ViewCast Niagara 4100 User manual

© 2012 ViewCast Corporation. All rights reserved.
ViewCast, GoStream, VMp, ViewCast logo, SimulStream, Niagara, SchedulStream, Niagara logo,
Osprey, and Niagara SCX are trademarks or registered trademarks of ViewCast Corporation or its
subsidiaries.
Microsoft, Windows XP, Windows, and Windows Media are trademarks or registered trademarks of
Microsoft Corporation.
QuickTime, iPhone, and iPod, are trademarks or registered trademarks of Apple Inc.
Adobe and Flash are trademarks or registered trademarks of Adobe Systems Inc.
Disclaimer
The information in this publication remains the property of ViewCast Corporation. Users may not use, reproduce, or disclose this information
without the implied consent and written approval of the company.
ViewCast Corporation makes no representations or warranties with respect to the contents or use of this manual and specifically disclaims any
express or implied warranties of merchantability or fitness for any particular purpose. Further, ViewCast Corporation reserves the right to
revise this publication to make enhancements in the products described in this manual, at any time, without obligation to notify any person or
entity of such revisions or changes. In no event will ViewCast Corporation be liable for direct, indirect, special, incidental, or consequential
damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
ViewCast Corporation is not responsible for any third-party license fees that may occur with the use of our products by an end user including
but not limited to creating or distributing content. The user is responsible for any fees the Multimedia Patent Trust may apply for creating and
distributing MPEG content.
Warranties
For complete warranty details, refer to the specific warranty included with each product. General warranty information includes the following:
Limited Warranty: ViewCast warrants its hardware products against defects in material and workmanship under normal use for the period of
one year (12 months) from date of sale. Where specific warranties exist that provide more substantial coverage, notwithstanding the warranty
provisions herein, such product warranties control and preempt or supersede the warranty provisions herein.
Reseller Pass Through of Standard Limited Warranties: Resellers pass the ViewCast standard limited warranties for the products through to
the customer without modification. Any modification of a product voids the ViewCast warranties or any other existing or available warranty.
Corporate Contact Information
ViewCast collaborates and partners with various clients to integrate products into their individual environments.
Niagara Technical Support: Phone: [phone], Fax: [phone] or submit the technical support online request from the ViewCast
website.
ViewCast USA Support: Monday through Friday: 9 a.m. –5 p.m. Central Time. Typical response time is within one business day for customers
without a Priority Support Agreement.
ViewCast Corporation 3701 West Plano Parkway, Suite 300, Plano, TX 75075-7840 USA
Toll Free (U.S. only): 800.250.6622 website: www.viewcast.com

Niagara 4100 User Guide
ViewCast iii
Contents
Before You Begin ......................................................................................................... 1
Product description.............................................................................................................1
Audience .............................................................................................................................1
Conventions for this guide.................................................................................................. 2
Rack mount safety instructions .......................................................................................... 3
FCC notice ...........................................................................................................................4
Environmental notices........................................................................................................ 5
Installing additional software .............................................................................................6
Connecting to the Internet .................................................................................................6
Warnings............................................................................................................................. 7
Overview....................................................................................................................... 9
Media system functions...................................................................................................... 9
Install overview................................................................................................................. 10
Prerequisites .....................................................................................................................10
Package contents ..............................................................................................................10
System requirements........................................................................................................11
Specifications..............................................................................................................11
Niagara 4100 front panel diagram....................................................................................12
Niagara 4100 back panel diagram ....................................................................................13
Connecting the Niagara 4100 ........................................................................................... 14
Niagara 4100 system menu .............................................................................................. 15
Niagara 4100 home page..................................................................................................16
Menu bar commands .................................................................................................16
Niagara 4100 browser windows flow ...............................................................................18
Easy Setup...................................................................................................................19
Web interface ...................................................................................................................20
Easy first time set up.........................................................................................................21
Connecting to an electrical power source.................................................................. 21
Performing the initial startup..................................................................................... 22
Connecting to an IP network......................................................................................23
Changing the network settings...................................................................................23

