ViewSonic PerfectFlat E90fB-4 User manual

Service Manual
ViewSonic E90fB-4
Model No. VS10794
19” PerfectFlatTM Color Monitor
(E90fB-4_SM Rev. 1a Nov. 2005)
ViewSonic®381 Brea Canyon Road, Walnut, California 91789 USA -[phone]

Copyright
Copyright © 2005 by ViewSonic Corporation. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of ViewSonic Corporation.
Disclaimer
ViewSonic makes no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranty of merchantability or fitness for any particular purpose. Further,
ViewSonic reserves the right to revise this publication and to make changes from time to time in the contents
hereof without obligation of ViewSonic to notify any person of such revision or changes.
Trademarks
Optiquest is a registered trademark of ViewSonic Corporation.
ViewSonic is a registered trademark of ViewSonic Corporation.
All other trademarks used within this document are the property of their respective owners.
Revision History
Revision
SM Editing Date
ECR Number
Description of Changes Editor
1a 11/24/05 Initial Release Sophia Kao
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 i

TABLE OF CONTENTS
1. Precautions and Safety Notices 1
2. Specification 3
3. Front Panel Function Control Description 6
4. Circuit Description 10
5. Adjusting Procedure 13
6. Trouble Shooting Flow Chart 17
7. Recommended Spare Parts List 24
8. Exploded Diagram And Spare Parts List 36
9.BlockDiagram38
10. Schematic Diagrams 46
11. PCB Layout Diagrams 50
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 ii

1. Precautions and Safety Notices
WARNING!
This service information is designed for experience repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service
a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians.
Any attempt to service or repair the product or products dealt within this service information by anyone else
could result in serious injury or death.
1. CAUTION
No modification of any circuit should be attempted. Service work should only be performed after you are thoroughly
familiar with all of the following safety checks and servicing guide lines.
2. SAFETY CHECK
Care should be taken while servicing this CRT display because of the high voltage used in the deflection circuits.
These voltages are exposed in such areas as the associated flyback and yoke circuits.
3. FIRE & SHOCK HAZARD
3-1 Insert an isolation transformer between the CRT display and AC power line before servicing the chassis.
3-2 In servicing pay attention to original lead dress especially in the high voltage circuit. If a short circuit is found,
replace all parts which have been overheated as a result of the short circuit.
3-3 All the protective devices munt be reinstalled per original design.
3-4 Soldering must be inspected for possible cold solder joints, frayed leads, damaged insulation, solder splashes or
sharp solder points. Be certain to remove all foreign material.
4. LEAKAGE CURRENT COLD CHECK
4-1 Unplug the AC cord and connect a jumper between the two prongs on the plug.
4-2 Turn the CRT display power switch “on”.
4-3 Measure the resistance value with an ohmmeter between the jumpered AC plug and each exposed metallic part on
the CRT display such as the metal frame, screwheads, control shafts, etc. When the exposed metallic part has a
return path to the chassis, the reading should be 1.8 megohm minimum.
5. LEAKAGE CURRENT HOT CHECK
5-1 Plug the AC cord directly into the AC outlet. Do not use an isolation transformer during this check.
5-2 Connect a 1500 ohm, 10 watt resistor, paralleled by a 0.15uF capacitor between each exposed metallic part and a
good earth ground (as shown in Fig.1).
5-3 Use an AC voltmeter with 1000 ohm/volt or more sensitivity and measure the AC voltage across the
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 1

combination 1500 ohm resistor and 0.15uF capacitor.
5-4 Move the resistor connection to each exposed metallic part and measure the voltage.
5-5 Reverse the polarity of the AC plug in the AC outlet and repeat the above measurement.
5-6 Voltage measured must not exceed 7.5 volt RMS, from any exposed metallic part to ground A leakage current
tester may be used in the above hot check, in which case any current measured must not exceed 5.0 milliamp. In
the case of a measurement exceeding the 5.0 milliamp value, a rework is required to eliminate the chance of shock
hazard.
Note：High voltage is present when this CRT display is operating. Always discharge the anode of the picture tube to the
display chassis to prevent shock hazard.
AC VOLTMETER
Fig. 1
6. IMPLOSION PROTECTION
Picture tubes are equipped with an integral implosion protection system, but care should be taken to avoid damage and
scratching during installation. Use only Panasonic replacement picture tubes.
7. X-RADIATION
WARNING：The only potential source of X-Radiation is the picture tube. However when the high voltage circuit is
operating properly there is no possibility of X-Radiation problem. The basic precaution which must be exercised is to
keep the high voltage at the following factory-recommended level.
Note It is important to use an accurate periodically calibrated high voltage meter.
7-1 The procedure for adjusting high voltage is shown on page 12.
7-2 If can not be adjust 25.0 KV at immediate service is required to prevent the possibility of premature
component failure.
7-3 To prevent X-Radiation possibility it is essential to use the specified picture tube
There are special components used in this CRT displays which are
important for safety. These parts are identified by the international
symbol
on the schematic diagram and on the replacement parts
list. It is essential that these critical parts should be replaced wit
h
manufacture’s specified parts to prevent X-RADIATION, shock, fire,
or other hazards. Do not modify the original design or this will voi
d
the original parts and labor guarantee.
！
IMPORTANT SAFETY NOTICE
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 2

