Viessmann VITOCAL 060-A Operating instructions

Installation and service instructions
for contractors
VIESMANN
Vitocal 060-A
Type T0E-ze
DHW heat pump with dry immersion heater
Type T0S-ze
DHW heat pump with connection for external heat generator or solar collectors
VITOCAL 060-A
6136003 GB 3/2020 Please keep safe.

2
Please follow these safety instruc-
tions closely to prevent accidents
and material losses.
Safety instructions explained
Danger
This symbol warns against the risk
of injury.
!Please note
This symbol warns against the risk
of material losses and environmen-
tal pollution.
Note
Details identified by the word "Note"
contain additional information.
Target group
These instructions are exclusively inten-
ded for qualified contractors.
■Work on the refrigerant circuit may only
be carried out by authorised refrigera-
tion engineers.
■Work on electrical equipment may only
be carried out by a qualified electrician.
■The system must be commissioned by
the system installer or a qualified per-
son authorised by the installer.
Regulations to be observed
■National installation regulations
■Statutory regulations for the prevention
of accidents
■Statutory regulations for environmental
protection
■Codes of practice of the relevant trade
associations
■Relevant country-specific safety regu-
lations
Safety instructions
Safety instructions
6136003

3
Safety instructions for working on the system
Working on the system
■Isolate the system from the power sup-
ply, e.g. by removing the separate fuse
or by means of a mains isolator, and
check that it is no longer live.
Note
In addition to the control circuit there
may be several power circuits.
Danger
Contact with live components can
result in severe injuries. Some
components on PCBs remain live
even after the power supply has
been switched off.
Prior to removing covers from the
appliances, wait at least 4 minutes
until the voltage has completely
dropped out.
■Safeguard the system against recon-
nection.
■Wear suitable personal protective
equipment when carrying out any work.
Danger
Hot surfaces and fluids can lead to
burns or scalding.
■Before maintenance and service
work, switch off the appliance and
let it cool down.
■Do not touch hot surfaces on the
appliance, fittings or pipework.
!Please note
Electronic assemblies can be dam-
aged by electrostatic discharge.
Before beginning work, touch
earthed objects, such as heating or
water pipes, to discharge any static.
Work on the refrigerant circuit
Refrigerant R1234ze is a colourless,
odourless gas that displaces air.
■R1234ze is mildly flammable (safety
class A2L according to ISO 817).
■R1234ze belongs to fluid group 2
(according to the Pressure Equipment
Directive 2014/68/EU).
Danger
Direct contact with liquid and gas-
eous refrigerant can cause serious
damage to health.
■Avoid direct contact with liquid and
gaseous refrigerant.
■Wear protective gloves/protective
clothing/eye protection/face pro-
tection (P280).
■Wear respiratory protection
(P284).
■If exposed or concerned: Get
medical advice/attention
(P308+P313).
■Protect from sunlight and store in
a well ventilated place
(P410+P403).
Details in brackets pursuant to
Regulation (EC) No 1272/2008
Danger
Contains gas under pressure; may
explode if heated (H280).
Do not heat the refrigerant circuit
from the outside.
Safety instructions
Safety instructions (cont.)
6136003

4
Danger
Unregulated escape of refrigerant in
enclosed spaces can lead to
breathing difficulties and suffoca-
tion.
■Do not breathe dust/fumes/gas/
mist/vapours/spray (P260).
■Ensure adequate ventilation in
enclosed spaces.
Perform the following measures before
beginning work on the refrigerant circuit:
■Check the refrigerant circuit for leaks.
■Ensure very good ventilation especially
in the floor area and sustain this for the
duration of the work.
■Inform all persons in the vicinity of the
system about the type of work to be
carried out.
■Secure the area surrounding the work
area.
Danger
Damage to the refrigerant circuit
can cause refrigerant to enter the
hydraulic system. This can cause
serious damage to health.
After completion of work on the
refrigerant circuit, professionally
vent the hydraulic system on the
primary and secondary sides.
Repair work
!Please note
Repairing components that fulfil a
safety function can compromise the
safe operation of the system.
Replace faulty components only
with genuine Viessmann spare
parts.
Auxiliary components, spare and
wearing parts
!Please note
Spare and wearing parts that have
not been tested together with the
system can compromise its func-
tion. Installing non-authorised com-
ponents and making non-approved
modifications or conversions can
compromise safety and may invalid-
ate our warranty.
For replacements, use only original
spare parts supplied or approved by
Viessmann.
Safety instructions for operating the system
What to do if water escapes from the
appliance
Danger
If water escapes from the appliance
there is a risk of electric shock.
Switch off the heating system at the
external isolator (e.g. fuse box,
domestic distribution board).
Danger
If water escapes from the appliance
there is a risk of scalding.
Never touch hot heating water.
Safety instructions
Safety instructions (cont.)
6136003