Contents
iv ViewCast
Basic Operations.........................................................................................................27
Starting up.........................................................................................................................27
Shutting down................................................................................................................... 28
Starting an encoder...........................................................................................................29
Checking CPU usage.......................................................................................................... 31
Stopping an encoder......................................................................................................... 32
Connecting an external storage device ............................................................................ 33
Exporting captured video files ..........................................................................................33
Web Interface...............................................................................................................35
Logging in..........................................................................................................................35
Registering your product ..................................................................................................37
Viewing all encoders .........................................................................................................40
Creating an encoder..........................................................................................................41
Starting an encoder...........................................................................................................42
Stopping an encoder......................................................................................................... 44
Advanced Operations .................................................................................................47
Editing an Adaptive Apple HTTP encoder .........................................................................47
Video tab ....................................................................................................................49
Adaptive encoder video stream table........................................................................51
Audio tab ....................................................................................................................53
Output tab..................................................................................................................54
Editing an Adaptive Adobe Flash encoder ........................................................................56
Video tab ....................................................................................................................57
Adaptive encoder video stream table........................................................................60
Audio tab ....................................................................................................................62
Output tab..................................................................................................................63
Editing an Adaptive Smooth Streaming encoder..............................................................65
Video tab ....................................................................................................................66
Adaptive encoder video stream table........................................................................68
Audio tab ....................................................................................................................70
Output tab..................................................................................................................71
Editing an Adobe Flash H.264 encoder.............................................................................73
Video tab ....................................................................................................................74
Audio tab ....................................................................................................................76
Output tab..................................................................................................................77
H.264 Presets tab .......................................................................................................79
Editing an MPEG-4 encoder..............................................................................................80
Video tab ....................................................................................................................81

Niagara 4100 User Guide
ViewCast v
Audio tab ....................................................................................................................85
Output tab..................................................................................................................86
H.264 Presets tab .......................................................................................................88
MPEG4 Presets tab..................................................................................................... 89
MPEG2 Presets tab..................................................................................................... 90
Editing a Windows Media encoder................................................................................... 91
Video tab ....................................................................................................................92
Audio tab ....................................................................................................................94
Output tab..................................................................................................................95
DRM tab......................................................................................................................98
TS Container................................................................................................................99
Streaming to a TS container..............................................................................................99
Streaming........................................................................................................................102
Output tab................................................................................................................102
Encoder Groups ........................................................................................................105
Viewing encoder groups .................................................................................................105
Creating encoder groups ................................................................................................106
Starting an encoder group ..............................................................................................107
Stopping an encoder group ............................................................................................107
Editing encoder groups...................................................................................................108
Additional Settings and Features.............................................................................109
Configuring the Preset ABC buttons ...............................................................................109
Using Preset ABC buttons to start an encoder group.....................................................111
Viewing all encoders .......................................................................................................112
Editing preset encoders ..................................................................................................112
Configuring machine properties .....................................................................................113
Changing the computer name.................................................................................. 114
Changing the login password from the factory default ........................................... 115
Restoring the login password to the factory default ...............................................115
Configuring alerts............................................................................................................ 116
Configuring network properties .....................................................................................117
Configuring network cards ....................................................................................... 117
Configuring the IP address .......................................................................................118
Configuring advanced network settings...................................................................118
IP Route table..................................................................................................................120
System configuration settings ........................................................................................121
Setting current system configuration.......................................................................122
Configuring email/SMTP settings.............................................................................123

Contents
vi ViewCast
Configuring idle screen information.........................................................................124
Configuring default directory setting .......................................................................125
Setting CPU thresholds............................................................................................. 126
Restoring Niagara 4100 factory defaults..................................................................126
Viewing the activity log................................................................................................... 128
Viewing alerts .................................................................................................................129
Connecting an external storage device .......................................................................... 130
Using the Niagara SCX web interface .............................................................................130
SNMP..........................................................................................................................131
External SNMP Manager ..........................................................................................131
SNMP UDP Ports Used by SNMP Manager and SNMP Agents .......................................132
UDP Port for SNMP Requests...................................................................................132
UDP Port for SNMP Traps.........................................................................................132
Install ViewCast SNMP Agent Service.............................................................................133
Installing for the first time........................................................................................133
Installing new version of ViewCast SNMP Agent Service.........................................136
Install and Configure Supero Doctor III Agent Service.................................................... 138
Configure Supero Doctor III SNMP Agent Service...........................................................139
Disable health monitoring for devices not in use ....................................................139
Enabling health monitoring for devices not in use ..................................................140
Configure ViewCast SNMP Agent Service.......................................................................141
Configuring community names ................................................................................141
Configuring permitted SNMP managers ..................................................................142
Configuring trap destinations................................................................................... 144
Configuring SNMP Agent contact and location (optional) .......................................146
Use UDP Port Other Than 161 for SNMP Requests ........................................................147
ViewCast SNMP Agent Logging.......................................................................................148
Disable IIS Logging for ViewCast Encoders Web Service ................................................148
ViewCast SNMP Agent MIB Files.....................................................................................150
Retrieving IP and MAC Addresses of the Encoder System ............................................. 150
SNMP Examples ..............................................................................................................150
Query of system information (SNMP GET Example) ................................................ 150
Start/stop an encoder through SNMP......................................................................151
Start/stop all encoders per group through SNMP ...................................................151
Start/stop all encoders in the system through SNMP.............................................. 151
Start SNMP trap listener...........................................................................................152
Appendix A: DRM for Windows Media.....................................................................153
Importing a DRM profile .................................................................................................154

