VG710b/s 17" digital LCD Display
Ideal for the discriminating user, the DigitalMedia VG710b/s LCD display features
impressive brightness and contrast ratio for ultra-readable text and saturated, lifelike
images through an optimal combination of analog and digital technology.
ClearMotiv™ technology with super-fast 16ms video response delivers superior
picture clarity, ideal for viewing moving images. Delivering ViewSonic's renowned
image quality in a stylish design with the ultra-slim bezel which enhances the visual
experience with clean, minimalist borders around the active image area. Advanced
ergonomic engineering also conforms to the latest TCO'03 safety standards. The
DigitalMedia VG710b/s makes a sophisticated statement with your desktop
computer.
Innovative style, high quality digital image.
17’’ LCD DISPLAY
VG710b/s
TCO’03
Certified
Built-in Stereo Speakers
sRGB
Compliant
Slim Bezel Design
OptiSync
™
Technology
Built-in Digital Input

www.viewsonic.com
ClearMotiv™Technology
•17.0”Viewable Area
•1280 x 1024 Resolution
•OptiSync™Technology
This multi-mode input technology supports both
analog video (VGA) and direct-digital input (DVI) for
superior image quality. The digital interface delivers
optimized image quality with minimum adjustment
for ultimate configuration flexibility.
•sRGB Compliant
The sRGB color management chip technology
ensures color accuracy from screen to print when
used with other sRGB-compliant peripherals.
•AutoTune™Function
Provides the best image by monitoring signals from
the computer and automatically optimizing the
monitor settings.
•OSD/Power Lock Function
When activated, the user-controlled OSD/Power
lock function prevents changes to monitor settings,
maintaining an optimized image.
•Bezel-Integrated Stereo Speakers
The two 3-watt built-in audio speakers provide
superior audio quality for all multimedia applications
while reducing desktop space required by separate
speakers.
•TCO'03 and Energy Certified
•Best Service & Support
At ViewSonic, we are devoted to customer
satisfaction. We strive constantly to understand your
interests and concerns, and treat you with respect,
courtesy and consideration. For the warranty
information, please contact your local ViewSonic
distributor or ViewSonic service center.
ViewSonic Service Center :
Taiwan - [email protected]
China - [e-mail]
Japan - [email protected]
S. Asia & S. E. Asia - [email protected]
Australia & New Zealand - [email protected]
H.K &. S. Africa & other countries - [email protected]
VG710b/s 17"LCD Display Model No : VLCDS23719-4W/5W
LCD Display Area 17.0" diagonal
Optimum Resolution 1280 x 1024
Brightness 280 nits (max), 250 nits (typ)
Contrast Ratio 500 :1 (max), 450:1 (typ)
Viewing Angle 140° horizontal, 120° vertical
Response Time 16ms (typ)
Panel Surface Anti-glare
INPUT Analog RGB analog (75Ω, 0.7 Vp-p)
Digital DVI-D
Sync H/V separated (TTL)
Frequency Fh:30~82 kHz, Fv:50~85 Hz
COMPATIBILITY PC VGA up to 1280x1024 non-interlaced
Mac®Power Mac®up to 1280x1024
Audio Speaker 3WX2
CONNECTOR Analog 15-pin mini D-sub
Digital DVI-D
Power 3-pin AC Plug (CEE22)
POWER Voltage AC 100–240V, 50/60Hz(auto switch)
Consumption 36 W (typ)
CONTROLS Basic Power (soft), 1, down, up, 2, Mute, Volume (+/-)
OnView®
Auto Image Adjust, Contrast, Brightness, Input Select
(Analog, digital), Audio Adjust (Volume, Mute),
Information (Mode, Serial Number, Model Number, Web
Site), Manual Image adjust(H. Position, V. Position, H.
Size, V. Size, Fine Tune, Sharpness), Setup Menu
(Language, Resolution Notice, OSD Position, OSD
Timeout, OSD Background), Color Adjust (sRGB, 9300K,
6500K(Default), 5400K, 5000K, R,G,B), Memory Recall
OPERATING Temperature 32-104ºF (0-40ºC)
CONDITIONS Humidity 10-90% (non-condensation)
DIMENSIONS Physical 378mm x 405mm x 177mm
(W x H x D)
WEIGHT Net 5.3 kg
REGULATIONS UL, c-UL, IC-B, CB Report, CE, FCC-B, TUV/Ergo,
ISO13406-2, TUV/GS, BSMI, VCCI, PSB, PCBC,
TUV-S, TCO’03 (VG710s), TCO’99(VG710b), EPA,
NOM, C-TICK, GOST-R, CCC, Energy
POWER MANAGEMENT ąVG710sĈMeets TCO’03 and Energy Standards
ąVG710bĈMeets TCO’99 and Energy Standards
Specifications subject to change without notice.
Selection, offers, warranties and programs may vary by country; see your ViewSonic representative for complete details.
Headquarters :
381 Brea Canyon Road,
Walnut, CA91789, U.S.A
Tel:[phone] [phone]
Fax:[phone]
E-mail:[email protected]
www.viewsonic.com
Asia Pacific :
9F, No. 192 Lien Chien Road,
Chung Ho, Taipei, R.O.C
Tel:[phone]
Fax:[phone]
www.viewsonic.com.tw
Human vision allows images shown at 24 frames per
second (fps) to be perceived as smooth motion
video. Movies play at 24fps, analog TV at 30fps, and
DTV ranges between 24-60 fps depending on HDTV
format. ClearMotivTM fast video-response technology
allows frame rates up to 62.5fps for true broadcast-
quality full-motion video.
VG710bVG710s