5
1. Information Disposal of packaging ............................................................................ 6
Symbols ................................................................................................. 6
Intended use .......................................................................................... 6
Product information ................................................................................ 7
■Vitocal 060-A ...................................................................................... 7
■Outside temperature limits .................................................................. 7
■Permissible air intake temperatures ................................................... 8
System examples .................................................................................. 8
Spare parts lists ..................................................................................... 8
2. Preparing for installation ................................................................................................................ 9
3. Installation sequence Siting the DHW heat pump .................................................................... 12
Conversion to outdoor air mode ............................................................ 12
■Fitting the outdoor air adaptor ............................................................ 13
■Fitting the air intake/air discharge ductwork ....................................... 15
Connecting the condensate drain .......................................................... 17
Connections on the DHW side ............................................................... 18
Type T0S-ze: Solar thermal system ....................................................... 20
■Maximum collector area and sizing information ................................. 20
■Connecting the solar collectors .......................................................... 20
Type T0S-ze: External heat generator ................................................... 20
■Fitting the temperature sensor ............................................................ 20
Adjusting the draw-off rate ..................................................................... 21
Electrical connections ............................................................................ 22
■Type T0S-ze with external heat generator .......................................... 22
Connecting to the power supply ............................................................ 23
■Power cable ........................................................................................ 24
4. Commissioning, inspec-
tion, maintenance
Steps - commissioning, inspection and maintenance ............................ 25
5. Diagnosis and service
checks
Installation menu .................................................................................... 33
■Programming unit ............................................................................... 33
■Setting parameters in the installation menu "INST" ........................... 33
■Restoring factory settings (reset) ........................................................ 33
■Overview of parameters ..................................................................... 33
■Checking the actuators ....................................................................... 34
■Actual temperatures ........................................................................... 34
■Safety high pressure switch ................................................................ 35
6. Troubleshooting Messages .............................................................................................. 36
■Red LED on the heat pump control unit ............................................. 36
■Messages on the programming unit ................................................... 36
■Acknowledging messages .................................................................. 37
7. Maintenance ................................................................................................................ 38
8. Connection and wiring dia-
gram
................................................................................................................ 43
9. Reports ................................................................................................................ 45
10. Specification ................................................................................................................ 46
11. Declaration of Conformity ................................................................................................................ 50
12. Keyword index ................................................................................................................ 51
Index
Index
6136003

6
Please dispose of packaging waste in line with statu-
tory regulations.
Symbols
Symbol Meaning
Reference to other document containing
further information
1.
Step in a diagram:
The numbers correspond to the order in
which the steps are carried out.
Warning of material losses and environ-
mental pollution
Live electrical area
Pay particular attention.
■Component must audibly click into place.
or
■Acoustic signal
■Fit new component.
or
■In conjunction with a tool: Clean the sur-
face.
Dispose of component correctly.
Dispose of component at a suitable collec-
tion point. Do not dispose of component in
domestic waste.
The steps in connection with commissioning, inspec-
tion and maintenance are found in the "Commission-
ing, inspection and maintenance" section and identified
as follows:
Symbol Meaning
Steps required during commissioning
Not required during commissioning
Steps required during inspection
Not required during inspection
Steps required during maintenance
Not required during maintenance
Intended use
The appliance is only intended to be installed and
operated in sealed unvented heating systems that
comply with EN 12828, with due attention paid to the
associated installation, service and operating instruc-
tions.
The appliance may only be used for heating DHW.
The range of functions can be extended with additional
components and accessories.
Intended use presupposes that a fixed installation in
conjunction with permissible, system-specific compo-
nents has been carried out.
Commercial or industrial use for purposes other than
domestic hot water heating shall be deemed inappro-
priate.
Any usage beyond this must be approved by the man-
ufacturer in each individual case.
Information
Disposal of packaging
6136003
Information