Niagara 4100 User Guide
ViewCast vii
Appendix B: H.264 Advanced Settings....................................................................159
H.264 Presets ..................................................................................................................159
Settings ...........................................................................................................................160
MPEG-4 Presets ..............................................................................................................162
Settings ...........................................................................................................................163
MPEG-2 Presets ..............................................................................................................165
Settings ...........................................................................................................................166
Appendix C: Mapped Network Drive Setup .............................................................169
Appendix D: System menu .......................................................................................179
Encoder menu.................................................................................................................180
Encoder start ............................................................................................................180
Encoder stop.............................................................................................................180
Encoder status.......................................................................................................... 180
Access Health menu........................................................................................................181
CPU status ................................................................................................................181
Memory available..................................................................................................... 181
Setup system menu ........................................................................................................182
Network link status ..................................................................................................182
Network MAC address..............................................................................................182
View network settings..............................................................................................183
Enable DHCP............................................................................................................. 183
Set static IP addresses ..............................................................................................184
Set gateway address................................................................................................. 185
Set date and time .....................................................................................................186
Set video standard....................................................................................................186
Factory restore .........................................................................................................187
Export files menu............................................................................................................188
Export to USB drive ..................................................................................................188
Shutdown Niagara 4100........................................................................................... 188
Index...........................................................................................................................189

Niagara 4100 User Guide
ViewCast 1
Before You Begin
Thank you for purchasing the ViewCast Niagara 4100 streaming media system. This user guide provides
step-by-step instructions for installing and using your new streaming media system. For the latest
ViewCast product information and news, visit our website at www.viewcast.com.
Product description
The Niagara 4100 is designed with a combination of simplicity, portability and power to quickly and
easily stream your high-definition (HD) content to broadband and mobile networks including Microsoft®
Live IIS Smooth Streaming, live Adaptive streaming to Adobe® Flash Media Server and Apple® (iPhones®
and iPads®), Adobe Flash® H.264, MPEG-4, H.263, H.264, and Microsoft Windows Media® (Silverlight®
compatible) SD and HD, as well as container support for 3GPP and 3GPP2. With the ability to ingest HD
video, the Niagara 4100 is ideal for live sports, live newsgathering, webcasting or any streaming
application where you need rock-solid HD performance on the go.
This rugged, portable streaming system can ingest standard- or high-definition video sources through its
SDI input, and accommodates a variety of audio input formats, including embedded SDI, AES/EBU, and
balanced or unbalanced stereo.
Figure 1. ViewCast Niagara 4100
Audience
The audience for this publication includes anyone who uses or administers the Niagara 4100. They
should have a basic technical understanding of streaming media. This user guide provides information
on the Niagara 4100 only.

Before You Begin
2 ViewCast
Conventions for this guide
This guide uses the document conventions specified below to help you identify different types of
information.
Convention
Description
Example
Bold text
Characters to enter when
referenced in a procedure. The
name of fields or keys to press.
Enter DTMF as the group type.
Press Enter to save all your
changes.
Note:
Provides supplemental
information.
Note: The prompt may not
display if …
IMPORTANT!
Provides important data that
affects how the system or
software responds.
IMPORTANT! You must install
Niagara SCX prior to
configuring SCX options…
WARNING!
Provides information to ensure
you avoid potential injury,
death, or permanent system
damage.
WARNING! Do not touch
exposed wires.
CAUTION!
Provides information to help
avoid possible damage to
hardware or a system crash
(without data loss).
CAUTION! Use case sensitive
commands to keep from
destroying…

