ViewSonic N1930w-2M User manual

Service Manual
ViewSonic N1930w-2M
Model No. VS12115-2M
19” LCD TV
(N1930w-2M_SM Rev. 1aJun.2008)
ViewSonic®381 Brea Canyon Road, Walnut, California 91789 USA - [phone]

Copyright
Copyright © 2008by ViewSonic Corporation. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of ViewSonic Corporation.
Disclaimer
ViewSonic makes no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranty of merchantability or fitness for any particular purpose. Further,
ViewSonic reserves the right to revise this publication and to make changes from time to time in the contents
hereof without obligation of ViewSonic to notify any person of such revision or changes.
Trademarks
Optiquest is a registered trademark of ViewSonic Corporation.
ViewSonic is a registered trademark of ViewSonic Corporation.
Revision History
Revision SM Editing Date ECR Number Description of Changes Editor
1a 06/26/08Initial Release Sophia Kao
All other trademarks used within this document are the property of their respective owners.
The lamp in this product contains mercury. Please dispose of in accordance with local, state or federal laws.
Product disposal at end of product life
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
i

TABLE OF CONTENTS
1. Precautions and Safety Notices................................................................. 1
3. Front Panel Function Control Description................................................ 8
4. Circuit Description....................................................................................... 25
5.AdjustmentProcedure................................................................................ 29
6. Trouble Shooting Flow Chart................................................................ ..... 55
7.BlockDiagram............................................................................................. 58
8.SchematicDiagrams.................................................................................... 59
9.PCBLayoutDiagrams................................................................................. 72
10.Exploded View And Exploded Parts List..................................................77
11. Recommend Spare Parts List................................................................... 80
2.Specification................................................................................................. 3
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
ii

1. Precautions and Safety Notices
1. Appropriate Operation
(1) Turn off the product before cleaning.
(2) Use only a dry soft cloth when cleaning the LCD panel surface.
(3) Use a soft cloth soaked with mild detergent to clean the display housing.
(4) Disconnect the power plug from AC outlet if the product is not used for a long period of time.
(5) If smoke, abnormal noise, or strange odor is present, immediately switch the LCD display off.
(6) Do not touch the LCD panel surface with sharp or hard objects.
(7) Do not place heavy objects on the LCD display, video cable, or power cord.
(8) Do not use abrasive cleaners, waxes or solvents for your cleaning.
(9) Do not operate the product under the following conditions:
- Extremely hot, cold or humid environment.
- Areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic field.
- Place in direct sunlight.
2. Caution
No modification of any circuit should be attempted. Service work should only be performed after you are
thoroughly familiar with all of the following safety checks and servicing guidelines.
3. Safety Check
Care should be taken while servicing this LCD display. Because of the high voltage used in the inverter
circuit, the voltage is exposed in such areas as the associated transformer circuits.
4. Power Supply Requirements
The external AC power operating range shall be from 90 to 264Vac
5. LCD Module Handling Precautions
5.1. Handling Precautions
(1) Since front polarizer is easily damaged, pay attention not to scratch it.
(2) Be sure to turn off power supply when inserting or disconnecting from input connector.
(3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
(4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
(5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
(6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
(7) Do not open nor modify the Module Assembly.
(8) Do not press the reflector sheet at the back of the module to any directions.
(9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of the CCFL Reflector edge. Instead, press at the far
ends of the CFL Reflector edge softly. Otherwise the TFT Module may be damaged.
(10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
(11) After installation of the TFT Module into an enclosure (LCD monitor housing, for example), do
not twist nor bend the TFT Module even momentary. At designing the enclosure, it should be
taken into consideration that no bending/twisting forces are applied to the TFT Module from
outside. Otherwise the TFT Module may be damaged.
(12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow local
ordinances or regulations for disposal.
(13) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
(14) The LCD module is designed so that the CFL in it is supplied by Limited Current Circuit
(IEC60950 or UL1950). Do not connect the CFL in Hazardous Voltage Circuit.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
1

5.2. Handling and Placing Methods
Correct Methods: Incorrect Methods:
Only touch the metal frame of the LCD panel or the
front cover of the monitor. Do not touch the surface
of the polarizer.
Surface of the LCD panel is pressed by fingers and
that may cause “Mura”
Take out the monitor with cushions Taking out the monitor by grasping the LCD panel.
That may cause “Mura”
Place the monitor on a clean and soft foam pad. Placing the monitor on foreign objects. That could
scratch the surface of the panel or cause “Mura”
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
2