7
Incorrect usage or operation of the appliance (e.g. the
appliance being opened by the system user) is prohibi-
ted and will result in an exclusion of liability. Incorrect
usage also occurs if the components in the heating
system are modified from their intended function.
Note
The appliance is intended exclusively for domestic
use, i.e. even users who have not had any instruction
are able to operate the appliance safely.
Product information
Vitocal 060-A
A DHW cylinder is integrated into the type T0E-ze
DHW heat pump.
The heat pump uses the thermal energy in the indoor
or outdoor air for DHW heating.
At times of peak DHW demand, an immersion heater
can provide reheating (fitted at the factory for type
T0E-ze; accessory for type T0S-ze).
Type T0S-ze contains the full function range of type
T0E-ze. In addition, a solar thermal system or external
heat generator (e.g. oil/gas boiler) can be connected.
The heat pump is available for recirculation air
mode, outdoor air mode and recirculation air mode
with air discharge to the outside.
Recirculation air mode
In recirculation air mode, the ambient temperature
(indoor air in the installation room) is used for DHW
heating.
When DHW is being heated, the installation room is
cooled and dehumidified.
Recirculation air mode with air discharge to the
outside
Ambient air is supplied to the DHW heat pump. A sep-
arate outdoor air aperture simultaneously allows out-
door air to enter the room.
The ambient air that is cooled down during DHW heat-
ing is routed outdoors by the DHW heat pump.
Outdoor air mode
In outdoor air mode, outdoor air is supplied via a duct.
The outdoor air that is cooled down during DHW heat-
ing is routed outdoors by the DHW heat pump.
Outside temperature limits
Note
What DHW temperature the heat pump can achieve
depends on the outside temperature.
The maximum achieved is 62 °C.
Information
Intended use (cont.)
6136003
Information

8
-5
30 0 10 20 30
40
50
60
70
Air intake temperature in °C
DHW temperature in °C
A
6
62
Fig. 1
AMaximum DHW temperature achievable by the
heat pump: 62 °C
Permissible air intake temperatures
The DHW heat pump shuts down outside the permissi-
ble air intake temperatures. In some operating pro-
grams, DHW can also be heated outside the permissi-
ble air intake temperatures, through the use of an
immersion heater (accessories). With type T0S-ze, an
external heat generator can be connected.
Permissible air intake temperatures:
■For DHW heating in recirculation air mode and recir-
culation air mode with air discharge to the outside
(temperature in the installation room):
3 °C to 35 °C.
■For DHW heating in outdoor air mode (outside tem-
perature):
-5 °C to 35 °C.
System examples
Available system examples: See www.viessmann-
schemes.com.
Spare parts lists
Information about spare parts can be found at
www.viessmann.com/etapp or in the Viessmann
spare part app.
Information
Product information (cont.)
6136003
Information

9
Overview of connections
802
907
1501
702
1755
Ø631
160
73
927
1339
1397
1641
706
734
DN DN160
46
187 187
46
H, K, L, N, O
A
B
M
R
D
C
E
F
G
R
A B
P
O
N
H
P
Q
Fig. 2
AAir discharge
BAir intake
CProgramming unit
DHeat pump control unit
ESensor well for draw-off profile L
Factory-fitted temperature sensors:
■Cylinder temperature sensor
and
■High limit safety cut-out for DHW heat pump
FSensor well for draw-off profile XL
G■Inspection port
■Protective magnesium anode
■Impressed current anode (accessories)
■Immersion heater (accessory for type T0S-ze,
part of standard delivery for type T0E-ze)
HCold water/drain R ¾
KType T0S-ze only:
■External heat generator:
Return G 1
■Solar collector:
Return G 1 and threaded elbow (accessories) for
lower cylinder temperature sensor
LType T0S-ze only:
Flow of external heat generator/solar collector G 1
Preparing for installation
Preparing for installation
6136003
Installation

