 60529;
safeguard through appropri-
ate design and installation
Function: Type 1B to EN 60 730‐1
Permissible ambient temperature
–during operation: 0 to +40 °C
Installation in living spaces
or boiler rooms (standard
ambient conditions)
–during storage and transport: ‐20 to +65 °C
Approval: CTR 21
Internal extensions H1 and H2 and external extensions H1 and H2
For connection options and specification, see accessories for the
Vitotronic 200 from page 27.
External extension H4
Part no. 7197 227
Connection extension for connecting the Vitotrol 100, type UTD or
24 V clock thermostats via a LV cable.
With cable (0.5 m long) and plug for the connection to the
Vitotronic 100.
Specification
Rated voltage
–primary 230 V ~
–secondary 24 V ~
Rated frequency 50 Hz
Rated current 2 A
Power consumption 2.5 VA
Protection class I
Protection IP 41
Permissible ambient temperature
–during operation 0 to +40 °C
Installation in living spaces
or boiler rooms (standard
ambient conditions)
–during storage and transport -20 to +65 °C
Vitotronic 200, type HO1 (weather-compensated mode)
Structure and functions
Layout and functions
Modular construction
The control unit is integrated into the boiler.
The control unit is comprised of a basic unit, electronic modules
and a programming unit.
Basic unit:
&ON/OFF switch
&Optolink laptop interface
&Operating and fault display
&Reset button
&Fuses
Programming unit:
&With digital time switch
&Illuminated display with plain text support
&Adjustment and display of temperatures and codes
&Fault message display
&Rotary selector for the temperature in standard mode
&Keys:
–Program selection
–Holiday program
–Party and economy mode
–Temperature for reduced mode
–DHW temperature
–Emissions test function
Functions
&Weather-compensated control of the boiler water and/or flow
temperature
&Electronic maximum and minimum temperature limit
5822 335-1 GB
18 VIESMANN VITOPEND 222
AccessoriesfortheVitotronic100,typeHC1 (cont.)

&Demand-dependent heating circuit pump and burner OFF con-
trol
&Adjustment of a variable heating limit
&Anti-seizing pump protection
&Heating system frost protection
&Integral diagnostics system
&Maintenance display
&Integral DHW heating
&Screed drying program
&External starting and blocking (accessories)
The requirements of DIN EN 12831 for heating load calculation
are met. To reduce the heat-up load, the night setback is reduced
in case of low outside temperatures. The flow temperature will be
raised for a limited time to reduce the heat-up time after a setback
period.
According to the Energy Savings Order [Germany], the tempera-
ture in each room must be individually controlled, e.g. through
thermostatic radiator valves.
Control characteristics
PI characteristics with modulating output.
Time switch
Digital time switch
&Day and week program, annual calendar
&Automatic summer/winter time changeover
&Automatic function for DHW heating and DHW circulation pump
&Time, day and standard switching times for central heating,
DHW heating and the DHW circulation pump are factory-set
&Switching times are individually programmable, i.e. up to four
switching periods per day.
Shortest switching interval: 10 minutes
Power backup: 5 years
Setting the heating programs
The heating system frost protection (see frost protection function)
applies to all heating programs.
You can select the following heating programs with the program
keys:
&Heating and DHW
&DHW only
&Standby mode
External heating program changeover in conjunction with an
external extension H1 or H2.
Frost protection function
&The frost protection function will be started when the outside
temperature drops below approx. +1 °C.
With active frost protection, the heating circuit pump will be
switched ON and the boiler water is maintained at a lower tem-
perature of approx. 40 °C.
&The frost protection function will be switched OFF when the out-
side temperature rises above approx. +3 °C.
Summer mode
Heating program "w"
The burner starts only when the DHW cylinder needs to be heated
up again.
Adjusting the heating curves (slope and level)
The Vitotronic 200 controls the boiler water temperature (= flow
temperature of the heating circuit without mixer) and the flow tem-
perature of the heating circuit with mixer (in conjunction with the
extension kit for one heating circuit with mixer) subject to outside
temperature. The boiler water temperature is automatically
boosted by between 0 and 40 K higher than the currently required
set flow temperature (delivered condition 8 K).