LCD panel of this product shall be provided by “MTD” with a model number of M190MWW1-401.
The following table defines this panel specification. Any changes in panel must be pre-approved by
ViewSonic in written.
Parameter Specification
LCD Type a-Si TFT Active Matrix Wide Color, Transmissive Mode, Normally
Black
LCD Interface 1-Channel LVDS
Resolution (Native) 1440 x 900
Display Area 19” diagonal; 410.4 mm (H) 256.5 mm (V)
Pixel Pitch 0.285 (H) x 0.285 (V) mm
Viewing Angle H = 160, V = 160 with CR≥10 (Typical)
Contrast Ratio 1000:1 (Typical)
Brightness 300 nits (Typical)
Response Time 5 ms, (Typical),
Brightness Uniformity 72% (Min), measured per panel spec.
Chromaticity(CIE1931) White-x:0.313,White-y:0.329 (Standard Mode Only)
Colors 167M (8-bits)
Surface Treatment Hard coating (3H)
Backlight 4 CCFLs (Cold cathode Fluorescent Lamp)
Preset Color Panel Default
Gray Scale 0-255
Rated Life (Backlight) > 50KHrs* (60KHrs Typical)
Front Screen Artifacts
VS Standard:
a.) No Visible Streaking, Sag or Smearing artifacts when driven by
the specified video cards (see 7.1 General Test Equipment) in
the primary mode (VGA & 60 Hz) and after user adjustment
b.) No image drift or lose fine-tune settings due to panel
temperature change.
Panel Acceptance Spec
Refer to the panel acceptance criteria specification.
Note: Intermittent and/or Display Pattern defects which result in
further bright or dark dots will be counted individually against the
above specification.
Note: Also refer to the panel defect acceptance specification.
Panel performance characteristics “ MUST BE” met in all display modes/inputs at standard test
conditions.
1. RF Tuner
RF tuner of this product shall be provided by “Samsung DTVS205CH201A” for NTSC/ATSC. The
following table defines this tuner specification.
Parameter Specification
RF Tuning Range NTSC/ATSC: 55.25 to 803 MHz, 2-69 Channels for Off-Air and
1-125 Channels for CATV
RF Tuner Sensitivity (S/N
Ratio at un-weight) 44 dB (min.)
Channel Bandwidth NTSC/ATSC/Digital Cable: 6 MHz Maximum
CVBS Characteristics:
Video Amplitude Signal
0.8(min.)–1.2(max.) V
Audio Characteristics:
SIF out level
500mV (typ.)
Compatible system TUNER NTSC/ATSC/QAM
Compatible system AV NTSC M
2. Specification
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
3

2. Video
Built-in A/D converter shall provide analog to digital converter for this product.
Input Parameter Specification
CVBS Characteristics:
Video Amplitude Signal
DC Level Sync Pulse
0.7(min.) – 1.1(max.) V
Typical. 0.3 V
S-Video Characteristics:
Video Amplitude Signal
Y : 1.0Vp-p W / Neg. Sync (IN 75 Ω)
C : 0.285Vp-p (IN 75 Ω)
Y, Pb, Pr Characteristics:
Video Amplitude Signal
Y:1.0Vp-p (IN 75 Ω)
Pb:0.7 Vp-p(IN 75 Ω),Pr:0.7 Vp-p (IN 75 Ω)
Video Bandwidth NTSC:6MHzMaximum
HDMI Characteristics Panel Link T.M.D.S HDMI-1.1
RGB Characteristics:
Signal Type
Sync Type
Input Signal Rating
Sync Level:
Frequency Range
Pixel Color
DDC Compliance
EDID Data Table
Analog VGA
TTL, Separate Sync, with 4.7KΩpull-down resistors
1250mV Max without damage to the product, 0-700 mV Full Range
2.5-5.25 V
Horizontal: 30-80K Hz, Vertical: 50-75 Hz
16.7 M
DDC2B Compliant, Rev 1.3
Refer to Appendix
3. Audio
Audio amp of this product shall be provided by “ESMT” with a Model Number of AD5265A.
“MST” MSD2232AL for N1930W2M shall be used as sound processor. In addition, a pair of speakers
shall be integrated within this product. The audio signals of this product shall comply with the
specification listed in the following table.
Parameter Specification
Tuner Input Base band Input
Power Output Max Rating 2.5W at 10 % T.H.D Distortion 2.5W at 10% T.H.D
Distortion
Speaker Impedance main speaker :4 Ωmain speaker :4 Ω
Line In
NTSC: BTSC Mono /
Stereo(standard)
PAL: FM Mono / Stereo(standard)
500 mV rms (Typ)
1.6 V rms (Max)
Impedance: 600 ohms
Line Out earphone jack 500 mV rms
50 mW@16Ω
Flatness of Amplitude
Response +/- 3 db (at 1KHz @1W) +/- 3 db (at 1KHz @1W)
Total Harmonic Distortion
(Po=0.1 to 1 W, f=1KHz) <2% <2%
Signal to Noise: 12 dB (100Hz to 1KHz)
8 dB (1kHz to 10kHz) 35 dB (100Hz to 10 kHz)
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
4