10
MType T0S-ze only:
■Temperature sensor, external heat generator
or
■High limit safety cut-out for stopping the solar cir-
cuit pump
NDHW circulation R ¾
ODHW R ¾
PCondensate 7 20 mm
QSensor well for draw-off profile recognition
RPower cable (3 m long)
Transport and siting
!Please note
Impacts, compression and tensile loads can
cause damage to the outside panels of the
appliance.
Never put weight on the top or front of the appli-
ance or cylinder jacket.
The DHW heat pump can be transported vertically or
horizontally.
Note for horizontal transport
Position the DHW heat pump. Allow the DHW heat
pump to stand for at least 24 hours before commis-
sioning.
Lifting straps (accessories) are available to facilitate
transport.
Installation room requirements
■The installation room must be dry and free from the
risk of frost.
■The intake air must be kept free from dust, grease
and contamination through halogenated hydrocar-
bons (e.g. as contained in sprays, paints, solvents
and cleaning agents).
■To prevent the transmission of structure-borne noise,
never site the appliance above ceilings with wooden
joists (e.g. in the attic).
■A separately fused standard power socket must be
available.
■A condensate drain pipe must be available.
■Always maintain the minimum clearances for service
and maintenance work.
Fig. 3
Minimum clearances
Recirculation air mode
Note
The specified appliance output cannot be guaranteed if
the room volume is < 20 m3.
V 20 m³
2 °C 40 °C
500 kg
2000
650
100
Fig. 4
ADHW heat pump
BCondensate drain pipe
Recirculation air mode with air discharge to the
outside
Note
■The specified appliance output cannot be guaran-
teed if the room volume is < 20 m3.
■This operating mode is only permissible in unheated
rooms.
Preparing for installation
Preparing for installation (cont.)
6136003
Installation

11
V 20 m³
2 °C 40 °C
500 kg
2000
650
100
B A
C
Fig. 5
ADHW heat pump
BCondensate drain pipe
COutside air aperture:
With outdoor air adaptor DN 160: ≥ DN 160
With outdoor air adaptor DN 180: ≥ DN 180
Minimum room height
When using ductwork made from EPP (accessories),
the height of the room must be at least 2060 mm.
Outdoor air mode
500 kg
2000
-5 °C 35 °C
650
100
Fig. 6
ADHW heat pump
BCondensate drain pipe
Minimum room height
When using ductwork made from EPP (accessories),
the height of the room must be at least 2060 mm.
Preparing for installation
Preparing for installation (cont.)
6136003
Installation

12
!Please note
Incorrect handling can lead to irreparable dam-
age to the DHW heat pump.
■Never drill into the sheet steel casing of the
DHW heat pump.
■Never use the connectors as a transport aid.
■Carefully remove the DHW heat pump from
the pallet. The EPS padding underneath can
be removed for this.
Align the DHW heat pump horizontally.
35
!
3x
Fig. 7
Conversion to outdoor air mode
Note
In outdoor air mode, at outside temperatures below 6 °C, the maximum DHW tem-
perature of 62 °C is not achieved in the operating programs "ECO" and "SMART".
-5
30 0 10 20 30
40
50
60
70
Air intake temperature in °C
DHW temperature in °C
A
6
62
Fig. 8
AMaximum DHW temperature achievable by the heat pump
Installation sequence
Siting the DHW heat pump
6136003
Installation

13
Fitting the outdoor air adaptor
Danger
Hot surfaces can cause burns.
■Switch off the appliance before carrying out
maintenance and service work. Allow the
appliance to cool down.
■Never touch hot surfaces on the appliance, fit-
tings or pipework.
Installation sequence
Conversion to outdoor air mode (cont.)
6136003
Installation

14
Danger
Sharp-edged fins can cause injury.
Wear protective clothing.
Note
The air discharge aperture is converted for recircula-
tion air mode with air discharge to the outside.
4.
2.
1.
5.
6.
3.
Fig. 9
AAir discharge
BAir intake
Installation sequence
Conversion to outdoor air mode (cont.)
6136003
Installation

15
Fitting the air intake/air discharge ductwork
System diagram
A B
Fig. 10
AAir discharge
BAir intake
Ductwork DN
1Bend 90° 160
45° 160
2■Folded spiral-seam tube
■Flexible pipe
■EPP pipe
Length 3.0 m 160
3Outdoor air intake grille as air discharge duct wall outlet 160
4Exhaust air roof outlet Round, with protective grille and insu-
lation sleeve, for air discharge duct
160
5Supply air vent Wall/external connection, for air in-
take duct
160
Check valve (on site)
Installation sequence
Conversion to outdoor air mode (cont.)
6136003
Installation

