EXTENDER USER MANUAL
Please read this manual thoroughly before use, and keep it handy for future reference.
HDMI OVER IP(CAT 5/5e/6/6a/7) Extender
with IR, HDCP 2.2
VZ-1TR X-4K
06272022-Rev. A

2User ManualVisit the ViewZ USA website at https://www.viewzusa.com
06272022-Rev. A
This symbol is intended to alert the user to the presence of uninsulated & dangerous voltage
within the monitor’s enclosure that may be of sucient magnitude to constute a risk of
electric shock to persons.
This symbol is intended to alert the user to the presence of important operang and
maintenance (servicing) instrucons in the literature accompanying the monitor.
Important Safety Instruction
Mark Indication and Substance
Nominal Operating Temperature & Humidity
Warning
SAFETY INSTRUCTION
CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL
1. Read all warnings.
2. Do not expose this unit to rain, heavy moisture, or liquid
3. Do not repair the device or open the enclosure without professional guidance to avoid electric shocks. Doing so
may void your warranty
4. Keep the product in a well-venlated locaon to avoid damage from overheang
5. Turn o the power and make sure the environment is safe before installaon
6. Do not plug the HDMI cables and IR cables in/out when the device is in use to avoid cable damage. Make sure
they are plugged into the correct ports
7. Use the included DC 5V power adapter only. Make sure the specicaon matches if using 3rd-party DC power
adapters.
8. Plug the included DC 5V power supply into Transmier or Receiver. Do not need to plug both Transmier &
Receiver
• Operang Temperature : -4°F ~ 104°F / -20°C ~ 60°C
• Operang Humidity : 0 ~ 90% RH

3User Manual Visit the ViewZ USA website at https://www.viewzusa.com
06272022-Rev. A
The following tools may be required depending on your installaon.
Your ViewZ monitor is shipped with all proper installaon hardware and components. If there are parts missing and/or damaged,
please stop the installaon and contact ViewZ USA at (888)-998-4399.
Electronic Stud Finder Protecve Eye-wearPencil Level Phillips Screwdriver
Assembly Components - provided
Installation Tools
Transmier TX (Qty 1),
Receiver RX (Qty 1)
Mounng Bracket (Qty 8)
DC 5V /2A Power Supply (Qty 2)
Screw (Qty 18)
IR Receiver Cable (Qty 1),
IR Blaster Cable (Qty 1)
User Manual (Qty 1)
INSTALLATION
HDMI

4User ManualVisit the ViewZ USA website at https://www.viewzusa.com
06272022-Rev. A
The following image is the descripon of interface input & output ports of 1TRX-4K transmier extender.
Interface Input Ports - Transmitter (TX)
CONNECT EXTERNAL EQUIPMENTS
q
q
r
t
u
i
w
w
t
y
i
o
e
re
y
u
1. Reset - Press to restart the device
2. RJ45 Signal Output - Use a CAT 5/5e/6/6a/7 cable
3. Power Signal Indicator
q Flashing Light - No HDMI signal, but power is on
w Solid Blue - When the transmier get the HDMI
signal, transmier will display solid blue light.
4. DC 5V/2A - Connect to the provided power adapter
1. Reset - Press to restart the device
2. Audio Switch - Choose to decode audio from HDMI or
ARC output from ber opc interface
3. RJ45 Signal Input - Use a CAT 5/5e/6/6a/7 cable
4. Power Signal Indicator
q Flashing Light - No HDMI signal, but power is on
w Solid Blue - When the transmier get the HDMI
Interface Input Ports - Receiver (RX)
5. HDMI Out - Connect to the monitor
6. HDMI In - Connect to the HDMI source device
7. IR In - Connect to the IR receiver (which provided)
8. IR Out - Connect to the IR blaster (which provided)
signal, transmier will display solid blue light.
5. DC 5V/2A - Connect to the provided power adapter
6. S/PDIF Out - Connect to the digital audio signal
7. HDMI Out - Connect to the monitor
8. IR In - Connect to the IR receiver (which provided)
9. IR Out - Connect to the IR blaster (which provided)
The following image is the descripon of interface input & output ports of 1TRX-4K receiver extender.
You just need to put the included DC 5V/2A power adapter into Receiver.
Warning

5User Manual Visit the ViewZ USA website at https://www.viewzusa.com
06272022-Rev. A
TX RX HDMI Display
HDMI Display
Video Source
Speaker
HDMI Out
HDMI Out
ARC
Network Cable
HDMI IN
The following image is the descripon of connecon of VZ-1TRX-4K.
Installation Process
CONNECT EXTERNAL EQUIPMENTS
1. Turn o all devices including your HDMI source and HDMI display.
2. Connect your HDMI source to the Transmier's HDMI Input port with a HDMI cable (HDMI cable not included).
Oponal: Connect the IR Blaster Extension Cable to the Transmier's IR output port. Face the (IR Blaster) eye towards your
HDMI source's IR window. This connecon is needed if you want to control your HDMI source from the remote locaon.
3. Plug your CAT 5/5e/6/6a/7 cable between the Transmier's RJ45 Output and Receiver's RJ45 Input.
4. Connect your monitor to the Receiver's HDMI output port with a HDMI cable (HDMI cable not included).
Oponal: Connect the IR Receiver Extension Cable to the Receiver's IR input port. This connecon is needed if you want to
control your HDMI source from the remote locaon.
5. Plug the provided power adapters into the Transmier's and Receiver's power jacks (DC 5V), then plug both power
adapters into a reliable power source.
6. Turn on all connected devices.
7. The HDMI extender is ready for use.
1. IR blaster extension cable should plug into the IR OUT port of the transmier (TX) and receiver (RX). IR Receriver extension
cable should plug into the IR IN port of the transmier (TX) and receiver (RX).
2. The emier of the IR blaster extension cable should be closed to the IR receiving panel of the source device.
3. Face the receiving head of the IR receiver extension cable to the user for convenient remote control.
IR Installation Process