4. Electrical
The following table defines the electrical specification of this product.
ELECTRICAL SPECIFICATION
1 Power Input Voltage Range 100-240VAC +/- 10% Wide Range
2 Input Frequency Range 47-63 Hz
3 Power Supply Inrush Max in < 50A(with fully loaded power supply) at 230Vac Shall not
result in permanent failure of power supply (including blown fuse)
4 Power Consumption: 40 W (Normal), 45W (Max) // Stand by: < 1 W
5 Interference with RF and Video
There shall be no visible interference between power supply, RF and
video signals.This applies to all available RF channels and video
modes.
6 Electromagnetic Compatibility This product shall adhere to the compatibility and immunity
specifications in FCC.
7
Power Supply Transient
Immunity
(Supply Transients and Outage)
Able to withstand an ANSI / IEEE C62.41 – 1980 2000V ring wave
with no damage.
8 Surge Immunity Test Able to withstand 1.25X nominal Line Voltage for one cycle with no
damage.
Picture Mode Standard, Dynamic, Soft ,Personal
Contrast 0~75~100
Brightness 0~50~100
Sharpness 0~50~100
Tint -50~0~+50
Color 0~84~100
Color Mode Cool, Normal, Warm
Zoom Mode Full, Movie Scale, Zoom In,4:3
NR Standard, Strong, Weak, Auto, Off
Sound Mode Standard, Music, Movie, Sports, Personal
Treble/Bass Bass, Treble, Balance
Prefer Language(ATSC) English, French, Spanish
Surround Sound On, Off
ADUIO
Audio Only On, Off
Sleep Timer OFF, 5,10,15,30,45,60,90,120,180,240 Min
Time Zone Pacific, Alaska, Eastern, Central, Mountain,
Hawaii
DST On, Off
Time-Format 12/24-hour
Auto Sync On, Off
TIME
Clock Year, Month, Day, Hour, Min, OK, Cancel
Menu Language English, French, Spanish
Transparency 0%,25%,50%,75%,100%
OSD Time Out 5,15,30,45,60 sec.
Closed Caption CC off, CC on, CC on mute
Basic Selection off, CC 1~4 Text 1~4
Advanced Selection(ATSC) off, Service 1~6
Option, Font style, Front size, Front edge style
Front edge color, FG color, BG color, F G
Opacity
Option(ATSC)
GG Opacity
DCR On, Off
OPTION
Restore Default Yes, No
TV Source Air, CATV
CHANNEL Auto Scan Scan all channels, Digital channel only, Analog
channel only
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
5

9 Power Supply Missing Cycle
Immunity
Function properly without reset or visible screen artifact when 1/3
cycle of AC Power is randomly missing.
10 Power Supply Acoustics
The Power Supply shall not produce audible noise that would be
detectable by the user (Excluding Power Supply Fan).
“Audible” shall be defined in accordance with ISO 7779 (DIN
EN27779:1991).
Power Switch noise shall be Excluded.
11 Efficiency >= 80% @ full load, nominal line
12 Leakage Current <0.5mA @ 240VAC
13 Power Saving(DPMS) N/A
14 Recovery Time < 3 sec.
15 Power Factor Correction Compliant with EN61000-3-2
5. Remote Control Unit (RCU)
An IR remote control unit shall accompany this product along with battery. In addition, this remote
control unit shall have an operational distance of 5 meters and an operational angle of 15 degrees for
both horizontal and vertical. Besides the key-code and protocol has fully conformed to VS standard.
Parameter Specification
Type IR; Made by Sighter Electronics Co., Ltd.
Range Off axis ±15°≥5M
On axis: ≥7M
Life Testing
(Buttons)
100,000 cycle operations at a rate of 20~30 cycle / minute without load (with
battery)
Color
Painting Color - PANTONE 427C (Black for front & back cover)
Power Key - PANTONE 032C (RED)
Key Pads – PANTONE 10C & PANTONE 7C(Cool Gray)
Texts Printed on Front Cover and Key Pads - PANTONE 427C
Protocol VS key-code & protocol.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
6