16
Information on ductwork
!Please note
The simultaneous operation of open flue com-
bustion equipment (e.g. an open fireplace) and
the DHW heat pump in a space with combustion
air interconnection results in dangerous negative
pressure inside the room. Negative pressure
can result in flue gases re-entering the room.
■Never operate the DHW heat pump simultane-
ously with open flue combustion equipment
(e.g. an open fireplace).
■Operate combustion equipment exclusively in
room sealed mode with a separate supply of
combustion air. We recommend combustion
equipment with general building regulations
approval as room sealed combustion equip-
ment, issued by the Deutsches Institut für
Bautechnik DIBt [or local equivalent].
■Doors to boiler rooms where the combustion
air supply is not interconnected with the living
space must be airtight and must be kept shut.
Note
In recirculation air mode with air discharge to the out-
side, ensure an adequate supply of fresh air to the
installation room (on site), e.g. via separate vents (min.
DN 160).
■Thermally insulate the ductwork with vapour diffu-
sion-proof material.
■Always route the ducts for air intake and air dis-
charge with a 2 to 3° fall, so that rain and conden-
sate can drain away to the outdoors.
■Ensure air intake temperatures from -5 to 35 °C.
■Maximum permissible total pressure drop Δptotal
(ductwork and appliance): 100 Pa
■Fit silencers to prevent flow noise.
■Ducts, wall outlets and connections to the DHW heat
pump can be installed using anti-vibration insulation
to reduce noise (see diagram).
Connections and installation options which are not per-
missible:
■Connection of kitchen extractor hoods to the duct-
work
■Installation of a DHW heat pump with recirculation air
mode in a heated room
■Connection of the air intake duct to a mechanical
ventilation system
■Connection of the air intake duct to an air/geothermal
heat exchanger
■Connection of the air intake duct to a tumble dryer
■Reversed connections (air intake to the outside and
air discharge to the inside)
■Installation of the DHW heat pump in an attic
■Installation of the DHW heat pump in dusty rooms
■Operation of the DHW heat pump in conjunction with
an open flue boiler
Anti-vibration insulation
Fig. 11
ADHW heat pump
BFlexible hydraulic connections
CEPP insulated plastic pipes or insulated flexible
pipes (min. DN 160) for air intake/air discharge
ductwork
DAnti-vibration insulation for air intake wall duct
EAnti-vibration bracket for air intake duct
FAir intake silencer
GAir discharge silencer
HAnti-vibration bracket for air discharge duct
KAnti-vibration insulation for air discharge wall duct
LAnti-vibration insulation for floor
MAdjustable feet
Measures for minimising the pressure drop
■Use as few bends as possible.
■As far as possible, avoid elements that increase the
pressure drop.
■Route the air intake duct above the air discharge
duct if possible.
Positioning of air intake and air discharge aper-
tures
!Please note
An "air short circuit" will result in the cooled dis-
charged air being drawn back in to the unit. This
can result in reduced heat pump efficiency and
defrosting problems.
Position the air intake and air discharge aper-
tures so that any "air short circuit" is prevented.
Installation sequence
Conversion to outdoor air mode (cont.)
6136003
Installation

17
Air intake and air discharge duct through the wall
Fig. 12
AAir discharge
BAir intake
Air intake and air discharge duct through the roof
1000
Fig. 13
AAir discharge
BAir intake
Installation sequence
1. Join individual duct sections together with connec-
tion pieces or female connections (see system dia-
gram on page 15).
!Please note
Drilling swarf can cause faults in the DHW
heat pump.
Never allow drilling swarf to fall into the
DHW heat pump air intake aperture or air
discharge aperture.
2. Secure the connections with self-tapping screws or
blind rivets. Use shrink tape to make the connec-
tions airtight.
Connecting the condensate drain
When heating DHW, condensate forms on the inside of
the heat pump module. This condensate needs to be
routed via the condensate drain to a sewer.
1. Secure the condensate drain hose to the conden-
sate drain connector with a hose clip.
!Please note
Mechanical stress will damage the conden-
sate connection and may cause leaks.
Never twist the condensate drain connector
on the appliance.
2. Route the condensate hose as a U-bend and con-
nect with a constant fall and a pipe vent to the pub-
lic sewage system or a neutralising system. If nec-
essary, connect to an on-site trap. Ensure that the
trap is connected securely.
Note
Connecting the condensate drain to rainwater
downpipes is not permissible.
3. Check that the condensate can drain freely. Flush
the condensate drain if necessary.
Installation sequence
Conversion to outdoor air mode (cont.)
6136003
Installation

