ViewSonic N1630W - 16" LCD TV User manual

N1630w
16" (15.6" VIEWABLE)
WIDESCREEN HDTV
WITH 10,000:1 Dynamic Contrast Ratio
ViewSonic’s high-style, high-performance N1630w 16" (15.6" viewable)
widescreen HDTV/PC monitor is the perfect solution for dual
purpose use in dorms, kids’ rooms, dens, kitchens and other
small rooms. It features 1360x768 resolution, high brightness
and 10,000:1 DYNAMIC CONTRAT RATIO and fast 8ms video
response for crystal-clear, blur-free videos, games and movies.
The high resolution and brightness also make it easy to read
word processing documents, spreadsheets and other business/
student applications. With support for HD SIGNALS UP TO 1080i,
you’ll thoroughly enjoy your digital entertainment. Watch your
favorite movies and TV shows and surf the Internet in amazingly crisp
detail. With multiple inputs and HDMI CONNECTIVITY, the N1630w
is the versatile, high-performance HDTV that fits your lifestyle.
Performance and style
in a small package.
IDEAL FOR SMALL LIVING SPACES
Experience widescreen HDTV
Enjoy a widescreen theater experience and high-definition picture
quality with this display’s widescreen aspect ratio, true HDTV
capability, and wide viewing angles.
ClearPicture™electronics deliver clearer, crisper, sharper images
ClearPicture electronics eliminate noise, increase contrast and
detail and optimize color for rich, vibrant images. High-definition
images look amazing and even standard television images are
unbelievably smooth and sharp.
Vivid graphics, clear text, stunning TV
Ultra-high brightness of 250 nits (typ), dynamic contrast ratio of
10,000:1, and 1360x768 PC resolution provide vibrant video and
crisp data images on the desktop or in the living room.
Expand your options with plug-and-play connectivity
This HDTV provides the ultimate viewing experience with integrated
HDTV tuner and plug-and-play, high-end connectivity for HD set-top
boxes, DVDs, game consoles and camcorders.
OptiSync®technology now features HDMI
Add versatility to your LCD TV with support for
HDMI with high-definition content protection
(HDCP) and analog (VGA) signals, plus
component, S-video, composite,
and TV/cable input.
Built-in stereo speakers
Integrated stereo speakers complete
with multimedia experience.
>
>
>
>
>
>

N1630w
16" (15.6" VIEWABLE) WIDESCREEN LCD HDTV
WITH 10,000:1 DYNAMIC CONTRAST RATIO
LCD Type 16" (15.6" viewable) color TFT active matrix, wide LCD
Display Area 13.5" horizontal x 7.6" vertical; 15.6" diagonal
Optimum Resolution 1366x768
Contrast Ratio 10,000:1 dynamic
Viewing Angles 160º horizontal, 160º vertical
Response Time 8ms
Light Source Long life 50,000 hrs (typ)
Brightness 250 cd/m2(typ)
Aspect Ratio 16:9
Glass Surface Anti-glare, anti-reflective coat
INPUT PC RGB analog (75 ohms, 0.7 Vp-p)
TV TV/cable, composite (RCA), component YPbPr/YCbCr, S-video
Audio 3.5mm mini stereo audio in/out and RCA (left/right) audio in
RGB Frequency Fh: 24~82kHz, Fv: 50~75Hz
Sync H/V separated (TTL)
Digital HDMI (with HDCP and audio support)
Tuner ATSC/NTSC
AUDIO OUTPUT Speakers 2 x 2.5-watt
RCA Left/right
COMPATIBILITY PC 1360x768 (preferred), 1280x1024, 1360x768
Mac®* Power Mac™G3/G4/G5 up to 1440x900
INPUT SIGNAL TV/Video comp. 480i, 480p, 720p, 1080i
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital HDMI
Power 3-pin plug
POWER Voltage AC 100–240V, (universal), 47–63Hz
Consumption 48W (typ)
CONTROLS Basic Power, enter, channel +/-, volume +/-, menu, source
OnView®(PC mode) Auto adjust, contrast, brightness, H position, V position,
fine tune, color temperature, picture mode
(Video Mode) Picture (contrast, brightness, color, tint, sharpness, color
temperature), sound (volume, balance, bass, treble), input
menu (TV, AV, S-video, YCbCr, YPbPr, HDMI, VGA), parental
control (caption, change password, V-chip temporary
disable), setup menu (time out, language, memory recall)
(TV Mode) TV/CATV, auto scan, set channel, channel delete,
label, favorite, fine tune
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITIONS Humidity 10–65% (non-condensing)
DIMENSIONS Physical with stand 14.8" x 11.8" x 4.7" (375mm x 300mm x 120mm)
(W x H x D) Physical without stand 14.8" x 10.0" x 2.6" (375mm x 254mm x 67mm)
WEIGHT Net with stand 6.4 lb. (2.9 kg)
Net without stand 5.9 lb. (2.7 kg)
Gross with stand 9.4 lb. (4.3 kg)
VESA®MOUNT 75mm x 75mm
REGULATIONS UL, FCC, NOM, EN 55013, CB
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please dispose
of in accordance with local, state and federal laws
PACKAGE CONTENTS LCD TV display, power cable(s), remote control with
batteries, Quick Start Guide, User Guide
WARRANTY One-year limited warranty on parts and backlight.