6. Mechanical
The following table defines the mechanical specifications of this product for both chassis and cabinet.
Parameter Specification
Dimension
W/O stand
443.0 x 375.9 x 213 mm
443.0 x 322.3 x 74.6 mm
Net Weight 4.85kg
Gross Weight 6.46kg
Net weight *without* stand 4.43kg
Chassis Plastic Material ABS (ABS HB / PC)
External Plastic Chassis
Components
Plastic Chassis, Cover, Stand (Metal + Plastic),Lens and Button
Exterior Chassis
Color/Texture/Details
Refer to – Product ID Guide
Chassis Color Drift Due to UV-Light The color drift due to UL-Light shall be less than 10 “Delta E” in the
1976 CIE L*a*b color space. Testing shall be performed according
to the requirements of ASTM Test Method D4459-93.
Molded Plastic Workmanship shall be inspected according to ViewSonic Molded
Plastic Parts Specification, VSCMPPSPEC001V1.2.
Screen Printed Parts, Bird Logo
Recess
Artwork shall be provided and confirmed by ViewSonic.
Rear Label A label identifying the product name, model/serial number and FCC
ID/Logo shall be placed into the rear label recess located on the rear
panel of the chassis.
Wall Mount 100 mm x 100mm VESA high hole (n=4), M4 X 10 mm, pitch
=0.7mm screw mounting kit not included.
Sample Sample of textured color chips, plastic material specification, and
Material Safety Data Sheets shall be submitted to ViewSonic prior to
Mass Production Release.
In addition, all exterior surfaces shall have uniform texture/color. The maximum acceptable gap between
the buckets to bezel plastic pieces shall be within 1mm.The maximum acceptable gap between LCD
panel and bezel shall be within 1mm.
7. Environmental
The following table defines the operational/storage conditions of the product.
Operating Temperature 0°C to +40°C
Humidity 10% ~ 65% non-condensing
Altitude 0 meter to +3000 meters above sea level
Storage Temperature -20°C to +60°C
Humidity 0 ~ 90% non-condensing
Altitude 0 meter to 12,000 meters above sea level
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
7

3. Front Panel Function Control Description
Front View of the Product
Item Description
1Power ON/OFF button Turn the power on from standby mode or turn the power off to
return to the standby mode.
2Power LED Indicator Lights up in blue when the TV is turned on. Lights up in orange
when the TV is in standby mode.
3Remote Control Receiver Receives IR signals from the remote control.
4Volume Down Decrease sound volume or adjust a highlighted control while in
OSD menu.
5Volume Up Increase sound volume or adjust a highlighted control while in
OSD menu.
6MENU Turn OSD menu ON/OFF.
7CH Down Channel down when source is TV, or select a control while in
OSD menu.
8CH Up Channel up when source is TV, or select a control while in OSD
menu.
9INPUT Select input source.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
8

Rear View of the Product
Item Description
1 Power (AC input) Plug-in the supplied AC Power cord and connect to the AC input
power source.
2HDMI Input Terminal Connect this port to the HDMI/HDMI-DVI jack of the compatible
equipment.
3VGA signal input Connect a 15-pin D-sub RGB cable to the RGB output of your
computer and the other end to the RGB input on the rear of the LCD
TV.
4YPbPr signal input Connect this jack to the YPbPr output of A/V device.
5Composite Video input Connect this jack to the composite video output connectors on your
A/V equipment.
6S-Video input Connect the S-Video cable from the compatible device to this
connector on the rear panel of the LCD TV.
7AV/ S-Video/ YPbPr/ DVI
Audio input (left/ right)
Connect the Audio in cable for AV/ S-Video/ YPbPr/ HDMI-DVI from
this jack to the corresponding connectors on your A/V device.
8PC Audio input Connect the RGB Audio Out on your computer to the RGB Audio
on the rear of the LCD TV.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
9

