ViewSonic VA2246m-LED User manual

Small Format, Stylish Design VA2246m-LED
The ViewSonic®VA2246m-LED is a 22" (21.5" viewable)
widescreen monitor with an LED backlight and glossy,
thin-bezel design ideal for use in the home or at the
ofce. With Full HD 1920x1080 resolution and a 10M:1
MEGA Dynamic Contrast Ratio, the VA2246m-LED
delivers stunning brightness and contrast, while a quick
5ms response time ensures crisp pictures and smooth
playback. As a complete multimedia package, the display
also includes a pair of integrated speakers. VGA and
DVI inputs provide flexible and convenient connectivity,
while a VESA-mountable design offers additional mount
flexibility. With an LED backlight and energy-saving
Eco-mode, the VA2246m-LED is an environmentally
friendly display choice. In addition, a 3-year limited
warranty, along with one of the industry’s best pixel
performance policies make the VA2246m-LED a great
value choice for corporate and educational use as well.
Full HD 1080p for Superlative Pixel Performance
The VA2246m-LED features Full HD 1080p 1920 x 1080 resolution for
unbelievable pixel-by-pixel image performance. You’ll experience the most
amazing clarity and detail whether it be for working, gaming, or enjoying
the latest in multimedia entertainment. A 16:9 widescreen ratio minimizes
eye fatigue even after hours of viewing and is perfectly compatible with
multi-window viewing without toggling.
10,000,000:1 MEGA Dynamic Contrast Ratio
Dynamic contrast ratio defines a differentiating relationship between
darkest and brightest colors when reproducing an image. With dynamic
contrast ratio, VA2246m-LED is capable of automatically detecting the
brightness and darkness of an image and adjusts the LED backlight
accordingly. It maximizes grayscale and color ranges and boosts contrast
ratio to an ultrahigh 10,000,000:1, resulting in rich, vibrant visuals.
Normal Dynamic Contrast Ratio
Normal Full HD 1080p
22" (21.5" Viewable)
Full HD 1080p LED Monitor

Specications
Sales: [phone] or [email protected] • More product information: www.ViewSonic.com
*Energy savings may vary based on cost, actual usage and other factors. Specications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details.Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2013 ViewSonic Corporation. All rights reserved. [16712-00B-05/13]
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
LCD PANEL Type 22" (21.5" viewable) Wide Color TFT Active Matrix LCD
Display Area 18.8" horizontal x 10.6" vertical; 21.5" diagonal
Optimum Resolution 1920x1080
Brightness 250 cd/m2(typ.)
Contrast Ratio 1000:1 (typ.)
Dynamic Contrast Ratio 10,000,000:1
Viewing Angles 170º horizontal, 160º vertical
Response Time 5ms (typ)
Backlight White-light LED
Backlight Life 40,000 hours (min.)
Panel Surface Anti-glare, hard-coating (3H)
VIDEO INPUT Analog RGB analog (0.7 / 1.0 Vp-p, 75 ohms)
Digital DVI (TMDS, 100 ohms)
Frequency Fh: 24~82kHz, Fv: 50~75Hz
Sync Separate Sync
COMPATIBILITY PC PC compatibles (VGA up to 1920x1080 non-interlaced)
Mac® Up to 1920x1080
CONNECTOR Video Analog 15-pin mini D-sub (VGA)
Video Digital DVI-D (V1.3 with HDCP)
Audio In 3.5 mm mini jack
Power Internal Power Board, 3-pin plub (CEE22)
POWER Voltage AC 100–240V (universal), 50 / 60Hz
Consumption 26W (typ.) / 34W (max.)
Optimize 16W (typ.)
Conserve 12W (typ.)
CONTROLS Front Panel Buttons Power, 1, up, down, 2
OSD Auto Image Adjust, Contrast/Brightness, Input Select, Audio
Adjust, Color Adjust, Information, Manual Image Adjust,
Setup Menu, Memory Recall (See user guide for complete
OSD functionality)
ERGONOMICS Tilt Forward 5º, Back 18º
OPERATING Temperature 32–104º F (0–40º C)
CONDITIONS Humidity 10–90% (non-condensing)
DIMENSIONS Physical with Stand 20.1 x 14.4 x 7.8 in. / 509.6 x 366.1 x 197.6 mm
(W x H x D) Physical without Stand 20.1 x 12.5 x 1.9 in. / 509.6 x 316.6 x 48.3 mm
Packaging 22.2 x 15.4 x 4.9 in. / 565 x 391 x 114 mm
WEIGHT Net with Stand 7.7 lb. / 3.5 kg
Net without Stand 6.9 lb. / 3.1 kg
Gross 10.3 lb. / 4.7 kg
WALL MOUNT VESA 100x100 mm
REGULATIONS CE, CB, WEEE, RoHS, REACH SVHC List, TCO5.1,
ENERGY STAR 5.0, Windows 8, Window7, UL, cUL,
FCC-B / ICES-003B, TUV-S, Nemko ERGO, GOST-
R+Hygienic, UkrSEPRO, ErP, CCC, CEL Level 1, BSMI,
PSB, C-tick, KC, e-standby
RECYCLE / DISPOSAL Please dispose of in accordance with local, state
or federal laws.
POWER MANAGEMENT ENERGY STAR®standards
WARRANTY Three-year limited warranty on parts, labor and backlight.
VA2246m-LED display, power cable, video cable, audio cable, Quick Start Guide, ViewSonic Wizard CD
(available in some countries only), Base instruction guide
What's in the box?
Kensington®
Lock Slot
VESA Wall Mount
(100x100mm) Integrated SpeakersIntegrated Speakers
VA2246m-LED
Up to 50%* Energy Savings with LED
Advanced LED panel technology uses up to 50%* less
energy than traditional CCFL monitors. Embedded
mercury-free LED backlighting and Eco-mode featuring
energy-saving mode make this VA2246m-LED monitor
an eco-friendly choice.
Planet-Friendly LED Backlighting
Environmentally-friendly with ENERGY STAR®and
RoHS certications.
Stylish Slim-Bezel Design
The slim bezel lets you see more without taking up
valuable desktop real estate.
The VA2246m-LED is Perfect for:
• Small Ofce / Home Ofce
• Government / Education
• Corporations
• Web Surng
sRGB Color Correction Denes
the Truest Color
With built-in sRGB color correction
technology, the VA2246m-LED can
reproduce 100% sRGB rich color
performance and capture the original and
true colors from screen to print.
DVI
Audio In
VGAAC In
22" (21.5" Viewable)
Full HD 1080p LED Monitor
