ViewSonic G773 - 17" CRT Display User manual

• 0.26mm dot pitch
This super fine dot pitch produces clear,
crisp images with great picture definition,
even at the highest resolutions.
• 1,280 x 1,024 maximum
resolution
Displays a maximum resolution of 1,280
x 1,024; 1,024 x 768 at 87Hz flicker-free
refresh rate for easy viewing.
1,280 x 1,024 @ 66Hz
1,024 x ,768 @ 87Hz
,800 x ,600 @ 110Hz
• SuperClear™screen
SuperClear screen technology incorporates
an enhanced phosphor treatment and
optimized glass to deliver “power color”
images that are up to 30% brighter than
conventional CRT monitors with up to
10% improved color fidelity. This provides
vivid, realistic color and optimized clarity.†
• Universal Serial Bus
This monitor has four accessory ports
which allow the use of USB compliant
peripherals without having to open your
PC or worry about add-in cards or switch
settings. And you don’t even have to turn
your system off.††
17" (16.0" viewable) Monitor
The ViewSonic G773 offers a new level of performance for the most discriminating business graphics
users. This feature packed monitor provides a flawless display of rich, vivid colors with exceptional
contrast and brightness. Equipped with USB controls and four accessory ports, additional USB
compatible peripherals can easily be connected. Designed to accommodate demanding color
intensive applications, the 17" (16.0" viewable) G773 is ideal for both corporate and SOHO (small
office/home office) desktop publishing, presentation design, website development and web surfing.
Graphics Series
G773 Monitor
ViewSonic®

GRAPHICS
SERIES
17" (16.0" VIEWABLE) COLOR MONITOR WITH SUPERCLEAR
™
MODEL NO. VCDTS21380-1X
CRT Type 17" (16.0" diagonal viewable area)
0.26mm dot pitch, 90˚deflection
Phosphor RGB medium-short persistence
Glass Surface Tint (TM=53.5%) ARAG®screen treatment
INPUT SIGNAL Video RGB analog (0.7Vp-p, 75 ohms)
Sync H/V separate (TTL) composite
Frequency Fh:30-70kHz, Fv:50-180Hz
COMPATIBILITY PC IBM®XT, AT, 386, 486, Pentium®
, PS/2 and compatibles
(from VGA up to 1,280 x 1,024 non-interlaced)
Mac®*Power Mac
™
(from 640 x 480 to 1024 x 768)
CONNECTOR Signal 15-pin mini D-sub,1.8m cable
Power 3-pin plug (IEC320)
POWER Voltage AC 90–132V/198-264VAC (auto switch) 50/60 (+/-3)Hz
Consumption 95W (typ)
USER CONTROLS Basic Power on/off, Key–1, Key–2, down, up
OnView Contrast, brightness, H/V-position, H/V-size, pincushion,
pin-balance, ViewMatch color, trapezoid, tilt, ViewMeter®
,
language select, degauss, parallelogram, moiré, recall
VIDEO INPUT Bandwidth 110MHz (typ)
USB Up/Down Stream 1 connection, 4 connections
MISCONVERGENCE 0.3mm (max) at center
0.4mm (max) at corner
DISPLAY AREA Factory Setting 300mm(H) x 225mm(V) (standard display area)
Maximum Scan 330mm(H) x 240mm(V)
OPERATING Temperature 32˚F to 104˚F (0˚C to 40˚C)
CONDITION Humidity 5% to 95% (non-condensing)
DIMENSIONS Physical 423mm (W) x 426mm (H) x 439mm (D)
(16.7" x 16.8" x 17.3")
WEIGHT Net 18.0Kg (40.8 lbs.)
OTHER DDC1 & DDC2B
REGULATIONS UL, CSA, NORDIC, TUV/GS, DHHS, PTB, FCC-B,
EN55022, MPR-II, ISO9241-3, TCO ’95, CE, DOC Class B
POWER MANAGEMENT Meets Energy Star®
, VESA®DPMS
™
, TCO ’95 and Energy
2000 standards
WARRANTY Three year limited warranty on CRT, parts and labor
48 hour Express Exchange®Service option available
ViewSonic G773
• OnView
®
controls including
ViewMatch
®
All screen adjustments are made via an on-screen
menu using simple controls. ViewMatch allows the
user to adjust color temperature and individual
color intensity for screen-to-print matching.
• Invar shadow mask
A special type of alloy that withstands higher
heat levels, extending the picture tube life while
displaying sharp, bright pictures.
• Fully supports the Windows®95 auto-installation
standard for easy, trouble-free configuration and
set-up.
• TCO ’95 certified
This monitor complies with the world’s strictest
standards of low radiation, safety, ergonomics,
recycling and power management while saving
costs through automatic power saving modes.
• PC and Mac compatible
• Three year limited warranty
381 Brea Canyon Road, Walnut, CA 91789 • Phone [phone] • [phone]
Fax [phone] • Internet: www.viewsonic.com
*Free universal Mac cable adapter available. †Compared to conventional CRTs, results may vary. ††USB is compatible with Windows 98 and also requires USB-equipped computers and
peripheral devices. Copyright © 1998, ViewSonic Corporation. All rights reserved. Corporate names and trademarks stated herein are the property of their respective companies.
Microsoft, Windows, Windows NT and the Windows logo are the registered trademarks of Microsoft Corporation in the United States and other countries. Specifications subject to change without
notice. The EPA only promotes energy efficiency and does not endorse any particular company or product.
VS-10/98-30K-rev 3