The flow temperature required to reach a specific room tempera-
ture depends on the heating system and the thermal insulation of
the building to be heated.
Adjusting both heating curves matches the boiler water tempera-
ture and the flow temperature to these operating conditions.
Heating curves:
The upper boiler water temperature is limited by the temperature
limiter and the temperature set at the electronic maximum thermo-
stat.
The flow temperature cannot exceed the boiler water temperature.
Heating systems with low loss header
When using a hydraulic separation (low loss header), connect a
temperature sensor for use in the low loss header.
Boiler water temperature sensor
The boiler water temperature sensor is connected to the control
unit and built into the boiler.
Specification
Permissible ambient temperature
–during operation 0 to +130 °C
–during storage and transport -20 to +70 °C
Cylinder temperature sensor
The cylinder temperature sensor is integrated into the boiler.
Specification
Protection IP 32
Permissible ambient temperature
–during operation 0 to +90 °C
–during storage and transport -20 to +70 °C
Outlet temperature sensor
The outlet temperature sensor is integrated into the boiler.
Specification
Protection IP 32
Permissible ambient temperature
–during operation 0 to +90 °C
–during storage and transport -20 to +70 °C
Outside temperature sensor
Installation location:
&North or north-western wall of the building
&2 to 2.5 m above the ground, for multi-storey buildings in the
upper half of the second floor
Connection:
&2-core lead, length up to 35 m with a cross-section of 1.5 mm2
(copper)
&Never route this lead immediately next to 230/400 V cables
5822 335-1 GB
VITOPEND 222 VIESMANN 19
Vitotronic 200, type HO1 (weather-compensated mode) (cont.)

Specification
Protection IP 43 to EN 60529;
safeguard through appro-
priate design and instal-
lation
Permissible ambient temperature dur-
ing operation, storage and transport -40 to +70 °C
Specification Vitotronic 200, type HO1
Rated voltage 230 V~
Rated frequency 50 Hz
Rated current 6 A
Power consumption incl. circulation
pump
–open flue 98 W
–balanced flue 148 W
Protection class I
Function Type 1 B to EN 60730-1
Permissible ambient temperature
–during operation 0 to +40 °C
Installation in living spaces
or boiler rooms (standard
ambient conditions)
–during storage and transport -20 to +65 °C
Electronic control thermostat set-
ting:
76 °C (fixed)
Electronic temperature limiter set-
ting (heating mode)
84 °C (fixed)
Temperature limiter setting 100 °C (fixed)
Setting range for the DHW tem-
perature
10 to 60 °C
Heating curve setting range
–Slope 0.2 to 3.5
–Level –13 to 40 K
AccessoriesfortheVitotronic200,typeHO1
Notes regarding room temperature hook-up (RS function) for remote control units
Never activate the RS function for underfloor heating circuits
(inertia).
The RS function must only affect the heating circuit with mixer.
Notes regarding the Vitotrol 200 and 300
If required, the Vitotrol 200 and 300 can also be used together in a
single heating system, respectively for one heating circuit each.
Vitotrol 200
Part no. 7450 017
KM BUS user
The Vitotrol 200 remote control regulates the heating program for
one heating circuit and the required set room temperature in stan-
dard mode, from any room in the house.
The Vitotrol 200 is equipped with illuminated heating program
keys and a party or economy key.
The fault display shows faults on the control unit.
WS function:
Installation at any point in the building.
RS function:
Installation in the main living room on an internal wall opposite
radiators. Never install inside shelf units, niches, immediately by a
door or heat source (e.g. direct sunlight, fireplace, TV set, etc.).
The integral room temperature sensor captures the actual room
temperature and effects any necessary correction of the flow tem-
perature as well as a rapid heat-up at the start of the heating
operation (if suitably encoded).
Connection:
&2-core lead, length max. 50 m (even if connecting several
remote control units)
&Never route this lead immediately next to 230/400 V cables
&LV plug as standard delivery
5822 335-1 GB
20 VIESMANN VITOPEND 222
Vitotronic 200, type HO1 (weather-compensated mode) (cont.)