2. Specification
1. CRT : 46CM(19") 90 Deflection, Shadow mask ,29mm Neck, flat high contrast CRT, 0.21mm(H) / 0.25mm
(D) dot pitch, Non-Glare Screen
2. Viewable image Size: 45.7CM (18") diagonal
3. Display Color: Unlimited Colors
4. External Controls:
Power On/Off, OSD key, Function knob: Contrast, Brightness, Degauss, H-Size, H-Center, V-Center, V-Size, ZOOM,
Pincushion, Trapezoid, Pin-Balance, Parallelogram, Rotation, Color Temperature, H-Moire Reduce, V-Morie,
Memory Recall, Language, ViewMeter,OSD position select
5. Input Video Signal
Timing Timing116 Timing119 Timing 127 Timing 129 Timing 139
Resolution 640*480 640*480 800*600 800*600 1024*768
H(KHz) 31.347 43.269 46.875
53．000 60.023
V(Hz) 60 85.008 75.000
85．000 75.029
Timing Timing140
Timing 148 Timing 156 Timing179
Resolution 1024*768 1280*1024 1600*1200 640*480
H(KHz) 69．000 79.976 75．000 31.469
V(Hz) 85．000 75.025 60．000 70.086
6. Display Size
Default: 352 mm(H) ×264 mm(V)
Full scan 352 mm(H) ×264 mm(V)
7. Scanning Frequencies
Horizontal: 30KHz ~86KHz
Vertical: 50 Hz ~160 Hz
8. Factory Preset Timings: 9
User Timings: 10
9. Misconvergence
A Zone: 0.25 mm Max.
B Zone: 0.35 mm Max.
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 3

10. Video Bandwidth: 210 MHz
11. Power Source:
Switching Mode Power Supply
AC 90 ~264V, 50/60Hz Universal Type
12. Operating Temperature: 0°C to 40°C Ambient
13. Humidity: 5% to 95% Relative, Non-Condensing
14. Weight: 18.0 kgs / 39.7 (lbs) (Net), 21.2 kgs / 46.7 (lbs) (Gross)
15. Dimensions
Machine Package
Width: 445 mm (17.6 inches) 540 mm
Height: 424 mm (16.7 inches)
378 mm (14.9 inches) w/o base 530 mm
Depth: 465 mm (18.3 inches) 570mm
16. External Connection:
15 Pin D-sub Connector
AC Power Cord
17. Power Consumption Modes :
On<75W max (Green LED)
Sleep<4W(AmberLED)
Off<2W
18. Regulatiory/Safety
UL/CUL, FCC-B, CB, CE, DHHS, ICES 003, NOM, TUV/GS, TUV/Ergo, MPRII, GOST-R, SASO, BSMI, CCC,
PSB, Argentina-TUV/S, EPA Energy Star (Y2005 tier1)
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 4

OPERATING INSTRUCTIONS
This procedure gives you instructions for installing and using the Color display.
1. Position the display on the desired operation and plug the power cord into a convenient AC outlet. Three-wire
power cord must be shielded and is provided as a safety precaution as it connects the chassis and cabinet to the
electrical conduit ground. If the AC outlet in your location does not have provisions for the grounded type plug,
the installer should attach the proper adapter to ensure a safe ground potential.
2. Connect the 15-pin color display shielded signal cable to your signal system device and lock both screws on the
connector to ensure firm grounding. The connector information is as follow:
15 - Pin Color Display Signal Cable
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1. RED-V 9. 5V From PC
2. GREEN-V 10. Sync GND
3. BLUE-V 11. NC
4. NC 12. SDA
5. GND 13. H- SYNC
6. GND-R 14. V- SYNC
7. GND-G 15. SCL
8. GND-B
3. Apply power to the display by turning the power switch to the "ON" position and allow about thirty seconds for
display tube warm-up. The Power-On indicator lights when the display is on.
4. With proper signals feed to the display, a pattern or data should appear on the screen, adjust the brightness and
contrast to the most pleasing display.
5. This monitor has power saving function following the VESA DPMS. Be sure to connect the signal cable to the PC.
6. If your color display requires service, it must be returned with the power cord.
1
6
11 15
5
10
ViewSonic Corporation Confidential -Do Not Copy E90fB -4
5

