VX500 LCD Display
ViewSonic®
• technology
This multi-mode input technology supports
both digital (DVI) and analog (VGA) signals.
The digital interface delivers optimized image
quality with minimum adjustment for ultimate
configuration flexibility.
•Full 15" viewable screen
Equivalent to a 17" CRT monitor.
•1024x768 native resolution
•Bezel integrated speakers
The two 2-watt built-in audio speakers save
desk and work space while offering superior
sound quality.
•Touch-sensitive digital controls
Sleek, metallic soft-touch buttons utlilize
capacitive sensors to respond to the slightest
touch for easy adjustments.
•Asset management
Conforms to industry standards for
remote identification in an enterprise
networked environment.
•ViewSonic Wizard
This software provides user-friendly installation.
The included CD-ROM automates the set-up
process to deliver optimized screen performance.
•Built-in microphone
Allows bi-directional communications in true
multimedia applications such as video
conferencing and computer telephony.
High-tech and high-style converge with this 15" LCD display.
Sculpted with a modern silver and black bezel, this 15" LCD display
combines technical sensibility with stylish ingenuity. Its sleek design
and ultra-thin profile make it ideal for professionals with limited
workspace. ViewSonic’s exclusive OptiSync™digital/analog multi-
mode input technology supports both digital and analog signals for
ultimate compatibility and configuration flexibility. And its multimedia
functionality, including built-in speakers and integrated microphone,
make the VX500 ideal for office applications, computer training and
videoconferencing.

•OSD/Power lock function
When activated, the user-controlled OSD/Power
lock function prevents changes to monitor
settings, maintaining an optimized image.
•Elegant silver-on-black design
The graceful design complements both home
and office computing environments.
•TCO’99 and ENERGY certified
•Three-year limited warranty
•Give your desktop a signature look
ViewSonic has a wide variety of accessories for
your LCD, including stylish multifunctional
keyboards and video solutions. For
a complete accessories list,
visit ViewSonic.com.
ViewSonic®
VX500 LCD Display
*Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks
stated herein are the property of their respective companies. Copyright © 2003 ViewSonic Corporation. All rights reserved. [10381-05B-07/03] VX500-2
15.0" TFT LCD DISPLAY
LCD PANEL Type 15.0" color TFT active matrix
Display Area 12.0" (horizontal) x 9.0" (vertical); 15.0" diagonal
Optimum Resolution 1024x768
Contrast Ratio 400:1 (typ)
Viewing Angles 120º horizontal, 100º vertical (typ)
Response Time 30ms (typ)
Light Source Long life, 50,000 hrs. (typ)
Brightness 300 cd/m2(typ)
Panel Surface Anti-glare
VIDEO INPUT Analog
RGB Analog (75 ohms, 0.7/1.0 Vp-p)
Digital DVI-D (TMDS, 100 ohms)
Frequency Fh: 30~62kHz; Fv: 50~85Hz
Sync H/V Separated (TTL), composite, sync-on-green
COMPATIBILITY PC
VGA up to 1024x768 non-interlaced
Mac®*Power Mac™G3/G4 up to 1024x768
CONNECTOR Analog 15-pin mini D-sub
Digital Digital DVI-D
Power 3-pin AC Plug (CEE22)
Audio 3.5mm audio line-in
AUDIO Speakers 2 x 2-watts
Amplifier 2-watts at 1KHz
POWER Voltage AC 100–240V, 50–60Hz (auto switch)
Consumption 38W (typ), <3W (standby)
CONTROLS Basic Power, 1, down, up, 2, mute, volume ( +, –)
OnView®Auto image adjust, contrast, brightness, input
select, ViewMatch®color adjust (9300K, 6500K-
default, 5400K, 5000K, RGB), audio adjust
(volume, balance, bass, treble, mute), information
(resolution, model number, serial number,
website), manual image adjust (H. size, H/V
position, fine tune, sharpness), setup menu
(language, resolution notice, OSD position, OSD
timeout, OSD background), memory recall
OPERATING Temperature 32ºF–104ºF (0ºC–40ºC)
CONDITIONS Humidity 10%–90% (non-condensing)
DIMENSIONS Physical 360.0mm x 342.0mm x 139.5mm
(W x H x D) (14.2" x 13.5" x 5.5")
WEIGHT Net 8.6 lbs. (3.9 kgs)
Gross 13.0 lbs. (5.9 kgs)
REGULATIONS UL, c-UL, IC-B, CB Report, CE, FCC-B,TUV/Ergo,
ISO13406-2, TUV/GS, SEMKO, DEMKO, FIMKO,
NEMKO, BSMI, VCCI, PSB, PCBC, TUV-S, TCO’99,
EPA, NOM, C-TICK, GOST-R, PCT (BZ02), CCC,
ENERGY STAR®
POWER MANAGEMENT Meets TCO‘99 and ENERGY standards
WARRANTY Three-year limited warranty on parts, labor and backlight.
Keyboard sold separately.