Niagara 4100 User Guide
ViewCast 3
Rack mount safety instructions
Operating Temperature
The operating ambient temperature of a rack environment may
be greater than room ambient if installed in a closed or multi-unit
rack assembly. Therefore, you should install the equipment in an
environment compatible with the maximum ambient
temperature of 40° C.
Reduced Air Flow
You must not compromise the airflow required for safe
equipment operation when you install the equipment in a rack.
Mechanical Loading
Mounting of the equipment in the rack should be such that you
do not cause a hazard due to uneven mechanical loading.
Circuit Overloading
Consider the connection of the equipment to the supply circuit
and the effect that the overloading of the circuits might have on
current protection and supply wiring. You must also consider and
use the equipment nameplate ratings when you address this
concern.
Reliable Grounding
You must maintain reliable earth grounding of rack-mounted
equipment. Pay particular attention to supply connections other
than direct connections to the branch circuit (such as using power
strips).

Before You Begin
4 ViewCast
FCC notice
WARNING! You must connect this device and peripherals using shielded cables to comply with FCC
radio emission limits.
WARNING! Modifications to this device not approved by ViewCast Corporation could void the FCC-
granted authority for you to operate the device.
WARNING! The Niagara 4100 complies with the limits for a Class A digital device pursuant to Part 15
of the FCC Rules. These limits provide reasonable protection against harmful interference when you
operate the equipment in a commercial environment. This equipment generates, uses, and may
radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area will likely cause harmful interference. In this case you must correct the interference
at your own expense.
To CATV Installer: Pay special attention to Section 820-40 of the NEC that provides guidelines for
proper grounding. It particularly specifies that you must connect the cable ground to the grounding
system of the building as close to the point of cable entry as practical.
WARNING! Equipment installation must comply with local and national electrical codes.

Niagara 4100 User Guide
ViewCast 5
Environmental notices
Product Disposal
Information:
Dispose of this product in accordance with local and
national disposal regulations (if any) including those
regulations governing the recovery and recycling of Waste
Electrical and Electronic Equipment (WEEE).
RoHS Compliant:
ViewCast Corporation commits to compliance with the
European directive on the Restriction of the Use of Certain
Hazardous Substances in Electrical and Electronic
Equipment, Directive 2002/95/EC, the RoHS directive.
This product supplied to the European Union does comply
with the RoHS directive. ViewCast certifies that this
equipment shipped to the European Union conforms to the
2002/95/EC directive.
For current RoHS statement, see www.viewcast.com.
Underwriters Laboratories
Inc. Statement
Underwriters Laboratories Inc. has not tested the
performance or reliability of the security or signaling
aspects of this product. UL only tested for fire, shock, and
casualty hazards as outlined in UL’s Standard for Safety UL
60950-1. UL Certification does not cover the performance
or reliability of the security or signaling aspects of this
product.
UL does not represent, warranty, or certify the
performance of reliability of any security or signaling
related functions of this product.

Before You Begin
6 ViewCast
Installing additional software
The Niagara systems run an embedded version of the Microsoft Windows 7 operating system (OS),
which is a sub-set of the normal retail version. The Microsoft License agreement limits the use of the
system to what the machine is designed to do.
The Microsoft Update process is turned off by default to prevent interruptions during live streaming
events. It is also not advised to use a Windows 7 installation CD to add features to the system or the
appliance may fail.
You may load additional software on the appliance; however, ViewCast does not support this additional
software. You also need to ensure the primary drive is not full or the appliance will fail. In the event of a
problem, you may need to perform a Factory Restore, which returns the appliance to the original
software load. You may save the current encoder profiles and reload them when the Factory Restore is
complete.
You can perform a Factory Restore at any time. This process returns the appliance to the software load
that came with the appliance. Perform a Factory Restore if the appliance becomes unstable due to
installed applications, viruses, etc. Please refer to the user guide for instructions.
ViewCast Support can provide assistance should the system fail to start. In most cases, you can restore a
system to operation without returning it to ViewCast. There is a fee in the event a user returns a system
due to applications the user installed or if the appliance failed because the primary partition (drive C) is
full.
Connecting to the Internet
Never connect a Niagara system directly to the Internet. ViewCast recommends taking precautions
against unwanted access such as installing Niagara systems behind a router or firewall. The speed of the
router or switch should match or exceed the speed of the system’s network card. See your network
administrator for recommendations.