3. Front Panel Function Control Description
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD controls .The OSD controls are explained at the top of
the next page and are defined in “Main Menu Controls” on page 8.
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 6

OSD Lock Settings
You have the option of using the On Screen Display (OSD) locking feature, OSD LOCK, to prevent unwanted changes
to the current image settings.
• OSD Lock: Press and hold the [1] button on the face of the monitor for 10 seconds. The message "OSD LOCK" will then
display briefly, indicating that the OSD image settings are now locked.
• OSD Unlock: Press and hold the [1] button again for 10 seconds. The message "OSD UNLOCK" will then display
briefly, indicating that the OSD image settings are now unlocked.
Do the following to adjust the screen image:
1 To display the Main Menu, press button [1].
2 To select a control you want to adjust, press the arrow buttons on the front control panel of your monitor and scroll
through the choices. When the desired control is highlighted, press button [2].
NOTE: Some controls on the Main Menu are listed in pairs, such as Contrast/Brightness. Display control screen (sample
shown in step 3 below). Press button [2] to toggle to the next control in the pair.
3 To adjust the setting, such as CONTRAST in the sample below, press the arrow buttons.
4 To save the control setting and Exit the menu press button [1] twice.
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 7

Main Menu Controls
Adjust the menu items shown below by using the up and down buttons.
Control Explanation
Brightness adjusts the background black level of the screen image
ZOOM expands and contracts the entire screen image
Horizontal Position moves the screen image left or right.
Vertical Size adjusts the height of the screen image.
Horizontal Size adjusts width of the screen image.
Vertical Position moves the screen image up or down.
Pincushion curves the vertical sides of the screen image.
Pin Balance curves the vertical edges of the screen image to the left or right.
Trapezoid adjusts the top and bottom of the screen image until they have equal length.
Parallel slants the vertical edges of the screen image until they are parallel.
Tilt rotates the entire screen image.
Contrast adjusts the difference between the image background (black level)
and the foreground (white level).
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 8

Control Explanation
Degauss removes the build-up of magnetic fields that can cause irregular colors to
appear around the edges of screen images. There are two ways to degauss the display:
automatically by turning the monitor on, or manually by selecting the Degauss
control from the menu. With Degauss selected from the menu, press button [2] to
degauss the monitor manually.
Important: Do not degauss repeatedly. Doing so can be harmful to the
display. Wait at least 20 minutes (before selecting this control again.
ViewMatch
®
Color
p
rovides several color options: several preset color temperatures and Use
r
Color which allows you to adjust red (R), green (G), and blue (B). The factory setting for this
product is 9300K (9300° Kelvin).
9300K — Adds blue to the screen image for cooler white (used in most office settings with
fluorescent lighting).
6500K — Adds red to the screen image for warmer white and richer red.
5000K — Adds blue and green to the screen image for a darker color.
User Color — Individual adjustments for red, green, and blue.
Moire reduces interference patterns that appear as ripples, waves, or unwanted backgroun
d
color textures. Interference patterns of this type are most noticeable when viewing images
having closely spaced lines or finely detailed patterns.
Language allows you to choose from among several languages for the menus and
control screens: English, French, German, Italian, and Spanish.
Memory Recall returns adjustments to the original factory settings if the display is operating
in a factory preset timing mode listed in this user guide.
E
xception: This control does not affect changes made with the User Color control.
OSD Position allows you to move the on-screen display menus and control screens.
ViewMeter displays the frequencies (horizontal and vertical) coming from the graphics
card of the computer.
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 9