ENGLISH
Item Description
9 Headphone Jack Connect to your headphones. By connecting the headphones, you can
listen to the sound from the TV on headphones.
＊If you connect the headphones, the TV speakers will be muted.
10 AV/ S-Video signal
Audio input (left/ right)
Connect the Audio in cable for AV/ S-Video from this jack to the
corresponding connectors on your A/V device.
11 YPbPr/ DVI signal
Audio input (left/ right)
Connect the Audio in cable for YPbPr/ HDMI-DVI from this jack to
the corresponding connectors on your A/V device.
12 TV Input Jack Connect this jack to your Cable or VHF/UHF antenna.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
10

Remote Control
ENGLISH
Button Description
2 ENTER Press to conrm the selection in the OSD menu, or
to enter the OSD menu you select.
Press ENTER after you input channel numbers
will change channels immediately.
3 TV Press to direct to TV source when in any other
source.
4 - VOL + Press to adjust the volume.
5 GUIDE Press to display the Electronic Program Guide
(EPG). It contains the program information for the
channel you’re watching.
＊The picture here shows an example of the GUIDE
screen in a DTV source.
6 LIST Press this button to show a small window showing
program list, you can scroll through the list to select
the channel you want directly without using the ▲
/▼ button.
7 0~9, -
number
buttons
Press 0~9and “-” to select a channel. After you
input the channel numbers, press ENTER button
to direct to the channel immediately, or wait for 3
seconds to change automatically.
8 POWER Press this button to turn the power on from standby
mode. Press it again to return to the standby mode.
9▲▼◄►
buttons
Press these buttons to navigate the OSD menus. ▲/▼
is for function select, and ◄/► is for function
adjustment.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
11

N4750p
ENGLISH
ENGLISH
Button Description
10 MENU Press to turn the OSD (On-Screen Display) menu
on.
11 ▼ CH ▲ Press to change the channels up or down.
12 ZOOM Press this button repeatedly to select the screen size.
You can select from Full, 4:3,Movie Scale, and
Zoom In.
＊The digital TV HD signal is available in Full
and 4:3.
13 FAV Press this button to show Favorite List and select your
favorite channels that have already been stored.
＊To preset favorite channels, use the Favorite item
in the TV menu.(see page 27)
14 MUTE Press to turn off the sound. To restore the sound,
press this button again, or press the VOL+ button.
15 INFO Press this button to display the current state of the
LCD TV.
16 SLEEP Press repeatedly to set the off timer. The function
is used to automatically shut off the LCD TV after
a preset period of time passed. There are several
times for choice – Off, 5 Min, 10 Min, 15 Min, 30
Min, 45 Min, 60 Min, 90 Min, 120 Min, 180 Min,
240 Min.
17 MTS Press this button to choose the available sound
output that is preset by TV broadcasting station.
(EX: Mono, Stereo, SAP)
18 C.C Press to select the Closed Caption menu in the TV
mode.
19 RECALL Press to return to previous channel.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
12

ENGLISH
Turning the TV On and Off
Press the POWER button on the remote control.
You can also use the Power button on the front of the
panel.
Changing Channels
1. Using Channel Buttons
Press ▼CH▲ button to change channels, and the TV
changes channels in sequence. You will see all channels
that have been memorized. Channels erased or not
memorized will not be shown.
2. Using Number Buttons
(1) ATV
The “-” button has no function in ATV mode. Directly
press the number buttons to select channels.
(2) DTV
Use “-” button to select the sub channel in DTV.
Ex: Your desired number is 80-3.
Press 8 → press 0 → press “-” → press 3.
＊Return to the previous channel, press RECALL
button.
Adjusting the Volume
Press VOL +/- to adjust volume.
To turn off the volume, press MUTE.
To restore volume, press MUTE again, or press VOL +/-
directly.
Viewing the Displayed Information
To display the current information of the LCD TV:
Press INFO, and the current state will be displayed on
the screen. (It shows all or some of the information about
Input, Channel, Resolution, Audio Type, etc., depending
on what input source it is in)
＊The picture here shows an example of the INFO screen
in a DTV source.
Operation
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
13

