EP3202r
32" DIGITAL SIGN BOARD
ViewSonic’s new ePoster products make it easy to replace
those old backlit printed signs with new impactful high-
denition digital posters. These sleek new displays feature
built-in memory for storing high impact graphics as well as a
powerful management tool featuring a content scheduler,
duration timer and special effects editor for image transitions.
Retail messaging is easy with ViewSonic’s new ePoster family
of retail displays. Information is disseminated through the
ePoster’s internal network connection or locally via the USB port.
ViewSonic’s new ePoster products are available in various sizes
and models and can be free standing or wall mounted. Great
for announcing special promotions, computer-generated
information or communicating multimedia with photos, audio,
signage, and video.
Impactful High-
Definition Digital Poster
32" Full HD 1366x768 display resolution
450 nits of brightness
with 5,000:1 contrast ratio
Embedded media player
Supports HD photos (JPEG),
music (MPEG1) and text
ePoster Manager Express
Content scheduling and management
software – MS Windows compatible
2GB CF memory
Allows for thousands of images,
hundreds of video clips with music
Easy loading of content through
USB or Network (RJ45) Ethernet
Built in 2Wx2 audio
>
>
>
>
>
>
>

DISPLAY Diagonal 32" (812.8 cm)
Resolution 1366x768 dots
Color Over 16.7M color (depending on video card used)
Brightness 450 cd/m2 (typ)
Contrast Ratio 5000:1 (typ)
Response Time 8ms (typ gray-to-gray)
View Angle Up and down 178º, left and right 178º (typ) @ CR>10
CONNECTIVITY Ethernet RJ45 (10/100M)
Storage 2GB Compact Flash
USB 1.1 (x1)
FILE FORMATS Music LPCM, sampling rate: 32–48KHZ/16–24 bit
MPEG1 Layer 3, sampling rate: 32–48KHZ, bit rate: 32–320Kbps
Photo JPEG baseline 5120x3840, progressive 2048x1536
AUDIO Speakers 2W (x2)
CONTENT Software ePoster Manager Express
MANAGEMENT Operating System MS Windows
POWER Supply 3.2–1.38 A @ 100–240VAC, 50/60Hz
Consumption Max 145W
Save Off < 1W
OPERATING Temperature 32–122º F (0–50º C)
CONDITIONS Humidity 20–90% (non-condensing)
STORAGE Temperature -4–158º F (-20–70º C)
ENVIRONMENT Humidity 10–90% (non-condensing)
DIMENSIONS (WxHxD) Physical 19.2" x 31.5" x 3.4" (490mm x 800mm x 87mm)
WEIGHT Net 62.8 lbs. (28.5 kg)
Gross 66.1 lbs. (30.0 kg)
WALL MOUNT 400mm x 200mm, 350mm x 330mm
REGULATIONS FCC, ICES 003, CE
MTBF 50,000 hrs.
PACKAGE CONTENTS ePoster, power cord, remote control with batteries, key, wall mount
bracket, Quick Start Guide, User Manual and Software on CD
EP3202r 32" DIGITAL SIGN BOARD
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
Microsoft, Windows, and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or
other countries. Specications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright
© 2010 ViewSonic Corporation. All rights reserved. [14950-00B-04/10] EP3202r-1
01 – Stylish Glossy Design
02– Speaker
03– Wall Mount Bracket
04– Security Lock Door
CF Card and USB 1.1
1
2
2
3
46
5 7
8
05– Power Port
06– Ethernet RJ45
07 – Horizontal Format
08 – Vertical Format