4. Circuit Description
4-1 MICRO CONTROLLER AND DEFLECTION CIRCUIT
MICRO Controller
The micro controller(IC101) core is a 80C51 type. The micro clock frequency of 12 Mhz is derived from the
Xtal oscillator,which is running at 48MHz. The DDC interface is suitable to handle DDC2 by a modified
hardware I2C-bus interface .Standard high current ports,3 ADC pouts with voltage inputs and 4 static standard 8
bit DAC outputs (low interference) and one PWM output for digital control application are implemented. The
central processing unit (CPU) manipulates operands in two memory spaces.These are the 1024byte internal
data memory(consisting of 256 bytes standard RAM and 768 bytes AUX-RAM) and 48K-byte internal program
memory . The programmemory of the SAA4849 consists of 48K bytes ROM.
The SAA4849P provides sync. Processing with full auto sync. Capability, a flexible SMPS block and an
extensive set of geometry control facilities. Further the IC generates the drive waveforms for DC coupled vertical
boosters to the TDA4863A.
H/V sync signals processor
The functions of the sync processor include polarity detection, H-SYNC & V-SYNC signals counting,
Programmable SYNC signals output, free running signal generator. Pin52/Pin53 are for the H-SYNC and
V-SYNC input. and the polarity are setting in the positive. When no signal input, the Pin49 will output a 75Hz
V-SYNC free run signal. The Pin18/20will output a 60KHz H-SYNC free run signal. for the monitor testing use.
Reset Circuit(pin23)
There are three ways possible to invoke a reset and initialize the SAA4849 micro controller part:
Via power-on reset circuit
Via watchdog timer overflow(only micro controller reset)
Via deflection reset after start up(only micro controller reset)
The reset pin(pin23) is connected to a Schmitt trigger for nose reduction. A reset is accomplished by holding the
Reset pin HIGH.
2.7K
R153
+
22U
C145
0.1UF
C102
5V RST Pin23
ViewSonic Corporation Confidential -Do Not Copy E90fB -4
10

x-ray protection
The x-ray ptotection(pin22) input XRAY provides a voltage detector with a precise voltage input for X-ray
protection .If the input voltage at XRAY exceeds the upper threshold for 150us to 300us,the system is forced to
shut down by switching off vertical,H-and B-drive signals.There are two different ways to handle the system in
case of XRAY occurrence:
1. If the xray latch enable bit UCXRAY[2] was set to “0” during startup the system will shut down without any
interference of the uC.The deflection controller is set to ldle mode.Restart of the system only possible due to
seitching power off/power on.
2. If register bit UCXRAY[2] was set to “1”,micro controller interaction is allowed .If the micro controller doesn’t
interrupt the system,the system will shut down to ldle mode.For any interaction of the micro controller the XRAY
occurrence has to be acknowledged by the micro controller by clearing the bit SY-STATUS[2].The micro
controller take over the control of the handling via software.The actual xray pin status can be read through bit
SY-STATUS[1].
Quartz Oscillator(pin45,pin46)
The quartz oscillator circuit is available on pins XTAL1(input) and XTAL2(output) and works together with an
external 48MHz 3rd overtone quartz.As a result the quartz oscillator is always running on 48MHz.Other quartz
crystal frequencies than 48 MHz cannot be used.External capacitors on XTAL1 and XTAL2 are not allowed.
B+ Control Function Block
The B+control block of the SAA4849 has the same behaviour as the TDA4856 with adapted threshol
voltages.The circuit allows the user to choose the trigger edge of the HDRV signal and the polarity of the output
stage via I2C-Bus.
The B+ control function block of the SAA4849 consists of an Operational TransconductanceAmplifier(OTA), a
voltage comparator,a flip-flop and a discharge circuit. This configuration allows easy application for different B+
control concepts.
HPLL
The horizontal part contains a PLL,which works over the full frequency range from 25kHz to 140 kHz.This range
can be reduced by a ower and an upper frequency limit(Write Once Registers HPMAX and HPMIN).Via I2C bus the
number of 48MHz clock cycles is sent through the register.The slewing speed during mode change is also
programmable in a write once register (HSLEW)
After the clocks for the HPLLare switched on,the HPLLstarts with a fixed freerunning frequency of 60 kHz.The
H-drive pulses are not active and the start up procedure is inhibited.The default setting of register bit HCONTROL
[0] will cause the HPLL to slew ,not switch.to the freerunning frequency defined in the I2C register HPFREE( the
default value is also 60 kHz).Independent on H-syncs which are possibly present.the HPLL will slew to that
freerunning frequency.To achieve an always defined starting point for the startup procedure,this procedure cannot
be interrupted.
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 11