ENGLISH
Storing Channels into Memory
1. Press the MENU button to display the OSD main menu.
2. Press ◄ or ► to select the “CHANNEL” menu.
Press ▲ or ▼ to select “TV Source”, and use ◄ or ►
to select the antenna connection to “Air” or “Cable”.
Air: RF signal programs by “Air”.
Cable: RF signal programs by “Cable”.
3. Press ▲ or ▼ to select “Auto Scan”, then press ► to
enter.
4. Press ▲ or ▼ to select “Scan all channels”, “Digital
channel only”, or “Analog channel only” and press ► to
perform Auto Scan function.
To stop scanning, press MENU at any time.
5. The Auto Scan screen will be shown, and after it is
done, the screen will return to the rst found channel.
Viewing the Menus
1. Press the MENU button to display the OSD main menu.
There are six top menus on the screen: PICTURE,
AUDIO, TIME, OPTION, LOCK, and CHANNEL.
2. Press ◄ or ► to select your desired top menu.
3. Press ENTER or ▼ to enter the menu you select.
4. Use ▲▼ to select the control you want to adjust.
5. When selecting the control with ►, press ► to enter
next level menu or enable the function. (► will only
appear when the control is highlighted)
6. Press ◄► to adjust or select the settings.
7. Press MENU to exit from the OSD menu.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
14

ENGLISH
Selecting the Input Source
To select the TV or other external input sources connected
to the TV.
1. Press the INPUT button on the remote control.
2. Press ▲ or ▼ to select the required input source between
TV, AV, S-Video, YPbPr, HDMI, or PC.
3. To conrm the selection, press ENTER.
Favorite Channel Setting
To set your favorite channel into memory:
1. Press the MENU button to display the OSD main menu.
2. Press ◄ or ► to select the “CHANNEL” menu.
Press ▲ or ▼ to select “Favorite”, then press ► button
to enter “Favorite” setting.
3. Press ▲ or ▼ to select the channel you’d like to be your
favorite channel.
Press ENTER to conrm your selection.
4. To cancel the selection, Press ENTER again on the selected
channel.
5. Press MENU to exit.
＊To view your favorite channels, press FAV button to
show Favorite List and select your favorite channels that
have already been stored.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
15

ENGLISH
Channel Name Setting
To edit a name for the current channel:
1. Press the MENU button to display the OSD main menu.
2. Press ◄ or ► to select the “CHANNEL” menu.
3. Press ▲ or ▼ to select “Channel No.”, then press ◄ or ►
to select the channel you want to edit the name.
4. Press ▲ or ▼ to select “Channel Label”, then press ►
button to enter “Channel Label” setting.
5. Use ▲ or ▼ to choose letters or signs, ◄ or ► to move
forward or backward.
6. After you input the channel name, press MENU or
ENTER to complete the setting.
7. Press MENU to exit.
Adding/Erasing Channel
When the channel is erased, it will not appear on the
screen when you browse the channels with ▼CH▲
button. To see the channel again, you must add the channel
or perform the “Auto Scan” (page 26) function again.
1. Press the MENU button to display the OSD main menu.
2. Press ◄ or ► to select the “TV” menu.
Press ▲ or ▼ to select “Show/Hide”, then press ►
button to enter “Show/Hide” setting.
3. Press ▲ or ▼ to select the channel you want to Show/
Hide, and check or uncheck it with ENTER button.
4. Press MENU to exit.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
16

ENGLISH
Adjusting the Settings
1.
(1) Press the MENU button to display the OSD main menu.
(2) Press ◄ or ► to select your desired top Menu.
(3) Press ▲ or ▼ to select the control of “Contrast”,
“Brightness”, “Sharpness”, “Tint”, “Color”, then press ◄
or ► to adjust the level.
(4) Press MENU to exit.
2.
(1) Press the MENU button to display the OSD main menu.
(2) Press ◄ or ► to select your desired top Menu.
(3) Press ▲ or ▼ to select the control of “Picture Mode”,
“Color Mode”, “Zoom Mode”, “NR” (Noise Restriction),
“Sound Mode”, “MTS”, “Prefer Language” (in DTV mode),
“Surround Sound”, “Audio Only”, “Sleep Timer”, “Time
Zone”, “DST”, “Time Format”, “Auto Sync”, “Clock”,
“Menu Language”, “Transparency”, “OSD Time Out”,
“DCR” (Dynamic Contrast Ratio), then press ◄ or ► to
select your desired option.
(4) Press MENU to exit.
3.
(1) Press the MENU button to display the OSD main menu.
(2) Press ◄ or ► to select your desired top Menu.
(3) Press ▲ or ▼ to select the control with ►, including
“Treble/Bass”, “Closed Caption”, “Restore Default”, then
press ► to perform the function or enter detailed
settings.
ViewSonic Corporation Confidential - DoNot Copy N1930w-2M
17
