A90f+ CRT Monitor
ViewSonic
®
A90f+ UltraBrite CRT for impressive graphics and video.
Built to impress, the ViewSonic 19" (18.0" viewable) A90f+ UltraBrite
CRT produces vibrant, bright, lifelike images in an attractive design.
Choose the brightness level you need with the convenient toggle button.
Toggle to UltraBrite mode for graphics, video, movies and gaming,
where vivid color and ultra-detailed viewing are critical. Toggle to normal
mode for optimum viewing of text intensive applications like word
processing, spreadsheets and e-mail. ViewSonic’s A90f+ offers the
perfect 2-in-1 monitor that’s smart enough for work and play.
MM
MMaa aakk kkee ee ii iitt tt aa aa TT TTVV VV,, ,,
aa
aadd dddd dd aa aa vv vvii iidd ddee eeoo oo
pp
pprr rroo oocc ccee eess ssss ssoo oorr rr
• UltraBrite 3X technology
UltraBrite technonlogy enables optimized viewing
of video and graphics applications. Games, TV and
DVDs come alive with rich, saturated color and vivid
contrast. Precise definition and photo-realistic image
quality boost 3-D video and professional graphics
performance.
•2 brightness modes for work and play
For work, engage normal mode to see text and
spreadsheets with perfect clarity. For play,
engage UltraBrite mode and step into high
brightness entertainment for Internet, gaming,
TV and video applications.
•SuperClear technology
SuperClear screen technology incorporates
enhanced phosphor treatment and optimized
glass filter to deliver vivid colors and image
clarity.
•PerfectFlat®screen
Absolutely flat screen provides realistically
proportioned, precise images with reduced
reflection, image distortion and eye fatigue.
•0.21mm horizontal dot pitch
0.25mm diagonal dot pitch
This ultra-fine dot pitch produces clear, crisp
images with precise picture definition, even at
the highest resolutions.
•1792x1344 maximum resolution
Displays a maximum resolution of 1792x1344;
1280x1024 at 80Hz flicker-free refresh rate for
easy-on-the-eyes viewing.
•Elegant metallic-on-black design
The graceful design compliments both home
and office computing environments.
SuperClear®for Work,
UltraBrite™for Play
(see back for details)

ViewSonic
®
A90f+ CRT Monitor
*Sold separately **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate
names, trademarks stated herein are the property of their respective companies. Copyright © 2003 ViewSonic Corporation. All rights reserved. [10702-02B-03/03_0M]
19.0" (18.0" VIEWABLE) PERFECTFLAT®ULTRABRITE™CRT COLOR MONITOR
CRT Type 19" (18.0" viewable), CRT 90ºdeflection
Dot Pitch 0.21mm horizontal, 0.14mm vertical, 0.25mm diagonal
Phosphor RGB medium/short persistence
Glass Surface Anti-static, anti-glare, Tint: TM ~ 52.6%
Case Color Metallic-on-black
INPUT SIGNAL Video RGB Analog (75 ohms, 0.7Vp-p)
Sync H/V separated (TTL), composite
Frequency fh: 30~86kHz, fv: 50~150Hz
COMPATIBILITY PC IBM compatible from VGA up to 1600x1200
Mac®** Power Mac G3/G4 up to 1024x768
RESOLUTION Maximum 1792x1344 @ 61Hz
1600x1200 @ 68Hz
1280x1024 @ 80Hz
1152x870 @ 94Hz
1024x768 @ 105Hz
800x600 @ 132Hz
CONNECTOR Signal 15-pin mini D-sub (high density)
Power 3-pin plug (IEC320)
POWER Voltage AC100–240V AC, 50–60 (+/-2) Hz\
Consumption 100W (typ) 110W (max)
CONTROLS Basic Power on/off, 1, down, up, 2
OnView®Contrast, brightness, H. size/position, V. size/ position,
pincushion, pinbalance, trapezoid, parallelogram, tilt,
H/V moiréreduction, degauss, color temperature (9300,
6500, 5000, user), OSD function, language, ViewMeter®,
recall, zoom, ViewMatch.
®
VIDEO INPUT Bandwidth 175MHz Pixel Clock (-3 dB nominal)
MISCONVERGENCE 0.25mm (max) at center
0.30mm (max) at corner
DISPLAY AREA Factory Setting 352mm(H) x 264mm(V)
Maximum Scan 360mm(H) x 270mm(V) (dependent on timing signal)
OPERATING Temperature 32°F–104°F (0°C–40°C)
CONDITIONS Humidity 5%–95% (non-condensing)
DIMENSIONS Physical 463.5mm x 491.5mm x 472mm
(W x H x D) 18.2" x 19.4" x 18.6"
WEIGHT Net 48.4 lbs. (22.0 kgs.)
Gross 56.1 lbs. (25.5 kgs.)
REGULATIONS ULcUL, FCC-B, DHHS, ICES-003, ENERGY STAR®,
CB, MPR II
POWER MANAGEMENT Meets ENERGY STAR®and MPR II standards
WARRANTY One-year limited warranty on CRT, parts and labor.
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
AA
AAdd dddd dd
TT
TTVV VV!! !!
•Add the entertainment accessory,
a ViewSonic video processor.*
•Watch high resolution TV
•Play Xbox, PS2, GameCube games in
UltraBrite color
•Experience full-screen DVD/VHS movies in
UltraBrite resolution
•OnView®controls including
ViewMatch®feature
Image adjustments are made via the OnView
menu using simple on-screen controls.
ViewMatch feature allows easy adjustment to
color temperature and intensity for optimal
screen-to-print color matching.
•OSD lock function
When activated, user-controlled OSD lock
function prevents changes to monitor settings,
maintaining an optimized image.
•Anti-static, anti-glare screen
This treatment cuts reflection and glare while
maintaining the highest image quality.
•
•PC and Mac®compatible
•One-year limited warranty