4-2 TRANSISTOR & DIODE CIRCUIT
LOCATION CIRCUIT FUNCTION DESCRIPTION
BD901 Bridge Rectifier for AC Source
D910 Clamp Diode for snub CKT
D919 Rectifier for Output Voltage
D922 Rectifier for Output Voltage
D923 Rectifier for Output Voltage
D930 Rectifier for Output Voltage
D918 Rectifier for Output Voltage
IC901 Power IC for Switching Power Control.
Q937, Q937 Use for Power Saving
Q912, Q920 Push-Pull Topology to Drive Q911
Q913 Degaussing Switcher Transistor
IC903 5V Regulator IC
Q403 HOR. Driver Transistor
Q417,Q418,Q416,Q420 Horizontal s correction control MOSFET
Q406 Transistor for H-Size Control
Q705 Brightness Control CKT
Q742 V-Dynamic focus CKT
Q402 Q403 Driver MOSFET
Q901 MOS FET for Switching Power Control.
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 12

5. Adjusting Procedure
5-1ADJUSTMENT CONDITIONS AND PRECAUTIONS
1. Approximately 30 minutes should be allowed for warm up before proceeding.
2. Adjustments should be undertaken only on those necessary elements since most of them have been carefully preset
at the factory.
5-2 MAIN ADJUSTMENTS
NO. FUNCTION LOCATION DESIGNATION
1. 14V ADJ PCB - MAIN VR903
2. B + ADJ PCB - MAIN VR902
3. SCREEN ADJ FLY BACK TRANS T402 SCREEN VR
4. FOCUS ADJ FLY BACK TRANS T402 FOCUS
VR1&VR2
5. ABL ADJ PCB - MAIN AB in factory OSD
6.
FUNCTION ADJ -MENU
PCB - MAIN (SW101)
-UP ▲PCB - MAIN (SW102)
-DOWN ▼PCB - MAIN (SW103)
-SELECT
PCB - MAIN (SW104)
5-3 ADJUSTMENT METHOD
1. 14V, B + & HV voltage adjustment:
A. Chroma-2000 Signal generator or PC equivalent set mode 1, VGA 640X480 pattern 1.0.
B. Connect a DC Volt meter between TP901 and ground, then adjust VR903to be 14VDC.
C. Connect a DC Volt meter between TP902 and ground, then adjust VR902 to be 65.5 VDC.
2. Factory preset Timings Adjustment:
A. Press Key to show OSD window press Up or Down Key to switch the functional controls.
B. Press the Up Key to select the "ZOOM" function, then press the MENU Key. While do not release the MENU Key
until the OSD window changed to the Factory preset window.
C. The Factory preset window contains the following functional controls. Select one of the control. Then press the
Up/Down Key to adjust its value for the optimum picture.
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 13

CONTRAST V-LINEARITY
BRIGHTNESS V-LINEARITY
H-CENTER R-GAIN
H-SIZE G-GAIN
V-CENTER B-GAIN
V-SIZE R-BIAS
DEGAUSS G-BIAS
PINCUSHION R-BIAS
TRAPEZOID 9300 COLOR TEMPERATURE
PIN-BALANCE 6500 COLOR TEMPERATURE
PARALLELOGRAM 50 COLOR TEMPERATURE
ROTATION OSD EXIT
HD H-DRIVER COMPENSATION VG MAX V-SIZE GAIN RANGE
HG H-SIZE GAIN H-MOIRE REDUCE
HS SUB H-SIZE V-MOIRE REDUCE
TOP CORNER HL H-Linearity Modify
BOTTOM CORNER VF V-FOCUS ADJUST
HR V-HV Variation rate ajust TM BURN IN TIME
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 14