Niagara 4100 User Guide
ViewCast 7
Warnings
Only trained and qualified personnel should install, replace, or service this equipment.
Do not attempt to open the case of the system. If you do, you incur a high risk of electrical shock that
may cause damage to the system or personal physical injury or death to you and/or others. No user-
serviceable parts exist inside the system. If you open the system case or make unauthorized changes to
the case, you void the warranty.
Install the system away from any heat sources. This remains vital to the safety of the product users. Do
not install the system near any heat sources such as:
Radiators
Heat registers
Stoves
Other heat-producing equipment
WARNING! Installing the system near heat sources could result in personal injury or death.
Never insert objects of any kind into the system through any system openings, as the objects may
touch dangerous voltage points, short out parts, and result in a risk of fire or electrical shock.
Do not stack the system atop or below other electronic devices as this can cause heat build-up and
vibration of the system. These conditions can damage the system thereby voiding the limited warranty.
You may stack multiple Niagara 4100 units as these systems accommodate stacking.
Do not install the system in any area where the temperature is less than 5°C or more than 40°C. Transfer
from temperature extremes may cause condensation. Let the system remain unplugged at room
temperature for at least 45 minutes before connecting it.
Use an outlet with surge suppression or ground fault protection when using the system. Unplug the
power cord from the wall outlet, disconnect the network connection, and disconnect the lines between
the system and the video source for added protection:
During a lightning storm
During dangerous weather conditions
When the encoder remains unattended or unused for long periods
Reduce the risk of fire or electric shock. Do not expose the system to any rain or moisture. Exposing the
system to rain or other types of moisture could result in system damages. Do not place any liquids on or
near the system. If you place liquids in any form on or near the system, do so at your own risk, for you
incur a high risk of electrical shock that could occur and cause damage to the system.
WARNING! Exposing the system to rain or other types of moisture could result in physical injury or
death. Any liquids on or near the system may result in electrical shock and personal injury or death.

Before You Begin
8 ViewCast
Refer all servicing to authorized service personnel. You must have authorized personnel only service any
damaged system. Relevant damage may occur with but is not limited to the following:
An unplugged or damaged power supply cord
Spilled liquid on the system
Fallen objects in or on the system
Appliance exposure to rain or other moisture or liquid
Failure to perform as described in the User Guide
A dropped system
ViewCast assumes no liability or responsibility for any damaged system that clients continue using.
Use only attachments, accessories, or equipment specified by the manufacturer with the system. Using
accessories or attachments not recommended by the encoder manufacturer voids the Limited
Warranty.
WARNING! When using 4-pin XLR to cigarette car plug cables, do not disconnect the car battery
adaptor or turn off the car engine before you turn off the player. Doing so may damage the player.
Do not attempt to service the system yourself. If you open or remove covers, you may be exposed to
dangerous voltage. Such action voids the Limited Warranty. Refer all servicing issues to authorized
service personnel only.
The plug-socket combination that serves as the main disconnecting device must be accessible at all
times.
Protect the power cord from anyone walking on it and being strained or pinched particularly at plugs,
electrical receptacles, and the point where the power cord exits the system.
Do not use adapter plugs or remove the grounding prong from the power cable.
Use only the type of power source indicated on the marking label on the back panel of the unit to
operate the system. Unplug the system power cord by gripping the plug and removing it from the power
source. Do not pull the cord to remove the power source from the system.
Do not plug the system into a wall outlet that contains an overload of electrical cords or power
strips/extension cords. This type of overload may result in fire or electrical shock risks.
Always handle the system carefully. Always avoid excessive shock and vibration to the system. Excessive
shock or vibration can damage the system.
WARNING! Excessive shock or vibration to the system may result in electrical shock and personal injury
or death.