6User ManualVisit the ViewZ USA website at https://www.viewzusa.com
06272022-Rev. A
SPECIFICATION
INTERFACE
Transmission Distance
Net Weight
Gross Weight
IR Signal
Operating Temperature
Storage Temperature
Operating Humidity
Safety & EMC Certification
Electrical Ratings
Power Consumption
Accessories
Protection Level
Network Cable
In / Out TDMS Signal
In / Out DDC Signal
In/Out HDMI Cable Length
5V DC, 2A (100 ~ 240 VAC, 50/60 Hz)
Tx & Rx ≤ 4 W
Receiver RX - Power Input (DC 5V) x1, RJ45 Out x1, S/PDIF Out x1, HDMI Out x1 IR In x1, IR Out x1
CE / FCC / ROHS
Transmitter TX - Power Input (DC 5V) x1, RJ45 Out x1, HDMI In x1, HDMI Out x1 IR In x1, IR Out x1
480i / 480p / 720p / 1080i / 1080p /3840x2160 @59.94/60 Hz
576i / 576p / 720p / 1080i / 1080p / 3840x2160 @50 Hz,
3840x2160 / 4096x2160 @30Hz | 3840x2160 / 4096x2160 @23.98/25 Hz
HDCP 2.2
HDMI 2.0a
LPCM / DTS-H D / DTS / Dolby Digital 5.1ch
Support
UTP & STP over Cat 5 / 5e / 6 / 6a / 7
0.7 ~ 1.2 Vp-p (TDMS)
5 Vp-p (TTL)
≤ 8 m (AWG 24)
CAT 6 / 6a / 7 - up to 230ft / 70m
CAT 5 / 5e - up to 131ft / 40m
TX - 0.46 lbs (0.210 kg ) / RX - 0.46 lbs (0.210 kg)
1.85 lbs (0.83 kg )
20 ~ 60 kHz
4 ~ 140°F / -20 ~ 60°C
-22 ~ 158°F / -30 ~ 70°C
0 ~ 90% RH
Power Adapter x1, Transmitter TX x1, Receiver RX x1, User’s Manual x1, Mount Ear Kit x1,
1a Contact discharge level 3, 1b Air discharge level 3 implementation of the standard : IEC61000-4-2
IR Blaster Extension Cable x1, IR Receiver Extension Cable x1
Model No. VZ-1TRX-4K
Resoluon
HDCP™ Version
HDMI Compliance
Audio Format
IPColor Technology

7User Manual Visit the ViewZ USA website at https://www.viewzusa.com
06272022-Rev. A
At start
We recommend that you test with dierent input sources when you have trouble with
the current input source. If symptom persists, follow the instrucons below. Aer
following the instrucons below, please contact us at 1-888-99-VIEWZ.
TROUBLESHOOTING GUIDE
- Check the following before calling for service.
- If the same problems connue aer checking, contact the reseller you purchased the monitor from.
No image or
Noise on the screen
Receiver's Link LED
is ashing
The extender is not
working properly
RX Link LED is on
but there is no image
- Make sure the cable is correctly plugged into the outlet
- Make sure the power cable is correctly plugged into the transmier & receiver
- Make sure the cable is correctly connected between monitor & receiver (RX)
- Check brightness and see if brightness is set to 'Ø'
- Check video source
- Press the Receiver's reset buon to reset the unit.
- Use the shorter network cable.
1) Make sure the network cable follows the IEEE-568B wiring standard.
2) Check the Transmier (TX) correctly connected HDMI input.
3) Reset both TX & RX and reconnect.
1) Please check the cable lengths:
HDMI cables: Up to 5m, Network cables (CAT 6/6a/7): Up to 230ft (70m),
Network cables (CAT 5/5e): Up to 131ft (40m)
2) Press the reset button on the TX/RX and reconnect.
1) Press RX reset button to reset the unit.
2) Make sure the HDMI cable is firmly connected to the monitor.
3) Make sure your HDMI monitor is set to the correct HDMI input.
4) Use the high quality network cable.
ViewZ USA intends to make this manual accurate and complete. However, ViewZ USA makes no claim that the informaon contained
herein covers all details, condions or variaons, nor does it provide for every possible conngency in connecon with the
installaon or use of this monitor. The informaon contained in this document is subject to change without noce or obligaon of
any kind. ViewZ USA makes no representaon of warranty, expressed or implied, regarding the informaon contained herein.
ViewZ USA assumes no responsibility for accuracy, completeness or suciency of the informaon contained in this document.