18
4. Should the condensate drain run partially through
unheated rooms, provide thermal insulation or a
ribbon heater around the condensate drain on site.
!Please note
Freezing condensate in the heat pump leads
to appliance damage.
If required, fit the condensate drain with ther-
mal insulation or a ribbon heater on site.
Condensate drain via trap
Ø 20
≥ 60
Fig. 14
Condensate drain via water seal
Ø 20
≥ 60
Fig. 15
Connections on the DHW side
The DHW heat pump is designed to be connected per-
manently to the water supply.
For connecting the DHW side, observe DIN 1988,
DIN 4753 and EN 806.
Furthermore observe the following:
■Connect all pipework with detachable fittings.
■Equip the DHW circulation pipe with a DHW circula-
tion pump, check valve and time switch. Gravity
operation is possible only to a limited extent.
Installation sequence
Connecting the condensate drain (cont.)
6136003
Installation

19
A
B
C
D
S
M
E
F
G H K L M G
N
G M O P G RN
T
Fig. 16
ADHW
BDHW circulation pipe
If no DHW circulation is being connected, seal the
relevant connection.
CDHW circulation pump
DSpring-loaded check valve
EVisible discharge pipe outlet point
FSafety valve
GShut-off valve
HFlow regulating valve
KPressure gauge connection
LNon-return valve
MDrain valve
NCold water
ODrinking water filter
PPressure reducer
RNon-return valve/pipe separator
SExpansion vessel, suitable for potable water (not
CH)
TAutomatic thermostatic mixing valve (on site, for
DHW temperatures > 60 °C)
The safety assembly to DIN 1988 is available as an
accessory. The safety assembly contains the following
components:
■Shut-off valve
■Diaphragm safety valve
■Non-return valve and test connector
■Pressure gauge connector
Information on drinking water filter
According to DIN 1988-2, a drinking water filter must
be installed in systems with metal pipework. We also
recommend the installation of a drinking water filter
when using plastic pipes to DIN 1988, to prevent con-
taminants entering the DHW system.
Information on the automatic thermostatic mixing
valve
The DHW heat pump can heat drinking water to above
60 °C. Therefore, an automatic thermostatic mixing
valve must be fitted in the DHW pipe to protect against
scalding.
Information on the safety valve
Install a safety assembly to DIN 1988 (DN 15 (R ¾)/
1 MPa) at the cold water connection.
If no safety assembly to DIN 1988 is installed, equip
the system with a type-tested diaphragm safety valve
as protection against excess pressure.
Installation information:
■Install the safety valve in the cold water line. Ensure
it cannot be shut off from the DHW cylinder.
■There must be no constrictions in the pipework
between the safety valve and the DHW cylinder.
■Never seal off the safety valve discharge pipe.
Ensure that any expelled water is safely and visibly
drained into a drainage system. Position a sign close
to the safety valve discharge pipe, or ideally on the
safety valve itself, with the following inscription: "For
safety reasons, water may be discharged from the
discharge pipe during heating. Never seal off."
■Install the safety valve above the top edge of the
DHW heat pump.
■Install the safety valve so it is free from the risk of
frost and connect it to an outlet pipe with a continu-
ous fall.
Technical requirements:
■Permissible temperature: 3 to 65 °C
■Permissible operating pressure: 1 to 10 bar (0.1 to
1 MPa)
Installation sequence
Connections on the DHW side (cont.)
6136003
Installation

20
Maximum collector area and sizing information
DHW heat pump technical guide
Connecting the solar collectors
Solar collector installation instructions
For connections to the DHW heat pump, see pages 9
and 22.
Note
■The cylinder temperature sensor is fitted at the fac-
tory.
■A high limit safety cut-out (accessories) for stopping
the solar circuit pump must be fitted.
High limit safety cut-out (accessories) installa-
tion instructions
Note
In outdoor air mode, the immersion heater (accesso-
ries) is essential.
Type T0S-ze: External heat generator
For connections to the DHW heat pump, see pages 9
and 22.
Fitting the temperature sensor
!Please note
Damage to the connecting cables and sensor
leads (capillaries) causes malfunctions.
■The connecting cables and sensor leads must
not come into contact with hot components.
When routing and securing connecting cables
and sensor leads, ensure that the maximum
permissible temperatures for these cables/
leads are not exceeded.
■Do not kink the capillary tubes.
Installation sequence
Type T0S-ze: Solar thermal system
6136003
Installation