Niagara 4100 User Guide
ViewCast 9
Overview
Before you can use your Niagara 4100 streaming media system, you first need to set up and configure it.
This chapter is dedicated to providing you with the details and step-by-step instructions you need to
make your installation as quick and easy as possible.
All you need to get started are the four following requirements:
AC power source (100 - 240 V)
Your audio and video source (such as a camera, video player, or other A/V output device)
A streaming media server or hosting provider
IP connection and/or Internet connection
The Niagara 4100, an easy-to-use streaming device, allows you to:
Connect to a compatible browser on a dynamic host configuration protocol/domain name server
(DHCP/DNS) network.
Configure and connect your audio and video source to the Niagara 4100.
Select your output formats and streaming settings.
Enter your streaming server information.
Start streaming your media.
You can configure and use the Niagara 4100 straight from the box for any streaming activities. Use the
web interface for setting options and controlling your Niagara 4100 from another networked computer,
as well as more advanced options.
WARNING! Read the installation instructions before connecting the system to the power source.
Media system functions
Although it has many features and capabilities, the Niagara 4100 streaming media system performs, in
its most basic functions, as follows:
Takes analog audio and SDI video inputs
Captures the signals
Encodes the signals into digital IP video formats
Delivers the IP audio and video content to a storage device or streams it over an IP network

Overview
10 ViewCast
Install overview
This section addresses the high-level actions you must perform to physically connect and set up your
Niagara 4100 system.
You must complete the following primary tasks to install the Niagara 4100:
Address and comply with all prerequisites.
Connect the Niagara 4100 streaming media system using its power source.
Connect the video source (camera or video recorder) to the system.
Connect the Niagara 4100 to an IP network.
Configure the Niagara 4100 system.
Prerequisites
Before installing and connecting the Niagara 4100, ensure you comply with the following prerequisites:
All packaged items are undamaged and in working order.
Your environment meets all system requirements.
Safety instructions, notices, and warnings detailed in Before You Begin including:
oRack Mount Safety Instructions
oFCC Notice
oEnvironmental Notices
oWarnings
Package contents
Completely unpack all contents from the box and inspect each item for damage. Ensure that you have all
the components listed below:
Appliance
Niagara 4100
Power Cables
One of the following:
oNorth America power cable (110 vac)
oInternational power cable (220 vac)
oUK power cable (220 vac)
AC to DC converter
Guides
Package insert (end-user license agreement, welcome letter,
package content list)
User guide (on CD in PDF format)
Quick Start Guide
Software
1 Niagara 4100 CD
Hardware
Rugged carrying case

Niagara 4100 User Guide
ViewCast 11
If any components are missing or damaged, do not continue with the installation. Contact the ViewCast
reseller from which you purchased your Niagara 4100 streaming media system for assistance in
obtaining any missing parts or for parts replacement.
System requirements
Ensure your computer meets the following system requirements.
Browser Interface
Any Internet Explorer (IE)-based computer, workstation, or laptop that
interfaces to a dynamic host configuration protocol/domain name
server (DHCP/DNS)-compatible network
User Interface
High-speed Internet, dial-up, and mobile device users
Specifications
Intel i7 processor
4 GB RAM or larger
HDD (160 GB or larger)
Osprey 710e HD technology
4.5”H x 8” W x 12” D)
8 lbs (3.6 kg)
90 W power supply

Overview
12 ViewCast
Niagara 4100 front panel diagram
You should familiarize yourself with the front panel controls for the Niagara 4100 (Figure 2). Besides the
basic buttons for power, start/stop, up/down and menu access, there are indicator lights that are
hidden until illuminated.
Figure 2. Niagara 4100 front panel
A
Press this button once to power up the system. When the system is powered up, press
this button once will power it down.
B
Allows exporting files to USB devices and installing updates or firmware.
C
Indicates audio input presence.
D
Allows headphones to be connected to the system for audio monitoring.
E
Controls the audio level on the headphones.
F
Press this button to stop an encoder when it is highlighted on the LCD display.
G
Press this button to start the encoder highlighted on the LCD display.
H
These buttons are used for system menu navigation on the LCD display.
I
Press this button to enter or accept the menu choice highlighted on the LCD display.
This button is used for system menu operations.
J
Press this button to activate the system menu on the LCD display.
K
When the Alarm Light indicator is lit, press this button to view a log of the most recent
alarms recorded.
Press Enter to clear these alarms from the log.
L
Displays menus and system messages.
M
This light indicates when the system detects that a video source is connected to one of its
video inputs.
Note: This light only illuminates when you start an encoder.
N
Indicates that another user is accessing the system across the network from a computer.
O
Indicates that an application alert has occurred.
P
When an encoder profile is assigned to one of these buttons, press the assigned button
and then Stream to start the encoder.
Press the assigned button and then Stop to stop the encoder.