HM MAX H-SIZE RANGE BI SET BURN-IN
Hs SUB H-SIZE Bb BOTTOM BALANCE
Hb H-SIZE WAVE BALANCE Bp B+ VOLTAGE ADJUST
Tb TOP BALANCE EU EHT CURRENT
EO EHT OFFSET EA EHT AUTO ADJUST
VG MAX V-SIZE GAIN RANGE DC video IC dc off set
HG H-SIZE GAIN SW H-frequency select
SB HIGH BRIGHTNESS SELECT LH Brightness Save
RETURN VO V-CENTER OFFSET
D. To switches the input signal to the other Timing Mode. Please follow step A ~ C to get the optimum picture.
E. Select the " " RETURN function and press the MENU Key, then the Factor Preset window will be returned
to the original OSD window.(user's operating condition)
F. The setting data of the CONTRAST, BRIGHTNESS, PIN-BALANCE, PARALLELOGRAM, ROTATION,
COLOR TEMPERATURE are common mode saved in the memory. Don't needed adjust it individual at every
timing Mode and save in the memory.
3. White Balance, Luminance adjustment:
A. Press MENU Key to show OSD menu ,and press the down Key to select the "size/center" function, then press the
menu Key to enter second menu, press the down key to select “ ”(zoom) about 10S,,then enter into factory setting
area for modulation.
B. Set R,G,B gain DAC value for 30, R ,G ,B bias DAC value for 40.
C. Raster Pattern, Brightness & contrast ratio MAX, fix to G-BIAS,fix to 40. adjust R or B bias, make x=265±10,
y=290±10, adjust G2,make Y=3.0 cd/m2 ,and then adjust brightness,make Y=0.05 cd/m2 ,then save it into
9300K,6500K,5000K color temprature.
D. adjust R or G or B gain, make x=346±10, y=359±10, Y=150±5 cd/m2,then save it into 5000K color temprature .
E. adjust R or G or B gain, make x=313±10, y=329±10, Y=150±5 cd/m2,then save it into 6500K color temprature .
F. adjust R or G or B gain, make x=283±10, y=297±10, Y=150±5 cd/m2,then save it into 9300K color temprature
G. After modulation, it’s necessary to check if the white balance accords with the normal specification. If not, which
needs reset.
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 15

4. Focus Adjustment:
A. under 1024×768 Fv: 85Hz with character full page.
B. Adjust brightness to center and contrast to max.
C. Then adjust focus VR1 to a fine vertical line.
D. Adjust focus VR2 to a fine horizontal line.
E. Repeat step C & D.then fix the Focus VR, G2 VR .
5. Purity Adjustment
A. Be sure that the display is not being exposed to any external magnetic fields.
B. Ensure that the spacing between the Purity, Convergence, Magnet, (PCM), assembly and the CRT stem is 29mm.
(See below diagram)
C. Produce a complete, red pattern on the display. Adjust the purity magnet rings on the PCM assembly to obtain a
complete field of the color red. This is done by moving the two tabs in such a manner that they advance in an
opposite direction but at the same time to obtain the same angle between the two tabs, which should be
approximately 180'.
D. Check the complete blue and complete green patterns to observe their respective color purity. Make minor
adjustments if needed.
RELATIVE PLACEMENT OF TYPICAL COMPONENTS
Purity Magnets
Deflection Yoke
4-pole Convergence Magnets
6-pole Convergence Magnets
6. Convergence adjustment
A. Produce a magenta crosshatch on the display.
B. Adjust the focus for the best overall focus on the display.
Also adjust the brightness to the desired condition.
C. Vertical red and blue lines are converged by varying the angle between the two tabs of the 4 pole magnets on the
PCM assembly. (See above diagrams)
D. Horizontal red and blue lines are converged by varying the two tabs together, keeping the angle between them
constant.
E. Produce a white crosshatch pattern on the display.
F. Vertical green and magenta lines are converged by varying the angle between the two tabs of the 6-pole magnets.
G. Horizontal green and magenta lines are converged by varying the two tabs together, keeping the angle between
them constant.
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 16

6. Trouble Shooting Flow Chart
6-1-1.NO RASTER, CRTRELATIVE CIRCUIT PROBLEMS
REFER ITEM S.M.P.S.
BRIGHTNESS SET TO MAX. THEN
CHECK CRT G1 VOLTAGE
N
G
N
G
N
G
N
G
N
G
O
K
O
K
O
K
O
K
O
K
CHECK THE HIGE VOLTAGE
CHECK THE VOLTAGE OF CRT
HEATER ABOUT 6.3V
CHECK VOLTAGE OF THE CRT
CHECK BRIGHTNESS CIRCUIT
O
K
CHECK POWER SAVING CIRCUIT,
"ABNORMAL
H-SYNC, V-SYNC SIGNAL
CHECK SCREEN VOLTAGE ABOUT
LESS THAN 300V
CHECK FBT
CHECK MAIN PCB POWER SUPPLY
CHECK IC101 PIN18 OUTPUT
Q907,Q935
CHECK CRT'S HEATER RELATIVE
CIRCUIT Q907, Q935
Q705 RELATIVE CIRCUIT
.
OF CRT ABOUT 25.5~ 26.5KV
400V TO 600V
REFER ITEM 6-2
200V, 14V, -12V,7V,80V
CATHODE ABOUT 56V TO 65V
ViewSonic Corporation Confidential -Do Not Copy E90fB -4 17
