ViewSonic CD4232T User manual

CD4232T
42" SLIM BEZEL
COMMERCIAL DISPLAY WITH
3M DST TOUCH SCREEN
ViewSonic’s 42" CD4232T Commercial Display features touch
screen control powered by 3M’s MicroTouch™DST Touch
System. The elegant slim bezel design and dynamic touch panel
technology is ideal for use in mall kiosks, corporate directories,
product selectors, hotel lobbies, training rooms and point of
information applications. The high brightness, high contrast ratio
and wide viewing angles clearly communicate your message
regardless of ambient light. The fast 8ms response time delivers
blur-free scrolling text or video. VGA and RS-232 inputs/outputs
allow you to daisy chain multiple displays into your network and
still control each display individually. Other inputs include HDMI,
S-video, component, composite and PC RGB. The CD4232T with
3M touch screen technology sets a new standard for interactive
digital signage displays.
Interactive digital signage.
>Features 3M's MicroTouch™
DST Touch System
>Full HD 1920x1080 panel for
vibrant video and crisp images
>700 nits high brightness and
contrast ratio
>RS-232 daisy-chain capable
>VGA and DVI inputs/outputs for
flexible connectivity and control
>Remote and panel control
lock out
>Installation options include
stand or VESA®wall mount
>Integrated ON/OFF scheduling
Shown with optional stand.

Complete Your Digital Signage Solution
Add a network media player and digital signage software.
Media Players
• NMP-560 (RISC-based)
• NMP-640 (X86-based)
Software
• Friendlyway Composer Software
• Best Wave DisplayIt! Software
• ViewSonic®Siganage Manager Express
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
Programs specications and availability are subject to change without notice. Selection, offers and programs may vary by country;
see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their
respective companies. Copyright © 2011 ViewSonic Corporation. All rights reserved. [15737-00B-06/11] CD4232T-1
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
CD4232T
LCD Type 42" color TFT active matrix, wide LCD
Display Area 36.6" horizontal x 20.6" vertical; 42" diagonal
Optimum Resolution 1920x1080
Contrast Ratio 3500:1 (typ)
Viewing Angles 178º horizontal, 178º vertical
Response Time 8ms
Light Source Long life, 50,000 hrs. (typ)
Brightness 700 cd/m2 (typ)
Aspect Ratio 16:9
Panel Surface Anti-glare, hard coating (3H)
INPUT Video Input HDMI, DVI, component, VGA
Video Output VGA, component, DVI
Control Input/Output RS-232
AUDIO OUTPUT Speakers
INPUT SIGNAL TV/Video Comp. 480i, 480p, 720p, 1080i, 1080p
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital HDMI, DVI
Power 3-pin plug
POWER Voltage AC 100–240V (universal), 50–60Hz
Consumption 250W (max)
CONTROLS Panel Power, Exit, +, –, Menu/Enter
Picture Picture mode, contrast, brightness, color temperature,
temperature adjust, sharpness
VGA Setting Auto adjustment, clock, phase, sharpness,
H. position, V. position
OSD Setting Languages, OSD H. position, OSD V. position, OSD timer
Input VGA, DVI, HDMI, YPbPr, S-video, CVBS (BNC)
Audio Volume, mute
Special Aspect ratio, over scan, power save, image retention,
auto adjustment, monitor ID, reset
Diagnostic Thermal, back light, ambient, 5V detect, 12 detect
OPERATING Temperature (landscape) 32–104ºF (0–40ºC)
CONDITIONS Temperature (portrait) 41–95ºF (5–35ºC)
Humidity 20–80% (non-condensing)
DIMENSIONS Physical with stand (optional) 37.9" x 23.5" x 6.2" (963mm x 598mm x 157mm)
(W x H x D) Physical without stand 37.9" x 21.8" x 4.3" (961mm x 554mm x 109mm)
WEIGHT Net with stand (optional) 56.7 lb. (25.7 kg)
Net without stand 52.0 lb. (23.5 kg)
Gross without stand 62.0 lb. (28.0 kg)
VESA®MOUNT 400mm x 200mm
REGULATIONS UL/FCC-B
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS LCD display, power cable, VGA cable, remote control
with batteries, Quick Start Guide
WARRANTY Three-year limited warranty on parts, labor and backlight
Shown with optional stand.
42" SLIM BEZEL COMMERCIAL
DISPLAY WITH TOUCH SCREEN
NMP-640
NMP-560
