ViewSonic VX2423w User manual

VX2423w
24” (23.6” VIEWABLE)
WIDESCREEN LCD
ViewSonic’s 24" (23.6” viewable) VX2423w 16:9 widescreen LCD
delivers 1,920 × 1,080 performance and ultra-high 20,000:1 dynamic
contrast ratio for unsurpassed HD content on your desktop. It’s
ideal for business applications where blur-free motion, crisp detail
and precise images are critical. The aspect ratio adjustment ensures
that even your 4:3 images are displayed without any stretching or
distorion. This display is multimedia ready with finest HDTV picture
quality. The VX2423w is environmentally friendly and Eco-mode that
automatically reduces power consumption and can extend backlight
life. The VX2423w is ideal for corporate use where an eco-friendly,
high-performance LCD can enhance your productivity.
>Full HD resolution (1,920x1,080) with 16:9 aspect ratio
Perfect for Full HD Games and Movies, playing and editing,
or for viewing massive spreadsheets or multiple applications
simultaneously.
>20,000 :1 dynamic contast ratio
Provides darker black levels and better overall video display
performance.
>ECO Mode (2 Types)
Environmentally-friendly Eco-mode reduces power
consumption and extends backlight life.
Optimized Mode: 30% Power Saving
Conserve Mode: 40% Power Saving
>Aspect ratio function to adjust 4:3 and full screen image
Eliminates image distortion by maintaining correct image
proportions for both widescreen and native 4:3 content.
>OptiSync®digital/analog inputs expand your connectivity
Multi-mode input technology supports both digital (DVI)
and analog (VGA) signals for ultimate compatibility and
configuration flexibility.
>ENERGY STAR®qualified
Environmentally friendly, 1,920 × 1,080 LCD
High-performance for your desktop
WITH 20,000:1 DYNAMIC CONTRAST RATIO

Size
Display Area
Optimum Resolution
Brightness
Contrast Ratio
Viewing Angles
Response Time
Pixel Pitch
Panel Surface
Light Source
Color Support
Analog
Digital
Sync
Frequency
PC
Mac **
Analog
Digital
Power
Voltage
Consumption (W)
Eco Mode
Save mode (W)
Tilt
Basic
OnView
Temperature
Humidity
Physical (w/ stand)
Physical (w/o stand)
Net
Gross weight
23.6" wide Color TFT Active Matrix LCD 16:9 aspect ratio
521 (mm) × 293 (mm)
1,920 × 1,080 WUXGA (Full HD)
300 cd/m² (typ.)
1,000:1 (typ.) ; 20,000:1 dynamic
170° (H), 160° (V) at CR≧10 / 170° (H), 170° (V) at CR≧5
5ms (on/off)
0.2715mm (H) × 0.2715mm (V)
Anti-Glare, Hard coating (3H)
50,000 hrs (typ.)
16.7 M (6-bits + Hi FRC)
RGB Analog (75 ohms, 0.7 Vp-p) DVI-D
DVI-D
Separate Sync
Fh: 24-82kHz, Fv: 50-75Hz
VGA up to 1,920 × 1,080 non-interlaced
Power Mac, up to 1,920 × 1,080
15 pin mini D-sub × 1
DVD-I
3-pin AC plug (CEE22)
AC 100-240V (Universal); 50 / 60Hz (Switch)
47 (Max)
Standard 45W / Optimize 31W / Conserve 26W
≦1W
20° ~
- 5°
[1], [2], Power, Down, Up
Auto Image Adjust, Contrast/Brightness, Audio Adjust (Volume, mute),
Color Adjust (sRGB, 9300K, 7500K, 6500K, 5000K, User Color [R, G, B]),
Information, Manual Image Adjust (H/V Position, Horizontal Size, Fine
Tune, Sharpness, Dynamic Contrast, Aspect Ratio, ECO Mode), Setup
Menu (Language, Resolution Notice, OSD Position, OSD Timeout, OSD
Background, Sleep), Memory Recall
0 - 40°C (32 - 104°F)
5 - 90% (Non condensed)
564mm × 418mm × 261mm
564mm × 360mm × 67mm
5.4 kg
7.5 kg
CB, WEEE, RoHS, UL/cUL, FCC-B, NOM, Energy Star, ERGO, CE, Ukraine,
GOST-R+Hygienic, SASO, BSMI, PSB, C-TICK, MIC, CCC
VESA 100mm × 100mm
ViewSonic VX2423w LCD, VGA cable, Power cable, Quick Start Guide,
ViewSonic Wizard CD, DVI cable
LCD
INPUT
COMPATIBILITY
CONNECTOR
POWER
ERGONOMICS
CONTROLS
OPERATING
CONDITIONS
DIMENSIONS
(WxHxD)
WEIGHT
REGULATIONS
WALL MOUNT
PACKAGE CONTENTS
Model No.VS12515 (VX2423w)
VX2423w
24” (23.6” viewable) 16:9 widescreen LCD with Full HD 1080p resolution
